ATZ HDMI4K Plus VGA-EM100IR-RX User manual
pg. 1
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
pg. 2
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
INTRODUCTION:
This unit is part of a 4K UHD Multi-Function Extension system that allows you to extend
HDMI or VGA signals along with KVM using the TCP/IP protocol over regular Cat.5e/6/7
network cable. This extender supports the transmission of Ultra High-Definition signals
(up to 4K@30Hz YUV 4:4:4 or 4K@60Hz YUV 4:2:0) with audio and USB up to 100m on
a single cable. The transmission distance can be further extended (up to 100m per
segment) by using gigabit network switches, allowing the user to cascade the system
without signal loss or introducing delay.
It is also possible to have the extension system's Transmitter operatein multicast mode,
allowing you to send a single AV signal to a large number of Receivers within the same
local network. Additionally, that same multicast signal can be used to create large multi-
display video walls with amazing simplicity. This system is perfect for both residential
and commercial installation environments.
This system also features bi-directional IR and RS-232 pass-through, analog line level
in/out, and a microphone input (on the Receiver), providing the user with a variety of
audio options. The USB functionality allows the system to act like a remote USB hub
which, when combined with the VGA input/output feature, provides a flexible remote
KVM platform. Configuration information is provided via On Screen Display (OSD) and
control is by WebGUI, Telnet, and front panel controls.
APPLICATIONS:
•HDMI, VGA, USB, Audio, IR, and RS-232 extension
•Broadcasting a system over a single Cat.5e/6 cable
•Multimedia display on a large number of displays via multicast
•Hotel or convention center display multi-monitor broadcast
•Long distance data and video transmission via cascading
•Distributed video matrix system
•Distributed video wall system
•Remote KVM control of a system
pg. 3
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
SYSTEM REQUIREMENTS:
•HDMI or VGA source equipment such as media players, video
game consoles, PCs or set-top boxes.
•HDMI or VGA receiving equipment such as HDTVs, monitors or audio
•Analog audio receiving equipment such as headphones, audio
amplifiers or powered speakers.
•A Gigabit Ethernet network switch with jumbo frame support is required.
(8K jumbo frames are strongly recommended.)
•A Gigabit Ethernet switch with “IGMP snooping” enabled is required for multicast
support.
FEATURES:
• HDMI 2.0 and DVI 1.0 compliant
• HDCP 1.4 & 2.2 compliant
• 1×HDMI input, 1×VGA input & 1×VGA bypass output
• Video, audio and control transmission over TCP/IP in Unicast (point- to-point) or
Multicast (single-to-many) modes
• Multi-monitor video wall support with 90° rotation
• HDMI input resolutions up to 4K@60Hz (YUV 4:2:0, 8-bit) or 4K@30Hz
(YUV 4:4:4, 8-bit)
Note: 4K@50/60Hz (YUV 4:2:0) sources are automatically converted to 4K@25/30Hz
(RGB) for output
•VGA input and output resolutions up to WUXGA (RB)
•Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
and Bitstream over HDMI
Note: The optical output on Receivers can only support LPCM 2.0 & Bitstream sources.
•The analog Line In on the Transmitter sends audio directly to the analog Line Out
and is inserted into the HDMI output on connected Receivers
•The Mic In on the Receiver sends audio directly to the analog Line
Out on the Transmitter
pg. 4
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
•Both Tx and Rx may powered directly by PoE when connected to a
Gigabit Ethernet switch that provides PoE (802.3af)
•Supports USB keyboard, mouse and storage extension
•Supports IR and RS-232 bypass
•Unit can be controlled via WebGUI, Telnet, and front panel controls
TECHNICAL SPECIFICATIONS:
HDMI Bandwidth
340MHz/10.2Gbps
Input Ports
3×Cat.5e/6/7 (LAN)
1×3.5mm (Microphone Audio)
1×IR Extender [3.5mm]
Output Ports
1×HDMI
1×VGA
1×TOSLINK (S/PDIF Audio)
1×3.5mm (Stereo Audio) 1×IR Blaster
[3.5mm] 1×RS-232 [9-pin D-sub] 4×USB
Type-A
Supported Resolutions
480i@60Hz - 4K@30Hz (4:4:4, 8-bit)
VGA@60Hz
- WUXGA@60Hz (RB)
IR Frequency
30 - 50kHz (30 - 60kHz under ideal
conditions)
Power Supply
5V/4A DC (US/EU standards, CE/FCC/UL
certified)
ESD Protection
Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
pg. 5
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Dimensions
231.5mm×25mm×108mm (W×H×D)
[Case Only]
231.5mm×25mm×120mm (W×H×D)
[All Inclusive]
Weight
666g
Chassis Material
Metal
Silkscreen Color
Black
Operating Temperature
0˚C - 40˚C/32˚F - 104˚F
Storage Temperature
−20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity
20 - 90% RH (Non-condensing)
Power Consumption
17.68W
Video Specifications
Input
Ouput
Supported Resolutions (Hz)
HDMI
VGA
HDMI
VGA
640×480p@60
720×480p@59/60
720×576p@50
800×600p@60
1024×768p@60
1280×720p@50/59/60
1280×768p@60
1280×960p@60
1280×1024p@60
1440×480p@60
1440×576p@50
1366×768p@60
1600×1200p@60 (RB)
1920×1080p@24/25
1920×1080p@50/59/60
1920×1200p@60 (RB)
pg. 6
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
1920×1080i@50/59/60
3840×2160p@24/25/30
3840×2160p@50/60 (YUV
4:2:0)
4096×2160p@24/25/30
Notes:
• HDMI Input: Up to 4096×2160p@60Hz (YUV 4:2:0).
•HDMI Output: HDMI input at 4K@60Hz (YUV 4:2:0) will automatically be converted
to 4K@30Hz (RGB) for output.
•VESA VGA up to 1920×1200@60Hz (Pixel clock<150MHz).
Audio Specifications
Supported Audio Formats:
Supported Formats (kHz)
HDMI Input
HDMI Output
LPCM 2.0@32/48/96/192
LPCM 5.1@32/48/96/192
LPCM 7.1@32/48/96/192
Standard Bitstream
pg. 7
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
OPERATION CONTROLS AND FUNCTIONS:
Receiver's Front Panel
(1) POWER LED: This LED will flash while the unit is powering on and will
illuminate solidly once it is ready to be used.
(2) LINK LED: If the Transmitter has no network connection the LINK LED will not
illuminate. While the Transmitter is attempting to establish
a connection with a Receiver the LINK LED will flash. When the Transmitter has
established a stable connection with a Receiver the LINK LED will illuminate solidly.
(3) USB 2.0: These 2 USB 2.0 slots provide connections for USB devices
requiring higher transfer speeds such as thumb drives.
Note: Isochronous (steady streaming) data devices such as USB cameras and
external hard drives are not supported.
(4) USB 1.1: These 2 USB 1.1 slots provide connections for slower USB
devices such as keyboards, mice, etc.
Note: Isochronous (steady streaming) data devices such as USB cameras and
external hard drives are not supported.
(5) RESET: Press this recessed button to reboot the unit (Settings will not be reset).
(6) SWITCH/MODE: This button controls multiple functions:
(a) Switch Input: Press this button momentarily to switch between the two available
video inputs (HDMI and VGA).
pg. 8
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Note: Due to the nature of streaming video and HDCP, the switch may take up to
6–10 seconds to complete.
(b) Video Mode: Press and hold this button for 3 seconds to toggle the video data
streaming method between “Graphic” and “Video” modes. “Graphic” mode is optimized
for high-detail static displays
and “Video” mode is optimized for full motion video
(7) CH+/LINK: This button controls multiple functions:
(a) Channel +: Press this button momentarily to increase the streaming
channel to the next available channel on the local network.
Note: If no other channels are detected, the channel number will not change.
(b) Video Link: Press and hold the button for 3 seconds to enable or disable the Video
Link. When the link is disabled and the Receiver is connected to a display it will show
the system’s current IP and firmware information.
(c) Reset to Factory Defaults: Press and hold this button when powering the
unit on until both the POWER and LINK lights are blinking. Once both lights are
blinking you can reboot the unit and all settings will be returned to the factory
defaults (Including resetting the IP mode to auto, broadcast channel to 0, and the
streaming mode to multicast). A new IP address will be assigned automatically
within the 169.254.xxx.xxx address range.
(8) CH−/USB: This button controls multiple functions:
(a) Channel −: Press this button momentarily to decrease the streaming channel to
the previous available channel on the local network.
Note: If no other channels are detected, the channel number will not change.
(b) USB: Press and hold the button for 3 seconds to enable/disable the USB
connection between the Transmitter and the Receiver. (Multicast Mode ONLY)
Note: In Multicast mode is it only possible to provide USB support to a single Receiver
at a time. Enabling USB on one Receiver will disable it on all other Multicast Receivers
on the same channel.
(9) IR WINDOW: Accepts IR signals from any standard remote control
and sends the signal to the IR Out on the associated Transmitter.
(10) IR IN: Connect to the provided IR Extender to extend the IR control range of
remotely located devices. Ensure that the remote being used is within direct line-of-
pg. 9
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
sight of the IR Extender.
(11) IR OUT: Connect to the provided IR Blaster to transmit IR signals
from the
associated Transmitter to devices within direct line-of-sight of the IR Blaster
(12) ISP SEL: For Factory use only. By default this is set to the left (away
from the RS-232 port) and allows normal RS-232 functionality. Setting this switch
to the right enables ISP engineering mode.
(13) RS-232: Connect directly to an RS-232 controllable device to receive commands
from the device connected to the Transmitter. The baud rate is configurable, but the
default baud rate is 115200.
Note: When the Transmitter is in multicast mode every connected Receiver unit
can send RS-232 commands to the Transmitter and commands sent from the
Transmitter side will be sent to all connected Receivers.
pg. 10
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Receiver's Rear Panel
(1) MIC IN: Connect to an analog microphone using a 3.5mm plug. This audio will
be sent to the analog audio output on the connected Transmitter. (Unicast mode
ONLY)
Note: The Mic In audio channel back to the Transmitter is only active when an
analog source is also connected to the Line In port on the Transmitter.
(2) LINE OUT: Outputs stereo audio from the Transmitter (HDMI or Line In, LPCM
2.0 sources only). Connect to powered speakers or an amplifier for stereo analog
audio output.
(3) OPT OUT: Outputs audio from the Transmitter (HDMI or Line In, LPCM
2.0 & Bitstream sources only). Connect to powered speakers or an amplifier for stereo
analog audio output.
(4) HDMI OUT: Connect to HDMI TVs, monitors or amplifiers for digital
video and audio output.
(5) VGA OUT: Connect to a VGA monitor or display for analog video output. (VGA or
Non-HDCP HDMI sources only)
Note: PC text and content with fine details may display with some
visual artifacts when transmitted at 4K@60Hz (YUV 4:2:0).
(6) ISP: For factory use only.
(7) LAN 1 (PoE)~3: Connect via a Gigabit Ethernet switch to compatible
Receiver(s) to transmit data, or to a PC/laptop to control the unit via WebGUI.
pg. 11
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Note: This unit can be powered directly by the connected Gigabit Ethernet switch if it
provides PoE (802.3af). Only LAN 1 port supports PoE. Daisy chaining additional
Receivers using LAN 1, 2, or 3 is possible.
(8) DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power. (Optional if powered by PoE)
IR Cable Pin Assignments:
pg. 12
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Connection Diagram:
pg. 13
Notes: - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only.
Photo attached is for reference only, it may be slightly varied in items of colour, shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ HDMI4K+VGA-EM100IR-RX
Description: HDMI4K/VGA over IP Receiver with IR, RS-232, PoE/ LAN &
USB/KVM Extension
Packaging Includes:
1× HDMI/VGA over IP Receiver with USB/KVM Extension
1× IR Extender Cable
1× IR Blaster Cable
1× 5V/4A DC Power Adaptor
1× Power Cord
1× Operation Manual
Warranty: 2 Years
Warranty is effective from the date of original delivery.
This warranty shall be void if a serial number has been removed from the product.
Table of contents
Other ATZ Receiver manuals
