Atmel AT91SAM7S-EK User manual

AT91SAM7S-EK Evaluation Board
..............................................................................................
User Guide

AT91SAM7S-EK Evaluation Board User Guide i
6112C–ATARM–01-Feb-07
Table of Contents
Section 1
Overview...............................................................................................1-1
1.1 Scope........................................................................................................1-1
1.2 Deliverables ..............................................................................................1-1
1.3 AT91SAM7S-EK Evaluation Board...........................................................1-1
Section 2
Setting Up the AT91SAM7S-EK Board.................................................2-1
2.1 Electrostatic Warning ................................................................................2-1
2.2 Requirements............................................................................................2-1
2.3 Powering Up the Board.............................................................................2-1
2.4 Getting Started..........................................................................................2-1
2.5 AT91SAM7S-EK Block Diagram...............................................................2-2
Section 3
Board Description .................................................................................3-1
3.1 AT91SAM7S256 Microcontroller...............................................................3-1
3.2 AT91SAM7S256 Block Diagram...............................................................3-3
3.3 Memory .....................................................................................................3-3
3.4 Clock Circuitry...........................................................................................3-3
3.5 Reset Circuitry...........................................................................................3-4
3.6 Power Supply Circuitry..............................................................................3-4
3.7 Remote Communication............................................................................3-4
3.8 Analog Interface........................................................................................3-4
3.9 User Interface ...........................................................................................3-4
3.10 Debug Interface ........................................................................................3-4
3.11 Expansion Connector................................................................................3-4
3.12 Wrapping User Area..................................................................................3-4
Section 4
Configuration Straps .............................................................................4-1
4.1 Configuration Strap ...................................................................................4-1
Section 5
Schematics ...........................................................................................5-1
5.1 Schematics ...............................................................................................5-1
Section 6
Revision History....................................................................................6-1
6.1 Revision History ........................................................................................6-1

Table of Contents
ii AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07

AT91SAM7S-EK Evaluation Board User Guide 1-1
6112C–ATARM–01-Feb-07
Section 1
Overview
1.1 Scope The AT91SAM7S-EK evaluation board enables the evaluation of and code development
for applications running on an AT91SAM7Sxx device.
This document describes the evaluation board fitted with an AT91SAM7S256.
This guide focuses on the AT91SAM7S-EK board as an evaluation platform for the
AT91SAM7S family.
1.2 Deliverables
1.2.1 Standard Version
AT91SAM7S-EK
VAR
The AT91SAM7S-EK package contains the following items:
!An AT91SAM7S-EK board
!One A/B-type USB cable
!One DVD-ROM containing summary and full datasheets, datasheets with electrical
and mechanical characteristics, application notes and getting started documents for
all development boards and AT91 microcontrollers. An AT91 software package with C
and assembly listings is also provided. This allows the user to begin evaluating the
AT91 ARM®Thumb®32-bit microcontroller quickly.
1.3 AT91SAM7S-EK
Evaluation Board
The board is generally equipped with an AT91SAM7S256 (64-pin PQFP package)
together with the following:
!USB device port interface
!Two serial communication ports
!JTAG/ICE debug interface
!Four buffered analog inputs
!Four general-purpose LEDs and pushbuttons
!Expansion connector
!Prototyping area

Overview
1-2 AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07
Note: The user can also evaluate the AT91SAM7S32 with this board. A 48-pin TQFP
footprint has been provided for this purpose. To do so, the user must unsolder
the AT91SAM7S256 microcontroller (IC4) and fit the AT91SAM7S32 on the 48-
pin TQFP footprint (IC5).

AT91SAM7S-EK Evaluation Board User Guide 2-1
6112C–ATARM–01-Feb-07
Section 2
Setting Up the AT91SAM7S-EK
Board
2.1 Electrostatic
Warning
The AT91SAM7S-EK evaluation board is shipped in protective anti-static packaging.
The board must not be subjected to high electrostatic potentials. A grounding strap or
similar protective device should be worn when handling the board. Avoid touching the
component pins or any other metallic element.
2.2 Requirements In order to set up the AT91SAM7S-EK evaluation board, the following items are needed:
!The AT91SAM7S-EK evaluation board itself.
!Optional DC power supply capable of supplying 7V to 12V at 0.5 A.
Note: The AT91SAM7S-EK is not delivered with the JTAG/ICE interface required to
start evaluating the device.
2.3 Powering Up the
Board
AT91SAM7S-EK is self-powered by the USB port. If the USB port is not used, the card
can be supplied by an external DC power supply via the 2.1 mm socket (J1). The polar-
ity of the power supply is not critical.
The regulator allows the input voltage range to be from 7V to 12V.
2.4 Getting Started The AT91SAM7S-EK evaluation board is delivered with a DVD-ROM containing all nec-
essary information and step-by-step procedures for working with the most common
development toolchains. Please refer to this DVD-ROM, or to the AT91 web site,
http://www.atmel.com/products/AT91/, for the most up-to-date information on getting
started with the AT91SAM7S-EK.

Setting Up the AT91SAM7S-EK Board
2-2 AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07
2.5 AT91SAM7S-EK
Block Diagram
Figure 2-1. Block Diagram for AT91SAM7S-EK Board
4
Analog
Inputs
RS232
Driver
Power
Supply USB Device ICE Debug
Port
Oscillator,
PLL Extension
Connector
User Grid
RS232
Driver
Pushbutton
User Pushbuttons User LEDs
UART DBGU
AT91SAM7S256
5V
Input
7 - 14V DC
3.3V
VDDCORE
VDDOUT
1.8V
NRST

AT91SAM7S-EK Evaluation Board User Guide 3-1
6112C–ATARM–01-Feb-07
Section 3
Board Description
3.1 AT91SAM7S256
Microcontroller
•Incorporates the ARM7TDMI®ARM®Thumb®Processor
– High-performance 32-bit RISC Architecture
– High-density 16-bit Instruction Set
– Leader in MIPS/Watt
– EmbeddedICE™In-circuit Emulation, Debug Communication Channel Support
•256 Kbytes of Internal High-speed Flash, Organized in 1024 Pages of 256 Bytes
– Single Cycle Access at Up to 30 MHz in Worst Case Conditions,
Prefetch Buffer Optimizing Thumb Instruction Execution at Maximum Speed
– Page Programming Time: 4 ms, Including Page Auto-erase, Full Erase Time: 10
ms
– 10,000 Write Cycles, 10-year Data Retention Capability, Sector Lock Capabilities,
Flash Security Bit
– Fast Flash Programming Interface for High Volume Production
•64 Kbytes of Internal High-speed SRAM, Single-cycle Access at Maximum Speed
•Memory Controller (MC)
– Embedded Flash Controller, Abort Status and Misalignment Detection
•Reset Controller (RSTC)
– Based on Power-on Reset and Low-power Factory-calibrated Brown-out Detector
– Provides External Reset Signal Shaping and Reset Source Status
•Clock Generator (CKGR)
– Low-power RC Oscillator, 3 to 20 MHz On-chip Oscillator and one PLL
•Power Management Controller (PMC)
– Software Power Optimization Capabilities, Including Slow Clock Mode (Down to
500 Hz) and Idle Mode
– Three Programmable External Clock Signals
•Advanced Interrupt Controller (AIC)
– Individually Maskable, Eight-level Priority, Vectored Interrupt Sources
– Two External Interrupt Sources and One Fast Interrupt Source, Spurious Interrupt
Protected
•Debug Unit (DBGU)
– 2-wire UART and Support for Debug Communication Channel interrupt,
Programmable ICE Access Prevention
•Periodic Interval Timer (PIT)
– 20-bit Programmable Counter plus 12-bit Interval Counter
•Windowed Watchdog (WDT)

Board Description
3-2 AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07
– 12-bit key-protected Programmable Counter
– Provides Reset or Interrupt Signals to the System
– Counter May Be Stopped While the Processor is in Debug State or in Idle Mode
•Real-time Timer (RTT)
– 32-bit Free-running Counter with Alarm
– Runs Off the Internal RC Oscillator
•One Parallel Input/Output Controller (PIOA)
– Thirty-Two Programmable I/O Lines Multiplexed with up to Two Peripheral I/Os
– Input Change Interrupt Capability on Each I/O Line
– Individually Programmable Open-drain, Pull-up resistor and Synchronous Output
•Eleven Peripheral Data Controller (PDC) Channels
•One USB 2.0 Full Speed (12 Mbits per second) Device Port
– On-chip Transceiver, 328-byte Configurable Integrated FIFOs
•One Synchronous Serial Controller (SSC)
– Independent Clock and Frame Sync Signals for Each Receiver and Transmitter
– I²S Analog Interface Support, Time Division Multiplex Support
– High-speed Continuous Data Stream Capabilities with 32-bit Data Transfer
•Two Universal Synchronous/Asynchronous Receiver Transmitters (USART)
– Individual Baud Rate Generator, IrDA®Infrared Modulation/Demodulation
– Support for ISO7816 T0/T1 Smart Card, Hardware Handshaking, RS485 Support
– Manchester Encoder/Decoder
– Full Modem Line Support on USART1
•One Master/Slave Serial Peripheral Interface (SPI)
– 8- to 16-bit Programmable Data Length, Four External Peripheral Chip Selects
•One Three-channel 16-bit Timer/Counter (TC)
– Three External Clock Inputs, Two Multi-purpose I/O Pins per Channel
– Double PWM Generation, Capture/Waveform Mode, Up/Down Capability
•One Four-channel 16-bit PWM Controller (PWMC)
•One Two-wire Interface (TWI)
– Master Mode Support Only, All Two-wire Atmel EEPROMs Supported
•One 8-channel 10-bit Analog-to-Digital Converter, Four Channels Multiplexed with
Digital I/Os
•IEEE®1149.1 JTAG Boundary Scan on All Digital Pins
•5V-tolerant I/Os, including Four High-current Drive I/O lines, Up to 16 mA Each
•Power Supplies
– Embedded 1.8V Regulator, Drawing up to 100 mA for the Core and External
Components
– 1.8V or 3.3V VDDIO I/O Lines Power Supply, Independent 3.3V VDDFLASH
Flash Power Supply
– 1.8V VDDCORE Core Power Supply with Brown-out Detector
– 3.3V VDDANA Analog Voltage Supply
•Fully Static Operation: Up to 55 MHz at 1.65V and 85°C Worst Case Conditions
•Available in a 64-lead TQFP Package

Board Description
AT91SAM7S-EK Evaluation Board User Guide 3-3
6112C–ATARM–01-Feb-07
3.2 AT91SAM7S256
Block Diagram
Figure 3-1. AT91SAM7S256 Block Diagram
3.3 Memory !256 Kbytes of internal high-speed Flash
!64 Kbytes of internal high-speed SRAM
3.4 Clock Circuitry !18.432 MHz standard crystal for the embedded oscillator
TDI
TDO
TMS
TCK
NRST
FIQ
IRQ0-IRQ1
PCK0-PCK2
PMC
Peripheral Bridge
Peripheral Data
Controller
AIC
PLL
RCOSC
SRAM
64 Kbytes
ARM7TDMI
Processor
ICE
JTAG
SCAN
JTAGSEL
PIOA
USART0
SSC
Timer Counter
RXD0
TXD0
SCK0
RTS0
CTS0
NPCS0
NPCS1
NPCS2
NPCS3
MISO
MOSI
SPCK
Flash
256 Kbytes
Reset
Controller
DRXD
DTXD
TF
TK
TD
RD
RK
RF
TCLK0
TCLK1
TCLK2
TIOA0
TIOB0
TIOA1
TIOB1
TIOA2
TIOB2
Memory Controller
Abort
Status
Address
Decoder
Misalignment
Detection
PIO
PIO
APB
POR
Embedded
Flash
Controller
AD0
AD1
AD2
AD3
ADTRG
PLLRC
11 Channels
PDC
PDC
USART1
RXD1
TXD1
SCK1
RTS1
CTS1
DCD1
DSR1
DTR1
RI1
PDC
PDC
PDC
PDC
SPI
PDC
ADC
VDDANA
PDC
PDC
TC0
TC1
TC2
TWD
TWCK
TWI
OSC
XIN
XOUT
VDDIN
PWMC
PWM0
PWM1
PWM2
PWM3
1.8 V
Voltage
Regulator
USB Device
FIFO DDM
DDP
Transceiver
GND
VDDOUT
BOD
VDDCORE
VDDCORE
AD4
AD5
AD6
AD7
VDDFLASH
Fast Flash
Programming
Interface
ERASE
PIO
PGMD0-PGMD15
PGMNCMD
PGMEN0-PGMEN1
PGMRDY
PGMNVALID
PGMNOE
PGMCK
PGMCM0-PGMCM3
VDDIO
TST
DBGU PDC
PDC
PIO
PIT
WDT
RTT
System Controller
VDDCORE

Board Description
3-4 AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07
3.5 Reset Circuitry !Internal bi-directional reset controller with brown out detector
!External reset pushbutton
3.6 Power Supply
Circuitry
!USB powered. The dynamic power consumption on VDDCORE is less than 50 mA at
full speed when running out of the Flash. The total current drawn by all the I/O lines
cannot exceed 200 mA.
!External power can be applied via the 2.1 mm connector to the regulator in either
polarity because of the diode-rectifying circuit (CR3 to CR6). The minimum voltage
required is 7V. The board has a voltage regulator providing +3.3V. The regulator
allows the input voltage to be from 7V to 14V (REG1).
!The two power supplies are separated from each other by the diodes CR1 and CR2.
!On-chip embedded VDDCORE 1.8V regulator
3.7 Remote
Communication
!Two serial interface via RS-232 DB9 male sockets
– DBGU COM Port
– UART COM Port with RTS/CTS handshake control possibility (USART 0)
!USB V2.0 full-speed compliant, 12 Mbits per second (UDP)
3.8 Analog Interface !Four analog inputs (0V to 3.3V) via J7, J8, J9, J10 footprints
3.9 User Interface !Four pushbuttons via general PIO lines
!Four LEDs via high current PIO lines
3.10 Debug Interface !20-pin JTAG/ICE interface connector
!DBGU COM port
3.11 Expansion
Connector
One expansion connector (J5) gives access to all the microcontroller's signals.
All I/Os of the AT91SAM7S256 are routed to this connector. This allows the developer
to check the integrity of the components and to extend the features of the board by add-
ing external hardware components or boards.
3.12 Wrapping User
Area
This allows the developer to fit additional components for prototyping use.

AT91SAM7S-EK Evaluation Board User Guide 4-1
6112C–ATARM–01-Feb-07
Section 4
Configuration Straps
4.1 Configuration
Strap
Table 4-1 gives details on configuration straps on the AT91SAM7S-EK evaluation board
and their default settings.
Table 4-1. Configuration Straps
Designation
Default
Setting Feature
JP1 Closed Enables the use of the remote DP pull-up (USB)
JP2 Closed Enables the use of the VBUS detect (USB)
JP3 Opened Disable external VCC on the expansion connector J5
(pin 1, 2)
JP4 Closed The System Reset signal (NRST) is connected to the
ICE/JTAG socket (J4, pin 15).
JP5 Opened Do not use: Factory test mode
JP6 Closed Enables the use of the CTS signal (UART)
JP7 Closed Enables the use of the TXD signal (UART)
JP8 Closed Enables the use of the RTS signal (UART)
JP9 Closed Enables the use of the RXD signal (UART)
JP10 Closed
JP11 Closed Enables the use of the RXD signal (DBGU)
JP12 Closed Enables the use of the TXD signal (DBGU)
JP13(1) Closed VDDFLASH Jumper
JP14(1) Closed VDDIO Jumper
JP15 Closed Enables the use of the User LED (DS1)
JP16 Closed Enables the use of the User LED (DS2)
JP17 Closed Enables the use of the User LED (DS3)
JP18 Closed Enables the use of the User LED (DS4)
JP19 Opened Select ICE mode or JTAG mode (Closed)
JP20(1) Closed ADVREFP Jumper
JP21(1) Closed VDDPLL Jumper

Configuration Straps
4-2 AT91SAM7S-EK Evaluation Board User Guide
6112C–ATARM–01-Feb-07
Note: 1. These jumpers are dedicated to power consumption measurement use. The user has
to open the jumper and insert an anmeter.
If these jumpers are not populated (previous revisions of the kit), the related straps
are wired on board. In this case and in order to use the power consumption measure-
ment feature, the user has to open the strap by cutting it before soldering a jumper
and inserting an anmeter.
JP22(1) Closed VDDIN Jumper
JP23(1) Closed VDDCORE Jumper
JP24 Closed Enables the use of the EXT_AD0 (Analog Input 0)
JP25 Closed Enables the use of the EXT_AD1 (Analog Input 1)
JP26 Closed Enables the use of the EXT_AD4 (Analog Input 4)
JP27 Closed Enables the use of the EXT_AD5 (Analog Input 5)
JP28 Opened Erases all internal Flash memory when the board is
powered. To do so, the user must close J28 for at least
10 ms.
TP1 N.A GND Test point
TP3 N.A GND Test point
TP5 N.A GND Test point
TP6 N.A GND Test point
Table 4-1. Configuration Straps
Designation
Default
Setting Feature

AT91SAM7S-EK Evaluation Board User Guide 5-1
6112C–ATARM–01-Feb-07
Section 5
Schematics
5.1 Schematics This section contains the following schematics:
!Board Layout And Silkscreen Printing - Top View
!64-pin SAM7 Microcontroller (dual footprint)
!48-pin SAM7 Microcontroller
!Power Supply
!ICE/EXT Connectors
!Device Interface
!PIO
!User PAD Grid
