ATOMSTACK MR 20 User manual

ATOMSTACK MR 20
F03-0198-0AA1 Version: A
Note: The picture is for reference only, the actual product shall prevail.
For more information, please scan the QR code
English

Packing List
Laser module TYPE-C data cable Laser signal cable Power cable Z-axis component
Laser slider Knurled screws 2PCS (M4*12) Screws 8PCS (M4X6) Screws 2PCS (M5X8) Screws 4PCS (M4X10)
Allen wrench Control box T-nut 2PCS Instruction manual
ATOMSTACK MR 20
F03-0198-0AA1Version: A
Note: The picture is for reference only,the actual product shall prevail.
For more information, please scan the QR code
English
1
H2
H2.5
H3

Step 1 Connect the Z-Axis and Slider to the Machine
Option 1 Connect the Z-axis and slider to the machine from the back.
1
2
M4*10

Tighten the screws
Precautions:
Do not fold the fiber optic cable
behind the laser.
2
3
3
M4*6

Connect the Z-axis and slider to the machine from the front.
Rotate the handle to
move the slider.
Option 2
1
4
M4*6

Tighten the screws
Precautions:Do not fold the fiber optic
cable behind the laser.
2
3
5
M4*6

This type of Z-axis does not require replacement and can be inserted
directly into the laser head.
Tighten the screws
Option 3
6

Step 2 Replace the control box
7
Tighten the screws
Don't overtighten it
Remove the original control box and cable Install the control box in the manifest
Install the control box in the manifest Install the T-nut
M5*8
M5*8
The trial installation control box is paired with the hole position before the type, and the control box is directly installed.
The trial control box is not matched with the hole position in front of the type, and it is necessary to wear a T-nut and
lock two M5*8 screws.
Method 1
Method 2

Step 3 Connecting cables
8
2
1
4
5
67 8
3
Control line
Type-C data cable
Laser signal cable
2
1
4
5
6
7
8
3
Note:
To use the original laser
head, there is no need to
disassemble the control box
again. Simply connect these
two wires together.

Step 4 Test Process - Power On
1. Turn on the machine power switch
2. Focus Adjustment
1) Position the test material on the machine.
2) Observe whether the red light spots at the left and right ends of the laser head overlap. If not, adjust the height by rotating the
knob on the Z-axis to make the two spots coincide.
First turn on the power switch of the machine, and then turn on the switch of the fiber laser control box to avoid the
probability of random emission for about 2 seconds after power-up.
9
√×

3.Laser Frequency Adjustment
Step 5 Testing Process - Use on PC
1) When using Lightburn for online or offline engraving of images and pattern filling, it is recommended to enable overscanning for
better engraving results.
The frequency of the control box can be adjusted from 30kHz to 60kHz. Refer to the parameter table for adjustments.(pp. 16-19)
10
1
2
3
4

2) Refer to the machine's user manual for instructions on how to use Lightburn. The only difference is in the framing process. For
framing in Lightburn, select "Move" > "Power" and set it to 0. You can monitor the framing process through the red light indicator.
3) Refer to the machine's user manual for instructions on how to use LaserGRBL. The only difference is in the framing process. When
performing framing in LaserGRBL, the framing energy needs to be changed to 0.
1.Right-click Frame and click Edit button.
2.Set to S0
3.Save
11
1
2

Step 6 Testing Process - Offline Use of K1 Machine
1) When using a blue laser offline with lightburn, click on "Edit" and select "Machine Settings." Change the PWM min value
($35) from 0 to 1. Note that $35 of FL20 should be set to 0 and that of blue laser should be set to 1.
2) When using a blue laser offline with GRBL, click on "Grbl" and select "Grbl Configuration." Change the $35 value from 0 to 1.
Note that $35 of FL20 should be set to 0 and that of blue laser should be set to 1.
12
1
1
2
2
3
3

Step 7 Testing Process - Offline Use of A40 Pro Machine
1) When using a blue laser offline with lightburn, click on "Edit" and select "Machine Settings." Change the PWM min value
($35) from 0 to 1. Note that $35 of FL20 should be set to 0 and that of blue laser should be set to 1.
2) When using a blue laser offline with GRBL, click on "Grbl" and select "Grbl Configuration." Change the $35 value from 0 to 1.
Note that $35 of FL20 should be set to 0 and that of blue laser should be set to 1.
13
1
1
2
2
3
3

Step 8 Testing Process-Offline use without machine
shipment
1) lightburn: When using a blue laser offline, click on "Edit" and select "Machine Settings." Change the PWM min value ($60)
from 0 to 1. Note that $60 of FL20 should be set to 0 and that of blue laser should be set to 1.
2) GRBL: When using a blue laser offline, click on "Grbl" and select "Grbl Configuration." Change the $60 value from 0 to 1.
Note that $60 of FL20 should be set to 0 and that of blue laser should be set to 1.
14
1
2
3

Step 9 FAQ
3. lightburn Engraving power settings : Power Max(%) > 10%, refer to the parameter table for specific values.
Please note: Engraving vector mode should be set to "M3 mode". Follow the steps below to operate: "Cuts / Layers" ->
"Line" -> "Constant Power Mode".
1) If the engraving or cutting effect is not satisfactory:
a) Check if the laser is in the focal position.
b) Check the cleanliness of the lens.
2) If there is a malfunction with the red light indicator and it is inconvenient to check the focal distance through
overlapping red lights, you can adjust the focal distance through fixed focus method (distance from laser end face to
the measured object: 96.1mm/94.1mm).
3) If there are no traces or uneven energy in the engraved vector lines:
a) Check if the laser is in the focal position.
b) Confirm if it is operating in M3 constant power mode.
15
2
1
3

16
Remark：
1.Our parameter list is only for the most widely used materials. Customers may need to try other uncommon materials
by themselves, or they can contact us to apply for testing.
2.Line mode for vector lines requires M3 mode
Engraving Parameter for Common Material
Material
Engraving
Quality Speed
（mm/m）Max-Power Frequency （KHz）Image Mode Needs to be blackened Case illustration
Copper 100 7000 800 30 Threshold NO
Iron 100 5000 800 30 Threshold NO
Natural color
alumina 100 10000 800 30 Threshold NO
Coated alumina 100 7000 800 30 Threshold NO
Brushed Stainless
Steel 100 5000 500 30 Threshold NO

17
Coated alumina 100 7000 800 30 Threshold NO
Brushed Stainless
Steel 100 5000 500 30 Threshold NO
Mirror Stainless
Steel 100 6000 800 40 Threshold NO
painted furniture 100 10000 600 30 Threshold NO
ABS 100 10000 400 30 Threshold NO
Plastic 100 15000 800 30 Threshold NO
Remark：
1.Our parameter list is only for the most widely used materials. Customers may need to try other uncommon materials
by themselves, or they can contact us to apply for testing.
2.Line mode for vector lines requires M3 mode
Engraving Parameter for Common Material
Material
Engraving
Quality Speed
（mm/m）Max-Power Frequency （KHz）Image Mode Needs to be blackened Case illustration
Copper 100 7000 800 30 Threshold NO
Iron 100 5000 800 30 Threshold NO
Natural color
alumina 100 10000 800 30 Threshold NO

18
Material
Engraving
Quality Speed
（mm/m）Max-Power Frequency （KHz）Image Mode Needs to be blackened Case illustration
Leather 100 10000 700 30 Threshold NO
Acrylic 100 13000 700 30 Threshold NO
Rubber 100 6000 600 30 Threshold NO
Oil painting
paper 100 12000 700 30 Threshold NO
Rock 100 15000 800 30 Threshold NO
Mirrors 100 12000 500 30 Threshold YES
Ceramic tile 100 5000 800 30 Threshold YES
Cutting Parameter for Common Material
Material
Cutting
Thickness
（mm）
Speed
（mm/m）
Max-Power Frequency
（KHz）
Number of
passes
Needs to be
blackened
Case illustration

19
Ceramic tile 100 5000 800 30 Threshold YES
