AUDAC TMP40 User manual

TMP40
User Manual
www.audac.eu

2
ADDITIONAL INFORMATION
This manual is put togheter with much care, and is as complete as could be on the
publication date. However, updates on the specifications, functionality or software
may have occurred since publication. To obtain the latest version of both manual and
software, please visit the Audac website @ www.audac.eu.

3
Index
Introduction 5
Precautions 6
Safety requirements 6
Caution servicing 7
EC Declaration of Conformity 7
Waste of Electrical and Electronic Equipment (WEEE) 7
Chapter 1: Connections and connectors 8
Connection standards 8
Chapter 2: Overview TMP40 9
Chapter 3: Using the TMP40 10
Module screen 10
Settings screen 11
Chapter 4: Installing the TMP40 13
Chapter 5: Additional information 15
Technical specifications 15
Notes 16

4

5
Introduction
SourceCon™ FM tuner module
The TMP40 is a tuner with worldwide FM band support featuring SourceCon™ modular
technology. This unique technology guarantees true plug & play implementation to any
compatible device. When inserted to a supporting slot, the module is instantly installed,
discovered and ready for operation without requiring any additional internal wiring or
complex configuration.
The TMP40 provides access to a wide variation of radio stations while guaranteeing a
high-quality audio reproduction. Station selection can be done manually or automatically,
while up to 10 preferred channels can be internally stored and recalled. Radio station
information carried by RDS can be retrieved, while other functions such as mono/stereo
switching (FM) always guarantee the best possible audio clarity.
Besides the signal output level which is user configurable, the traffic announcement
volume can be individually set which guarantees the best ,intelligibility in specific requiring
applications.
Signal reception strength can be retrieved from the module and indicated on the graphical
interface of the controlling device. The antenna input is implemented by an F-type
connector on its panel, allowing connection of the included antenna cable or any other
external antenna using 75 Ωcoaxial cabling. The balanced stereo line output is connected
through two 3-pin terminal block connections.

6
Precautions
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
• ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER
THROW THEM AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS
• AVOID ELECTROSTATIC DISCHARGE BY TOUCHING GROUNDED POINT BEFORE
REMOVING THE MODULES FROM THEIR PROTECTIVE BAG
• AVOID TOUCHING OF THE COMPONENTS ON THE CIRCUIT BOARD DIRECTLY
• NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR
SPLASHING LIQUID. NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP
OF THIS DEVICE
• DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS
OR OTHER APPARATUS THAT PRODUCE HEAT
• DO NOT PLACE THIS UNIT IN ENVIRONMENTS WITH A HIGH LEVEL OF DUST,
HEAT, MOISTURE OR VIBRATION
• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS
• ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
• UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED
FOR LONG PERIODS OF TIME
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER UNPACKING.
IF THERE IS ANY DAMAGE TO THE CARTON BOX OR THE UNIT ITSELF,
INFORM YOUR VENDOR IMMEDIATELY.
• ONLY CONNECT THIS UNIT TO A MAINS SOCKET OUTLET WITH PROTECTIVE
EARTHING CONNECTION
• THE INSTALLATION, CONNECTION AND CONFIGURATION OF THE DEVICE
SHOULD BE DONE BY QUALIFIED TECHNICIANS

7
CAUTION - SERVICING
This product contains no user serviceable parts. Refer all servicing
to qualified service personnel. Do not perform any servicing
(unless you are qualified to do so.)
EC DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and
further relevant specifications described in following directives:
2004/108/EC (EMC) and 2006/95/EC (LVD)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The WEEE marking indicates that this product should not be
disposed with regular household waste at the end of its product
life. This regulation is created to protect both the environment
and human health.
This product is developed and manufactured with high quality
materials and components which can be recycled and/or reused.
Please dispose of this product at your local collection point or
recycling centre for electrical and electronic waste. Do this to
make sure that the product is recycled in an environmental friendly
way, and help to protect the environment in which we all live.
CAUTION
The symbols shown are internationally recognized symbols that warn about potentional
hazards of electrical products. The lightning flash with arrowpoint in an equilateral
triangle means that the unit contains dangerous voltages. The exclamation point in
an equilateral triangle indicates that it is necessary for the user to refer to the users
manual.
These symbols warn that there are no user serviceable parts inside the unit. Do not
open the unit. Do not attempt to service the unit yourself. Refer all servicing to qualified
personnel. Opening the chassis for any reason will void the manufacturer’s warranty.
Do not get the unit wet. If liquid is spilled on the unit, shut it off immediately and take
it to a dealer for service. Disconnect the unit during storms to prevent damage.

8
Chapter 1
Connections and connectors
CONNECTION STANDARDS
The in- and output connections for AUDAC audio equipment are performed
corresponding to international wiring standards for professional audio equipment.
3-Pin terminal block:
For balanced in & output connections
Left: Signal - (XLR Pin 3)
Center: Signal + (XLR Pin 2)
Right: Ground (XLR Pin 1)
For balanced line output connections:
For unbalanced line output connections:

9
Chapter 2
Overview TMP40
The TMP40 is a SourceCon™ compatible module featuring an (internal) board-edge
connector which carries all signals for getting it connected to any supporting main unit.
All external in & output connections shall be made using the available connectors on
the panel.
1) Balanced stereo line output:
The balanced stereo line output is implemented using two 3-pin terminal block
connectors. The audio output available on this connector allows it to be fed to any
amplifier or pre-amplifier.
2) F-type antenna connection:
The antenna (input) connection is implemented using an F-type connector whereto the
supplied FM antenna should get connected. Depending of the installation conditions,
location and signal strength, it can be recommended / necessary to extend the antenna
using 75 Ωcoaxial cable and connect an external or outdoor antenna.

10
Chapter 3
Using the TMP40
Since the TMP40 is a SourceCon™ module, it can be combined with a variation of
supporting main units. The operation and configuration interface might be different of
the unit where installed, however the offered functionality is identical. Some devices
will support control and configuration through a front panel graphical control interface
on a display, while others are also supporting web-control.
This manual describes the control configuration possibilities using front panel control. For
applications where more control possibilities are offered, check the instruction manual
of the used main device for more instructions.
Module screen
Radio station selection:
• Automatic tuning:
The currently playing radio station can be
selected by pressing the (tuning down) and
(tuning up) buttons. When selected, it will
automatically start searching for the next station
with sufficient signal strength. The currently
tuned frequency will be indicated at the center
of the screen, also indicating additional carried
RDS information (if available) such as the
currently playing station or track name.
• Manual tuning:
The tuning frequency can be manually adjusted by rotating the function dial until the
tuned frequency is highlighted in blue colour. When highlighted, confirm manual tuning
adjustment by single pressing the rotary dial and adjust the tuner frequency by rotating
clockwise (tuning up) or counter-clockwise (tuning down). Once tuned to the desired
frequency, conform the tuned frequency by single pressing the function dial once again.

11
Save radio station:
The currently playing station can be stored to one of the 10 available positions. A horizonal
array with numbers from 1 to 10 is indicated on the bottom of main tuner screen,
representing the 10 positions whereto the presets can be saved. Rotate the function dial
until the number for radio station storage is highlighted, and press the (save) icon for
saving the currently selected frequency to the selected position.
Recall radio station:
A stored radio station can be recalled by rotating the function dial until the number on the
horizontal array on the bottom of the main tuner screen is highlighted. When highlighted,
confirm the recall of the stored frequency by single pressing the function dial. The stored
frequency under this position is now recalled and the radio station will start playing.
Home:
The (home) button gets you back to the main screen of the device where the TMP40
is installed to.
Settings screen
The settings menu for TMP40 can be loaded
by rotating the rotary dial until the (settings)
symbol is highlighted in blue colour. When
highlighted, confirm to proceed to the settings
menu by single pressing the rotary dial.
Gain:
The gain can be adjusted within a range of +8 dB and -55 dB, allowing optimalization
of the output level according to the input sensitivity of the connected amplifier or pre-
amplifier. For adjusting the output gain, rotate the function dial until ‘Gain’ is highlighted
and press it for proceeding to the gain settings. The level can be adjusted by rotating
clockwise (tuning up) or counter-clockwise (tuning down). Press the rotary dial for
confirming the currently set output level.
Gain TA (Traffic announcement):
The traffic announcements gain allows a different output level for traffic announcements
(if playing radio station includes TA information). This feature can be useful for applications
where traffic announcements should be heard at higher volumes than background music.

12
The traffic announcement gain can be adjusted within a range of +8 dB and -55 dB,
allowing to switch to the set TA gain when any TA signal is detected on the currently
playing radio station. In the maximum position (TA GAIN = TA), the output level will
remain unchanged when any TA carrier is detected.
Freq. Range:
The FM reception frequency range can be switched between 87.5 ~ 108 MHz and 64 ~
108 MHz, depending in which part of the world the system will be used. Toggling between
both frequency ranges can be done by single pressing the function dial.
Mono:
The FM reception is standard set to stereo mode, however it will switch automatically
to mono mode if the signal reception strength is insufficient. This reduces the noise and
improves the sound quality when having poor signal reception.
Manual switching the output to mono mode is possible using this function, allowing the
output to be fed to mono systems, such as 100V public address amplifiers. Toggling
between mono and stereo mode can be done by single pressing the function dial.
Factory reset:
Factory reset will recall all settings to factory defaults and all previously made settings
and configurations will be lost. After selecting factory reset, a confirmation will be asked
whether all settings definitely need to be reset to factory defaults. When confirmed, all
settings will be lost.
Back:
Returning to the module screen is done by selecting ‘Back’.

13
Chapter 4
Installing the TMP40
CAUTION
Before installing the TMP40 to any SourceCon™ compatible device,
make sure the power is switched off. Malfunctions or electrical shocks
may occur otherwise.
Step 1:
Make sure that the slot whereto the module should be installed is open and ready for
installation. Depending of the main unit, some module slots will be covered by blind
panels when delivered. The corresponding blind panels should be removed by releasing
the screws on both ends.
Step 2:
Before removing the modules from their protective bag, we recommend touching a
grounded metal chassis (or any other grounded point) to prevent electrostatic discharges
affecting the sensitive electronic components. It is recommended to always hold the
module card by the metal connection panel and avoid touching of the components on
the circuit board directly.
Step 3:
Align both edges of the module with the guide rails inside the slot and carefully insert
the module into the slot. It should slide into the slot without any considerable resistance
when well positioned into the guide rail.

14
Step 4:
Some resistance might occur when the module’s board edge connector reaches the
connection counterpart on the main board. Gently push the module all the way into the
slot to ensure that the contacts are correctly inserted. The module is well inserted when
its connection panel touches the metal chassis of the main device where inserted to.
Step 5:
Fasten the module into the slot using the included screws. Be aware that damage or
malfunctions may occur if the module is not correctly fastened.
Step 6:
Once the module correctly installed, the system can be powered-on and the module
functionality will be automatically discovered.

15
Chapter 5
Technical specifications
Connection SourceCon™ interface card slot
Input F-type antenna connection (75
Ω)
Output Balanced stereo line output
(2 x 3-pin Euro Terminal Block ~ 3.81 mm)
FM tuning range 64 ~ 108 MHz
87.5 ~ 108 MHz
Output level +8 dB ~ -55 dB
(Software configurable)
Sensitivity - 100 dBm
Signal/noise 42 dB
THD+N < 0.1%
Frequency response 30 Hz - 15 kHz
Crosstalk 42 dB
Power consumption 0.5 Watt
Dimensions (W x H x D) 87 x 34.5 x 114 mm
Weight 0.071 Kg
Packaging Carton box
Shipping weight & Volume 1.08 Kg - 0.028 Cbm
Compatible devices XMP44 Modular audio system
Optional Accessories ASK10S 4-Way antenna splitter kit
RGA10 Omnidirectional outdoor antenna

16
Notes
