BABEI HT702 User manual

User Manual
Model:HT702
INFRARED BODY
THERMOMETER

User Manual
Please read these instructions carefully before
using the thermometer and keep it in a safe place.
Features
1 sec.Measurement
Fever alarm
Celsius Fahrenheit
Short beeps will sound when the
temperature is higher than 38.0℃
The Infrared Body Thermometer HT702 is a high
quality product incorporating the latest
technology and tested in accordance with
international standards.
The HT702 is intended for the periodic
measurement and monitoring of human body
temperature in the home.It is intended for use on
people of all ages.
Please read the
following instructions to achieve the most
accurate temperature and safe operation.
With proper care and use,your thermometer
will provide you reliable reading for many years.
And usually operated by
medical staffs, patient himself or his families. Not
used for life support or rescue. If the device is
invalid will not cause any accident, no need
special or emergency measures.
Infrared Body Thermometer
1

In order to enable you use the thermometer
safely and properly, and keep away from the
harm because of please note the
warning signs and symbols in the manual.
misusing,
Warning signs, symbols and their meaning
are explained as follows:
Casualties may occurred when misuse
Refer to instruction
Warning
Misuse may cause personal injury
or product damaged.
Note
No rain
Fragile
UP
Indicates is BF-type equipment.
Keep dry
Stand-by
Manufacturer
Authorised
Representative
In The European
Community
EC REP
Fragile,
Handle with care
This way up
European Union's Waste Electrical and Electric
Equipment in accordance with Article 11(2) of
Directive 2002/96/EC WEEE
To protect the environment, product must be
disposed at the definite places according to your
national or local regulations
2
Symbols
Safety Precautions

It is very dangerous if the patients make
self-judgement and treatment by means
of measuring results. So please be sure to
follow the doctor's guidance.
Self-judgement may worsen the illness.
The thermometer is only for
temperature. So don't use for other
parts ( such as in the Oral).
Forehead
& Ear
Otherwise, the thermometer will not
measure the body temperature, and it may
hurt the body.
When the infrared sensor is damaged or
dirty,it may cause incorrect measurement
results.
When the infrared sensor is dirty,please
wipe with soft and dry fabric gently.
Keep the thermometer in measure location
for 30 minutes before operation, if there is
big difference in temperature between
Otherwise may get incorrect measurement
results.
Please note the battery polarity when
replace the battery.
Otherwise it may cause leakage, heat,
rupture even damage the thermometer.
Don't take down, repair and reform
product by yourself.
Otherwise may get incorrect measurement
results.
Do not measure body temperature within
30 minutes after meal, sports or bath.
3
The operator not at the same time
contact battery and patients.
The front part of the thermometer
favorable angle, the operation that
should pay attention to scratch hand.
storage site and measuring site.
Warning

Keep the infrared body thermometer far
from the place which kid can touch.
The measure result can not be substituted
for the consultation from doctors.
Avoid keep product in place with direct
sunshine, high temperature, heavy humidity,
dust, close to the fire, easy shock and
vibration areas.
Please do not use the thermometer when
suffer electromagnetic interference.
4
Use of this IR thermometer is not intended
asa substitute for consultation with your
physician.
Important Note

Display
ambient
temperature
and time in
turn
5

Changing from Celsius to Fahrenheit
To toggle the measurement scale between
℃ or by pressing and holding the
SET button for 2 seconds
℉
(3 .3)
(3 .4 )
Remove the battery cover on the back and
then press the SET button.
While the hour or minute digit flashes,adjust
the current time by pressing the SCAN button.
When time has been set,the time and ambient
temperature will be shown in turn.
(Refer to the picture 3.3,3.4).
Set Time
Replacing the battery
Getting Started
(3.１)
(3.２)
If long time no use of this thermometer,
please remove the battery.
NOTE
This thermometer is supplied with
one lithium battery,type CR2032 .
Remove the battery cover by
sliding it in the direction shown.
Take out the battery and put a new
one.
(Refer to the picture 3.1 and 3.2)
If long time no use of this thermometer,please
remove the battery.
In order to protect the environment, please
send the waste batteries to the appropriate
collection points according to the national
or local laws.
Note:
Please properly dispose of the batteries away
from small children and heat.
6

(3.6)
How to measure ear temperature
Remove the probe cap,and
then “ ” icon will be display
on LCD.
Operating Guide
How to measure forehead temperature
Make sure the probe cap is on,
“ ” flashes on LCD,and press the
SCAN button to directly measure the
forehead temperature.
(Refer to picture3.5)
Put the tip of probe cap vertically
on one temple with certain force and
move it to other temple through
forehead.Release the SCAN button
and you have the right measurement.
(Refer to picture 3.5.1-3)
A long beep sound will emit to acknowledge the
completion of measurement.Read the recorded
temperature from the LCD display.
(3.5.3)
(3.5 .1)
(3.5.2)
When “ ” flashes, it means you can
measure the ear temperature now.
Straighten the ear canal by gently pulling
the middle of the ear back and up.
Insert the probe snugle into the ear canal
and press the SCAN button.Release the button
and wait for the beep sound.This is the
indication that confirms the end of measurement.
(Refer to the picture 3.6)
Remove the thermometer from the ear canal.
The LCD displays the measured temperature.
7
If the ear hole is small and difficult to
insert, please pull the ear back softly
(Adult:pull the ear upward softly;
Child:pull the ear downward softly),
Do not insert forcibly, and please
gently insert close to the ear.
Note:

Peng!
Precaution
Patients should not drink,eat,or exercise
before/while taking the measurement.
Never immerse this thermometer into
water or other liquids
Accumulation of ear wax on the
probe tip canresult in less
accurate temperature readings
cross infection between users.
Therefore,it is essential that a clean probe tip
is used before each measurement.
In order to assure the accurate
readings,please wait at least
30 seconds after continuous
measurements.
Use an alcohol swab or cotton tissue
moistened with alcohol to clean the
thermometer casing and the
measuring probe.
For accurate results,wait at least 30 minutes
after exercising,bathing or returning from the
outdoors.
Wait at least 1 minute between readings.
The measurement of forehead is equivalent
to the oral temperature.
Keep your forehead dry and clean as the
liquid(water or sweater)effects the measure
result.
Because everyone’s temperature varies
slightly,keep a record of your body temperature
to serve as a reference when judging a fever.
If multiple readings are taken over a short
period of time,use the average of those readings.
8
Helpful Hints

Specifications
Name： Infrared Body Thermometer
Model： HT702
DC3V(CR2032)
0.03W
Applied Part:
Measuring range：
Accuracy：
Function and intended usage:
Classification according to prevent electric shock:
type of internal power and B-type application part
Classification according to operation mode:
Continuous operation
Production classification:
Ear:
Forehead:
±0.2℃（35.0℃～42.0℃）
±0.3℃（<35.0℃ or ＞42.0℃)
±0.2℃（36.0℃～39.0℃）
±0.3℃（34.0℃～36.0℃&
39.0℃～42.1℃）
Measure temperature of ear,forehead
2 years
about 6000 times measuring) 1 year (
about 45g（with battery）
L46mm xW34mm xH122mm
+16℃～+35℃ ≤85%RH
700hpa～1060hpa
Transport/Storage
environment：
User's manual（with Product Guarantee）、
CR2032 battery 1pcs（already pre-loaded in the unit）
Battery
Any improvement on this product no need a
special notice
-20℃～+55℃ ≤95%RH
500hpa～1060hpa
Probe
34.0℃～42.1℃
Consumables：
Accessories：
Operation
environment：
Expected service life:
Power supply：
Power consumption：
Battery life：
Weight：
Dimension：
9

Free repair the thermometer within one
year since purchase date if proper use.
In the warranty period, if the unit is
failure, you may return it to the store you
purchased or our headquarters together
with this Product Guarantee.
The following situation can not be repaired
in free of charge:
Products damaged by misuse or the user
revise without factory permission in writing.
Products damaged by collide or drop.
Products damaged by force-majeure, such
as fire, earthquake, flood and other
abnormal natural disaster, public hazard,
abnormal voltage.
Products damaged by failure not follow the
instruction.
Remove or take away the series no and
reparation labels on products.
Consumables
Non-failure of the product itself
1.
2.
3.
Please take care of this Product
Guarantee.Will not issue one more if lose.
We repair the thermometer in free of charge
according to this Product Guarantee
direction. However, this guarantee do
not restrict customers legal rights.
4.
5.
Note:Manufacturer will provide circuit
diagrams, component part lists, descriptions,
calibration instructions to assist to nominated
service person in parts repair.
Service: must return to
manufacturers, by professionally trained
personnel to repair it.
Thermometer
10
Product Guarantee

Free repairing within one year since
purchase date if proper use.
In the request for warranty service, you
must have a seal of the purchase date
and place of purchase (including name
and address). Be sure to purchase this
product requires the clerk stamped on
this Guarantee.
1.
2.
Out of the warranty, repair service will
be charged.
Not reissue, please keep this warrantee
safely.
3.
Repair Card
Name：Infrared Body Thermometer
Item：
Purchase date：
Shop name:
Shop address：
Name：
HT702
Family address：
Telephone：
Shop stamp：
After-sale service
11
MIEO Product Guarantee

Table1-Guidance and MANUFACTURER’S declaration -ELECTROMAGNETIC
EMISSIONS-for all EQUIPMENT and SYSTEMS
Guidance and MANUFACTURER’S declaration -ELECTROMAGNETIC EMISSIONS
The [ EQUIPMENT or SYSTEM] uses RF
energy only for its internal function. Therefore,
its RF emissions are very low and are not likely to
cause any interference in nearby electronic
equipment.
The [ EQUIPMENT or SYSTEM] is intended for use in the electromagnetic environment
specified below.The customer or the user of the [ EQUIPMENT or SYSTEM] should assure that
it is used in such an environment.
Emissions test Compliance Electromagnetic environment – guidance
RF emissions
CISPR 11 Group 1
RF emissions
CISPR 11 Group 2
The [ EQUIPMENT or SYSTEM] must emit
electromagnetic energy in order to perform its
intended function. Nearby electronic equipment
may be affected.
RF emissions
CISPR 11 Class [A or B]
Harmonic emissions
IEC 61000-3-2
[Class A, B, C, D,
or Not applicable]
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
[Complies or Not
applicable]
Row
1
2
3
4
5
6
7
8
12

Emissions test Compliance Electromagnetic environment – guidance
[See 6.8.3.201 a)
3)and Figure 201]
[See 6.8.3.201 a)
3)and Figure 201]
[See 6.8.3.201 a)
3)and Figure 201]
The [ EQUIPMENT or SYSTEM] is suitable for
use in all establishments, including domestic
establishments and those directly connected to the
public lowvoltage power supply network that supplies
buildings used for domestic purposes.
The [ EQUIPMENT or SYSTEM] is suitable for use
in all establishments other than domestic, and may be
used in domestic establishments and those directly
connected to the public low-voltage power supply
network that supplies buildings used for domestic
purposes, provided the following warning is heeded:
Warning: This equipment/system is intended for
use by healthcare professionals only. This
equipment/ system may cause radio interference or
may disrupt the operation of nearby equipment. It
may be necessary to take mitigation measures,
such as re-orienting or relocating the
[ EQUIPMENT or SYSTEM] or shielding the
location.
The [ EQUIPMENT or SYSTEM] is suitable for use
in all establishments other than domestic and those
directly connected to the public low-voltage power
supply network that supplies buildings used for
domestic purposes.
RF emissions
CISPR 14-1 Complies The [ EQUIPMENT] is not suitable for interconnection
with other equipment.
RF emissions
CISPR 15 Complies The [ EQUIPMENT] is not suitable for interconnection
with other equipment.
9
10
11
12
13
Row
13

Table2-Guidance and MANUFACTURER’S declaration -electromagnetic
IMMUNITY-for all EQUIPMENT and SYSTEMS
Guidance and MANUFACTURER’S declaration -ELECTROMAGNETIC IMMUNITY
The [ EQUIPMENT or SYSTEM] is intended for use in the electromagnetic environment specified below. The
customer or the user of the [ EQUIPMENT or SYSTEM] should assure that it is used in such an environment.
IMMUNITY test IEC 60601
test level
Compliance
level
Electromagnetic environment –
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
NOTE Uis the a.c. mains voltage prior to application of the test level.
T
±6 kV contact
±8 kV air
±2 kV for power
supply lines
±1 kV for input/output
lines
±1 kV line(s) to
line(s)
±2 kV line(s) to
earth
<5 % UT
(>9 5 % dip in UT)
for 0,5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>9 5 % dip in UT)
for 5 s
3 A/m
A1
A1
A1
A1
Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material, the
relative humidity should be at least 30 %.
Mains power quality should be that of a
typical commercial or hospital
environment.
Mains power quality should be that of a
typical commercial or hospital
environment.
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the
[ EQUIPMENT or SYSTEM] requires
continued operation during power
mains interruptions, it is recommended
that the [ EQUIPMENT or SYSTEM]
be powered from an uninterruptible
power supply or a battery.
Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical commercial
or hospital environment.
14

EC REP
F.1,No. 788 Yijing Road, Economic Development Zone,
Shengzhou City,Zhejiang Prov.China
Babei Sapience Technology CO.,Ltd.
Shanghai International Holding Corp.GmbH(Europe)
Eiffestrasse 80,20537 Hamburg,Germany
Version:A/O
0123
