Technical Specification Host Adapter
3-Gb SAS/SATA II Connectivity
The ATTO ExpressSAS H30F Host Adapter
combines 3-Gb SAS/SATA II connectivity with six-
teen internal ports, making it the ideal SAS host
adapter for both IT and digital media environments
requiring flexible connectivity options and ultimate
performance.
The ATTO ExpressSAS host adapter product
family provides enhanced reliability and
performance thanks to more than 15 years of
experience with SCSI hardware and storage
connectivity solutions. Using the latest in PCI
Express bus technology and an eight internal port
configuration, the ATTO ExpressSAS H30F Host
Adapter delivers blazing fast performance with
transfer rates of up to 3-Gb per second per port.
The ATTO ExpressSAS line of host adapters are
engineered for the most stringent IT server and
digital media workgroup environments and are
compatible with multiple operating systems,
applications and drives.
An easy-to-use utility enables management,
monitoring, and configuration. ATTO also
incorporates it’s field proven Advanced Data
Streaming (ADS™) technology to meet the most
demanding performance requirements of data
intensive applications. In addition, ATTO provides
industry standard PCIe to SAS control using Serial
SCSI Protocol (SSP), Serial ATA Tunneling
Protocol (STP), and Serial Management Protocol
(SMP).
Technical Highlights
• x8 PCIe host interface
• Half-height
• 16 internal ports
• Outstanding performance
with up to 3-Gb/sec per
port
• SAS, SATA and SATA II
connectivity
• Support for up to 16
internal direct attached
SAS/SATA drives
• Exclusive Advanced Data
Streaming (ADSTM)
technology
• User friendly configura-
tion utility
• Driver support for
Windows®and Linux
• RoHS Compliant
• 3-year standard
product warranty
Blazing Fast Performance
• Up to 3-Gb/sec per port
transfer rates with SAS, SATA
and SATA II attachment
• Increased bandwidth through
x8 PCI Express host interface
• Point-to-point technology
delivers full throughput to
each connected storage
device
Smooth Data Streaming
• Alleviate data transfer
bottlenecks and move data
more efficiently while
managing latency with
ATTO’s exclusive ADS™
technology
• Improve I/O through
optimized data movement
One Click Installation
• One-click installation allows
for quick and easy set-up
• Simple host based utility for
effortless configuration
• BIOS setup utility provides
flexibility for custom
applications
ExpressSAS H30F Host Adapter
ExpressSAS H30F
16 Port SAS Host Adapter

Rev. 4/08
©2008 ATTO Technology, Inc. Specifications subject to change without notice
Technical Specification Power Behind the Storage
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
[phone]
Hardware Specifications
Applications • Support for IT server and digital media workgroup solutions requiring high-bandwidth and reliability.
Applications include audio/video, VOD, fixed content, database and other data intensive environments.
Maximum Transfer Rate • Up to 3-Gb/sec per port
Advanced Capabilities • Device support for SAS, SATA and SATA II
• User friendly GUI for quick and easy configuration
• Advanced management functions
• Support for SCSI Enclosure Services (SES)
• SGPIO Support
• PC BIOS bootability
PCI Bus Specifications • x8 PCI Express host interface
• Supports PCI Express Base Spec 1.0a
Connectors • Easy-to-install low-profile connection bracket; full-height bracket included in Finished Goods packaging
• Four x4 Internal Mini SAS (SFF-8087) connectors
Software Specifications
Driver Support • Windows® Server 2003, 2008, XP, Vista
• Linux (Red Hat and SuSE)
Agency Approvals
Safety and Environmental • FCC Rules, Part 15, Class B
• CE Mark: CISPR 22:2002/EN55022:2002, Class B
Compliancy • RoHS Compliant
Environmental & Physical Specifications
Dimensions • Length 6.600”
• Height 2.900”
Operating Environment • Temperature: 0-60° C (32°-140°F) at 300 lf/m airflow
• Temperature 0-40° C (32° - 104°F) at 150 lf/m airflow
• Humidity: 5 - 95% non-condensing
Storage Environment • Temperature: -40°-70°C (-40°-157°F)
• Humidity: 5 - 95% non-condensing
Power • 12V @ 1.45A
• 3.3V @ 0.50A
Ordering Information
Model Number • ESAS-H30F-000 (RoHS)
ExpressSAS 16 Port Host Adapter
3-Gb SAS/SATA II Connectivity
ExpressSAS H30F Host Adapter
