User Guide
Space™Series
LOW-PROFILE SUBWOOFER
SPC-10S2 | SPC-10S4 | SPC-12S2 | SPC-12S4
Features
• Maximum bass when there's little space
• Rugged, weather-resistant design
• Removable subwoofer grille
• Structurally rigid heavy duty voice coil
• Optimal thermal eciency design
• Fiber matrix injection molded polypropylene cone
• Bass: The Final Frontier

2
User Guide
Space™Series
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not submerge this apparatus in water.
6. Clean only with a dry cloth.
7. WARNING: The subwoofer enclosure must be properly secured in the
vehicle. Improper installation may lead to permanent injury or death.
Installation of the speaker enclosure must be done with great care by
qualied personnel, to prevent damage to fuel lines, power and other
electrical wiring, hydraulic brake lines, and other systems, that might
compromise vehicle safety.
8. Use speaker wire of sucient size to ensure adequate current to the speak-
er. For Space Series Subwoofers, this means 10-14 gauge speaker wire.
9. To prevent excessive cone excursion and potential damage to the sub-
woofer is it advisable to use a infrasonic (subsonic) lter set 1/2 octave
below Fb. (Hz)
10. Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as the power
input terminals are damaged, objects have fallen into the apparatus,
does not operate normally, or has been dropped.
11. Not tested for use in outer space.
12. Exposure to high sound pressure levels may lead to permanent hearing
loss. Take every precaution to protect your hearing.
The exclamation point within an equilateral triangle is intended to alert the
user of the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the
appliance.
Recycling notice: If the time comes and this apparatus has fullled its destiny,
do not throw it out into the trash. It has to be carefully recycled
for the good of mankind, by a facility specially equipped for the
safe recycling of electronic apparatii. Please contact your local or
state recycling leaders for assistance in locating a suitable nearby
recycling facility. Or, contact us and we might be able to repair it
for you.
Important Safety Instructions

3
Enclosure Talk
Right on! You got yourself a shiny new AudioControl subwoofer, or maybe
two. After you're done admiring the quality workmanship and attention to
detail, you need to get 'er in a proper enclosure. Enclosure is just a fancy
name for a speaker box. Below are some tips you should consider before
buying or building an enclosure. If you're not into math, or have trouble
plugging in power tools, your best bet is to seek out a qualied AudioControl
dealer. They have the skills, experience and specialized tools to get the bass
bumpin' and they usually smell alright, too.
Sealed vs. Ported Enclosure
Aaahh... the age old question: Which is better, a sealed or ported enclosure?
The answer usually boils down to a few things; available space in the vehicle,
music listening preference and the speaker manufacturer's recommendation
for enclosure type. Below are a few characteristics of sealed and ported
enclosures:
Sealed Enclosures
Smaller enclosure size
Excellent transient response
Less output per watt, but punchier, tighter sound
Lower dynamic output
Ported/Vented Enclosure
Larger enclosure size
Extended low frequency response
More bass output per watt
Better dynamic output
If you have the space, we recommend a slot vented enclosure for the best
all-around bass experience.
Enclosure Size... It Matters
Once you decide on a sealed or ported enclosure, you can ne-tune the size
of the enclosure to t your vehicle space and listening habits. For both sealed
and ported enclosures, we list recommended size ranges, (MIN - IDEAL - MAX)
for each subwoofer size in the following pages. Whether buying pre-made
or designing and building a custom enclosure, try to stay within these
parameters for the best overall performance. Below is the eect enclosure size
has on the overall sound.
The MIN value is the smallest recommended enclosure
size. It provides the most compact size, but sacrices
some low bass response. It generally provides punchy, tight bass that is great
for Rock and Country music.
The IDEAL value is recommended for most listeners.
Excellent blend of low bass, with accurate and strong
overall output. Suited well for Pop and R&B music.
The MAX value is the largest recommended enclosure
size. It's big, but provides exceptional bass output.
Perfect for all you Hip Hop and EDM fans.
MIN IDEAL MAX
MIN IDEAL MAX
MIN IDEAL MAX
Enclosure size recommendations do not include driver and / or port
displacement.

4
User Guide
Space™Series
SPC-10S2 Specications
200 400 600
MIN IDEAL MAX
WATTS RMS
Continuous Power Handling
Thiele/Small Parameters
Nominal Impedance (Z).................................................................... 2 ohms
DC Resistance (Re)..........................................................................1.8 ohms
Resonance Frequency (Fs) ...............................................................37.48 Hz
Piston Area (Sd) ............................................................................0.0330 m2
Force Factor (BL)............................................................................ 10.03 T.m
Mechanical Q Factor (Qms).................................................................4.0332
Electrical Q Factor (Qes)......................................................................0.4879
Total Q Factor (Qts).............................................................................0.4353
Sensitivity 1W/M (SPL)......................................................................86.0912
Mechanical Comp (Cms)..........................................................0.1554 mm/N
Moving Mass (Mms) ....................................................................116.0099 g
Linear Excursion (Xmax) ......................................................................9 mm
Volume Acoustic Comp (Vas)............................... 23.6364 Ltr/0.834712 cu ft
Reference Eciency (NO.)................................................................... 0.25%
RMS Power (Pe) .............................................................................400 Watts
Other Fun Facts
Frequency Response ....................................................................20–250 Hz
Voice Coil Diameter ...............................................................2.5 in/63.5 mm
Displacement ................................................................ 0.045 cu ft/1.275 Ltr
Dimensions
Overall Diameter (A)...........................................................10.39 in/264 mm
Cut Out Diameter (B) ............................................................9.13 in/232 mm
Mounting Depth (C)........................................................3.50 in/89 mm
Mounting Height (w/o Grille) (D)...................................... .0.71 in/18 mm
Mounting Height (w/ Grille) (E)..........................................1.22 in/31mm
Internal volume range (Cu.Ft.)................0.9–2.0
Enclosure tuning range (Hz).................... 33–45
Internal volume range (Cu.Ft.) ............. 0.4–0.8
A
B
C
E
D
0.4 0.6 0.8
0.9 1.4 2.0
MIN IDEAL MAX
MIN IDEAL MAX
CUBIC FEET
CUBIC FEET
Sealed Enclosure
Ported Enclosure

5
SPC-10S4 Specications
200 400 600
MIN IDEAL MAX
WATTS RMS
Continuous Power Handling
Thiele/Small Parameters
Nominal Impedance (Z).................................................................... 4 ohms
DC Resistance (Re)..........................................................................3.2 ohms
Resonance Frequency (Fs) ...........................................................37.3460 Hz
Piston Area (Sd) ............................................................................0.0330 m2
Force Factor (BL)........................................................................ 14.0082 T.m
Mechanical Q Factor (Qms).................................................................2.8618
Electrical Q Factor (Qes)......................................................................0.4044
Total Q Factor (Qts).............................................................................0.3543
Sensitivity 1W/M (SPL)......................................................................87.2957
Mechanical Comp (Cms)..........................................................0.1719 mm/N
Moving Mass (Mms) ..................................................................105.6787 g
Linear Excursion (Xmax) ......................................................................9 mm
Volume Acoustic Comp (Vas)............................... 26.1432 Ltr/0.923238 cu ft
Reference Eciency (NO.)................................................................... 0.32%
RMS Power (Pe) .............................................................................400 Watts
Other Fun Facts
Frequency Response ....................................................................20–250 Hz
Voice Coil Diameter ...............................................................2.5 in/63.5 mm
Displacement ................................................................ 0.045 cu ft/1.275 Ltr
Dimensions
Overall Diameter (A)...........................................................10.39 in/264 mm
Cut Out Diameter (B) ............................................................9.13 in/232 mm
Mounting Depth (C)........................................................3.50 in/89 mm
Mounting Height (w/o Grille) (D)...................................... .0.71 in/18 mm
Mounting Height (w/ Grille) (E)..........................................1.22 in/31mm
A
B
C
E
D
0.4 0.6 0.8
0.9 1.4 2.0
MIN IDEAL MAX
MIN IDEAL MAX
CUBIC FEET
CUBIC FEET
Sealed Enclosure
Ported Enclosure
Internal volume range (Cu.Ft.)................0.9–2.0
Enclosure tuning range (Hz).................... 33–45
Internal volume range (Cu.Ft.) ............. 0.4–0.8

6
User Guide
Space™Series
SPC-10S2/10S4 Ported Enclosure
Material Prep
Specications
Top / Bottom 24.00" × 12.00" 2
Front 21.50" × 13.00" 1
Rear 24.00" × 13.00" 1
Left 10.50" × 13.00" 1
Right 11.25" × 13.00" 1
Port 1 10.25" × 13.00" 1
Port 2 8.75" × 13.00" 1
24.00” 12.00”
14.50”
12.00”
13.00”
10.50”
21.50” 10.50”
PORT 1
PORT 2
* Please note there are no ngers mentioned in the
list above. Cut safe my friends.
External Dimensions......... 24.00" W × 14.50"H × 12.00"D
Net Internal Volume ......................................................1.40 ft3
Total Internal Volume.......................................................1.75 ft3
Gross External Volume....................................................2.38 ft3
Material Thickness..................................................................0.75"
Tuning Frequency................................................................ 40 Hz
Port Area.......................................................................22.75 inch2
Port Inlet ............................................................1.75"W× 13.00"H
Port Length ............................................................................22.25"
F3 (Hz)...............................................................................................34
Enclosure Example
FRONT VIEW LEFT SIDE
TOP VIEW

7
SPC-10S2/10S4 Sealed Enclosure
Material Prep
Specications
Front / Rear 26.00" × 14.50" 2
Top / Bottom 26.00" × 3.50" 2
Left / Right 13.00" × 3.50" 2
14.50”
13.00”
3.50”
26.00”
26.00”
BOTTOM BOTTOM
PORT 2
RIGHT
* Please note there are no ngers mentioned in the
list above. Cut safe my friends.
External Dimensions............26.00" W × 14.50"H × 5.00"D
Net Internal Volume ......................................................0.60 ft3
Total Internal Volume.......................................................0.65 ft3
Gross External Volume....................................................1.09 ft3
Material Thickness..................................................................0.75"
F3 (Hz)...............................................................................................60
Qtc................................................................................................0.703
Enclosure Example
TOP / BOTTOM
LEFT / RIGHT
FRONT / REAR
5.00”
3.50”

8
User Guide
Space™Series
SPC-12S2 Specications
200 400 600
MIN IDEAL MAX
WATTS RMS
Continuous Power Handling
Thiele/Small Parameters
Nominal Impedance (Z).................................................................... 2 ohms
DC Resistance (Re)..........................................................................1.8 ohms
Resonance Frequency (Fs) ...........................................................27.8430 Hz
Piston Area (Sd) ............................................................................0.0511 m2
Force Factor (BL)........................................................................ 10.3379 T.m
Mechanical Q Factor (Qms).................................................................4.0762
Electrical Q Factor (Qes)......................................................................0.4703
Total Q Factor (Qts).............................................................................0.4216
Sensitivity 1W/M (SPL)......................................................................87.3655
Mechanical Comp (Cms)..........................................................0.2047 mm/N
Moving Mass (Mms) ....................................................................159.6086 g
Linear Excursion (Xmax) ......................................................................9 mm
Volume Acoustic Comp (Vas)............................... 74.5578 Ltr/2.632984 cu ft
Reference Eciency (NO.)................................................................... 0.33%
RMS Power (Pe) .............................................................................400 Watts
Other Fun Facts
Frequency Response ....................................................................20–250 Hz
Voice Coil Diameter ...............................................................2.5 in/63.5 mm
Displacement .............................................................. 0.0619 cu ft/1.752 Ltr
Dimensions
Overall Diameter (A)...........................................................12.37 in/316 mm
Cut Out Diameter (B) ..........................................................11.10 in/282 mm
Mounting Depth (C)...................................................... 3.94 in/100 mm
Mounting Height (w/o Grille) (D)...................................... .0.71 in/18 mm
Mounting Height (w/ Grille) (E)..........................................1.42 in/36mm
Internal volume (Cu.Ft.)..........................1.2–2.0
Enclosure tuning range (Hz).................... 32–40
Internal volume (Cu.Ft.) ...................... 0.8–1.7
A
B
C
E
D
0.8 1.25 1.7
1.2 1.4 2.0
MIN IDEAL MAX
MIN IDEAL MAX
CUBIC FEET
CUBIC FEET
Sealed Enclosure
Ported Enclosure

9
SPC-12S4 Specications
200 400 600
MIN IDEAL MAX
WATTS RMS
Continuous Power Handling
Thiele/Small Parameters
Nominal Impedance (Z).................................................................... 4 ohms
DC Resistance (Re)..........................................................................3.2 ohms
Resonance Frequency (Fs) ...........................................................30.7061 Hz
Piston Area (Sd) ............................................................................0.0511 m2
Force Factor (BL)........................................................................ 12.4924 T.m
Mechanical Q Factor (Qms).................................................................3.7494
Electrical Q Factor (Qes)......................................................................0.5764
Total Q Factor (Qts).............................................................................0.4996
Sensitivity 1W/M (SPL)......................................................................87.3024
Mechanical Comp (Cms)..........................................................0.1844 mm/N
Moving Mass (Mms) ....................................................................145.7101 g
Linear Excursion (Xmax) ......................................................................9 mm
Volume Acoustic Comp (Vas)............................... 67.1494 Ltr/2.371348 cu ft
Reference Eciency (NO.)................................................................... 0.32%
RMS Power (Pe) .............................................................................400 Watts
Other Fun Facts
Frequency Response ....................................................................20–250 Hz
Voice Coil Diameter ...............................................................2.5 in/63.5 mm
Displacement .............................................................. 0.0619 cu ft/1.752 Ltr
Dimensions
Overall Diameter (A)...........................................................12.37 in/316 mm
Cut Out Diameter (B) ..........................................................11.10 in/282 mm
Mounting Depth (C)...................................................... 3.94 in/100 mm
Mounting Height (w/o Grille) (D)...................................... .0.71 in/18 mm
Mounting Height (w/ Grille) (E)..........................................1.42 in/36mm
A
B
C
E
D
0.8 1.25 1.7
1.2 1.4 2.0
MIN IDEAL MAX
MIN IDEAL MAX
CUBIC FEET
CUBIC FEET
Sealed Enclosure
Ported Enclosure
Internal volume (Cu.Ft.)..........................1.2–2.0
Enclosure tuning range (Hz).................... 32–40
Internal volume (Cu.Ft.) ...................... 0.8–1.7

10
User Guide
Space™Series
SPC-12S2/12S4 Ported Enclosure
Material Prep
Specications
Top / Bottom 24.00" × 15.00" 2
Front 21.25" × 13.50" 1
Rear 24.00" × 13.50" 1
Left 13.50" × 13.50" 1
Right 14.25" × 13.50" 1
Port 1 1.25" × 13.50" 1
Port 2 11.50" × 13.50" 1
24.00” 15.00”
15.00”
15.00”
13.50”
13.50”
21.25” 13.50”
PORT 1
PORT 2
* Please note there are no ngers mentioned in the
list above. Cut safe my friends.
External Dimensions......... 24.00" W × 15.00"H × 15.00"D
Net Internal Volume ......................................................2.02 ft3
Total Internal Volume.......................................................2.28 ft3
Gross External Volume....................................................3.01 ft3
Material Thickness..................................................................0.75"
Tuning Frequency................................................................ 40 Hz
Port Area.......................................................................27.00 inch2
Port Inlet ............................................................2.00"W× 13.50"H
Port Length ............................................................................16.25"
F3 (Hz)...............................................................................................40
Enclosure Example
FRONT VIEW LEFT SIDE
TOP VIEW

11
SPC-12S2/12S4 Sealed Enclosure
Material Prep
Specications
Front / Rear 32.00" × 15.00" 2
Top / Bottom 32.00" × 5.50" 2
Left / Right 13.50" × 5.50" 2
15.00”
13.00”
5.50”
32.00”
32.00”
RIGHT
* Please note there are no ngers mentioned in the
list above. Cut safe my friends.
External Dimensions............32.00" W × 15.00"H × 7.00"D
Net Internal Volume ......................................................1.25 ft3
Total Internal Volume.......................................................1.31 ft3
Gross External Volume....................................................1.94 ft3
Material Thickness..................................................................0.75"
F3 (Hz)...............................................................................................51
Qtc................................................................................................0.765
Enclosure Example
TOP / BOTTOM
LEFT / RIGHT
FRONT / REAR
7.00”
5.50”

12
User Guide
Space™Series
