AudioBahn AWC10T User manual

Theile / Small Parameters
7
Model # AWC10T AWC12T
Fs 32.6 Hz 31.4 Hz
Qts 0.55 0.59
Qes 0..65 0.71
Qms 3.78 3.57
Vas(Liters) 35Liters 69Liters
Vas (Cu. Ft.) 1.20 Cu.Ft. 2.45 Cu.Ft.
Re 3.2 ohms 3.3 ohms
Le 1.35 mH 1.5 mH
Mmd 109 Grams 130 grams
Xmax +/- 7mm +/- 8mm
RMS 400 watts 500 Watts
Sd 0.034 M2 0.051 M2
Freq. Resp. 25Hz-800Hz 25Hz-800Hz
Efficiency 92.5 dB 92.9 dB
EBP 50 44
Depth 4 3/4" 5 1/16"
Hole 9" 10 7/8"
Diamater 10 1/4" 12 1/2"
Displacement 0.10 Cu. Ft. 0.15 Cu.Ft.
Audiobahn Woofer Parameters
Dimensions
Vas does not represent the volume of a Box. Vas is just a parameter used when calculating a box.
An EBP of less then 45 is SUGGESTED for only a sealed box and greater then 65 for a ported box.

Box Parameters
8
Model # AWC10T AWC12T
Ported
Air Space (Cu. Ft.) 0.65 1.3
Port Size (Inches) 2 x 6.6 3 x 7.75
Port Vel. (%) 18.52 14.96
-3dB (Hz) 40 38
Tune Freq. (Hz) 40 38
Sub Disp. (Cu. Ft.) 0.1 0.15
Port Disp.(Cu. Ft.) 0.01 0.029
Total Vol. (Cu. Ft.) 0.75 1.5
Ported
Air Space (Cu. Ft.) 1.4 2.3
Port Size (Inches) 3 x 7.25 4 x 8.4
Port Vel. (%) 9.06 8.45
-3dB (Hz) 32 32
Tune Freq. (Hz) 38 36
Sub Disp. (Cu. Ft.) 0.1 0.15
Port Disp.(Cu. Ft.) 0.026 0.055
Total Vol. (Cu. Ft.) 1.5 2.5
Ported
Air Space (Cu. Ft.) 2.35 3.3
Port Size (Inches) 4 x 7.5 (2) 3 x 5.75
Port Vel. (%) 5.26 7.57
-3dB (Hz) 30 30
Tune Freq. (Hz) 37 36
Sub Disp. (Cu. Ft.) 0.1 0.15
Port Disp.(Cu. Ft.) 0.048 0.04
Total Vol. (Cu. Ft.) 2.5 3.5
EBP
50 44
Model # AWC10T AWC12T
Sealed
Minimum (Cu. Ft.) 0.5 0.75
Maximum (Cu. Ft.) 2 2
SPL (dB) 84.6 86.7
All sealed boxes already include the displacment for the subwoofer. NR = (Not Recommended)
Audiobahn Box Specifications
Remember to build your box to the total volume, not just air space, as total volume includes all displacement.
An EBP of less then 45 is SUGGESTED for only a sealed box and greater then 65 for a ported box.
The larger a sealed box is, the lower the sub will play, but the less power it will handle. The smaller a sealed box is,
the higher the frequency the sub will play, and the more power it will handle.
All ports listed are circle ports unless otherwise stated. Surface area of a circle port = (3.14) X (radius) (squared)
Ultimate SPL Bass Box (not designed for competition use)
Everyday Bass Performer
Space Saver Bass Design
A port velocity of 20% or under is good for everday use and 5% or under for SPL competition . Port velocity
translates to port noise, so the lower the number, the less port noise you will incur.
