Audio Control MAESTRO X9S User manual
| | |
| | |
Immersive AV Processors & Receivers
Installation Manual
©2022. All Rights Reserved
2
X/XR Series Processors & Receivers
Important Safety
Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10. Only use attachments/accessories specified by the
manufacturer.
11. Unplug this apparatus during lightning storms or when
unused for long periods of time.
12. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
13. This apparatus shall not be exposed to dripping or
splashing, and no object filled with liquids, such as vases or
glasses, shall be placed on the apparatus.
14. The remote control is powered by two AAA batteries.
Only use new, identical batteries. Ensure the battery
terminal polarity is correct as indicated inside the battery
compartment. Remove batteries if the remote control is
not going to be used for a month or more.Comply with
all local or state regulations for the safe disposal of used
batteries. Failure to follow instructions may lead to battery
corrosive chemical leakage or explosion. Do not let your pet
dog use the remote as a chew toy. Tie the remote to a large
gold-painted brick to prevent accidental loss.
CAUTION: to reduce the risk of electric shock, do not remove
the top cover. There are no user-serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure, that may
be of sufficient magnitude to constitute a risk of electric shock
to persons.
The exclamation point within an equilateral
triangle is intended to alert the user of the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAUTION: Changes or modifications to this device not expressly
approved by AudioControl Inc. could void the user’s authority to
operate the equipment under FCC rules.
Recycling notice: If the time comes and this apparatus has
fulfilled its destiny, do not throw it out into the trash. It has
to be carefully recycled for the good of mankind, by a facility
specially equipped for the safe recycling of
electronic apparatii. Please contact your local or
state recycling leaders for assistance in locating a
suitable nearby recycling facility. Or, contact us
and we might be able to repair it for you.
CAUTION AVIS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
Important Safety Instructions
3
X/XR Series Processors & Receivers
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by AudioControl, Inc. is under license. Other
trademarks and trade names are those of their respective
owners.
Qualcomm is a trademark of Qualcomm Incorporated,
registered in the United States and other countries, used with
permission. aptX is a trademark of Qualcomm Technologies
International, Ltd., registered in the United States and other
countries, used with permission.
Dolby Atmos, Dolby Audio, Dolby Vision
Manufactured under license from Dolby Laboratories. Dolby,
Dolby Atmos, Dolby Audio, DolbyVision and the double-D
symbol are trademarks of Dolby Laboratories.
DTS:X®
For DTS patents, see http://patents.dts.com. Manufactured
under license from DTS Licensing Limited. DTS the Symbol,
DTS in combination with the symbol, DTS:X and the DTS:X
logo are registered trademarks or trademarks of DTS, Inc.
in the United States and/or other countries. © DTS, Inc. All
Rights Reserved.
DTS Virtual:X™
For DTS patents, see http://patents.dts.com. Manufactured
under license from DTS Licensing Limited. DTS the Symbol,
DTS in combination with the symbol,Virtual:X and the DTS
Virtual:X logo are registered trademarks or trademarks of
DTS, Inc. in the United States and/or other countries. © DTS,
Inc. All Rights Reserved.
IMAX® and DTS®
Manufactured under license from IMAX Corporation.IMAX®
is a registered trademark of IMAX Corporation in the United
States and/or other countries.
AAC/AAC Plus
aacPlus is a trademark of Coding Technologies. See www.
codingtechnologies.com for more information.
Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
Wi-FI Alliance.
®
Manufactured under license from Auro Technologies.
trademarks of Auro Technologies.
Google, Google Play, Chromecast, and other related marks
are trademarks of Google LLC. Chromecast built in may
require subscription(s). the Google Assistant requires an
internet connection and is not available in certain countries
and languages. Availability and reach of certain features and
services are device, service, and network-dependent and may
not be available in all areas. Controlling certain devices in
your home requires compatible smart devices. Subscriptions
for services and applications may be required and additional
terms, conditions and/or charges may apply.
Apple, AirPlay and the AirPlay logo, iPod, iPhone and iPad
are trademarks of Apple Inc., registered in the U.S. and other
countries. App Store is a service mark of Apple Inc. AirPlay
later, Mac with OS X Mountain Lion or later, and PC with
Acknowledgements
Being Roon Ready means that AudioControl uses Roon
streaming technology, for an incredible user interface, simple
setup, rock-solid daily reliability, and the highest levels of
audio performance, without compromise.
MQA (Master Quality Authenticated)
AudioControl X/XR Series Processors and Receivers include
MQA technology, MQA is an award-winning technology that
hear, MQA captures and authenticates the sound of the
original studio performance.
‘MQA’ indicates that the product is decoding and playing an
the sound is identical to that of the source material. ‘‘MQA
which has either been approved in thestudio by the artist/
Fraunhofer IIS and Thomson multimedia.
This product is protected by certain intellectual property
rights of NEMS and BridgeCo. Use or distribution of such
technology outside of this product is prohibited without a
license from NEMS and BridgeCo or an authorized subsidiary.
The Spotify software is subject to third party licenses found
here:
https://developer.spotify.com/legal/third-party-licenses/
Redistribution and use in source and binary forms, with
following conditions are met:
– Redistributions of source code must retain the above
copyright notice, this list of conditions and the following
disclaimer.
– Redistributions in binary form must reproduce the above
copyright notice, this list of conditions and the following
disclaimer in the documentation and/or other materials
provided with the distribution.
– Neither the name of the Xiph.org Foundation nor the
names of its contributors may be used to endorse or
promote products derived from this software without
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS ‘AS IS’ AND ANY EXPRESS OR IMPLIEDWARRANTIES, INCLUDING,
BUT NOT LIMITEDTO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITEDTO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, ORTORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING
IN ANY WAY OUT OFTHE USE OFTHIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
FLAC
MP3
vTuner
4
X/XR Series Processors & Receivers
..................................................................
...................................................
Front Panel Features ..................................................
Rear Panel Features.................................................
.............................................................
Unit Placement ....................................................
Speaker Considerations and Placement................................
Height Speakers....................................................
Power Wiring ......................................................
Audio Connections .................................................
Video Connections..................................................
Navigating ........................................................
.................................................
General Setup......................................................
Speaker Types .....................................................
Speaker Distance ...................................................
Speaker Levels .....................................................
Video Inputs .......................................................
HDMI Settings .....................................................
Decoding Modes ...................................................
Zone Settings ......................................................
Network Settings...................................................
Bluetooth Settings .................................................
..........................
.....................................................
..................................................
............................................................
......................................................................
...................................................................
........................................................................
...............................................................
.....................................................
5
X/XR Series Processors & Receivers
Greetings from the rainforest
On behalf of everyone at AudioControl we want to congratulate you on the
purchase of your X/XR Series Immersive AV Processor/Receiver. Whether
audio veteran, you will truly enjoy the performance of our amazing sounding
processors.
While there are many components involved in creating a truly awesome
home theater from room design, speaker placement, and ultimately system
calibration, selecting the proper products is always very critical. For that
reason AudioControl created the X/XR Series Immersive AV Processors and
to a truly awesome home theater experience.
AudioControl’s passion for high quality, meticulous attention to detail and
professional sound heritage shows itself in the dozens of awards we have
won for our designs, products and service. This manual is designed to help
you get the most from your product. Even though you’re dying to plug it in
Given the
complicated nature of this product, we also recommend you visit our website
for updates to this manual. Continued technology changes/improvements will
require more information.
Go to www.audiocontrol.com/home-audio/
Enjoy the experience.
Your Friends At AudioControl
6
X/XR Series Processors & Receivers
Key Features
AudioControl X/XR Series Processors and Receivers are equipped with a large
number of features and functions that are designed to maximize your theater
experience.
eARC - ENHANCED AUDIO RETURN CHANNEL
connectivity.
X/XR Series Processors and Receivers use the latest in signal processing
architecture these DACs deliver outstanding sound quality, the highest
low noise, isolated power supplies are fully optimized, uncompromisingly
delivering your content in the truest method known.
IMAX ENHANCED
IMAX Enhanced brings you the latest in video processing and immersive audio
without compromise.
7
X/XR Series Processors & Receivers
Dolby Vision is a proprietary, dynamic HDR format developed by Dolby Labs
which enables HDR content to be delivered with better detail and brightness
than the standard HDR format.
ANALOG PREAMPLIFIER OUTPUTS
front/rear subs, center heights, or extra wide outputs for a total immersive
experience during playback of Dolby Atmos or DTS:X encoded source
material. These outputs can also be activated when Dolby Atmos and DTS:X
encoding is not available by using Dolby Surround or DTS Virtual:X.
SURROUND SOUND FORMATS
and DTS Virtual:X surround formats, the X series delivers the latest in audio
processing.
Using the included USB microphone and an external computer on the
same network, Dirac Live measures the sound output of the system, and
automatically calibrates speaker delay, speaker level, and Room EQ.
NETWORKED AUDIO STREAMING
X/XR Series Processors and Receivers are designed to operate with most of
today’s traditional source units like streaming set top boxes and cable TV
sources. Along with this connectivity you can stream audio directly to the unit
EXTENSIVE AUTOMATION INTEGRATION
An automation system is what really pulls most high-end home theaters
together. At our website and in the product pages, you can download the most
up to date drivers and modules to control the Processor/Receiver.
AudioControl X/XR Series Processors and Receivers, like all AudioControl
labor warranty. This comes from a company that has been designing and
Pro tip - set Control
to IP and disengage
your automation
system from the
Processor/Receiver
before running Dirac
Live.
8
X/XR Series Processors & Receivers
...the deep breath before the plunge...
9
X/XR Series Processors & Receivers
Front Panel Features
input. The AUX input can be selected with
the remote control.
nice pair of headphones.
This glows a
splendid blue when the unit is on, and
dashing red when it is in standby.
Press this button to access the
Setup Menu functions.
Press to cycle the display
Selects the information that appears
on the display of the unit (also used in
navigating the Setup Menu).
These allow you to
select a source for playback (also used in
navigating the Setup Menu).
Select between stereo and the
available surround modes (also used in
navigating the Setup Menu).
Used to enter selections you have
made in the Setup Menu.
When using stereo analog
inputs, this button defeats all digital signal
processing and directs the analog input
from the selected source to the front
speaker outputs.
Mutes all analog outputs in the
currently selected zone.
Select between the Main Zone and
This front panel blue light
bar is mined directly from the R-Coronae
Australis Nebula. The brilliance of this light
can be dimmed via a button on the back
panel.
This cool crisp display allows you
functions.
This hefty controller lets you
adjust the volume in the selected zone
(speaker outputs, line-level outputs, and the
headphone output).
This toggles the mains
power. Leave this in to control the standby
state via the remote or your automation
system.
10
X/XR Series Processors & Receivers
Rear Panel Features
WiFi ANTENNA - If you are using WiFi
features, attach the included antennas here.
The Processor/
Receiver can be connected and controlled
through a computer or automation network
via this Ethernet connection. Network
parameters can be set up and accessed
through the Menu on the Front Panel.
Connect
to the line-level analog outputs of your
source units. Maestro X Series Processors
have balanced XLR inputs in addition to
unbalanced inputs for the CD and BD
sources.
Connect to the HDMI
inputs of your TV displays, your main
home theater, and an alternate display.
The main output is eARC enabled for the
latest high quality audio formats from your
enables viewing and listening to a source
independently of the main home theater
CLASS 2 WIRING
R
L
R
L
BLUETOOTHWI-FI WI-FI
STB OUTAV
STBGAMEAVSATBD
RS232
FM
ETHERNET
SPEAKER OUTPUTS
8Ω / 4Ω LOAD IMPEDANCE RECOMMENDED
UHDPVR
R
L
R
L
Z2
Z1
Z2
Z1
SBL
SBR
SL
SR
FL
FR
CENTER
SUB 1
ZONE 2 L
HEIGHT 1 L
SURR BACK LSURROUND LCENTER FRONT L
ZONE 2 R
HEIGHT 1 R
SURR BACK R SURROUND R FRONT R
eARC
MAIN
ALT ZONE 2
ZONE 1
USB 5V / 1A
HEIGHT 2 HEIGHT 1 ZONE 2
LINE OUT
SUB 2
STB GAME AV BD PVR CD
CH 13 / 14 CH 15 / 16
115 230
SWITCH POSITIONS
115 = 110 - 115 V ~
230 = 220 - 240 V ~
交流输入
AC INLET
~ 50 - 60 Hz 1.5 KW MAX
PVR
CD
SAT
BD
FRONT LEDS
IRTRIGDIGITAL AUDIO
ANALOG
INPUTS
PREAMP OUTPUTS
22410 70th Ave West | Seattle, WA 98043
www.audiocontrol.com
Serial Number
CAUTION – SHOCK HAZARD, DO NOT OPEN
ATTENTION – RISQUE DE CHOC, NE PAS ENLEVER
PRECAUCION – PELIGRO DESCARGA, NO ABRIR
ACHTUNG – VOR OEFFNEN DES GERAETES
NETZSTECKER ZIEHEN
THIS DEVICE COMPLIES WITH PART15 OF THE FCC RULES.
OPERATIONIS SUBJEC TTO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAYNOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANYINTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THATMAY CAUSE UNDESIRED OPERATION.
Manufactured under license from Dolby Laboratories.
Dolby, DolbyVision, Dolby Atmos, and the double-D symbol are
trademarks of Dolby Laboratories.
For DTS patents,see https://patents.dts.com.
HDMI, the HDMI logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under license from Auro Technologies.
CAN ICES-3(B)/NMB-3(B)
BD LCD L
BD RCD R
BALANCED ANALOG OUTPUTSBALANCED ANALOG INPUTS
CHANNEL 15CHANNEL 13HEIGHT 2 LHEIGHT 1 LSURR BACK LSURROUND L CENTERFRONT L
CHANNEL 16CHANNEL 14HEIGHT 2 RHEIGHT 1 RSURR BACK RSURROUND R SUB 1FRONT R
11
X/XR Series Processors & Receivers
-This antenna input
should be connected to the supplied FM
antenna. For improved reception, you may
want to consider a roof-mounted external
antenna.
There are
each labeled with the name of a typical
source unit. Connect these to the digital
outputs of your source units.
- Connect digital audio and
video signals from source units equipped
with HDMI outputs. Make sure your
HDMI cables are properly inserted into
these connectors and that there no sharp
“pulls” on the cable that may prevent
your connectors from making a complete
reduces transmission losses resulting in a far
more stable connection than other HDMI
transport solutions.
Provides a digital
audio output of the program material
These
source units, video projectors, screens and
curtains in the home theater (the external
equipment should have corresponding
These jacks
enable the use of external IR sensors for
installations where it is not desirable (or
is used to connect to an external IR sensor
Use this
connection to control your Processor/
Receiver with an automation system.
If you are using WiFi
features, attach the included antennas here.
Press
this button to set the desired luminescence
of that nebulistic front panel light bar to
Similar to the
WiFi antenna, if you plan to use Bluetooth
devices for streaming, connect antenna here
to ensure the best possible connection.
-
output impedance, are at line level, and
can be supplemented or replaced with an
Savoy
). Connect the subwoofer outputs to your
active subwoofer(s).
The surround back outputs can be used to
to biamp the front speakers.
Maestro X Series Processors have balanced
XLR preouts in addition to the unbalanced
preouts for connecting to an external
Connect to an
- AudioControl
X/XR Series Processors and Receivers allow
you to connect up to sixteen speakers.
Maestro X Series Processors are designed to
all channels.
connect the main speakers for your two,
12
X/XR Series Processors & Receivers
The supplied remote control is an
eight device “universal” IR remote
controller with back-lit gum-drop
buttons. Use the remote for full
control of the Processor/Receiver,
plus various AV sources and displays
via the extensive library of device
codes. A complete list of codes is
available on our Knowledge Base at:
audiocontrol.com/knowledge-base/.
The remote is also a “learning
remote” which means that you can
capture the codes of your existing
does not contain the codes for your
device.
Many of the buttons have more than
one function, depending on which
device/source or mode you are using
the remote in. We will ease into
the complexities of the remote’s
multi-function modes after a quick
description of the basic features
below.
Please note: Device code library,
instructions on programming
the remote and more control
and automation documents are
available on our Knowledge Base at:
audiocontrol.com/knowledge-base/
The speaker terminals labeled surround
right, front right, center, front left, and
surround left, should only be connected
to the passive speakers as labeled. For
example, make sure that only a center
speaker is connected to the center
speaker terminal.
back speakers, Dolby Atmos and
DTS:X speakers, or to biamp the front
speakers. Use the Setup Menu to select
which speakers are being used.
The
Processor/Receiver is designed to
WARNING: Before the unit is
turned on, make sure that this
switch is set to your local AC
power voltage.
Connect the supplied AC
power cord securely to this input. Plug
the other end into an AC mains outlet
of the correct voltage rating for your
Hz); check the position of the Voltage
Selection switch on the rear panel to
- A fan is used to cool down the
Concert XR Series Receiver.
CAUTION: Do not block the fan
or any of the ventilation slots.
There should always be plenty of
good ventilation to cool the unit.
13
X/XR Series Processors & Receivers
Remote Features
Multifunction Remote -
the source buttons.
Learning -
source, such as the CD player, or Cable box.
LED indicator - This top red LED will blink when a key is pressed. It will also
blink multiple times when a device code is input for programming or signal
the beginning and end of a programmed sequence.
The keys are back-lit to make it easy for you to control your
devices in a dimly lit room.
Low Voltage Indicator -
press to tell you that new batteries are needed.
Other useful items
Time Out -
seconds after the last button is pressed, the remote returns to normal
operation.
If the remote has slipped into the cushions of your
stop sending IR information to conserve the battery. It will resume normal
operation after the button has been released.
General Functions
The Device or Source keys allow you to switch between the various inputs
on your Processor/Receiver. After pressing the device key, the remote
So if you have programmed the AV with the learned codes from an
Apple TV remote – after pressing the AV button, the remote buttons will
The volume control remains locked to the Processor/Receiver “AMP”
mode however. This ensures that anytime you press these keys, you are
controlling the Volume or Mute state of the Processor/Receiver regardless
of the device you are controlling (Blu-ray player or Cable box for instance).
Multifunction Remote
LED Indicator
14
Access the main system menu
for your Processor/Receiver.
Allows for navigation on
any menu in the Processor/
Receiver. This includes
using the USB input, and the
NET input.
Turns the Dirac Live EQ on or
Temporary subwoofer trim.
Use the left and right arrows to
adjust the subwoofer volume.
The settings are not remem-
bered when the unit is turned
Returns to the top level (home)
menu when using the network
menus.
Cycle through the available
surround modes.
Adjusts the front panel display
brightness.
Returns remote to Processor/
Receiver (AMP) control mode.
Stereo Direct mode toggle
processing on your analog
input source so that there is a
direct path from the input to
the amp.
Single press - toggles your
Processor/Receiver on, or back
to standby.
Press and hold - Forces both
Zones to Standby.
These number keys are used to
enter numeric values.
Cycle through the info
displayed on the front panel
display, when on Tuner, NET or
USB inputs.
Adjust the synchronization of
the video and audio. Use the
left and right arrow buttons to
make the adjustment.
In USB or NET radio, use these
as track controls: select next
track, previous track, stop,
play, pause.
Brings up the DTS:X dialog
control adjustment
X/XR Series Processors & Receivers
Pressing the AMP button puts the remote into the correct mode for controlling
the functions of the Processor/Receiver. This allows you to access the menus,
Please note: Not all buttons have a function in AMP mode.
15
Increase volume
Decrease volume
only, no matter which mode
the remote is in
Red and Green are used with
NET radio to add or delete a
favorite station. These buttons
the remote is not in AMP
mode.
Select TUNER input and
changes remote to control the
tuner interface.
Select AUX input.
Select Network/Ethernet
source and changes remote to
network control.
Select USB input source
and changes remote to USB
control.
Select the AV Input and chang-
es remote to AV control.
Select Satellite input and
changes remote to satellite
receiver control.
Select PVR (personal video
hard disk recorder) and chang-
es remote to PVR control.
Select Game input changes
remote to game control.
Select Blu-ray input and
changes remote to Blu-ray/
DVD control.
Select CD input changes
remote to CD control.
Select STB (Set Top Box –
cable box usually) as input and
change remote to STB control
Select UHD input and changes
remote to UHD control
UHD
X/XR Series Processors & Receivers
HTR-3 Remote
16
X/XR Series Processors & Receivers
Unit Placement
X/XR Series Processors and Receivers can be placed almost anywhere in your
audio equipment stack. It is good practice to ensure that the equipment
location is properly ventilated and to make certain not to block the ventilation
slots on this or any other component. We recommend placing it so there
is at least one foot of free space above, to the sides, and to the rear. Avoid
any other components that generate a lot of heat. Unless they are made
transformers that can induce hum into other audio components.
To present the most realistic sound stage, all three of the
front speakers must be tonally balanced. Ideally, these
speakers should be identical models.This ensures that the
sound doesn’t change as it pans across the screen. Place the
speakers at the seated ear level. Whenever possible, the three
front speakers should also be placed at the same horizontal
level for best imaging.
Wide speakers create a cohesive immersive sound stage that mitigates any
gaps in panning from the front stage to the side stage. Accordingly, these
wide speakers should be placed between the front stage speakers and the side
a multi-channel theater audio system. These speakers should be placed on
They should be directly to left and right sides of the listening position. If you
are using surround speakers, which have a dipole sound pattern, they should
be mounted in-line with the main seating position. If the surrounds are direct
radiator, they should be just behind the main listening seat.
listeners. Additionally, they should be mounted close together on the rear wall
of the theater facing the screen.
17
X/XR Series Processors & Receivers
Subwoofer(s)
The subwoofer is a large speaker that provides the bottom end “kick” in the
system. Depending on the size of your listening space, you may require more
than one subwoofer to get the bass volume levels that you desire. Outputs
drive Front and Rear subs discretely. Make certain you remember to include
the size of all spaces that are open to the theater in determining how many
subwoofers you need.
Up to six extra speakers may be used for Dolby Atmos or
DTS:X systems. One, two or three pairs of speakers (known
you to be surrounded in an amazing “dome of sound.”
Dedicated speakers for this application can be mounted in
We recommend that you research information directly from
wonderful systems.
If you are using just one pair of speakers, connect them as
the listening position and the display, either ceiling-installed,
just in front of your listening position.
Channels 13-16
Channels 13 & 14: Channel 15 & 16:
Front Wide Surrounds Middle Heights
Front Subwoofer Height Center
Rear Subwoofer
This is just an overview, so do your research carefully and talk with your dealer.
18
X/XR Series Processors & Receivers
Connection Tips
•
• When making connections, make sure that “left goes to left” and “right
goes to right.” The obvious and time-honored way to assure this is to
assign RED plugs to Right and WHITE/GREY/BLACK plugs to the left.
Yellow is usually used for video cables or digital audio connections.
• Wherever possible, keep power cords away from signal cables (inputs
from media players, cable box) to prevent induced hum. Bundle all power
cords down one side of your equipment cabinet and all the signal cables
down the other.
• If you need to run a long cable to the projector or TV, save yourself
transport.
• Use high quality interconnect cables. We’re not going to get into the
sound and picture quality of your system. We do know from experience
however that really, REALLY cheap connections can cause problems.
Power Wiring
Like many of today’s intelligent home electronics, the Processor/Receiver
should be plugged into an unswitched AC outlet so that it always has power.
Processor/Receiver is in standby. We always recommend the use of a high
quality surge protection device to keep all of your electronics safe from the
evils of spikes on power systems.
Audio Connections
labeled STB, AV, GAME, BD, PVR, and CD.The input circuits are all identical, so
you can connect any line-level analog audio source to any of these inputs.
optical digital audio inputs, labeled STB and AV.
digital audio through the HDMI connection. In these cases, you can also
connect the digital audio in addition to HDMI. This will provide the digital
audio signal necessary for high-quality digital surround sound.
19
X/XR Series Processors & Receivers
Video Connections
The Processor/Receiver is equipped with seven discrete HDMI inputs labeled
outputs
Main Output - Connect this to the primary display device located in your main
theater. This output is eARC enabled and includes CEC functions which can be
Alt Output - Connect this to your secondary display device.
Connect this to your display and system used in the second zone
eARC (Audio Return Channel)
The Main Output is compatible with HDMI Enhanced Audio Return Channel
(eARC). If you have a supported television then sound from the television’s
internal streaming services or connected sources will be available using the
Processor/Receiver’s ‘Display’ input.
IR (Infrared) Remote Control Connections
The Processor/Receiver has two rear-panel Infrared (IR) inputs to allow for
to place an external infrared receiver where it can “see” the signal from the
remote control when the main equipment may be hidden. The IR connections
jacks with “Tip” being the modulated signal and “Sleeve” being ground.
This is ideal to use when the front panel of the Processor/
Receiver is hidden away in some dark closet or equipment rack.To prevent the
possibility of receiving multiple commands, when you connect an IR receiver
to this input, it will disable the front panel IR receiver.
(Zone
any other purpose such as jump starting the old car on a frosty morning.
20
O
Input Config
General Setup
Speaker Types
Speaker Distances
Speaker Levels
Video Inputs
HDMI Settings
Zone Settings
Network
Bluetooth
X/XR Series Processors & Receivers
Setup Menus
This section of the manual discusses how to navigate the set-up menus of
the Processor/Receiver. X/XR Series Processors and Receivers are incredibly
performance theater system. While the set-up menus incorporate a number of
default settings that we determined will work well with many theater systems,
you will want to take the time to go through each of these set-up screens and
make the appropriate adjustments to the settings.
To get started in your set up, you can work directly from the front panel of the
to the set up options through a web browser by going to its IP address/setup
[http://your IP address/setup/]. The web page menus follow the same format as
the front panel menus noted below.
Front panel display: Main Menu
