ATTO Technology ExpressPCI UL4D Manual

Product Features
Technical Specification
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
[phone]
ExpressPCI UL4D
Host Adapter
Dual-channel Ultra320
SCSI Host Adapter
With PCI-X Support
The UL4D dual-channel Ultra320 host adapter is
the perfect complement to ATTO’s ExpressPCI
family of high-performance SCSI host adapters for
data-intensive environments. Boasting data-
transfer rates of up to 640 MB/sec. and offering
support for advanced PCI-X busses, the UL4D is
an ideal fit for Enterprise servers and high-end
workstations running high-volume, mission-critical
applications such as messaging and databases.
ATTO host adapters offer ATTO’s exclusive
Advanced Data Streaming (ADSTM) technology,
and the ExpressPCI UL4D is no exception. By
effectively managing latency and allowing for fast
and efficient data movement, utilization of the CPU
is reduced, freeing it up to perform other mission
critical tasks.
Installation of the ExpressPCI UL4D host adapter is
a fast and easy. Thanks to ATTO’s factory-preset
configurations, the UL4D is ready out-of-the-box for
plug and play operation. The included
Configuration Utility, featuring an easy-to-use GUI,
simplifies the effort associated with installation,
management and monitoring of the host adapter.
The ExpressPCI UL4D is the first choice for users
working in environments with demanding server
and professional workstation environments. By
offering support for Ultra320 SCSI and PCI-X, in
addition to ATTO-designed performance-enhancing
technologies including ADS, the ExpressPCI UL4D
offers both the performance and feature set neces-
sary for today’s data-intensive applications.
Technical Highlights
• Ultra320 SCSI
• Up to 320 MB/sec. per
channel data-transfer
rates
• Dual independent SCSI
channels (2 internal and
2 external connector
availability)
• 64-bit/133 MHz PCI-X
with backward
compatibility
• Exclusive ADSTM
technology
• Supports up to 30 SCSI
bus IDs
• Up to 12 meter cable
lengths
• RoHS Compliant
• 3-year standard
product warranty
Blazing Fast Performance
• Maximize data throughput
with dual channel connectivity
aggregating performance
across multiple SCSI ports
• Leveraging the latest in SCSI
storage connectivity, the
UL4D delivers up to 640 MB/
sec. data throughput, making
it twice as fast as Ultra160
SCSI.
Smooth Data Streaming
• Maintain accessibility to
mission-critical data by
transparently redirecting data
requests through alternate
channels.
• Alleviate data transfer
bottlenecks and move data
more efficiently while
managing latency with
ATTO’s exclusive ADS™
technology.
One Click Installation
• Save time with factory preset
configuration for plug and play
operation.
• Simplify installation,
management and monitoring
with multi-platform
Configuration Utility featuring
an intuitive GUI.
ExpressPCI UL4D

Rev 4/08
©2008 ATTO Technology, Inc. Specifications subject to change without notice
Technical Specification Power Behind the Storage
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
[phone]
Hardware Specifications
SCSI Interface • 320 MB/sec. per channel data-transfer rates
• Two (2) external VHDCI and two (2) internal high-density connectors per channel
• Low Voltage Differential (LVD) signaling
• Support for tagged command queuing
• Backward compatible with Ultra160, Ultra2, Ultra/WIDE, Fast/WIDE & Narrow SCSI devices
Advanced SCSI • Supports dynamic bus rescan (OS X) •Quick Arbitration Select (QAS)
• Double transition clocking •ASPI compliant (for PC users)
• Domain validation •Bootable from attached disks
• Cyclical Redundancy Checking (CRC) •Support for disconnect/reconnect
• Packetization •Support for multiple block sizes
Accelerated PCI Bus Management • PCI-X bus master rate of 1 GB/sec.
• PCI-X 1.0a compliant
• PCI 2.2 and PCI 99 compliant
• 64-bit/133 MHz PCI-X (backward compatible with standard PCI)
General Characteristics • Automatic termination
• Upper-byte termination for Narrow devices
• Flash ROM for easy field upgrades
• Plug and play compatible
• Includes ATTO ExpressPro-ToolsTM & ATTO Configuration Tool formatting & utility software
Software Specifications
Driver Support • Windows®Server 2003, 2008, XP, Vista
• Mac®OS X (v10.4.x & v10.5.x)
• Linux (Fedora, Red Hat and SuSE)
• Novell Netware®v6.5
Agency Approvals
Safety and Environmental • FCC Rules, Part 15 Sub-Part B, Class A
• CE Mark: CISPR 22 / EN 55022, Class A
Environmental & Physical Specifications
Dimensions • Length 6.521”
• Height 4.450”
Operating Environment • Temperature: 0-45° C
• Humidity: 10-90% non-condensing
• Airflow: 100 LFM (min)
Reliability • MTBF = 150,000 hours
• MTTR < 15 Minutes
Power • 0.75 typical/2.0 max. Amps @ + 5.0 VDC
• 0.05 Amps @ + 12.0 VDC
PCI Signal Compatibility • 3.3 Volts/5 Volts universal
RoHS Compliant • Yes
Ordering Information
Model Number • EPCI-UL4D-0R0 (RoHS)
Advanced Data Streaming (ADSTM) • Improved PCI system bandwidth use
• Optimized SCSI-3 algorithms
• Tagged command queuing
• Embedded RISC I/O processor
RAID Options • RAID 0 support with ATTO Express Power Center or ExpressStripe RAID software utilities
ExpressPCI UL4D
Host Adapter
ExpressPCI UL4D
