ATON CL108 User manual

1
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Overview.fm / 23.07.2008
Aton CL108 handset
V
11.12. 11:56
INT MENU
1 Charge status of
the batteries
2Ecomode+
3Displaykeys
4Messagekey
Flashes: new messages
received
5 Handsfree key
6 Control key (u)
7Talkkey
8Directorykey
(press down on
the control key)
9 End call key and
On/Off key
10 Ringer tone on/off
(press and hold in
idle status)
11 Keypad lock on/off
(press and hold)
12 Recall key
- Consultation call
(flash)
- Dialling pause
(press and hold)
13 Microphone
14 "Microphone off" key
11
3
5
7
4
6
9
13
1
12
14
8
10
Display keys:
Pressing a key launches the function that
appears above that key in the display.
Display Function when pressed
INT Call other registered
handsets ¢page 7.
MENU Open main/submenu (see
Menu tree ¢page 11).
“ Go back one menu level.
UScroll up/down or adjust
volume with u.
T Move cursor to left/right
with u.
˜Backspace deletes one
character at a time.
OK Confirm menu function or
save entry.
Environmental benefits of the Aton CL108
The Aton CL108 has a low level of energy consumption and reduces radiation.
Reduced power consumption
Your telephone has a power-saving adapter plug and uses 60% less power than standard devices. Power
consumption in standby mode is approx. 1.3 watt.
Minimal radiation
The Aton CL108 with its preset Eco mode+ switches off all radiation when in idle status. During a call,
the handset reduces the transmission power according to the distance from the base station.
In addition, you also have the option of further reducing the transmission power of your Aton CL108
during a call by reducing the range.
For further information, please see your phone's user guide.
2

2
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Overview.fm / 23.07.2008
Safety precautions
Emergency numbers cannot be dialled if the keypad lock
(¢page 1) is activated!
Not all of the functions described in this user guide are
available in all countries.
Care
Wipe the charging cradle and the handset with a
damp cloth (do not use solvent) or an antistatic
cloth. Never use a dry cloth. This can cause static.
Contact with liquid
If the handset should come into contact with liq-
uid:
◆Switch the handset off and remove the bat-
teries immediately.
◆Allow the liquid to drain from the handset.
◆Pat all parts dry, then with the battery compart-
ment open and the keypad facing down place
the handset in a dry, warm place for at least
72 hours (not in a microwave, oven etc.).
◆Do not switch on the handset again until it is
completely dry.
When it has fully dried out, you will normally be
able to use it again.
Read this user guide and the safety precautions carefully
before use. Explain their contents and the potential haz-
ards associated with using the telephone to your chil-
dren.
Only use the mains unit supplied.
Fit only the recommended, rechargeable
batteries (¢page 9), i.e. never use a
conventional (non-rechargeable) battery or
other battery types as this could result in
significant health risks and personal injury.
The operation of medical appliances may be
affected. Be aware of the technical conditions in
your particular environment, e.g. doctor's sur-
gery.
Do not hold the rear of the handset to your ear
when it is ringing. Otherwise you risk serious
and permanent damage to your hearing.
The handset may cause an unpleasant hum-
ming noise in hearing aids.
Do not install the phone in a bathroom or
shower room. The phone is not splashproof.
Do not use your phone in environments with a
potential explosion hazard, e.g. paint shops.
If you give your phone to someone else, make
sure you also give them the user guide.
Information about disposal
At the end of its service life, this product must
not be disposed of with normal household
waste, but must be handed in at the place of
purchase or at a collection point for recycling
electrical and electronic devices in accordance
with the ordinance governing the return,
acceptance and disposal of electrical and elec-
tronic equipment (VREG).
The materials can be recycled according to their
identification. By reusing and recycling materi-
als along with other methods of recycling used
equipment, you can make an important contri-
bution to protecting the environment.
$
ƒ
!

Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Version 4, / starting.fm / 23.07.2008
3
First steps
Check the pack contents
◆One handset,
◆one charging cradle,
◆one mains adapter,
◆two batteries,
◆one battery cover,
◆one user guide (German, French, Italian),
◆Environmental leaflet (Swisscom).
Setting up the charging cradle
The charging cradle is designed to be operated in enclosed, dry areas at temperatures
ranging from +5 °C to +45 °C.
¤Place the charging cradle on a level, non-slip surface.
The phone's feet do not usually leave any marks on surfaces. However, due to the multi-
tude of different varnishes and polishes used on today's furnishings, the occurrence of
marks on the surfaces cannot be completely ruled out.
Please note:
◆Never expose the telephone to the influence of heat sources, direct sunlight or other
electrical devices.
◆Protect your telephone from moisture, dust, corrosive liquids and vapours.
Connecting the charging cradle
Please note
Pay attention to the range of the base station.
This is up to 250 m in unobstructed outdoor areas and up to 40 m inside buildings.
The range is reduced when Eco Mode is activated (¢page 1).
1
2
1
2
¤Connect the flat plug from
the power supply 1.
¤Plug the mains adapter into
the plug socket 2.
If you need to disconnect the plug from the charging cradle,
press the release button 1and disconnect the plug 2.

Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Version 4, / starting.fm / 23.07.2008
4
Setting up the handset for use
The display is protected by a plastic film.
Please remove the protective film!
Inserting the batteries and closing the battery cover
Warning
Use only the rechargeable batteries (¢page 9). Never use a conventional (non-
rechargeable) battery or other battery types as this could result in significant health
risks and personal injury. For example, the outer casing of the batteries could be
destroyed or the batteries could explode. The phone could also malfunction or be
damaged as a result of using batteries that are not of the recommended type.
¤Insert the batteries the right
way round.
The polarity is indicated in/on
the battery compartment.
¤First insert the battery cover at
the top a.
¤Then press the cover buntil it
clicks into place.
If you need to open the battery cover,
f
or instance to replace the batteries,
place your fingertip in the cavity on the
casing and pull the battery cover
upwards.
a
b

Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Version 4, / starting.fm / 23.07.2008
5
Registering the handset to the base station
Before you can use the phone, you must first register the handset to the base station.
The actual registration procedure will depend on the type of base station.
Automatically register the handset to the Aton CL108 base station
Manually registering the handset
You must activate manual registration of the handset on both the handset and the
base station.
1. On the handset: MENU ¢Settings ¢OK ¢Handset ¢OK ¢Register HS
¢Enter the base station system PIN (default setting: 0000) ¢OK.
2. On the base station: Within 60 sec. of entering the system PIN, press and hold the reg-
istration/paging key (min. 3 sec.). See also the user guide belonging to the base station.
After successful automatic or manual registration, the idle display is shown:
The handset is assigned the lowest unassigned internal number (1–4). If more than one
handset is registered to the base station, the internal handset number appears in the top
left of the display, e.g. 2. If the internal numbers 1–4 are already assigned to other
devices, the number 4 will be overwritten.
Please note
Only place the handset in the base station or charging cradle that is intended for it.
V
Registering
The handset registers automatically.
Registration can take up to 5 minutes.
Do not remove the handset from the
base station during this time.
V
Put into base
MENU
¤Place the handset with
the display facing up in
the base station.
V
Registering
The registration screen is displayed.
V
INT MENU
Charge status of the batteries:
–= e V U(flat to full)
–=flashes: batteries almost flat
–e V Uflashes: charging

Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / Version 4, / starting.fm / 23.07.2008
6
Initial charging and discharging of the batteries
The correct charge level can only be displayed if the batteries are first fully charged and
discharged.
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming calls,
and so that the alarm can be used.
MENU ¢Settings ¢OK ¢Date/Time ¢OK
¢Date: ¢~(enter the day, month and year in 6-digit format) ¢OK
¢Time: ¢~(enter hours and minutes in 4-digit format) ¢OK (display message: Saved)
¢a(press and hold to return to idle status)
Display in idle status
Once the phone is registered and the time set, the idle dis-
play is shown as in this example.
Activating/deactivating the handset
Press and hold the akey to activate or deactivate the handset.
If you place a deactivated handset in the base station or charging cradle, it will automat-
ically activate.
Your phone is now ready for use!
If you have any questions about using your phone, please read the tips on troubleshooting
("Faults and self-help with troubleshooting" ¢page 9) or contact our Customer Care
team ¢page 10.
Please note
◆After the first battery charge and discharge you may replace your handset in its
base station or charging cradle after every call.
◆Always repeat the charging and discharging procedure if you remove the batteries
from the handset and reinsert them.
◆The batteries may warm up during charging. This is not dangerous.
◆After a while, the charge capacity of the batteries will decrease for technical rea-
sons.
Please note
When entering the time and date, you can move the position of an entry to the left
or right by pressing the control button up or down. When you receive an incoming
call, the date and time are automatically updated by the network.
¤Place the handset in the base station or charging cradle for eight hours.
¤Then remove the handset from the base station or charging cradle and
do not replace it until the batteries are completely discharged.
8h
V
11.12. 11:56
INT MENU

7
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / main.fm / 23.07.2008
Making calls
Making external calls and ending calls
External calls are calls using the public telephone
network.
~(Enter the phone number) ¢c.
The phone number is dialled. (Or you can first
press and hold c[dial tone] and then enter the
number.) During the call you can adjust the ear-
piece volume using tand set the volume with u.
End the call/cancel dialling:
Press the end call key a.
Accepting a call
The handset indicates an incoming call by ringing
and by a display on the screen.
Press the talk key cto accept the call.
When Auto Answer is activated (see Menu tree
¢page 11), simply remove the handset from the
base station/charging cradle.
In idle status, use tto activate the menu for set-
ting the call volume and use uto set the volume.
Muting
You can mute your handset when making external
calls. Your caller can no longer hear you.
Press the "Microphone off" key during the call to
activate/deactivate the function.
Handsfree
To activate while dialling:
Enter the number ~and press the handsfree key
d.
Switching between earpiece and handsfree
mode:
During a call and press the handsfree key dto acti-
vate or deactivate handsfree talking.
During a call, use tto activate the menu for set-
ting the handsfree volume and use uto set the
volume.
Making internal calls
Internal calls are free calls to other handsets that
are registered to the same base station.
To make a call to other handsets, press
◆INT ¢~(1...4, enter internal number of the
handset) ¢OK, the handset is called or
◆INT ¢star key P¢OK, all handsets are
called.
When a participant answers you can speak to
them. To end the call, press a.
Using the directory and lists
Directory
"Swisscom Hotline"
The first entry in the directory is pre-programmed
as the Hotline with the access number 0800 800
800. The entry can be edited and the setting
remains unchanged if the device is reset or there
is a power failure.
To open the directory: press h.
You can save up to 140 phone numbers
(max. 32 digits) with corresponding names
(max. 14 characters). Enter letters/characters
¢page 9.
Saving the second number in the directory
h¢New Entry? ¢OK
¢~(enter number) ¢OK
¢~ (enter number) ¢OK
Storing a number in the directory
h¢MENU ¢New Entry ¢OK
¢~(enter number) ¢OK
¢~ (enter number) ¢OK
Selecting a directory entry
Open the directory with h.You have the following
options:
◆Use uto scroll through the entries until the
required name is selected.
◆Enter the first character of the name and scroll
to the entry with u, if required.
Dialling with the directory
h¢u (select entry) ¢c
Using other functions
h¢u(select entry) ¢MENU
Please note:
Swisscom Contact Center 0800 800 800
If you need assistance, do not hesitate to call our
freephone number for telecommunication:
fixed network, mobile, broadband DSL, Bluewin TV,
questions relating to billing and much more.

8
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / main.fm / 23.07.2008
The following functions can be selected with u:
Using shortcut keys
You can assign directory entries to the keys 0 and
2–9:
h¢u(select entry) ¢MENU ¢Shortcut ¢OK
¢~(press the key you want to assign the entry to)
To dial, press and hold the required shortcut key.
Sending the directory to another handset
Preconditions:
◆The sending and receiving handsets must both
be registered to the same base station.
◆The other handset and the base station can
send and receive directory entries.
h¢u (select entry) ¢MENU ¢Send Entry /
Send List ¢OK ¢~(enter the internal number of
the receiving handset) ¢OK
Last number redial list
This list contains the ten last dialled numbers.
Dialling from the last number redial list
c(press briefly) ¢u (select entry) ¢c
Managing entries in the last number redial list
c(press briefly) ¢u (select entry) ¢MENU
You can select the following settings:
Opening lists with the message key
An advisory tone sounds and the message key
flashes as soon as a new entry appears in a list.
Amessage appears in the display.
If you press the message key f, you will see all
lists that contain new messages. If only one list
contains new messages, this will be opened auto-
matically.
Setting the alarm clock
Activating/deactivating the alarm clock
MENU ¢Alarm Clock ¢OK ¢Activation
¢OK (‰= on)
When activated:
¢Set the wake-up time ¢OK
When the alarm clock rings, press any key to switch
it off for 24 hours. If the alarm clock is set, the
wake-up icon 9will appear on the screen and the
wake-up time will be displayed instead of the date.
Setting the wake-up time
MENU ¢Alarm Clock ¢OK ¢Wake-up time ¢OK
Enter the wake-up time in hours and minutes, then
press OK.
Phone settings
For details on how to make audio settings, see
Menu tree ¢page 11.
Changing the display language
MENU ¢Settings ¢OK ¢Handset ¢OK
¢Language ¢OK ¢select the language ¢OK
The current language is indicated by ‰.
If you accidentally choose a language you do not
understand:
MENU ¢4 21 (press the keys one after the other)
Select the correct language with uand press OK.
Resetting the handset
You can reset individual settings and changes that
you have made. Entries in the directory, the calls
list and the handset's registration to the base sta-
tion will be retained.
MENU ¢Settings ¢OK ¢Handset ¢OK
¢Reset Handset ¢OK
Cancel the reset with a.
New Entry Save new phone number.
Show Number Display the phone number.
Use Number Edit or add to the number.
Then dial or use other functions
with MENU.
Edit Entry Edit selected entry.
Delete Entry Delete selected entry.
Send Entry Send a single entry to another
handset (¢page 8).
Delete List Delete all directory entries.
Send List Send the complete list to
another handset (¢page 8).
Shortcut For shortcuts, assign the cur-
rent entry to a key.
Use Number Edit or add to the number.
Then dial or use other functions
with MENU.
Copy to Dir. Copy an entry to the directory.
Delete Entry Delete selected entry.
Delete List Delete all entries.

9
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / main.fm / 23.07.2008
Appendix
Entering letters/characters
Press the required key the number of times indi-
cated.
Briefly press the hash key #to switch from
"Abc" to "123" mode, from "123" to "abc"mode and
from "abc" to "Abc" mode.
Standard characters
1) Space
Specifications
Recommended batteries
Technology: Nickel-metal-hydride (NiMH)
Size: AAA (Micro, HR03)
Voltage: 1.2 V
Capacity: 400–800 mAh
We recommend the following types of battery:
◆GP 550/700 mAh
◆Yuasa Phone 700/800 mAh
◆Peacebay 550/650 mAh
(Valid at the time of going to press)
The handset is supplied with recommended
batteries.
General specifications
Faults and self-help with
troubleshooting
Not every problem signifies a fault in your tele-
phone. In some cases, problems can be resolved by
briefly interrupting the power supply to the base
station (unplug the power supply unit and then
plug it in again) or removing the battery cells from
the handset and reinserting them. The following
information is designed to help you with specific
problems.
Important: Some problems or faults can only be
resolved if you take the complete device (base sta-
tion, handset and connection cable) to the place of
purchase.
1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x
11£$¥¤
2a b c 2 ä á à â ã ç
Id e f 3 ë é è ê
4gh i 4 ï í ì î
5j k l 5
Lm n o 6 ö ñ ó ò ô õ
Mp q r s 7 ß
Nt u v 8 ü ú ù û
Ow x y z 9 ÿ ý æ ø å
Q. , ? ! 0 + - : ¿ ¡ " ’ ; _
P* / ( ) < = > %
#Abc
-->
123
123
-->
abc # @ \ & §
DECT standard is supported
GAP standard is supported
Range up to 250 m outdoors
up to 40 m indoors
Environmental conditions
in operation
+5 °C to +45 °C, 20% to
75% relative humidity
1)
Problem Cause Solution
Nothing
appears in
the display.
The handset is
not switched on.
The batteries
are flat.
Press the end call key
afor approx.
5seconds or place
the handset in the
base station.
Charge or replace the
batteries.
No wireless
connection to
the base sta-
tion, Base
flashes in the
display.
The handset is
outside the range
of the base sta-
tion.
The handset is
not registered.
The base station
is not turned on.
Move the handset
closer to the base
station.
Register the handset
¢page 5.
Check the mains plug
on the base station.

10
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / main.fm / 23.07.2008
Warranty/Maintenance/Repair/
Approval
Warranty
The warranty period is 2 years as of the date of pur-
chase. For warranty repair, the warranty card, filled
out and stamped by the place of purchase must
accompany the faulty device. Excluded from the
warranty are damages due to improper use, wear
and tear or tampering by others. The warranty
does not include consumable materials and faults
that have only an insignificant affect on the value
or usability of the product. In case of errors, please
contact your place of purchase.
Repair/Maintenance
Rental devices
If your phone does not operate properly,
notify Technical Assistance (phone number
0800 800 800).
The repair*and the fault action are free of charge.
Purchased devices
Repair services are performed free of charge within
the warranty period in accordance with the regula-
tion of the warranty certificate. If a repair is neces-
sary, the device must be returned to the place of
purchase.
If Technical Assistance is made available (also dur-
ing the warranty period*)), the fault action is
charged (route lump sum price as well as expenses
for time). The repair costs are additional outside
the warranty period.
Batteries
Battery cells are considered consumed material,
which is not covered by the warranty service.
Faulty batteries are not replaced free of charge.
This applies to rented as well as purchased devices.
Help
If you have any general questions about products,
services etc., please contact your Swisscom
Information Centre (toll-free number
0800 800 800).
Approval
This device is intended for analogue telephone
connection in the Swiss network.
Country-specific requirements have been taken
into consideration.
Swisscom hereby declare that this device meets
the essential requirements and other relevant reg-
ulations laid down in Directive 1999/5/EC.
The Declaration of Conformity can be found on the
following website:
www.swisscom.com
under the heading "Online Shop", Telephones,
Conformity Declaration.
* An exception is damage to wearing parts (cable,
labels, batteries etc.) and due to improper handling
(damage from dropping, infiltrated fluids etc.).

11
Aton CL108 / Swisscom EN / A31008-M2054-F151-1-2X19 / main.fm / 23.07.2008
Menu tree
Your phone has a variety of features. These are
offered in the form of menus.
To select a function while the phone is in idle sta-
tus, press MENU (open menu), use the tand v
keys to scroll to the function you require and press
OK to confirm.
To return to idle status: press and hold the
akey.
As an alternative to selecting functions using the
tand vbuttons, you can also enter the digit
combination that is in front of the function in the
menu tree.
For setting the time and date, for example:
MENU ¢4 1 ¢OK
1Alarm Clock
1-1 Activation Activating/deactivating the alarm clock
1-2 Wake-up time Input format: HHMM
2Audio Settings
2-1 Handset Volume 2-1-1 Earpiece Can be set to one of 3 levels
2-1-2 Speaker Can be set to one of 5 levels
2-2 Ringer Volume 5 levels + "crescendo" available
2-3 Ringer Melody 2-3-1 External Calls 10 ringer tones available for external calls
2-3-2 Internal Calls 10 ringer tones available for internal calls
2-3-3 Alarm Clock 10 ringer tones available for alarm clock
2-4 Advis. Tones Activating/deactivating
2-5 Battery Low 2-5-1 Off Warning tone to indicate battery
is almost flat: never
2-5-2 On always
2-5-3 During Call only during a call
3Voice Mail (Menu dependent on base station)
4Settings
4-1 Date/Time Enter date (DDMMYY format), then time (HHMM format)
4-2 Handset 4-2-1 Language Set the display language ¢page 8
4-2-2 Auto Answer Automatically activate/deactivate auto answer ¢page 7
4-2-3 Register HS Manually register the handset ¢page 5
4-2-4 Reset Handset Reset the handset ¢page 8
4-3 Base (Menu dependent on base station)
