ATP Instrumentation THE1510 User manual

User’s Manual Mini Infrared Thermometer
1. Introduction
Congratulations on your purchase of our professional non-contact infrared thermometers.
These units can provide fast, easy and accurate temperature readings. With the non-contact (infrared) technology, they can
be used to measure the surface temperature of hard-to-reach objects like electrified equipment or moving objects, without
any damage or pollution to them.
2. Features
● Fast and easy measurement
●Precise non-contact measurement
●The built-in laser pointer increases the target accuracy
●Max/Min Record
●Backlight LCD display
●Automatic measurement range selection with resolution 0.1℃/℉
●Automatic trigger off
●Auto power off
3. Application
These units are widely used in Food preparation, Safety and Fire inspection, Plastic molding, Asphalt, Marine, Printing
ink and dryer temperature, Diesel and Fleet maintenance.
4. Safety
●Use extreme caution when the laser beam is turned on.
●Do not point the beam toward anyone or any animals.
●Do not allow the beam to strike the eye from a reflective surface.
●Do not use the laser near explosive gases.
Safety Symbol
Comply with EMC
5. Field of View
The meter's field of view is 13:1, for example, if the meter is
13 inches from the target spot, the diameter of the target must
be at least 1 inch. Other distance ratios are show below in the
field of view diagram.
6. Specifications
Range
-50～350℃;-58～662℉
-50～550℃;-58～1022℉
-50～850℃;-58～1562℉
Accuracy
-50℃～0℃: ±4 ℃
-50℃～0℃：±4 ℃
-50℃～0℃:±4 ℃
0℃～350℃：±2% ±2℃
0℃～550℃：±2% ±2℃
0℃～850℃：±2% ±2℃
Emissivity
fixed at 0.95
Optical Resolution
D:S=13:1
Resolution
0.1℃(0.1℉)
Spectral Response
8～14um
Polarity Display
Auto display, "-" indicates negative, while positive with no sign.
Diode Laser
Output＜1mW，630～670nm,class 2(Ⅱ)
Auto Power Off
Auto shuts off after 20 seconds inactivity
Operating Temp.
0℃to 50℃/ 32℉to 122℉
Storage Temp.
-20℃to 60℃/ -4℉to 140℉
Relative Humidity
Operating:10～95%RH,Storage:<80%RH
Power Supply
9V battery
Dimensions(L*W*H)
155.5*98.8*27.5mm
Weight
176g
7. Meter Description
A. Laser pointer beam B. IR Sensor
C. LCD Display D. ℃/℉Switch Button
E. MAX/MIN Button F. Laser Pointer/Backlit Button
G. Measurement Trigger H. Battery Compartment Cover
8. LCD Display Description
①Measurement Icon ②Data Hold Icon
③Emissivity Icon ④Backlit Icon
⑤Laser Icon ⑥Low Battery Indication
⑦Temperature Unit(℃/℉) ⑧Max/Min Record Reading
⑨Current Reading ⑩Max/Min Icon

9. Operating Instruction
A. Operating steps:
①Hold the meter by its handle grip and point it toward the surface to be measured.
②Pull and hold the Trigger to turn the meter on, the "SCAN" icon will appear and begin testing.
③The surface temperature being tested will be displayed on the LCD screen.
④Release the trigger, the "HOLD" icon will appear, and the reading will be hold for several seconds.
⑤The meter will automatically shut off after 20 seconds.
Measurement Note：
If the meter used in an ambient temperature with wide temperature change, allow it at least 30 minutes to adjust to it.
The laser is designed for aiming only; it can be shut off while operating in short distance to save the battery.
B. Button Function
①℃/℉button: In Measurement Mode, press button“ ”to switch the temperature unit ℃or ℉.
②Laser pointer/Backlight button: In Measurement Mode, press button“ ” to turn on/off backlight; In “HOLD”
Mode，press button“ ”to turn on/off laser pointer.
③During measuring，press button“ ”to display MAX/MIN readings.
C．Battery Replacement
①When the low battery icon“ ”appears, replace themeter's battery.
②Open the battery compartment, replace the 9V battery and close the battery
compartment cover.
10. Notes
(1) Work Principle
●The infrared thermometer is designed for measuring surface temperature of an object.
●The optical sensor can emit, reflect and transmit energy, which is collected and focused on a detector, then translate it
into the temperature reading by electronics and displayed on the LCD screen.
●The laser is used for aiming the target object only.
(2) Field of View
●The object under test should be larger than the spot size calculated by the field of view diagram.
●The smaller the target object is, the closer the meter should be to it for accurate measuring.
●When accuracy is critical, make sure the target is at least twice as large as the spot size.
(3) Distance & Spot Size
●As distance (D) from the object increases, the spot size (S) of the area measured by the unit becomes larger.
(4) Locating a hot spot
●To find a hot spot, first aim the thermometer to the outside of target area, then scan across in an up and down motion
until the hot spot is located.
(5) Notice
●Not recommend for measuring shiny or polished metal surfaces like stainless steel, aluminum, etc.
●Do not make measurement through transparent surface such as glass.
●If the surface of the object under test is covered with frost, oil, grime, etc., clean before taking measurement.
(6) Maintenance
●Do not use volatile liquids to clean the unit, swipe it with dry soft cloth.
●Do not disassemble the unit, repair it by qualified personnel
●Do not immerse it in water.
●Do not store it in high temperature or humidity.
11. Accessories
○
1 User's manual
○
2 9V Battery
