Atmel SAM3S-EK User manual

11031A–ATARM–14-Dec-09
SAM3S-EK Development Board
....................................................................................................................
User Guide

SAM3S-EK Development Board User Guide 1-1
11031A–ATARM–14-Dec-09
Section 1
Introduction.................................................................................................................1-1
1.1 SAM3S Evaluation Kit ........................................................................................................ 1-1
1.2 User Guide ......................................................................................................................... 1-1
1.3 References and Applicable Documents ............................................................................. 1-1
Section 2
Kit Contents ................................................................................................................2-1
2.1 Deliverables ....................................................................................................................... 2-1
2.2 Electrostatic Warning ......................................................................................................... 2-2
Section 3
Power Up....................................................................................................................3-1
3.1 Power up the Board ...........................................................................................................3-1
3.2 DevStart ............................................................................................................................. 3-1
3.3 Recovery Procedure .......................................................................................................... 3-1
3.4 Sample Code and Technical Support ................................................................................ 3-1
Section 4
Evaluation Kit Hardware .............................................................................................4-1
4.1 Board Overview.................................................................................................................. 4-1
4.2 Features List ...................................................................................................................... 4-2
4.3 Function Blocks.................................................................................................................. 4-2
4.3.1 Processor............................................................................................................. 4-2
4.3.2 Memory................................................................................................................ 4-2
4.3.3 Clock Circuitry...................................................................................................... 4-3
4.3.4 Reset Circuitry ..................................................................................................... 4-4
4.3.5 Power Supply and Management.......................................................................... 4-4
4.3.6 UART ................................................................................................................... 4-5
4.3.7 USART................................................................................................................. 4-5
4.3.8 Display Interface .................................................................................................. 4-6
4.3.9 JTAG/ICE............................................................................................................. 4-8
4.3.10 Audio Interface..................................................................................................... 4-9
4.3.11 USB Device ....................................................................................................... 4-10
4.3.12 Analog Interface ................................................................................................ 4-11
4.3.13 QTouch Elements .............................................................................................. 4-12
4.3.14 User Buttons ...................................................................................................... 4-13
4.3.15 LEDs .................................................................................................................. 4-13
4.3.16 SD/MMC Card ................................................................................................... 4-14
4.3.17 ZigBEE............................................................................................................... 4-14
4.3.18 PIO Expansion................................................................................................... 4-14

1-2 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
4.4 Configuration.................................................................................................................... 4-15
4.4.1 PIO Usage ......................................................................................................... 4-15
4.4.2 Jumpers ............................................................................................................. 4-19
4.4.3 Test Points......................................................................................................... 4-20
4.4.4 Solder Drops ...................................................................................................... 4-20
4.4.5 Assigned PIO Lines, Disconnection Possibility.................................................. 4-20
4.5 Connectors....................................................................................................................... 4-22
4.5.1 Power Supply Connector J9 .............................................................................. 4-22
4.5.2 USART Connector J5 With RTS/CTS Handshake Support ............................... 4-22
4.5.3 UART Connector J7 .......................................................................................... 4-23
4.5.4 USB Device Connector J15 ............................................................................... 4-23
4.5.5 TFT LCD Connector J8...................................................................................... 4-24
4.5.6 JTAG Debugging Connector J6 ......................................................................... 4-24
4.5.7 SD/MMC - MCI Connector J3 ............................................................................ 4-27
4.5.8 Analog Connector CN1 & CN2 .......................................................................... 4-27
4.5.9 RS485 Connector J14 ....................................................................................... 4-28
4.5.10 Headphone Connector J11................................................................................ 4-28
4.5.11 ZigBEE Connector J16 ...................................................................................... 4-28
4.5.12 PIO Expansion Port C Connector J12 ............................................................... 4-29
4.5.13 PIO Expansion Port A Connector J13 .............................................................. 4-30
4.5.14 PIO Expansion Port B Connector J14 ............................................................... 4-31
Section 5
Schematics .................................................................................................................5-1
5.1 Schematics......................................................................................................................... 5-1
Section 6
Troubleshooting..........................................................................................................6-1
6.1 Self-Test............................................................................................................................. 6-1
6.2 Board Recovery ................................................................................................................. 6-1
Section 7
Revision History..........................................................................................................7-1
7.1 Revision History ................................................................................................................. 7-1

SAM3S-EK Development Board User Guide 1-1
11031A–ATARM–14-Dec-09
Section 1
Introduction
1.1 SAM3S Evaluation Kit
The SAM3S Evaluation Kit (SAM3S-EK) enables evaluation capabilities and code development of appli-
cations running on a SAM3S4C device.
1.2 User Guide
This guide focuses on the SAM3S-EK board as an evaluation platform. It is made up of 6 sections:
Section 1 includes references, applicable documents, acronyms and abbreviations.
Section 2 describes the kit contents, its main features and specifications.
Section 3 provides board specifications.
Section 4 describes the development environment.
Section 5 provides instructions to power up the SAM3S-EK and describes how to use it.
Section 6 describes the hardware resources, default jumper and switch settings, and connectors.
Section 7 provides schematics.
Section 8 describes the troubleshooting.
1.3 References and Applicable Documents
Table 1-1. References and Applicable Documents
Title Comment
SAM3S Datasheet http://www.atmel.com/dyn/products/datasheets.asp?family_id=605#2127

SAM3S-EK Development Board User Guide 2-1
11031A–ATARM–14-Dec-09
Section 2
Kit Contents
2.1 Deliverables
The Atmel®SAM3S-EK toolkit contains the following items:
Board:
– a SAM3S-EK board
– a universal input AC/DC power supply with US, Europe and UK plug adapters
Cables:
– one USB cable
– one serial RS232 cable
A Welcome Letter
Figure 2-1. Unpacked SAM3S-EK
Unpack and inspect the kit carefully. Contact your local Atmel distributor, should you have issues con-
cerning the contents of the kit.

Kit Contents
2-2 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
2.2 Electrostatic Warning
The SAM3S-EK board is shipped in a protective anti-static package. The board must not be subjected to
high electrostatic potentials. A grounding strap or similar protective device should be worn when han-
dling the board. Avoid touching the components or any other metallic element of the board.

SAM3S-EK Development Board User Guide 3-1
11031A–ATARM–14-Dec-09
Section 3
Power Up
3.1 Power up the Board
Unpack the board taking care to avoid electrostatic discharge. Unpack the power supply, select the right
power plug adapter corresponding to that of your country, and insert it in the power supply.
Connect the power supply DC connector to the board and plug the power supply to an AC power plug.
The board LCD should light up and display a welcome page. Then, click or touch icons displayed on the
screen and enjoy the demo.
3.2 DevStart
The on-board NAND Flash contains “SAM3S-EK DevStart”.
It is stored in the “SAM3S-EK DevStart” folder on the USB Flash disk available when the SAM3S-EK is
connected to a host computer and you click on the Flash Disk icon of the on-board demo.
Click the file “welcome.html” in this folder to launch SAM3S-EK DevStart.
SAM3S-EK DevStart guides you through installation processes of IAR™ EWARM, Keil MDK and GNU
toolkits. Then, it gives you step-by-step instructions on how to rebuild a single example project and how
to program it into the SAM3S-EK. Optionally, if you have a SAM-ICE™, instructions are also given about
how to debug the code.
We recommend that you backup the “SAM3S-EK DevStart” folder on your computer before launching it.
3.3 Recovery Procedure
The DevStart ends by giving step-by-step instructions on how to recover the SAM3S-EK to the state as it
was when shipped by Atmel.
Follow the instructions if you deleted the contents of the embedded Flash or the NAND Flash and want
to recover from this situation.

Power Up
3-2 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
3.4 Sample Code and Technical Support
After boot up, you can run some sample code or your own application on the development kit. You can
download sample code and get technical support from Atmel website
http://www.atmel.com/dyn/products/tools_card.asp?tool_id=4678
Figure 3-1. Atmel Website for AT91SAM Products

SAM3S-EK Development Board User Guide 4-1
11031A–ATARM–14-Dec-09
Section 4
Evaluation Kit Hardware
4.1 Board Overview
This section introduces the Atmel SAM3S Evaluation Kit design. It introduces system-level concepts,
such as power distribution, memory, and interface assignments.
The SAM3S-EK board is based on the integration of an ARM®Cortex®-M3 processor with on-board
NAND Flash and a set of popular peripherals. It is designed to provide a high performance processor
evaluation solution with high flexibility for various kinds of applications.
Figure 4-1. SAM3S-EK Block Diagram

Evaluation Kit Hardware
4-2 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
4.2 Features List
Here is the list of the main board components and interfaces:
SAM3S4C chip LQFP100 package with optional socket footprint
12 MHz crystal
32.768 KHz crystal
Optional SMB connector for external system clock input
NAND Flash
2.8 inch TFT color LCD display with touch panel and backlight
UART port with level shifter circuit
USART port with level shifter circuit multiplexed with RS485 port with level shifter circuit
Microphone input and mono/stereo headphone jack output
SD/MMC interface
Reset button: NRST
User buttons: Left and Right
QTouch®buttons: Up, Down, Left, Right, Valid and Slider
Full Speed USB device port
JTAG/ICE port
On-board power regulation
Two user LEDs
Power LED
BNC connector for ADC input
BNC connector for DAC output
User potentiometer connected to the ADC input
ZigBEE connector
2x32 bit PIO connection interfaces (PIOA, PIOC) and 1x16 bit PIO connection interface (PIOB)
4.3 Function Blocks
4.3.1 Processor
The SAM3S-EK is equipped with a SAM3S4C device in LQFP100 package.
4.3.2 Memory
The SAM3S4 chip embeds:
256 Kbytes of embedded Flash
48 Kbytes of embedded SRAM with dual bank
16 Kbytes of ROM with embedded BootLoader routines (UART, USB) and In-Application Programming
functions (IAP) routines.
The SAM3S features an External Bus Interface (EBI) that permits interfacing to a broad range of external
memories and virtually to any parallel peripheral. The SAM3S-EK board is equipped with a memory
device connected to the SAM3 EBI:

Evaluation Kit Hardware
SAM3S-EK Development Board User Guide 4-3
11031A–ATARM–14-Dec-09
One NAND Flash MT29F2G08AADWP.
Figure 4-2. NAND Flash
NCS0 chip select signal is used for NAND Flash chip selection. Furthermore, a dedicated jumper can
disconnect it from the on-board memories, thereby letting NCS0 free for other custom purpose.
4.3.3 Clock Circuitry
The clock generator of a SAM3S microcontroller is made up of:
A Low Power 32.768 Hz Slow Clock Oscillator with bypass mode.
A 3 to 20 MHz Crystal Oscillator, which can be bypassed (12 MHz needed in case of USB).
A factory programmed fast internal RC Oscillator. 3 output frequencies can be selected: 4 (default
value), 8 or 12 MHz.
A 60 to 130 MHz PLL (PLLB) providing a clock for the USB Full Speed Controller.
A 60 to 130 MHz programmable PLL (PLLA), capable to provide the clock MCK to the processor and
to the peripherals. The input frequency of PLLA is from 7.5 and 20 MHz.
The SAM3S-EK board is equipped with one 12 MHz crystal, optional Piezoelectric Ceramic Resonator
12 Mhz (Murata ref. CSTCE12M0G15L99-R0), one 32.768 Hz crystal and an external clock input con-
nector (optional, not populated by default).
Figure 4-3. External Clock Source
The SAM3S chip internally generates the following clocks:
SLCK, the Slow Clock, which is the only permanent clock of the system
MAINCK, the output of the Main Clock Oscillator selection: either a Crystal Oscillator or a 4/8/12 MHz
Fast RC Oscillator
MT29F2G08AADWP
PC7
PC6
PC5
PC4
PC3
PC2
PC1
PC0
PC10
PC9
PC16
PC17
PC18
PC14
+3V3
DGND
+3V3
DGND
+3V3
+3V3
PC[0..31]{3,5,7}
MN3MN3
WE
18
N.C6
6
VCC 37
CE
9
RE
8
N.C11
20
WP
19
N.C5
5
N.C1
1
N.C2
2
N.C3
3
N.C4
4
N.C12
21
N.C13
22
N.C14
23
N.C15
24
R/B
7
N.C17
26
N.C1827
N.C19 28
I/O0 29
N.C21 34
N.C22 35
VSS 36
PRE38
N.C2339
VCC 12
VSS 13
ALE
17
N.C8
11 N.C7
10
N.C9
14
N.C10
15
CLE
16
N.C16
25
N.C20 33
I/O1 30
I/O332
I/O2 31
N.C2747
N.C2646
N.C2545
I/O744
I/O643
I/O5 42
I/O4 41
N.C2440
N.C2848
C27
100nF
C27
100nF
R15
47K
R15
47K
R2147KR2147K
R16
47K
R16
47K
C29
1uF
C29
1uF
R190R R190R
R22
DNP
R22
DNP
JP9 JP9
C28
100nF
C28
100nF
NOTPOPULATED
DNP
XOUT32
XIN32
XIN32
XOUT32
PA7
PA8
XIN
XOUT
PB8
PB9
DGND
DGND
DGND
DGND
DGND
R3DNP R3DNP
R6 DNP R6 DNP
R9D NPR9D NP
R1 DNPR1 DNP
C3
20pF
C3
20pF
R4 0RR4 0R
C4
20pF
C4
20pF
R2
49.9R 1%
R2
49.9R 1%
Y1Y1
12
3
R8DNP R8DNP
R7DN PR7DN P
AT91SAM3S
MN1
AT91SAM3S
MN1
PA7_RTS0_PWMH349
PA8_CTS0_AD12BTRG48
PB8_XOUT
96
PB9_XIN
97
R11
0R
R11
0R
Y21 2MHz Y21 2MHz
C120pF C120pF
R10DNPR10DNP
Y3
32.768KHz
Y3
32.768KHz
12
3
R50R R50R
R12
0R
R12
0R
J1J1
1
23
54
C220pF C220pF

Evaluation Kit Hardware
4-4 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
PLLACK, the output of the Divider and 60 to 130 MHz programmable PLL (PLLA)
PLLBCK, the output of the Divider and 60 to 130 MHz programmable PLL (PLLB)
4.3.4 Reset Circuitry
On-board NRST button BP1 provides an external reset control of the SAM3S.
The NRST pin is bidirectional. It is handled by the on-chip reset controller. It can be driven low to provide
a reset signal out to the external components. Conversely, it can be asserted low from the outside to
reset the microcontroller Core and the peripherals. The NRST pin integrates a permanent pull-up resistor
of about 100 kOhm to VDDIO.
On the SAM3S-EK board, the NRST signal is connected to the LCD module and JTAG port.
4.3.5 Power Supply and Management
The SAM3S-EK board is supplied with an external 5V DC block through input J9. It is protected by a
PolyZen diode MN9 and an LC combinatory filter MN10. The PolyZen is used in the event of an incorrect
power supply connection.
The adjustable LDO regulator MN12 is used for the 3.3V rail main supply. It powers all the 3.3V compo-
nents on the board.
Figure 4-4. Power Block
The SAM3S4/2/1 product series has different types of power supply pins:
VDDIN pin:
Power for the internal voltage regulator, ADC, DAC, and analog comparator power supplies.
The voltage ranges from 1.8V to 3.6V.
VDDIO pins:
Power for the Peripherals I/O lines.
The voltage ranges from 1.62V to 3.6V.
VDDOUT pin:
Output of the internal voltage regulator.
VDDCORE pins:
Power for the core, including the processor, embedded memories and peripherals.
The voltage ranges from 1.62V to 1.95V.
VDDPLL pin:
Power for the PLL A, PLL B and 12 MHz oscillator.
The voltage ranges from 1.62V to 1.95V.
DGND
+5V
+5V +3V3
C75
100uF
+
C75
100uF
C65
22uF
+
C65
22uF
C64
100nF
C64
100nF
MN10
BNX002-01
MN10
BNX002-01
SV
1
SG
2
CV3
CG14
CG2 5
CG36
C76
100nF
C76
100nF
C66
22uF
+
C66
22uF
MN9
ZEN056V130A24LS
MN9
ZEN056V130A24LS
1
2
3
R92
102K 1%
R92
102K 1%
MN12
MIC29152W U
Micrel's1.5A LDO, TO263-5
MN12
MIC29152W U
Micrel's1.5A LDO, TO263-5
VIN
2VOUT 4
SD
1
GND1
3
ADJ 5
GND2
6
R89
169K 1%
R89
169K 1%
J9
MP179P 2.1mm
J9
MP179P 2.1mm
1
2
3

Evaluation Kit Hardware
SAM3S-EK Development Board User Guide 4-5
11031A–ATARM–14-Dec-09
Note: VDDPLL should be decoupled and filtered from VDDCORE.
4.3.6 UART
The Universal Asynchronous Receiver Transmitter features a two-pin UART that can be used for com-
munication and trace purposes. It offers an ideal channel for in-situ programming solutions. This UART
is associated with two PDC channels to reduce the processor time on packet handling.
This two-pin UART (TXD and RXD only) is buffered through an RS232 Transceiver MN6 and brought to
the DB9 male connector J7.
Figure 4-5. UART
4.3.7 USART
The Universal Synchronous/Asynchronous Receiver Transmitter (USART) provides one full duplex uni-
versal synchronous/asynchronous serial link. The data frame format is extensively configurable (data
length, parity, number of stop bits) to support a broad range of serial communication standards. The
USART is also associated with PDC channels for TX/RX data access.
Note: For design optimization purposes, both transmitters have been implemented on the same
PIO lines, that is PA21, 22, 23, 24 25.
To avoid any electrical conflict, the RS485 transceiver is isolated from the receiving line PA21.
Should you need to implement an RS485 channel in place of the RS232, follow the procedure below:
1. make sure your software will permanently set PA23 to a high level - this will permanently disable the
RS232 receiver.
2. solder a shunt resistor in place of R25 (a solder drop will do).
4.3.7.1 RS232
SAM3S-EK connects the USART1 bus (including TXD, RXD, RTS, CTS handshake signal controls and
EN command) to the DB9 male connector J5 through the RS232 Transceiver MN5.
+3V3
DGND
DGND
+3V3+3V3
FGND
PA10
PA9
C39
100nF
C39
100nF
C40
100nF
C40
100nF
TP5
SMD
TP5
SMD
J7J7
5
4
3
2
1
9
8
7
6
10 11
R46
100K
R46
100K
C38
100nF
C38
100nF
TP6
SMD
TP6
SMD
C41
100nF
C41
100nF
R470R R470R
R480R R480R
C42
100nF
C42
100nF
MN6
MAX3232CSE
MN6
MAX3232CSE
T1IN
11
T2IN
10R1OUT
12
R2OUT
9
T1OUT 14
T2OUT 7
R1IN 13
R2IN8
V+
2
C1+ 1
C1- 3
C2+ 4
C2- 5
V-
6
VCC
16
GND
15
R45
100K
R45
100K

Evaluation Kit Hardware
4-6 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
Figure 4-6. USART
4.3.7.2 RS485
As noticed above, the USART1 is shared with the RS485 port, connected to the transceiver MN4, con-
nected to the 3-point connector J4. The design includes selectable jumpers for RS485 bus termination
resistors selection (JP10, JP11, JP12).
Figure 4-7. RS485
4.3.8 Display Interface
The SAM3S-EK carries a TFT Transmissive LCD module with touch panel, FTM280C34D. Its integrated
driver IC is ILI9325. The LCD display area is 2.8 inches diagonally measured, with a native resolution of
240 x 320 dots.
4.3.8.1 LCD Module
The LCD module gets reset from the NRST signal. As explained, this NRST is shared with the JTAG port
and the push-button BP1. The LCD chip select signal is connected to NCS1; the jumper JP13 can dis-
connect it so that this PIO line is available for other custom usage.
The SAM3S communicates with the LCD through PIOC where an 8-bit parallel “8080-like” protocol data
bus has to be implemented by software.
PA25
PA24
PA21
PA22
PA23
FGND
DGND
+3V3
DGND
+3V3
+3V3
DGND
R360R R360R
C34
100nF
C34
100nF
C35
100nF
C35
100nF
C36
100nF
C36
100nF
R32
47K
R32
47K
MN5
ADM3312EARU
MN5
ADM3312EARU
C1+6
C1-20
C2+2
C2- 4
C3+24
C3-22
VCC
3
V+
1
V-
21
GND
23
SD
19
EN
5
T1IN
7T1OUT18
R1IN 15 R1OUT
10
T2IN
8T2OUT17
R2IN 14 R2OUT
11
T3IN
9T3OUT16
R3IN 13 R3OUT
12
R38 0RR38 0R
C31
4.7uF
C31
4.7uF
C32
100nF
C32
100nF
R350R R350R
C37
100nF
C37
100nF
C33
100nF
C33
100nF
J5J5
5
4
3
2
1
9
8
7
6
10 11
R340R R340R
R33 0RR33 0R
R310RR310R
R3747KR3747K
PA22
PA24
PA25
PA21
PA23
DGND
+3V3
+3V3+3V3
DGND
FGND
MN4
ADM3485ARZ
MN4
ADM3485ARZ
RO
1
RE
2
DE
3
DI
4
VCC 8
GND 5
A6
B7
R280R R280R
R30
DNP
R30
DNP
J4J4
1
2
3
R29
120R
R29
120R
C30
100nF
C30
100nF
R260R R260R
JP11 JP11JP12JP12
JP10 JP10
R270R R270R
R23
DNP
R23
DNP
R25DNP R25DNP
R24
DNP
R24
DNP

Evaluation Kit Hardware
SAM3S-EK Development Board User Guide 4-7
11031A–ATARM–14-Dec-09
Figure 4-8. LCD Block
4.3.8.2 Backlight Control
The LCD backlight is made of four integrated white chip-LEDs arranged in parallel. These are driven by
an AAT3155 charge pump, MN8.The AAT3155 is controlled by the SAM3S through a single PIO line
PC13 interface; the 0 Ohm resistor R68 is mounted in series on this line, which permits to use it for other
custom purposes. In that case, the pull-up resistor R64 maintains the charge pump permanently enabled
by default.
On the anode drive line, a 0 Ohm resistor R59 is implemented in series for an optional current limitation.
Figure 4-9. Backlight Control
4.3.8.3 Touch Screen Interface
The LCD module integrates a 4-wire touch panel controlled by MN7 (ADS7843) which is a slave device
on the SAM3S SPI bus. The controller sends back the information about the X and Y positions, as well
NOT POPULATED
LCD_DB10
LCD_DB11
LCD_DB12
LCD_DB13
LCD_DB14
LCD_DB15
LCD_DB16
LCD_DB17
2.8" 320x240
TFT LCD DISPLAY
X_RIGHT
X_LEFT
Y_UP
Y_DOWN
X_LEFT
X_RIGHT
Y_DOWN
Y_UP
LED_K4
LED_K3
LED_K2
LED_K1
LED_A
PC0
PC1
PC2
PC3
PC4
PC5
PC6
PC7
NRST
PC15
PC19
PC11
PC8
PC13
PC24
PC25
PC26
PC27
PC28
PC29
PC30
PC31
LCD_DB9
LCD_DB8
LCD_DB7
LCD_DB6
LCD_DB5
LCD_DB4
LCD_DB3
LCD_DB2
LCD_DB1
LCD_DB0
LCD_DB0
LCD_DB4
LCD_DB9
LCD_DB5
LCD_DB7
LCD_DB6
LCD_DB8
LCD_DB1
LCD_DB3
LCD_DB2
PC23
PC22
DGND
DGND
+3V3
DGND
+3V3
DGND
DGND
NRST
PC[0..31]
D1
PACDN044Y5R
TVS, SOT23-5
D1
PACDN044Y5R
TVS, SOT23-5
1
2
3 4 5
R56
10K
R56
10K
JP13JP13
RA3
DNP
RA3
DNP
1
2
3
4 5
6
7
8
R61 DNPR61 DNP
+
C43
10uF
+
C43
10uF
PINs
on
BOT
PIN 39
PIN1
FTM280C34D-8bit
PINs
on
BOT
PIN 39
PIN1
FTM280C34D-8bit
C44
100nF
C44
100nF
J8
FH26-39S-0.3SHW
J8
FH26-39S-0.3SHW
VDD
1
DB17
2
DB16
3
DB15
4
DB14
5
DB13
6
DB12
7
DB11
8
DB10
9
DB9
10
DB8
11
DB7
12
DB6
13
DB5
14
DB4
15
DB3
16
DB2
17
DB1
18
DB0
19
VDD
20
RD
21
WR
22
RS
23
CS
24
RESET
25
IM0
26
IM1
27
GND
28
LED-A
29
LEDK1
30
LEDK2
31
LEDK3
32
LEDK4
33
Y+
34
Y-
35
X+
36
X-
37
NC
38
GND
39
R58
4.7K
R58
4.7K
C45
100nF
C45
100nF
R63DNP R63DNP
RA2
DNP
RA2
DNP
1
2
3
4 5
6
7
8
R590RR590R
R49
47K
R49
47K
LED_A
LED_K1
LED_K2
LED_K3
LED_K4
PC13
+3V3
+3V3
DGND
DGND
R68
0R
R68
0R
C57
4.7uF
C57
4.7uF
C55
1uF
C55
1uF
MN8
AAT3155ITP-T1
MN8
AAT3155ITP-T1
C1+
10
C1-
9
EN/SET
11
C2+ 7
C2-6
OUTCP8
IN
5
GND
4
D13
D22
D31
D412
R64
47K
R64
47K
B1
BN03K314S300R
B1
BN03K314S300RC56
1uF
C56
1uF
C54
1uF
C54
1uFTP7
SMD
TP7
SMD

Evaluation Kit Hardware
4-8 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
as a measurement for the pressure applied to the touch panel. The touch panel can be used with either
a stylus or a finger.
The ADS7843 touch panel controller connects to the SPI0 interface via the NPCS0 control signal. Two
interrupt signals are connected and provide events information back to the microcontroller: PenIrq and
Busy.
Note: PenIrq (PA16) is shared with ZigBEE signal IRQ0.
Busy (PA17) is shared with ZigBEE signal IRQ1.
Therefore, if using a ZigBEE interface in concurrence with the TouchScreen controller, take
care not to have both drivers enabled at the same time on either PA16 or PA17.
For that purpose, 0 Ohm resistors have been implemented on these PIO lines in order to disconnect
either end driver from the other:
On the touch panel controller side, R67 and R69.
On ZigBEE side, R117 and R120.
for further information, refer to the “Schematics” section.
Touch ADC auxiliary inputs IN3/IN4 of the ADS7843 are connected to test point (TP8, TP9) for optional
function extension.
Figure 4-10. Touch Panel Control
4.3.9 JTAG/ICE
A standard 20-pin JTAG/ICE connector is implemented on the SAM3S-EK for the connection of a com-
patible ARM JTAG emulator interface, such as the SAM-ICE from Segger.
Note: The NRST signal is connected to BP1 system button and is also used to reset the LCD mod-
ule. The 0 ohm resistor R44 may be removed in order to isolate the JTAG port from this sys-
tem reset signal.
Figure 4-11. JTAG Interface
PA12
PA13
PA14
PA17
PA11
X_RIGHT
Y_UP
X_LEFT
Y_DOW N
PA16
DGND
+3V3
+3V3
+3V3
AGND_TP AGND_TP
R62
100K
R62
100K
R70 0RR70 0R
R67 0RR67 0R
R66 0RR66 0R R65
100K
R65
100K
C60
100nF
C60
100nF
C58
100nF
C58
100nF
L2
10uH/100mA
L2
10uH/100mA
R72
100K
R72
100K
R69 0R R69 0R
C61
4.7uF
C61
4.7uF
TP9
SMD
TP9
SMD
R71
1R
R71
1R
C59
100nF
C59
100nF
TP8
SMD
TP8
SMD
R74
0R
R74
0R
R73
100K
R73
100K
MN7
ADS7843E
MN7
ADS7843E
XP
2
YP
3
XM
4
YM
5
DCLK 16
DIN 14
DOUT 12
CS15
BUSY13
PENIRQ11
VREF 9
VCC1 1
VCC2 10
GND 6
IN3
7
IN4
8
+3V3
DGND
NRST
PB5
PB7
PB6
PB4
R43
100K
R43
100K
R41
100K
R41
100K
R39
100K
R39
100KJ6
J6
VTref
1Vsupply 2
nTRST
3GND1 4
TDI
5GND26
TMS
7GND38
TCK
9GND410
RTCK
11GND512
TDO
13GND6 14
nSRST
15GND716
DBGRQ
17GND818
DBGACK
19 GND920
R42
100K
R42
100K
R40
100K
R40
100K
R440R R440R

Evaluation Kit Hardware
SAM3S-EK Development Board User Guide 4-9
11031A–ATARM–14-Dec-09
4.3.10 Audio Interface
The SAM3S–EK board supports both audio recording and playback.
The audio volume can be adjusted using the potentiometer RV1, and the microphone amplifier gain can
be adjusted via jumpers (fixed gain of 24 or 26 dB).
4.3.10.1 Microphone Input
The embedded microphone is connected to an audio pre-amplifier using the TS922 operational amplifier
(MN11). The gain is set by using JP14 and JP15 jumpers; both must be set or removed at the same
time.
By modifying the jumper positions, you can select each of the following gain values:
20 dB (default setting, both JP14 and JP15 are off)
26 dB (both JP14 and JP15 are on).
Note:
1. The TB1 series 0 Ohm resistor is a reservation for future impedance adaptation facility.
Under specific amplifier settings conditions, this enables the easy insertion of a capaci-
tor or any other bipolar device on the audio path. On the other hand, R83 is a default
0 Ohm resistor that enables the disconnection of PB0 from the audio input path for cus-
tom usage.
2. The audio pre-amplifier MN11 is powered by a dedicated low dropout regulator
MIC5219-3.3 (MN14).
Figure 4-12. Microphone Input
4.3.10.2 Headphone Output
The SAM3S-EK evaluation kit supports mono/stereo audio playback driven by a TPA0223 audio ampli-
fier connected to two DAC channels of the microcontroller.
The TPA0223 is a 2W mono Bridge-Tied-Load (BTL) amplifier designed to drive speakers with as low as
4Ohm impedance. The amplifier can be reconfigured on the fly to drive two stereo Single-Ended (SE)
signals into head phones.
JP14and JP15 shouldbeset
or removed together
AGND
AGND AGND
AVDD
AGND AGND
AGND
AVDD
AGND
AGND
DGND
AVDD
AGND
VCC33
PB0
C72
1nF
C72
1nF
R80
1K
R80
1K
R90
100K
R90
100K
C67
1uF
C67
1uF
C74
100nF
C74
100nF
R84
1K
R84
1K
R87
47K
R87
47K
R79
1K
R79
1K
R78
1K
R78
1K
R77
470R
R77
470R
B2 BN03K314S300RB2 BN03K314S300R
C71
22nF
C71
22nF
R83
0R
R83
0R
R88
470R
R88
470R
TB1
0R
TB1
0R
C63
22uF
C63
22uF
C62
100pF
C62
100pF
C77
4.7uF
C77
4.7uF
R85
1K
R85
1K
C73
22uF
C73
22uF
R75 47KR75 47K
MN11
TS922
MN11
TS922
IN1-
2
IN1+
3
OUT2
7
IN2-
6
IN2+
5
GND 4
VCC 8
OUT1 1
JP14JP14
R76 47KR76 47K
R93
100K
R93
100K
R91
0R
R91
0R
JP15JP15
C69
1nF
C69
1nF
R86
47K
R86
47K
R82
1K
R82
1K
C68
1uF
C68
1uF
MIC1
SVB6050
MIC1
SVB6050
12
R81
100R
R81
100R

Evaluation Kit Hardware
4-10 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
Figure 4-13. Headphone Output
Using a readily available 1/8-in. (3,5 mm) stereo headphone jack, the control switch is closed when no
plug is inserted. When closed, a 100-kOhm/1-kOhm divider pulls the ST/MN input low. When a jack plug
is inserted, the 1-kOhm resistor is disconnected and the ST/MN input is pulled high. The mono speaker
(J10 connector) is also physically disconnected from the RO/MO+ output so that no sound is heard from
the speaker while the headphones are inserted.
4.3.11 USB Device
The SAM3S UDP port is compliant with the Universal Serial Bus (USB) rev 2.0 Full Speed device speci-
fication. J15 is a micro B-type receptacle for USB device.
Both 27-Ohm resistors R114 and R116 build up a 90-Ohm differential impedance together with the
(embedded) 6-Ohm output impedance of the SAM3S full speed channel drivers.
R110 and R112 build up a divider bridge from VBUS +5V to implement plug-in detection (5V level gets
lowered to a PIO compatible 3.3V level) through PC21.
Figure 4-14. USB
AUDIO_OUTL
AUDIO_OUTL
AGND
VDD_AMP
AGND
AGND
AGND
AGND
+5V
AGNDDGND
VDD_AMP
AGND
PB14{3,7}
PB13
JP19 JP19
C82
100nF
C82
100nF
C88 0.47uFC88 0.47uF
+
C81220uF
+
C81220uF
R103100KR103100K
R95 1K R95 1K
C87
1uF
C87
1uF
R99 47K R99 47K
JP20 JP20
R9833
K
R9833
K
C860
.47uFC860 .47uF
MN13
TPA0223DGQ
MN13
TPA0223DGQ
VDD
3
RIN
5
MONO-IN
1
LIN
9
LO/MO- 10
RO/MO+ 6
ST/MN7
SHUTD0WN 2
BYPASS 4
GND8
PAD
11
+
C80
10uF
+
C80
10uF
C850.47uFC850.47uFR10033K
R10033K
R10533K R10533K
SD1SD1
12
+
C83 220uF
+
C83 220uF
J11
EARJACK
J11
EARJACK
5
4
3
2
1
R97 1K R97 1K
R1021
00K
R1021
00K
TP12
SMD
TP12
SMD
C840.47uF C840.47uF
SD2SD2
12
B3
BN03K314S300R
B3
BN03K314S300R
JP17JP17
J10 J10
1
2
R10447K R10447K
R1011 00KR1011 00K
C79
1uF
C79
1uF
( to DAC output
connector )
PC21
PB10
PB11
DGND
DGND FGND
FGND
C94
10pF
C94
10pF
R110 47K R110 47K
R116 27RR116 27R
5V D- D+ ID G
J15
USB MicroB
5V D- D+ ID G
J15
USB MicroB
1 2 3 4
7
5
6
8
9
RV1
V5.5MLA0603
RV1
V5.5MLA0603
RV2
V5.5MLA0603
RV2
V5.5MLA0603
R112 68K R112 68K
R1142
7RR1142 7R

Evaluation Kit Hardware
SAM3S-EK Development Board User Guide 4-11
11031A–ATARM–14-Dec-09
4.3.12 Analog Interface
4.3.12.1 Analog Reference
The 2V5 voltage reference is based on an LM4040 (Precision Micropower Shunt Voltage Reference).
This ADVREF level can be set as 2.5V or 3.3V via the jumper JP2.
Figure 4-15. Analog Vref
4.3.12.2 Analog Input
The BNC connector CN1 is connected to the ADC port PB1 as an external analog input. An on-board 50-
Ohm resistor termination can be applied by closing jumper JP16. A low pass filter can be implemented
for the BNC connector CN1 by replacing R94 and C78 with custom resistor and capacitor values,
depending on your application requirements.
A 10-KOhm potentiometer (VR1) is also connected to this channel to implement an easy access to ADC
programming and debugging (or implement an analog user control like display brightness, volume, etc.).
Either of these two functions can be selected by jumper JP18.
Figure 4-16. ADC Input
4.3.12.3 Analog Output
The BNC connector CN2 is connected to the DAC port PB13 and provides an external analog output. An
on-board 50-Ohm resistor termination can be enabled by closing jumper JP21. A filter can be imple-
mented on this output channel by replacing R106 and C90 with appropriate resistor and capacitor
values, depending on the application requirements.
ADVREF
DGND
DGND
VCC33
+5V
JP2JP2
1
2
3
C5
100nF
C5
100nF
AT91SAM3SAT91SAM3S
ADVREF 1
R13
2.2K
R13
2.2K
MN2
LM4040-2.5
MN2
LM4040-2.5
Potentiometer
AD12B5
ADC
DGND
DGND
VCC33
PB1
JP18 JP18
1
2
3
CN1
BNC
CN1
BNC
1
2
3
4
5
JP16JP16
VR1
10K
VR1
10K
13
2
R96
49.9R 1%
R96
49.9R 1%
C89
10nF
C89
10nF
R94
0R
R94
0R
C78
10nF
C78
10nF

Evaluation Kit Hardware
4-12 SAM3S-EK Development Board User Guide
11031A–ATARM–14-Dec-09
Figure 4-17. DAC Output
4.3.13 QTouch Elements
QTouch keys consist in a series of sensors formed by the association of a copper area and the capaci-
tive effect of human fingers approaching it.
4.3.13.1 Keys
The SAM3S-EK implements five individual capacitive touch keys (UP, DOWN, RIGHT, LEFT and
VALID) using five pairs of PIO.
Figure 4-18. QST Keys
4.3.13.2 Slider
A group of channels forms a Slider. A Slider is composed of three channels for a QTouch acquisition
method using three pairs of PIO. Such a sensor is used to detect a linear finger displacement on a sen-
sitive area. A typical implementation is volume control.
SOLDER DROP 2 pins open.Normal
DAC01
DAC
AUDIO_OUTL
DGND
PB14
C90 2.2uFC90 2.2uF
JP21JP21
R109
49.9R 1%
R109
49.9R 1%
SD1 SD1
12
R106
0R
R106
0R
CN2
BNC
CN2
BNC
1
2
3
4
5
SD2SD2
12
PC25
PC24
PC31
PC30
PC29
PC28
PC23
PC22
PC27
PC26
R531K R531K
C49
22nF
C49
22nF
R601K R601K
R51 1KR51 1K
R57 1KR57 1K
C51
22nF
C51
22nF
R55 1KR55 1K
C47
22nF
C47
22nF
K1
DNP
K1
DNP
C53
22nF
C53
22nF
C52
22nF
C52
22nF
