ICS Sub300
Down Firing..or..Front FiringDown Firing..or..Front Firing
Down Firing..or..Front FiringDown Firing..or..Front Firing
Down Firing..or..Front Firing
ICS, is for In-Cabinet Speaker. Placing conventional
speakers in cabinets, or near corners or walls causes
the sound to become cupped and chest . Snell ICS
speakers are referenced from our acclaimed “in-room”
models, then re-engineered for the boundaries and
conditions found in cabinets and millwork. Furthermore,
the ICS models are hand-finished in black texture paint,
ideal for these invisible locations.
The ICS Sub300, with its innovative mechanical design,
can be either front or down firing. The cleverl designed
enclosure allows the feet and 300 Watt amplifier to be
repositioned so that the long-throw, 10” woofer can be
placed firing downward, for a “slot grille” application, or
forward firing when in millwork with a full faced grille.
Derived from the Basis 300, the ICS Sub300 is a
compact 15” cube, capable of first octave bass at
levels 110dB, making it the perfect anchor for better
home theater s stems.
Snell
Design Bass Reflex, Powered Subwoofer
Frequenc Response 25Hz-150Hz+3dB
Amplifier Power 300 Watts
Crossover Variable 50-150Hz
Maximum Output @30Hz 110dB
Placement Front Firing or Down firing, Frontwall Recommended
Drive Unit Woofer: 10-inch Treated Paper Cone, 15mm Excursion
Inputs/Outputs L/R Low Pass, Low/High Level Inputs, Full Range Input/Output
Controls Front-Mounted Level Control
Variable Low-Pass
Phase Switch, 0 Degrees/180 Degrees
On/Off, Auto On-Off Switch with Instant On, and Turn-Off Dela
Video Shielding Optional
Dimensions Height: 16.5-inches, includes feet (1.5-inches)
Width: 15-inches
Depth: 15-inches
Finishes Cabinet: Black Painted MDF
Most wood and paint finished available for an extra cost
Grille: N/A
www.snellacoustics.com 978-538-6262 978-538-6266fax
