SHOGUN CONNECT
QUICKSTART GUIDE

Checklist
q 1 x SHOGUN CONNECT
q 1 x International DC Power Supply
q 1 x AtomX SSDmini Handle
q 1 x MasterCaddy III with screws
q 1 x RF Antenna
q 2 x WiFi Antenna with black caps
q 5 x Antenna colored caps:
White/Red/Yellow/Black/Green
q 3 x Antenna Mount Covers
q 1 x 3.5mm audio jack to jack cable
q 1 x Antenna Storage Pouch
q 1 x 7” Protective Pouch
q 1 x Quick Start Guide
q 1 x Screen Cloth
Power up
Using the International DC Power Supply
Secure the DC connector from the included International
DC Power Supply to the DC Power Jack on the SHOGUN
CONNECT. The optional ATOMOS D-Tap to DC Barrel Coiled
Cable (ATOMDTPCB2) can also be used to connect a D-Tap
power source.
Using Batteries
To connect a compatible battery, place the battery in front
of the retaining lug, align with the connectors and slide the
battery into the slot until it clicks into place.
Ensure NP-F / L-Series type batteries.
Tap the battery icon in the top right of your SHOGUN
CONNECT screen to view accurate remaining battery life.
Refer to the SHOGUN CONNECT User Manual for more
information.
Important
WARNING - Do not obstruct ventilation
When mounting and during use take care not to obstruct the
device ventilation at the top of the SHOGUN CONNECT unit.
ATOMOS Support
Download User Manual, technical specifications and firmware
updates, calibrate devices, supported cameras and media
atomos.com/support
my.atomos.com
Activate codecs/features for registered products, learn from
tutorials and download user manuals and firmware updates.
my.atomos.com/account
Register for Extended 3 Year Warranty
Register your product and upload proof of purchase to extend
your warranty from 1 to 3 years from the date of purchase.
my.atomos.com/register
ATOMOS Academy
Discover how ATOMOS products enhance
your filmmaking and content creation
atomos.com/academy

a. RF Antenna
Connect the supplied RF antenna for AirGlu™ wireless
SYNC functionality.
b. Tally Light
Red Tally light on the rear of the unit indicates active
recording.
c. Battery Slot
Attach NP-F / L-Series type batteries to supply power
in the eld.
d. WiFi Antennas
Connect the supplied WiFi antennas in this position. Wi-Fi
6 provides a high performance wireless connection and
mobile hotspot support for connection.
e. Battery Release
Press and slide batteries away from the unit to remove them.
f. Media Slot
Compatible with Master Caddy II, III, AtomX SSDmini,
AtomX CFast Adapter.
g. DC Power Connector
Connect the supplied DC power supply to the DC jack for
mains power.
h. 12G SDI In/Out
Connectors are 12G SDI compliant and backwards
compatible.
i. 4K HDMI In/Out
The 4K HDMI input provides for recording from HDMI
sources. The 4K HDMI Output provides a live loop out or
play-out in Playback mode.
j. USB-C
For future expanded functionality.
k. RJ45 Ethernet Port
1Gbe Ethernet for a high-speed robust hardwired network
connection.
l. On/O + Screen Lock
Press to power the unit on. Hold the button for at least 4
seconds to power off. Tap to lock/unlock the screen.
m. Mic/Line In
3.5mm input Jack, used to connect Microphone or Line
audio sources
n. Headphone/Audio Out
3.5mm output jack, used for the connection of
headphones. Can also be used for analogue audio out.
o. Remote Control/LANC and Calibration
Allows for remote camera control of supported cameras
with the optional USB-C to serial cable (ATOMCAB018)
and LANC control with a Y cable. The Calibrite
ColorChecker Display Pro /Display Plus can also be
connected for display calibration with the optional USB to
serial cable serial cable (ATOMCAB004).
Physical features
IN 12G OUT 12G IN 4K OUT 4K USB
6.2-16.8V
45W
REMOTE
MIC/LINE
SHOGUN
Physical features
h. 12G SDI
In/Out
i. 4K HDMI
In/Out
k. RJ45
Ethernet
Port
j. USB-C
l. On/Off +
Screen lock
m. 3.5mm Mic/Line in
n. 3.5mm Headphone/
Audio out
o. Remote/LANC
Calibration Port
f. Media Slot
e. Battery
release
g. DC Power
Connector
a. RF Antenna
d. WiFi Antennas
c. Battery Slot
b. Tally light
WiFi Antenna
mounting points
RF Antenna
3/8” screw mount
point with 1/4” adapter
(top and bottom)
Ventilation
TOP
BACK SIDE

Warranty & Conditions CONT.Safety Instructions
Your ATOMOS product has been designed to a high standard, but there
Your ATOMOS product has been designed to a high standard, but there
are some things you should be aware of that will prolong the life of the unit
and for your own safety.
Using your ATOMOS product safely
Although your ATOMOS product is very lightweight compared to all
the devices it replaces, it is still a solid object that could cause injury if
misused.
• Always make sure that your ATOMOS product is mounted securely and
is unable to fall onto anyone nearby. This is especially important when
there are children present who might be tempted to pull on cables.
• Always ensure that cables that run to your ATOMOS product are clearly
visible and do not present a trip hazard.
• Do not place on uneven or unstable surfaces.
• Do not insert anything but a Master Caddy III, AtomX SSDmini or CFast
II adapter in the drive slot on the rear of your ATOMOS product.
• Do not touch the screen with sharp, metallic or abrasive objects.
• Do not expose to strong electrical or magnetic elds.
• Do not expose to liquids, rain or moisture.
• Do not dispose of your ATOMOS product in municipal waste and do not
incinerate it, always follow local regulations for safe disposal.
Notifications
Contains FCC ID: PD9AX210NG | AYV-AGLU02
Contains IC ID:1000M-AX210NG | 10427A-AGLU02
USA
WARNING: This product contains the chemical lead (Pb) which is known
to the State of California to cause cancer.
For more information, visit p65warnings.ca.gov
CAUTION: Regulations of the FCC and FAA prohibit airborne operation
of radio-frequency wireless devices because their signals could interfere
with critical aircraft instruments.
Warranty & Conditions
Notice
Copyright © 2022 ATOMOS Limited (‘referred to as ATOMOS’). All rights
reserved. All information in this document is subject to change without
notice. No part of the document may be reproduced or transmitted in any
form, or by any means, electronic or mechanical, including photocopying
or recording, without the express written permission of ATOMOS. A
reference to ATOMOS includes its related entities, subsidiaries and parent
company.
Trademarks
ATOMOS, SHOGUN CONNECT and AirGlu are registered trademarks of
ATOMOS. All other trademarks are the property of their respective holders.
International Hardware Limited Warranty
(1 Year Standard/3 Years if registered)
ATOMOS warrants that:
• The main product, not including the IPS screen, or any external accessories,
will be free from defects in materials and workmanship for a period of 1 year
from the date of purchase; or 3 years upon completion of product registration
within 1 year from the date of purchase at my.atomos.com
• The TFT/LCD, batteries, case and master caddies will be free from defects in
materials and workmanship for a period of 1 year from the date of purchase
regardless of registration. This warranty is exclusively for the benet of the
original purchaser and is not assignable or transferable.
If during the warranty period the product is shown to be defective
ATOMOS may at its option:
a) replace the goods or supply equivalent ones, b) repair the goods, c) pay
the cost of replacing the goods or of acquiring equivalent ones and d)paying
the cost of having the goods repaired; The customer must notify ATOMOS
of any defect in the goods in writing prior to the expiry of the warranty
periods set out above. The customer will be solely responsible for returning
the goods to ATOMOS or its authorized distributor. Upon acceptance of a
warranty claim by ATOMOS, where ATOMOS repairs or replaces the goods,
it will be responsible for reasonable shipping costs incurred in sending the
goods to the Customer, provided that customer is located in a country in
which ATOMOS has an authorized distributor or repair center or agent.
Warranty Exclusions
This warranty applies only to defects in workmanship and does not cover
defects caused by:
• A failure to comply with the then current operating instructions issued by
ATOMOS;
• Neglect;
• Improper or negligent acts or omissions;
• Unauthorized repairs or attempted repairs;
• Tampering with or modication of the goods;
• Connection to incompatible equipment or power sources;
• Exposure to water or weather;
• Exposure to magnetic elds or corrosive liquids or substances;
EXCEPT AS STATED IN THIS WARRANTY, ATOMOS, IT’S VENDORS,
AGENTS, RESELLERS AND DISTRIBUTORS DISCLAIM IN THEIR
ENTIRETY ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION ALL WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THE REMEDIES OUTLINED
IN THIS WARRANTY ARE THE EXCLUSIVE REMEDY A CUSTOMER HAS
ARISING FROM DEFECTIVE GOODS WHICH ARE SUBJECT TO THE
WARRANTY. ATOMOS DOES NOT WARRANT THAT THE GOODS WILL
OPERATE IN A MANNER WHICH IS ERROR FREE, OR UNINTERRUPTED.
THE GOODS ARE NOT INTENDED TO BE THE PRIMARY OR ONLY
DATA STORAGE DEVICE FOR DATA – CUSTOMERS ARE SOLELY
RESPONSIBLE FOR BACK UP AND PROTECTION OF DATA.
Software License Agreement
IMPORTANT, PLEASE READ CAREFULLY. THIS IS A LICENSE AGREEMENT.
This ATOMOS software, related documentation, any included sample images
and other les (the “Software”), is protected by copyright laws and international
copyright treaties, as well as other intellectual property laws and treaties. The
Software is licensed, not sold.
This End User License Agreement (“EULA”) is a legal agreement between
you (either an individual or a single entity) and ATOMOS with regard to the
copyrighted Software provided with this EULA. Use of the Software provided to
you by ATOMOS in whatever form or media, will constitute your acceptance of
these terms, unless separate terms are provided by the software supplier, in which
case certain additional or different terms may apply. If you do not agree with the
terms of this EULA, do not download, install copy or use the Software. By installing,
copying or otherwise using the Software, you agree to be bound to the terms of
this EULA. If you do not agree to the terms of this EULA, ATOMOS is unwilling to
license the Software to you.
1. Eligible licensees. This Software is available for license solely to purchasers of
the ATOMOS product, who have purchased a unit manufactured by ATOMOS
and purchased through an ATOMOS authorized reseller, with no right of
duplication or further distribution, licensing or sub-licensing.
2. License Grant. ATOMOS grants you a personal, non-transferable and
non-exclusive right to use the copy of the Software provided with this EULA.
You agree you will not copy the Software except as necessary to use it with
the ATOMOS product. You agree that you may not copy the written materials
accompanying the Software. Modifying, reverse engineering, translating, renting,
copying, transferring or assigning all or part of the Software or any rights granted
hereunder, to any other persons or reverse engineering the hardware on which
the Software runs, is strictly prohibited. The software is license, not sold. You
acknowledge that no title to intellectual property in the Software is transferable to
you. You further acknowledge that title and full ownership rights to the Software will
remain the exclusive property of ATOMOS and/ or its suppliers, and you will not
acquire any rights to the Software, except as expressly set forth above. All copies
of the software will contain the same proprietary notices as contained in or on the
Software. All title and copyrights in and to the Software (including but not limited
to any images, animations, video, audio, text incorporated), the accompanying
printed materials, and any copies of the Software are owned by ATOMOS or its
suppliers.
3. Reverse engineering. You agree that you will not attempt, and if you are
a corporation, you will use your best efforts to prevent your employees and
contractors from attempting to reverse compile, derive circuits, modify, translate
or disassemble the Software and/or the ATOMOS product in whole or in part.
Any failure to comply with the above or any other terms and conditions contained
herein will result in the automatic termination of this license and the reversion of the
rights granted hereunder by ATOMOS.
ATOMOS reserves the right to terminate this license without prejudice to
any additional recourse ATOMOS may have against you if you violate any
of its terms and conditions.

© ATOMOS 2022. TM ® All trademarks and registered trademarks are the property of their respective owners.
GET STARTED
my.atomos.com
