Audio Control ACR User manual

IN-DASH CONVENIENCEREMOTE LEVEL CONTROL
AUDIOCONTROL ACCESSORIES

COMPATIBLE WITH COMPATIBLE WITH COMPATIBLE WITH
REMOTE LEVEL CONTROL
Placement And Mounting of Optional Dash Remote:
The dash control may be mounted under the dash using its own bracket or
through a custom hole in the dash. It should be within reach of the driver and in
a spot where the LED is plainly visible.
Bracket Installation: The dash control mounts with two screws,
which attach to the underside of the dashboard. Slide under the
dash and place the dash control in its mounting position, mark the
two mounting holes, drill pilot holes, and secure with two screws.
Custom Installation: For that custom, nished look, the dash control can be ush
mounted directly on the dash-board (or anywhere else). Referencing the drawing
right, disassemble the dash control from the mounting bracket. Drill a 9/32”(7 mm)
hole in the dashboard for the control along with a 3/32”(2.3 mm) hole for the lock tab
and a 1/8” (3 mm) hole(s) for the LED holder. Reassemble the dash control components
on the dashboard.
Available Models
LC2i™, LC6i™, LC7i™,
Overdrive™ Plus, Matrix™ Plus,
6XS, The Epicenter®, LC-4.800™
LCQ-1™,
The Epicenter® Plus
DQ-61™, DQDX™, LC8i™
DM-608™, DM-810™, D-4.800™
