Workshop Manual
Audi A8 2003 ➤
multitronic 01J, front-wheel drive
Edition 11.2007
Service
Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
List of Workshop Manual Repair GroupsList of Workshop Manual
Repair GroupsList of Workshop Manual Repair Groups
Repair Group
00 - Technical data
13 - Crankshaft group
37 - Controls, housing
38 - Gears, control
39 - Final drive - differential
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2010 Audi AG, Ingolstadt A0051085920

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Contents
00 - Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Gearbox identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Notes on CVT gearbox type “multitronic 01J (front-wheel drive)” . . . . . . . . . . . . . . . . . . . . 2
3 Code letters, gearbox allocation, ratios, equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Notes on towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6 Repair instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.1 Contact corrosion! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.2 General repair instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.3 Rules for cleanliness when working on the gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
13 - Crankshaft group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1 Damper unit, for description refer to: Engine, mechanics; Repair group 13 . . . . . . . . . . . . 10
37 - Controls, housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Checking ignition key removal lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3 Checking selector mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Servicing selector mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1 Exploded view - selector mechanism cover, selector lever handle . . . . . . . . . . . . . . . . . . 16
4.2 Removing and installing selector lever handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.3 Removing and installing selector mechanism cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Removing and installing tiptronic switch F189 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.5 Exploded view - selector mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.6 Operating manual release for selector mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.7 Removing and installing manual release mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.8 Removing and installing shift unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.9 Selector lever cable - exploded view of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.10 Removing and installing selector lever cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.11 Adjusting selector lever cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5 Removing and installing gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.1 Removing gearbox - vehicles with 3.0 ltr. MPI engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.2 Installing gearbox - vehicles with 3.0 ltr. MPI engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.3 Removing gearbox - vehicles with 3.2 ltr. FSI engine and 2.8 ltr. FSI engine . . . . . . . . . . 49
5.4 Installing gearbox on vehicles with 3.2 ltr. FSI engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6 Securing gearbox to assembly stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7 Transporting the automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8 Removing and installing gearbox mounting and gearbox support . . . . . . . . . . . . . . . . . . . . 60
8.1 Removing and installing gearbox mounting and gearbox support (left-side) . . . . . . . . . . . . 60
8.2 Removing and installing gearbox mounting and gearbox support (right-side) . . . . . . . . . . 62
9 Checking ATF level and changing ATF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.1 Checking ATF level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.2 Changing ATF or filling up after performing repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
10 Servicing ATF cooling system on vehicles with 3.0 ltr. MPI engine . . . . . . . . . . . . . . . . . . 74
10.1 Removing and installing ATF pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
10.2 Cleaning ATF pipes and ATF cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
10.3 Removing and installing additional ATF filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
10.4 Removing and installing additional ATF cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
10.5 Removing and installing bracket for additional ATF filter and additional ATF cooler . . . . . . 81
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
11 Servicing ATF cooling system on vehicles with 3.2 ltr. FSI engine and 2.8 ltr. FSI engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
11.1 Removing and installing ATF pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
11.2 Cleaning ATF pipes and ATF cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
11.3 Removing and installing additional ATF filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
11.4 Removing and installing additional ATF cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
11.5 Removing and installing bracket for additional ATF filter and additional ATF cooler . . . . . . 88
38 - Gears, control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
1 Dismantling and assembling gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
1.1 Removing and installing end cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
1.2 Removing and installing automatic gearbox control unit J217 . . . . . . . . . . . . . . . . . . . . . . 95
1.3 Cleaning selector shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
1.4 Removing and installing hydraulic control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
1.5 Removing and installing input shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
39 - Final drive - differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
1 Checking gear oil in front final drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
2 Servicing front final drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
2.1 Removing and installing flange shaft (left-side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
2.2 Removing and installing flange shaft (right-side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
2.3 Renewing flange shaft oil seal (left-side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
2.4 Renewing oil seal and grooved ball bearing for flange shaft (right-side) . . . . . . . . . . . . . . 103
2.5 Removing and installing cover for front final drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
00 – Technical data
1 Gearbox identification
The continuously variable automatic gearbox “multitronic 01J,
front-wheel drive” is installed in the Audi A8 2003 ▸ in combination
with various engine types. Allocation
⇒ “3 Code letters, gearbox allocation, ratios, equipment ”,
page 3 .
Location of code letters on gearbox
Gearbox code letters and gearbox serial number are stamped
onto the bottom of the gearbox case -arrow-.
Example: FRC 03 07 01
Code letters Day Month Year (2001)
of manufacture
Note
The code letters for the gearbox are also given on the vehicle data
stickers.
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
1. Gearbox identification 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Notes on CVT gearbox type “multi‐
tronic 01J (front-wheel drive)”
Detailed information on the basic principle of this gearbox ⇒ Self-
study programme No. 228 ; CVT gearbox multitronic 01J .
Note
The multitronic 01J is also referred to as “Continuously Variable
Transmission”, in short “CVT”.
Guided Fault Finding
Before commencing any repair work, always perform the “Guided
Fault Finding procedure” using vehicle diagnostic, testing and in‐
formation system -VAS 5051 A- .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
2 Rep. Gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3 Code letters, gearbox allocation, ra‐
tios, equipment
Front-wheel drive
multitronic 01J.G 01J.B 01J.B
Gearbox Code letters GVN GXU HCQ
Manufac‐
tured
from
to
06.03 05.04
05.05
07.03
05.04
Allocation Model Audi A8 2003 ▸ Audi A8 2003 ▸ Audi A8 2003 ▸
Engine 3.0 ltr. MPI 5V -
160 kW
3.0 ltr. MPI 5V -
162 kW
3.0 ltr. MPI 5V -
162 kW
Input stage 51 : 46 1.109 51 : 46 1.109 51 : 46 1.109
Final drive 41 : 8 5.125 43 : 9 4.778 43 : 9 4.778
multitronic 01J.M 01J.B 01J.B
Gearbox Code letters HJA HRZ HVA
Manufac‐
tured
from
to
05.05 03.05
05.05
05.05
Allocation Model Audi A8 2003 ▸ Audi A8 2003 ▸ Audi A8 2003 ▸
Engine 3.2 ltr. 4V FSI
-191 kW
3.0 ltr. MPI 5V -
162 kW
3.0 ltr. MPI 5V -
162 kW
Input stage 49 : 48 1.021 51 : 46 1.109 51 : 46 1.109
Final drive 43 : 9 4.778 43 : 9 4.778 43 : 9 4.778
multitronic 01J.M 01J.M 01J.M
Gearbox Code letters JLN JSP KEN
Manufac‐
tured
from
to
11.05 05.06 05.08
Allocation Model Audi A8 2003 ▸ Audi A8 2003 ▸ Audi A8 2003 ▸
Engine 3.2 ltr. 4V FSI
-191 kW
3.2 ltr. 4V FSI
-191 kW
3.2 ltr. 4V FSI
-191 kW
Input stage 49 : 48 1.021 49 : 48 1.021 49 : 48 1.021
Final drive 43 : 9 4.778 43 : 9 4.778 43 : 9 4.778
multitronic 01J.M 01J.C 01J.B
Gearbox Code letters KEP KFT KRH
Manufac‐
tured
from
to
05.08 05.08 05.08
Allocation Model Audi A8 2003 ▸ Audi A8 2003 ▸ Audi A8 2003 ▸
Engine 3.2 ltr. 4V FSI
-191 kW
2.8 ltr. 4V FSI -
154 kW
2.8 ltr. 4V FSI -
154 kW
Input stage 49 : 48 1.021 53 : 45 1.178 51 : 46 1.109
Final drive 43 : 9 4.778 43 : 9 4.778 43 : 9 4.778
multitronic 01J.C 01J.B 01J.M
Gearbox Code letters KRV KRW KTE
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
3. Code letters, gearbox allocation, ratios, equipment 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
multitronic 01J.C 01J.B 01J.M
Manufac‐
tured
from
to
09.07 11.07 09.07
Allocation Model Audi A8 2003 ▸ Audi A8 2003 ▸ Audi A8 2003 ▸
Engine 2.8 ltr. 4V FSI -
154 kW
2.8 ltr. 4V FSI -
154 kW
3.2 ltr. 4V FSI
-191 kW
Input stage 53 : 45 1.178 51 : 46 1.109 49 : 48 1.021
Final drive 43 : 9 4.778 43 : 9 4.778 43 : 9 4.778
multitronic 01J.M
Gearbox Code letters KTF
Manufac‐
tured
from
to
09.07
Allocation Model Audi A8 2003 ▸
Engine 3.2 ltr. 4V FSI
-191 kW
Input stage 49 : 48 1.021
Final drive 43 : 9 4.778
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
4 Rep. Gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4 Capacities
ATF section in gearbox
Capacities Gearbox multitronic
Initial filling approx. 7.5 ltr. 01J
Changing 4.5 … 5.0 ltr.
Change interval for ATF⇒
Maintenance tables
Lubricant ATF for CVT gearbox
ATF for CVT gearbox is available as a replacement part ⇒ Elec‐
tronic parts catalogue
Caution
The ATF required for the multitronic 01J gearbox is different to
the ATF used for fixed-ratio automatic gearboxes. Only the
ATF available as a replacement part for the CVT gearbox may
be used in the gearbox.
Checking ATF level and changing ATF ⇒ page 65
Front final drive
Capacities Front final drive multitronic
Initial filling approx. 1.3 ltr. 01J
Changing No change intervals
Lifetime filling
No change required un‐
less repair work has been
performed (max. 1.3 ltr.)
Lubricant Gear oil for multitronic
Gear oil for multitronic is available as a replacement part ⇒ Elec‐
tronic parts catalogue
Caution
The gear oil required for the multitronic 01J gearbox is different
from the oil used in fixed-ratio automatic gearboxes. Only the
gear oil available as a replacement part for the multitronic 01J
may be used in the front final drive.
Checking oil level in front final drive ⇒ page 97 .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
4. Capacities 5

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
5 Notes on towing
Caution
When the vehicle is towed, the selector lever must be set to
position “N” and the vehicle must not be towed for a distance
of more than 50 km or at a speed in excess of 50 km/h, as the
gearbox would otherwise be seriously damaged.
Note
It is not possible to start the engine by means of tow-starting, for
instance in the case of insufficient battery charge or if the starter
is not working.
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
6 Rep. Gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
6 Repair instructions
6.1 Contact corrosion!
General information:
Contact corrosion can occur if non-approved fasteners such as
bolts, nuts, washers etc. are used on the vehicle.
For this reason, only fasteners with a special surface coating are
fitted. These parts can be identified by their greenish colour.
Rubber, plastic and adhesives also consist of non-conductive
materials.
If you are not sure whether used parts can be re-installed, always
fit new parts.
The following applies in particular to gearboxes:
♦ The housing of the multitronic gearbox 01J is made of a mag‐
nesium alloy.
♦ Bolts and other components which have direct contact with the
gearbox have a surface coating which is compatible with the
magnesium gearbox housing.
♦ On gearboxes built of magnesium, the bolts must always be
renewed on the following bolted connections: gearbox cover
to gearbox housing, final drive cover to gearbox housing and
engine to gearbox.
♦ If the incorrect components are used (bolts, nuts, washers
etc.), this will cause contact corrosion. The gearbox housing
will be damaged.
♦ The gearbox housing, gearbox cover and cover for final drive
must also all be of the same material.
♦ If you are not sure whether used parts can be re-installed, al‐
ways fit new parts.
Caution
♦ We recommend using only Audi Genuine Parts.
♦ Accessories must be approved by AUDI AG.
♦ Damage resulting from contact corrosion is not covered
by the warranty.
6.2 General repair instructions
WARNING
Prior to performing work with engine running, move selector
lever to position “P” and operate parking brake button to apply
the electronic parking brake.
Proper tools and the maximum possible care and cleanliness are
essential for satisfactory gearbox repairs. The usual basic safety
precautions also naturally apply when carrying out repair work.
A number of generally applicable instructions for the various re‐
pair procedures - which were previously repeated at numerous
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
6. Repair instructions 7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
places in the Workshop Manual - are summarised here. They ap‐
ply to the work described in this Manual.
Special tools
For a complete list of special tools used in this Workshop Manual
⇒ "Special tools, Workshop equipment"
Gearbox
♦ Observe rules for cleanliness when working on gearbox
⇒ page 9 .
♦ The engine must not be run and the vehicle must not be towed
with the end cover removed or without ATF in the gearbox.
♦ Only install clean components: do not remove replacement
parts from packaging until just before installation.
♦ After installing, the following fluid levels must be checked and
topped up if necessary: ATF in planetary gearbox
⇒ page 65 and gear oil in front final drive ⇒ page 97 . Ca‐
pacities and specifications ⇒ page 5
O-rings, oil seals, gaskets
♦ Always install new O-rings, oil seals and gaskets.
♦ After removing gaskets and seals, always inspect the contact
surface on the housing or shaft for burrs resulting from removal
or for other signs of damage.
♦ Thoroughly clean housing joint surfaces before assembling.
♦ Lightly lubricate the outer circumference and sealing lip of
seals with ATF before installing.
♦ Lightly lubricate O-rings with ATF before installation to prevent
them getting crushed during assembly.
♦ Use only ATF for parts running in ATF. Other lubricants will
cause malfunction of the gearbox hydraulics.
♦ The open side of the oil seals faces toward the side with fluid
filling.
♦ When installing a new oil seal, position the seal in the housing
so that the sealing lip does not contact the shaft in the same
place as the old seal (make use of insertion depth tolerances).
♦ After installing, the following fluid levels must be checked and
topped up if necessary: ATF in planetary gearbox
⇒ page 65 and gear oil in front final drive ⇒ page 97 . Ca‐
pacities and specifications ⇒ page 5
Nuts, bolts
♦ Loosen bolts in reverse sequence to the specified tightening
sequence.
♦ Bolts and nuts used to secure covers and housings must be
tightened in steps according to the specified tightening se‐
quence and method.
♦ Nuts and bolts which secure covers and housings should be
loosened and tightened in diagonal sequence and in stages if
no tightening sequence is specified.
♦ The tightening torques stated apply to non-oiled nuts and
bolts.
♦ Always renew self-locking bolts and nuts.
♦ Use a wire brush to clean the threads of bolts which are se‐
cured with locking fluid. Then install bolts with locking fluid; for
locking fluid refer to ⇒ Electronic parts catalogue .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
8 Rep. Gr.00 - Technical data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Threaded holes which take self-locking bolts or bolts coated
with locking fluid must be cleaned (using a tap or similar). Oth‐
erwise there is a danger of the bolts shearing off the next time
they are removed.
Locking elements
♦ Do not over-stretch circlips.
♦ Always renew circlips which have been damaged or over-
stretched.
♦ Circlips must be properly seated in the base of the groove.
Bearings
♦ Install needle bearings so the lettering (side with thicker metal)
faces towards the installing tool.
♦ Lubricate bearings with gear oil or ATF, depending on fitting
location.
♦ Do not interchange inner or outer races of bearings of the
same size.
♦ Always renew the tapered roller bearings on one shaft togeth‐
er and use new bearings from a single manufacturer.
Shims
♦ Use a micrometer to measure the shims at several points.
Tolerance variations make it possible to obtain the exact shim
thickness required.
♦ Check for burrs and damage. Install only shims which are in
perfect condition.
Guided Fault Finding
Before commencing any repair work, always perform the “Guided
Fault Finding procedure” using vehicle diagnostic, testing and in‐
formation system -VAS 5051 A- .
6.3 Rules for cleanliness when working on
the gearbox
♦ Thoroughly clean all joints and surrounding areas before dis‐
mantling.
♦ Place removed parts on a clean surface and cover them over.
Use sheeting and paper. Use lint-free cloths.
♦ Carefully cover or seal open components if repairs cannot be
carried out immediately.
♦ Only install clean components: do not remove replacement
parts from packaging until just before installation.
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
6. Repair instructions 9

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
13 – Crankshaft group
1 Damper unit, for description refer to:
Engine, mechanics; Repair group 13
See the corresponding Workshop Manual ⇒ Rep. Gr. 13 for a
description of how to remove and install the damper unit.
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
10 Rep. Gr.13 - Crankshaft group

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
37 – Controls, housing
1 Electrical/electronic components and fit‐
ting locations
1. Diagnostic connector
♦ Fitting location: diagnostic connector -arrow- is located below
knee padding on left side of steering wheel.
2. Selector lever lock solenoid -N110-
♦ Fitting location: The selector lever lock solenoid -N110- is a
fixed component of the selector mechanism -arrow- and can
only be renewed together with the shift unit.
3. Control unit for automatic gearbox -J217-
♦ Fitting location: The multitronic gearbox control unit -J217- is
fitted to the rear end of the gearbox, directly onto the hydraulic
control unit.
The components listed below are integrated in the automatic
gearbox control unit -J217- :
A - Gearbox output speed sender -G195- and gearbox output
speed sender 2 -G196-
B - Gearbox oil temperature sender -G93-
C - Multi-function switch -F125-
D - Gearbox input speed sender -G182-
E - Automatic gearbox hydraulic pressure sender 1 -G193-
F - Automatic gearbox hydraulic pressure sender 2 -G194-
Note
♦ The automatic gearbox control unit -J217- is monitored via
self-diagnosis.
♦ Removing and installing automatic gearbox control unit -J217-
⇒ Servicing multitronic 01J and 0AN; Rep. Gr. 38 .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
1. 11

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4. Hydraulic control unit
♦ Fitting location: The hydraulic control unit is bolted to rear end
of gearbox. The multitronic gearbox control unit -J217- is fitted
directly onto the hydraulic control unit.
A - Connector for automatic gearbox pressure control valve 1 -
N215-
B - Connector for automatic gearbox pressure control valve 2 -
N216-
C - Connector for solenoid valve 1 -N88-
Note
Removing and installing hydraulic control unit ⇒ Servicing
multitronic 01J and 0AN; Rep. Gr. 38 .
The following valves are integrated into the hydraulic control unit
(not shown in illustration):
♦ Automatic gearbox pressure control valve 1 -N215- (clutch
solenoid valve)
♦ Automatic gearbox pressure control valve 2 -N216- (solenoid
valve for transmission ratio)
♦ Solenoid valve 1 -N88- (clutch cooling/safety shut-off).
♦ Clutch cooling valve
♦ Minimum-pressure valve
♦ Pressure limiting valve
♦ Clutch control valve
♦ Control-pressure valve
Note
♦ The valves are checked by self-diagnosis
♦ Description and function of the individual valves ⇒ Self-study
programme No. 228 ; CVT gearbox multitronic 01J .
5. tiptronic switch -F189-
♦ Fitting location: The tiptronic switch -F189- is integrated in the
printed circuit of the symbol panel, which is located in the se‐
lector mechanism cover.
Note
♦ If malfunctions occur in the tiptronic switch -F189- , first check
that the magnet on the transverse slide of the sliding cover is
secured properly. If necessary, renew sliding cover. The prin‐
ted circuit must only be renewed after the wiring has been
checked.
♦ Removing and installing tiptronic switch -F189- ⇒ page 18 .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
12 Rep. Gr.37 - Controls, housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
6. Kick-down switch -F8-
♦ Fitting location: The kick-down switch -F8- is bolted onto the
floor under the pedals.
Note
♦ The kick-down -F8- switch is tested via Self-diagnosis.
♦ Removing and installing kick-down switch -F8- ⇒ Fuel supply
system, petrol engines; Rep. Gr. 20 .
7. Selector lever position display -Y6-
♦ Fitting location: The selector lever position display -Y6- is in‐
tegrated in the instrument cluster.
Note
♦ If all the characters in the display light up together, this indi‐
cates a simple fault.
♦ A flashing display indicates a critical fault.
♦ A blank display indicates defective wiring or a defective se‐
lector lever position display -Y6- .
♦ If the selector lever position indicator -Y6- is defective, renew
the instrument cluster ⇒ Electrical system; Rep. Gr. 90 .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
1. 13

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Checking ignition key removal lock
WARNING
Prior to performing work with engine running, move selector
lever to position “P” and operate parking brake button to apply
the electronic parking brake.
– Turn the ignition key slightly clockwise to the “ignition on” po‐
sition.
– Press and hold brake pedal.
• When interlock button in selector lever handle is pressed, it
should be possible to move selector lever out of position “P”
without “catching”.
– Switch off ignition.
• It should not be possible to remove the ignition key when the
selector lever is in any position other than “P”.
– Shift selector lever to position “P”.
– Remove ignition key.
• It should only be possible to remove ignition key in selector
lever position “P”.
• Selector lever can then not be shifted out of “P” position with
interlock button pressed and brake pedal depressed.
If the ignition key removal lock does not function as described:
– Check entry and start authorisation control unit -J518- in func‐
tion “Guided fault finding” ⇒ Vehicle diagnosis, testing and
information system VAS 5051.
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
14 Rep. Gr.37 - Controls, housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3 Checking selector mechanism
WARNING
Prior to performing work with engine running, move selector
lever to position “P” and operate parking brake button to apply
the electronic parking brake.
♦ It should not be possible to operate the starter while the se‐
lector lever is in position “S”, “D”, “R” or in the “tiptronic gate”.
♦ When travelling at speeds above 5 km/h and shifting into se‐
lector lever position “N”, the solenoid for the selector lever lock
must not engage and block the selector lever. The selector
lever can be shifted into a driving gear.
♦ When travelling at speeds below 5 km/h (almost stationary)
and shifting into selector lever position “N”, the solenoid for the
selector lever lock should only engage after about 1 second.
Selector lever cannot be shifted out of “N” position until brake
pedal is depressed.
Selector lever in “P” position and ignition switched on:
– Do not depress brake pedal.
• Selector lever is locked and cannot be shifted out of “P”posi‐
tion. Solenoid for selector lever lock blocks selector lever.
– Press and hold brake pedal.
• Solenoid for selector lever lock releases selector lever. It is
possible to shift into a driving gear. Shift selector lever slowly
from “P” position through “R, N, D and S” and check whether
the display in the instrument cluster shows the correct selector
lever position in each case.
Selector lever in “N” position and ignition switched on:
– Do not depress brake pedal.
• After a short waiting time: Selector lever is locked and cannot
be shifted out of “N”position. Solenoid for selector lever lock
blocks selector lever.
– Depress brake pedal.
• Solenoid for selector lever lock releases selector lever. It is
possible to shift into a driving gear.
Selector lever in position “D”, ignition and lights switched on:
– Shift selector lever into “tiptronic gate”.
• The illuminated “D” symbol in the selector lever position dis‐
play should go out and the “+” and “-” symbols should light up.
• The selector lever position indicator in the instrument cluster
should switch from “PRNDS” to “7654321” when the selector
lever is shifted into the “tiptronic gate”.
– Adjust selector lever cable ⇒ page 33 .
– Checking ignition key removal lock ⇒ page 14 .
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
3. Checking selector mechanism 15

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4 Servicing selector mechanism
WARNING
Prior to performing work with engine running, move selector
lever to position “P” and operate parking brake button to apply
the electronic parking brake.
4.1 Exploded view - selector mechanism cover, selector lever handle
1 - Guide for sliding cover
❑ To separate the two
halves, lever out the re‐
taining tabs, see "Re‐
moving tiptronic switch -
F189- " ⇒ page 18 .
2 - Sliding cover
❑ With integrated magnet
for tiptronic switch -
F189- on transverse
slide.
❑ Removing and installing
⇒ “4.4 Removing and in‐
stalling tiptronic switch
F189 ”, page 18
3 - Frame with printed circuit
❑ With printed circuit; can
only be renewed as
complete unit
❑ With integrated tiptronic
switch -F189-
❑ With symbol illumination
switches
❑ If malfunctions occur in
the switches, first check
that the appropriate
magnet on the sliding
cover
⇒ Item 2 (page 16) is se‐
cured properly. If neces‐
sary, renew sliding cov‐
er.
❑ The printed circuit can
be checked via “Guided
Fault Finding”
❑ Removing and installing
⇒ page 18
❑ Before renewing printed circuit when fault memory indicates fault code “18161”, first check adjustment
of selector lever cable ⇒ page 33
4 - Selector lever handle
❑ Removing and installing ⇒ page 17
❑ Different versions (according to model) ⇒ Electronic parts catalogue
5 - Sleeve for selector lever
❑ Removing and installing ⇒ “4.2 Removing and installing selector lever handle”, page 17
Audi A8 2003 ➤
multitronic 01J, front-wheel drive - Edition 11.2007
16 Rep. Gr.37 - Controls, housing
