AUDAC SCP2 Series User manual

User manual
audac.eu
SCP2xx

SCP2xx - User manual2
ADDITIONAL INFORMATION
This manual is put together with much care, and is as complete as could be on the publication date. However,
updates on the specications, functionality or software may have occurred since publication. To obtain the latest
version of both manual and software, please visit the Audac website @ www.audac.eu.

SCP2xx - User manual 3
Table of contents
Introduction 5
Compact dual-channel power amplier � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Precautions 6
Chapter 1 8
Connections and connectors � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Chapter 2 9
Front panel overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Rear panel overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Technical specications 12

SCP2xx - User manual4

SCP2xx - User manual 5
Introduction
Compact dual-channel power amplier
The SCP series is a range of extremely powerful compact dual-channel power ampliers for commercial use.
These half 19” devices can be used in stereo low impedance or 70/100V bridge mode. There are 3 different
models to serve a wide range of applications with power ratings that vary between 240W to 600W in a half 19”
rack space housing.
The compact and elegant design of the half 19” rack space enclosure allows for single installation in a 10.5”
equipment rack, or side-by-side (two devices) in a 19” equipment rack.
A connection to the WP2xx series input wall panels or volume controllers can be made via the RJ45 connectors
on the back of the SCP.
Equipped with a standby mode switch, the SCP series will enter an energy-saving standby mode after a period
of inactivity. This feature together with the overall energy-efcient design makes the SCP meet the high standards
of the Energy Star certication.
When you combine the SCP series with a suitable pre-amplier or wall-mounted input panel you create a powerful
and complete solution for background music installations.

SCP2xx - User manual6
Precautions
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY
ALWAYS HANDLE THIS UNIT WITH CARE
HEED ALL WARNINGS
FOLLOW ALL INSTRUCTIONS
NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH
LIQUID ON TOP OF THIS DEVICE.
DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. ENSURE THERE IS ADEQUATE
VENTILATION TO COOL THE UNIT. DO NOT BLOCK THE VENTILATION OPENINGS.
DO NOT STICK ANY OBJECTS THROUGH THE VENTILATION OPENINGS.
DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS OR OTHER APPARATUS THAT PRODUCE HEAT
DO NOT PLACE THIS UNIT IN ENVIRONMENTS WHICH CONTAIN HIGH LEVELS OF DUST, HEAT, MOISTURE OR VIBRATION
THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS
PLACE THE UNIT ON A STABLE BASE OR MOUNT IT IN A STABLE RACK
ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE MANUFACTURER
UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME
ONLY CONNECT THIS UNIT TO A MAINS SOCKET OUTLET WITH PROTECTIVE EARTHING CONNECTION
THE MAINS PLUG OR APPLIANCE COUPLER IS USED AS THE DISCONNECT DEVICE, SO THE DISCONNECT DEVICE SHALL BE READILY
OPERABLE
USE THE APPARATUS ONLY IN MODERATE CLIMATES
THIS DEVICE CAN BE SOLD IN ALL EU REGIONS
CAUTION
The symbols shown are internationally recognized symbols that warn about potential hazards of electrical products.
The lightning ash with arrow point in an equilateral triangle means that the unit contains dangerous voltages. The
exclamation point in an equilateral triangle indicates that it is necessary for the user to refer to the users manual.
These symbols warn that there are no user serviceable parts inside the unit. Do not open the unit. Do not attempt to service
the unit yourself. Refer all servicing to qualied personnel. Opening the chassis for any reason will void the manufacturer’s
warranty. Do not get the unit wet. If liquid is spilled on the unit, shut it off immediately and take it to a dealer for service.
Disconnect the unit during storms to prevent damage.

SCP2xx - User manual 7
CAUTION - SERVICING
This product contains no user serviceable parts. Refer all servicing to qualied service personnel. Do
not perform any servicing (unless you are qualied to)
EC DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and further relevant specications described
in following directives: 2014/30/EU (EMC) and 2014/35/EU (LVD). All related standards are listed in a
Declaration of Conformity (DoC), which can be found in the products download section on the web-
page audac.eu, our through scanning the QR code on page 2 of this user manual.
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The WEEE marking indicates that this product should not be disposed with regular household waste
at the end of its life cycle. This regulation is created to prevent any possible harm to the environment
or human health.
This product is developed and manufactured with high quality materials and components which can be
recycled and/or reused. Please dispose this product at your local collection point or recycling centre for
electrical and electronic waste. This will make sure that it will be recycled in an environmentally friendly
manner, and will help to protect the environment in which we all live.
POWER SUPPLY AND POWER CORD REQUIREMENTS
Power supply class I grounding requirements:
For protection from fault currents, the equipment shall be connected to a grounding terminal. Plug the system power cord
into an AC outlet that provides a ground connection. Substitute cords may not provide adequate fault protection. Only use
the power cord supplied with this product or an authorized/equivalent replacement
SAFETY NOTICES:
DENMARK: Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver forbindelse til stikproppens jord.
FINLAND: Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
NORWAY: Apparatet må tilkoples jordet stikkontakt.
SWEDEN: Apparaten skall anslutas till jordat uttag.

SCP2xx - User manual8
Chapter 1
Connections and connectors
CONNECTION STANDARDS
The in- and output connections for AUDAC audio equipment are performed according to international wiring
standards for professional audio equipment
3-Pin Terminal block:
For balanced line input connections
For balanced signal input connections For unbalanced signal input connections
RJ45 (audio):
Remote input units
RJ45 (control):
Remote volume controller
Left:
Center:
Right:
Signal -
Signal +
Ground
(XLR Pin 3)
(XLR Pin 2)
(XLR Pin 1)
+
+
Pin 1 White-Orange Left channel +
Pin 2 Orange Left channel -
Pin 3 White-Green +24V DC
Pin 4 Blue Not connected
Pin 5 White-Blue Not connected
Pin 6 Green GND
Pin 7 White-Brown Right channel +
Pin 8 Brown Right channel -
Pin 1 White-Orange Not connected
Pin 2 Orange Not connected
Pin 3 White-Green GND
Pin 4 Blue Variable control voltage (0 ~ 10V)
Pin 5 White-Blue +10V
Pin 6 Green +10V
Pin 7 White-Brown Not connected
Pin 8 Brown Not connected

SCP2xx - User manual 9
Chapter 2
Front panel overview
Indicator LEDs (VU):
Channel monitoring is made convenient by four indicator LEDs for each channel.
The LEDs give a continuous indication of the operation of the corresponding channel. The green signal LED illuminates
whenever a signal is present, while the -20dB LED illuminates when the input signal exceeds the -20 dB level. The Clip LED
illuminates when the corresponding channel is working at maximum level. To ensure the best signal-to-noise ratio, the Clip
LED should illuminate only (or maximum) at peak levels.
When the Clip LED illuminates, the output limiter of the amplier will intervene avoiding a distorted “Clipping” sound on the
output. The Protection LED will illuminate when overheating occurs, or any other fault is detected. When the protection LED is
illuminated, no signal will be available on the outputs. The Protection LED will also illuminate when the external mute contacts
are activated.
Power switch:
A power switch is used to switch the amplier on and off. The LED ring around the switch illuminates in blue colour when the
power is switched on or will illuminate in orange color when switched to standby mode.

SCP2xx - User manual10
Rear panel overview
AC Power inlet with fuse:
The mains power supply (100-240V AC - 50/60 Hz) has to be applied to this AC power inlet.
Mute connection:
A priority mute contact connection is present which allows complete muting of background music at presence of a contact
closure between both ‘MUTE’ contacts.
This contact is convenient for situations where a separate emergency system is installed and complete background music
muting is required. For example at the occasion of a re alarm. The emergency system output contacts can be linked to
this contact input. When a N.C. contact trigger is being used, a contact bridge shall be used between both N.O. contact
terminals.
Audio output connection:
The speakers shall be connected to the terminal block output connector. Depending on the setup, two speakers can be
connected in low impedance stereo setup, or one speaker line can be connected in constant voltage 70/100V bridge
conguration. Typical wiring applications are shown in the following diagrams.
Output voltage Impedance Power
SCP212 22 Volt 4 Ohm 2 x 120 Watt
SCP224 31 Volt 4 Ohm 2 x 240 Watt
SCP230 35 Volt 4 Ohm 2 x 300 Watt
SCP2xx connected in stereo mode
Normal open mute contact diagram Normal closed mute contact diagram
SCP2xx connected in bridge mode
SCP series min load impedance in 4 Ohm stereo output mode
N.O.
N.C.
N.O.
N.C.

SCP2xx - User manual 11
Remote audio input:
A remote audio wall panel (e.g. WP2xx) can be connected to the bottom ‘Remote audio’ RJ45 connector for providing a
remote audio input. The connection of this extension port can be made by using CAT5e (or better) twisted pair cable in a
straight pinout conguration.
Pinout and colour coding is described in Chapter 1 of this instruction manual. The remote audio input provides stereo balanced
line input with an input sensitivity of +12dBV and a +24V output for powering external audio panels. The audio signal from
the remote audio input is mixed with the ampliers line inputs.
Remote volume control:
The top ‘Vol Ctrl’ RJ45 connector allows for an external control of the main volume of the SCP amplier. The connection of
this extension port can be made by using CAT5e (or better) twisted pair cable in a straight pinout conguration. Pinout and
colour coding is described in Chapter 1 of this instruction manual.
The remote volume controller connection is designed for use with a suitable volume controller (e.g. Audac WP200, VC3208). It
is a VCA input, working between 0-10V (linear envelope), and can be used with an external 0-10V control system. The ampliers
overall volume is controlled dependent on the applied control voltage. A control voltage of 10V means no attenuation, while
0V mutes the amplier. When no external controller is connected, the volume is at maximum.
Standby switch:
The Standby mode of the SCP can be turned on or off. When enabled, the SCP will automatically go into standby
mode after 30 minutes of inactivity (no signal detection).
Stereo- (Lo-Z) / bridge- (Hi-Z) mode switch:
Provides the possibility to switch the amplier between Lo-Z and Hi-Z mode. If this switch is set to Lo-Z stereo, the output
will be stereo can capable of driving low impedance speakers. If it is set to Hi-Z BTL/HPF, both output channels are bridged
and capable of driving high impedance / constant voltage speaker systems. The output voltage can be switched between
70/100V through using corresponding switch, depending on the requirements of the installation. An HPF (70 Hz) will be
enabled when switched to Hi-Z.
70V / 100V switch:
When switched in Hi-Z mode (STEREO - BTL-HPF) the output voltage can be switched between 70/100V using this switch.
Balanced stereo line input:
The balanced stereo line inputs use 3-pins terminal block connectors. All different kinds of balanced and unbalanced line
level audio sources can be connected to the line inputs. Some examples are pre-ampliers, mixers and spoken messages
through an audio source. It is tted with a gain control potentiometer by which the input sensitivity can be controlled within
a range of -3 dBV ~ +7 dBV.
Output voltage Impedance Power
SCP212 70 Volt 20.83 Ohm 240 Watt
SCP224 70 Volt 10.41 Ohm 480 Watt
SCP230 70 Volt 8.33 Ohm 600 Watt
Output voltage Impedance Power
SCP212 100 Volt 41.67 Ohm 240 Watt
SCP224 100 Volt 20.83 Ohm 480 Watt
SCP230 100 Volt 16.67 Ohm 600 Watt
SCP series min load impedance in 70 Volt bridge mode
SCP series min load impedance in 100 Volt bridge mode

SCP2xx - User manual12
Technical specications
SCP212 SCP224 SCP230
RMS/AES power handling @ 4 Ohm stereo 2 x 120 Watt 2 x 240 Watt 2 x 300 Watt
@ 8 Ohm stereo 2 x 60 Watt 2 x 120 Watt 2 x 150 Watt
@ 70/100V bridge 240 Watt 480 Watt 600 Watt
Frequency response 20 Hz - 20 kHz
Signal / Noise > 95 dB
THD+N < 0.05%
Amplier technology Class D
Cooling Convection cooled Fan cooled (controlled) Fan cooled (controlled)
Inputs Balanced line 2 x Balanced line input
3-pin terminal block ~ 3.81mm
Remote audio input RJ45
Remote volume controller RJ45
Priority mute contact NO or NC
Outputs Low Z & 70/100V speaker output
4-pin terminal block ~ 5.08 mm
Controls Gain control (potentiometer)
Stereo low Z & mono high
switch
70/100V switch
Standby ON/OFF
Power supply 100 ~ 240 V AC / 50 ~ 60 Hz
Power consumption Standby 0.5W 0.5W 0.5W
Idle 19W 19W 19W
1/8 rated power 60W 100W 115W
1/3 rated power 123W 220W 262W
Ambient temperature range (in operation) 0°C ~ +40°C
Relative humidity range < 80 %, not condensing
Dimensions (W x H xD) 217.5 x 43.7 x 300 mm
Weight 2.70 Kg
Mounting 1/2 19” / 1 HE or tabletop
Construction Steel
Color Black
Optional accessories WP2xx remote wall panel inputs
WP200 VC3208 Remote volume controller
VC3208 Remote volume controller
MBS310 rackmount adapter

SCP2xx - User manual 13
