Atmel AT88CK440RED User manual

8725A–SMEM–09/10
Atmel CryptoAuthentication Evaluation Kit
Atmel AT88CK440RED
Getting Started Guide
Features
•Installing Atmel CryptoAuthentication Utilities
•Powering the board
•Reading the Device Configuration Information
Atmel AT88SA102S device
Contents
•Atmel AT88CK440RED USB Dongle
•Quick Start Guide
Introduction
Atmel®AT88CK440RED is an Atmel CryptoAuthenticationEvaluation Kit, which can be used as a reference
design for an USB application requiring the Atmel CryptoAuthentication product family.
Figure 0-1. Atmel AT88CK440RED Evaluation Kit

2Atmel AT88CK440RED Quick Start Guide
8725A–SMEM–09/10
1. Install the Atmel CryptoAuthentication Utilities
•Visit www.atmel.com/cryptokits to download and install the latest Atmel®CryptoAuthentication
Utilities
•Scroll down the webpage to Software Files and select the software icon for:
CryptoAuthentication Firmware AT88CK440RED Version x.x
2. Powering up the board
The Atmel AT88CK440RED is a USB powered Device.
•Simply insert the board into an open USB port
Figure 2-1. Atmel AT88CK440RED USB device
3. Reading the Device Configuration Information
•Insert the Atmel AT88CK440RED into a USB port
•Launch the Atmel CryptoAuthentication Utilities
•Click Start, All Programs, Atmel Crypto Solutions, CryptoAuthentication Utilities
Figure 3-1. Atmel CryptoAuthentication Utilities
Power LED

Atmel AT88CK440RED Quick Start Guide 3
8725A–SMEM–09/10
The Atmel®CryptoAuthenticationUtilities will open to the AT88SA102S/ Hardware Operation tab.
Figure 3-2. Hardware Operations Tab
If the following screen appears, then one of two problems exists.
1. Atmel AT88CK440RED has not been inserted into a USB port
−The enumeration process must be completed prior to launching the utility
2. The firmware is outdated
−See Section 4, “Firmware Upgrade”
Figure 3-3. Incorrect Firmware Version Error Message

4Atmel AT88CK440RED Quick Start Guide
8725A–SMEM–09/10
•Click the Read button in the AT88SA102S Configuration Information section
The section will populate
Figure 3-4. Atmel AT88SA102S Configuration Information populated
Congratulations, your Atmel AT88CK440RED is up and running.
See the CryptoAuthentication Help shortcut on your desktop for additional information.
For additional samples, go to: http://www.atmel.com/forms/Samples.asp?family_id=699

Atmel AT88CK440RED Quick Start Guide 5
8725A–SMEM–09/10
4. Firmware Upgrade
To upgrade the firmware, click the Help tab and complete steps one through six.
The following steps enable the DFU mode:
1. Load the Atmel FLIP (FLexible In-System) Programming utility
2. http://www.atmel.com/dyn/products/tools_card_v2.asp?tool_id=3886
3. Click the Firmware upgrade mode Enable button
4. Click OK in the popup box
5. Both LEDs will light indicating the board is in DFU mode
6. Launch FLIP to load the new firmware
Figure 4-1. Device Firmware Upgrade Mode

6Atmel AT88CK440RED Quick Start Guide
8725A–SMEM–09/10
5. References and further information
A complete reference design including schematics, Gerber files, bill of materials (BOM), Hardware User
Guide and development and demonstration software is conveniently downloadable from the Atmel®
website at www.atmel.com/cryptokits.
