Atlas AH Series User manual

AH Series Stadium Subwoofer
AHSUB15-BSG
AtlasSound.com – 1 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

TABLE OF CONTENTS
Safety Instructions.................................................................................................................................. 3
Suspension and Mounting...................................................................................................................... 3
Introduction, Features, Applications ....................................................................................................... 4
Ground Installation ................................................................................................................................. 5
Suspended Installation Via Eyebolts ...................................................................................................... 6
Speaker Cable Recommendations and Connection............................................................................... 7
Amplier Considerations......................................................................................................................... 8
Specications ......................................................................................................................................... 9
Troubleshooting...................................................................................................................................... 9
Warranty ............................................................................................................................................... 12
AtlasSound.com – 2 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

SAFETY INSTRUCTIONS
Please Read Carefully Before Installing or Operating
• Read all instructions carefully
• Heed all warnings
• Assure that the speaker is securely mounted
Hearing Damage
CAUTION: All professional loudspeaker systems are capable of generating very high sound pressure
levels. Use care with placement and operation to avoid exposure to excessive levels that can cause
permanent hearing damage.
SUSPENSION & MOUNTING
Suspension or "ying" speaker systems requires training and expertise. Improper rigging of a ying
speaker may result in injury, death, equipment damage, and legal liability. Installation must be carried
out by fully qualied installers, in accordance with all required safety codes and standards at the place of
installation.
A 5:1 design factor is a generally accepted minimum standard. However, legal requirements for overhead
suspension vary by municipality, please consult your local safety standards ofce before installing any
product. We also recommend that you thoroughly check any laws and bylaws prior to installation.
Loudspeakers own in theaters, nightclubs, conference centers, or other places of work and
entertainment must be provided with an independent, correctly rated and securely attached secondary
safety — in addition to the principle suspension point(s). This secondary safety must prevent the
loudspeaker from dropping more than (6") should the principle suspension device fail. If you lack the
skills, training, and proper ancillary equipment to y a speaker system, do not attempt to do so.
For additional information regarding the suspension of loudspeakers or to purchase rigging materials,
please contact our friends at
ATM Group, Inc.,1635 E. Burnett St. Signal Hills, CA 90755.
www.atmyware.com
Telephone [phone] and Fax [phone]
• Always assure power is off to ampliers before making any connections
• Assure that all electrical equipment is properly grounded
• Keep instructions for future reference
• Should any questions arise after reading this document, please call Atlas Sound Tech Support at
800-876-3333
AtlasSound.com – 3 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

AH SERIES STADIUM SUBWOOFER
SYSTEMS
Thank you for your purchase of an Atlas Sound AH
Series loudspeaker system. We have designed this
product to be a reliable and versatile solution to your
needs for years to come.
The AHSUB15-BSG subwoofer system features high
output and amazing low frequency response for indoor
and outdoor applications including football stadiums,
sports arenas, baseball elds, and large auditoriums.
Unit features an efcient low frequency woofer loaded
into a durable, weather resistant, rear ring enclosure
FEATURES
• Impressive efciency rating of 103dB 1Watt/1Meter
makes the AH series a perfect choice for low
frequency augmentation of high energy music
playback at sporting events.
• Weather & rodent resistant. Rear ring woofer cavity
and mesh screen over the enclosure front protects
the speaker from weather and/or rodent damage.
• Easy installation. Secure surface mounting or
suspension installation is possible via the integral
forged eyebolts.
AHSUB15-BSG
(Front and Back View)
AtlasSound.com – 4 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

GROUND INSTALLATION
General considerations and hardware recommendations
Excellent results may be achieved by mounting the AHSUB15-BSG under bleacher seating. Electronic
delay is suggested to approximate time alignment of full range speakers with subwoofer(s) to the listener
locations.
CAUTION: The AHSUB15-BSG weighs 181 pounds (82.1kg). A fall from almost any height could result in
serious injury or death. Assure that the speaker is rmly mounted to an object that can handle the weight.
For on ground installation a 36" square 2" thick (minimum) concrete pad is suggested. If this pad is to be
poured concrete, rebar anchors are suggested to allow chain or cable securing of the AHSUB15-BSG for
theft resistance.
Overhead Suspension Installation
Remember that wind will add considerable torque to the point of attachment. The mounting surface the
speaker is being attached to should be able to handle ve or more times the weight of the AH speaker (7x
recommended for locations subject to high wind forces).
The installer must ensure that the surface is capable of safely and securely supporting the load. The
hardware employed must be safely and securely attached both to the loudspeaker and the surface in
question. A general rule for soft surface installations (wood beams) is to multiply the corresponding
working load limit by 75%: the result will be an approximate working load strength.
AtlasSound.com – 5 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

SUSPENDED INSTALLATION VIA EYEBOLTS (INCLUDED)
Using 1⁄4" Diameter Wire Rope
Note: Use of 1⁄4" load rated wire rope is suggested to provide a static working load limit of 1400lbs (635kg)
and moving load limit of 875lbs (397kg) per point. 1⁄8" cable is not recommended as load limits are reduced
to 400lbs (181kg) static, and 250lbs (113kg) moving.
Considerations for overhead suspension using AH Series eyebolts and wire rope:
1. Always apply the load to the eye in the plane of the eye.
2. Always use shoulder eyebolts for angular lifts.
3. Always tighten eyebolts securely against the load.
4. Apply rst load to test the assembly. This load should be of equal or greater weight than the loads
expected in use.
5. Use wire rope compression ttings & thimbles whenever possible and prepare terminations only
as instructed by the manufacturer.
6. If wire rope clips are used, check and retighten to the manufacturer's recommended torque.
Eyebolt Working Load Limits
1⁄4" Shank (Provided with AHSUB15-BSG)
90˚ angle: 650lbs (295kg)
60˚ angle: 420lbs (191kg)
45˚ angle: 195lbs (88kg)
Less than 45˚ angle: 160lbs (73kg)
LESSTHAN
45DEGREE
ANGLE
45?
60?
90?
0 ANGLE
AHSUB15S
LESS THAN
45 DEGREE
ANGLE
45˚
60˚
90˚
0 ANGLE
AtlasSound.com – 6 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

SPEAKER CABLE RECOMMENDATIONS AND CONNECTION INSTRUCTIONS
Wire Gauges
For very short distance speaker cable runs (less than 25’) #16-gauge, stranded, twisted pair speaker
cable may be used. For speaker cable runs between 25’ and 75’, #14-gauge, stranded, twisted pair
speaker cable is recommended. For speaker cable runs greater than 75’, #12-gauge, stranded, twisted
pair speaker cable is necessary. For runs exceeding 150’, please contact tech support for proper wire
gauge.
Input connections are provided on a convenient recessed terminal block located on the bottom of the
loudspeaker. This terminal block includes a clear weather resistant cover which should be re-installed
after terminating the speaker cabling to prevent corrosion in outdoor applications.
Allow an adequate service loop for this connection to allow tilt of the loudspeaker. If the speaker is tilted
above parallel to the ground, water may collect in the speaker cabinet causing damage — the product
should not be installed tilted upwards!
AtlasSound.com – 7 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

AMPLIFIER CONSIDERATIONS
Consult your amplier owner’s manual to conrm power output at the rated impedance.
The AHSUB15-BSG exhibits an 8 Ohm (nominal) impedance.
(x2) AHSUB15-BSG paralleled will present a 4 Ohm load to the amplier.
(x3) AHSUB15-BSG paralleled will present a 2.66 Ohm load to the amplier.
(x4) AHSUB15-BSG paralleled will present a 2 Ohm load to the amplier.
ATLAS SOUND speaker system specications list RMS power handling.
As a reference, peak power = RMS x 1.414.
These ratings should be considered in selecting the best amplier to power the speaker system.
For general use, amplier output should match or exceed the RMS rated power of the speaker system
(250 Watts).
For increased headroom and dynamic reproduction, the amplier’s output should match or exceed the
peak power rating of the speaker system (354 Watts).
In situations where experienced professionals are operating the speaker system with proper limiting and
frequency control devices inserted into the signal path and adjusted properly, amplier output may meet,
but should not exceed 2x the RMS power rating of the speaker system (500 Watts).
Utilizing the Atlas Sound model CP700 power amplier will allow you to easily match required power
ratings for most any installation. Visit www.AtlasSound.com for more details on this product.
AtlasSound.com – 8 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

SPECIFICATIONS
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE REMEDY
Call Atlas Sound tech support at 1-800-876-3333 with any additional questions.
MODEL POWER
RATING
RMS
FREQUENCY
RES. ±5dB
SOUND LEVEL DISPERSION IMPEDANCE DIMENSIONS WEIGHT
RP/1M 1W/1M
AHSUB15-BSG 250 Watts RMS 55Hz to 120Hz 127dB 103dB Omni 8 Ohms 30.56"H (776mm)
30"W (762mm)
28.1"D (714mm)
181 lbs (82.1kg)
There is no sound Power off. Equipment setting is wrong.
Volume set too low.
Assure that power is applied to all equipment in system. Check
that routing (input/output) controls are set correctly. Check that
volume level is above minimum.
Loose connection. Check system from start to nish for crossed wires, loose
connection, etc. On the AH location check for correct connection.
Low sound level Setting/volume control is set too low.
Connection is shorted or bad.
Check volume levels or ampliers and related equipment
(equalizer). Check that connections aren't partially shorted/
corroded.
Sound cuts in and out System overload/oscillation intermittent connection. Check for overload condition or bad connection.
Distortion at increased levels Amplier/speaker overdriven. Check that power to speaker isn't over limits. Check that amplier
isn't overdriven. Reduce power to amplier slightly.
Speaker makes "buzzing" noise Hardware loose or speaker damaged. Make sure speaker grille is tight. Check other hardware
connections. Check speakers for loose parts or speaker damage.
AtlasSound.com – 9 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

NOTES:
AtlasSound.com – 10 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

NOTES:
AtlasSound.com – 11 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer

Limited Warranty
All products manufactured by Atlas Sound are warranted to the original dealer/installer, industrial, or
commercial purchaser to be free from defects in material and workmanship and to be in compliance with
our published specications, if any. "This warranty shall extend from the date of purchase for a period
of three years on all Atlas Sound products, including SOUNDOLIER brand, and ATLAS SOUND brand
products except as follows: one year on electronics and control systems; one year on replacement parts;
and one year on Musician Series stands and related accessories. Additionally, fuses and lamps carry no
warranty." Atlas Sound will solely at its discretion, replace at no charge or repair free of charge defective
parts or products when the product has been applied and used in accordance with our published
operation and installation instructions. We will not be responsible for defects caused by improper storage,
misuse (including failure to provide reasonable and necessary maintenance), accident, abnormal
atmospheres, water immersion, lightning discharge, or malfunctions when products have been modied
or operated in excess of rated power, altered, serviced or installed in other than a workman like manner.
The original sales invoice should be retained as evidence of purchase under the terms of this warranty.
All warranty returns must comply with our return policy set forth below. When products returned to Atlas
Sound do not qualify for repair or replacement under our warranty, repairs may be performed at prevailing
costs for material and labor unless there is included with the returned product(s) a written request for an
estimate of repair costs before any non-warranty work is performed. In the event of replacement or upon
completion of repairs, return shipment will be made with the transportation charges collect.
EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF
CONSEQUENTIAL DAMAGES FOR PERSONAL INJURY, ATLAS SOUND SHALL NOT BE LIABLE IN
TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE
ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS. THE
ABOVE WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Atlas Sound does not assume, or does it authorize any other person to assume or extend on its behalf,
any other warranty, obligation or liability. This warranty gives you specic legal rights and you may have
other rights which vary from state to state.
©2013 Atlas Sound L.P. All rights reserved. Atlas Sound and Atlas Power are trademarks of Atlas Sound L.P.
All other trademarks are the property of their respective owners. ATS004623 RevA 5/13
AtlasSound.com – 12 –
Specifications are subject to change without notice.
Owner’s Manual
1601 Jack McKay Blvd. • Ennis,Texas 75119 U.S.A.
Telephone: [phone] • Fax: [phone]
AH Series Stadium Subwoofer
