Audio Control ACR-U User manual

UPGRADE ACCESSORY
PRECISE AND TACTILE REMOTE LEVEL CONTROL
ADD VOLUME CONTROL TO ANY LINE-LEVEL SIGNAL
REMOTE CAN BE FLUSH-MOUNTED FOR CUSTOM INSTALLATIONS
UNIVERSAL REMOTE LEVEL CONTROL

851523 00797 3
What’s Included?
ACR-U Remote, ACR-U Hub, Cat5e Cable (0.5 meter)
Quick Start:
1. Install the ACR-U Hub between a line level source (head unit, DSP,
EQ, Crossover) and your amplifier
2. Connect the output of your line level source to the input of the
ACR-U Hub
3. Connect the output of the ACR-U Hub to your amplifier
4. Connect the ACR-U Remote to the ACR-U Hub using the included
20 inch (0.5 meter) Cat5e cable*
5. The ACR-U Remote and Hub can be mounted using the integrated
mounts. The ACR-U Remote can be disassembled for custom
flush-mount installations
Add volume control to any system
The ACR-U is a universal remote volume control which can be inserted into any line-level signal path. The ACR-U can be surface or
custom-mounted to add subwoofer level control, zone level control, total system volume control, and more to your audio system.
Installation is simple and no power is required.
*Optional 20 foot (6 meter)
Cat5e cable available for
separate purchase. Any
Cat5e cable may be used
up to 300 feet in length.
Head unit, DSP,
EQ, Crossover
UNIVERSAL REMOTE LEVEL CONTROL
22410 70th Ave West, Mountlake Terrace, WA 98043 USA
Phone [phone]
www.audiocontrol.com
SOURCE
CAT5E CABLE
ACR-U
HUB
ACR-U
REMOTE
AMPLIFIER
Specifications
Audio Channels . . . . . . . . . . . . . . . . . 2 (RCA)
Insertion Loss . . . . . . . . . . . . . . . . . . 0.017 dB
Attenuation Range. . . . . . . . . . . . . . . -97 dB
Juggling Potential. . . . . . . add 1 bean bag
Warranty . . . . . . . . . . . . . . . . . . . . . . . .5 Years
©2021 AudioControl. All rights reserved. P/N 912-073-0
