AudioEngine D1 User manual

Preminu
Setup Guide
www.audioengineusa.com
D1
Premium 24-bit DAC
Premium 24-bit DAC

D1 setup guide 1
Contents
Introduction
Package Contents
Cleaning
Features
Overview
Quick Setup
Troubleshooting
Specications
Contact Us
About Audioengine
Page 3
Page 3
Page 3
Page 4
Page 4
Page 6
Page 8
Page 9
Page 10
Page 10

D1 setup guide
23
Basic Safety Instructions
• Read these instructions for all components before using
this product.
• Keep these instructions for future reference.
• Heed all warnings on the product and in the owner’s guide
Follow all instructions.
• Do not use this apparatus near water or moisture. Do not
use this product near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, near a swimming pool, or
anywhere else that water or moisture are present.
• Clean only with a dry cloth and as directed by the
manufacturer. Unplug this product from the wall outle
before cleaning.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions. To ensure
reliable operation of the product and to protect it from
overheating, put the product in a position and location that
will not interfere with its proper ventilation. For example,
do not place the product on a bed, sofa, or similar surface
that may block the ventilation openings. Do not put it in a
built-in system, such as a bookcase or a cabinet that may
keep air from owing through it’s ventilation openings.
• Do not install near any heat sources, such as radiators, heat
registers, stoves or other apparatus that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wider blade or
third prong are provided for your safety. If the provided
plug does not t in your outlet, consult and electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
• Only use attachments or accessories specied by the
manufacturer.
• Use only with the cart, stand, tripod, bracket or table When
a cart is used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when
unused for long periods of time to prevent damage to this
product.
• Refer all servicing to qualied service personnel.
• Servicing is required when the apparatus has been
damaged in any way such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• Do not attempt to service this product yourself. Opening
or removing covers may expose you to dangerous voltages
or other hazards. Please contact the manufacturer to be
referred to an authorized service center near you.
• To prevent risk of re or electric shock, avoid over loading
wall outlets, extension cords, or integral convenience
receptacles .
• Do not let objects or liquids enter the product as they may
touch dangerous voltage points or short out parts that
could result in a re or electrical shock.
• See product enclosure bottom for safety related markings.
• Use Proper Power Sources. Plug the product into a proper
power source, as described in the operating instructions or
as marked on the product.
• Avoid power lines– Use extreme care when installing an
outside antenna system to keep from touching power lines
or circuits, as contact with them may be fatal. Do not install
external antennas near overhead power lines or other
electric light or power circuits, nor where an antenna can
fall into such circuits or power lines.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: This device may not
cause harmful interference and this device must accept any
interference received, including interference that may cause
undesired operatio.
audioengine A5+ setup guide
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK.)
NO USER-SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
ATTENTION: POUR RÉDUIRE LE RISQUE DE DÉCHARGE
ÉLECTIQUE, NE RETIREZ PAS LE COUVERCLE (OU
L’ARRIÈRE.) IL NE SE TROUVE ÀL’INTÉRIEURAUCUNE
PIÉCE POUVANT ÊTRE RÉPARÉE PAR L’USAGER.
S’ADRESSER ÀUN REÉPARATEUR COMÉTENT.
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
1
Introduction
Welcome to the Audioengine family and congratulations on your
purchase of the Audioengine D1 Premium 24-bit DAC!
The Audioengine team is dedicated to bringing you the highest quality
listening experience possible. The Audioengine D1 is designed with the
same attention to detail and operational simplicity as all Audioengine
products. Our goal is to get you to your music as simply as possible,
without all the “gadget tinkering” that other products require.
As with our other past eorts, we thank all our customers and resellers
for helping us create another great Audioengine product!
Package Contents
• Audioengine D1 DAC
• USB cable
• Setup Guide
Cleaning
Your D1 components are not water-resistant, so it’s important that they
should be kept free of moisture. You should clean only with a dry cloth
or tissue and no liquid cleaners or solvents should be used.

D1 setup guide
45
Features
• Desktop or portable digital-to-analog convertor
• Mac or PC plug-and-play, no drivers to install
• High-performance headphone amp included
• USB and optical inputs
• USB-powered
• Stream bit-perfect 24/96 HD audio with low jitter
• Based on high-performance AK4396 DAC
Overview
The D1 24-bit DAC is a simple
yet powerful digital-to-analog
converter, with performance
and features usually found only
in much more expensive DACs.
It can accept USB or PCM-
stream optical inputs, and will
automatically congure to match
the inputs you deliver, with the
optical input being dominant.
The D1 can process digital audio at any bit depth up to 24 bits, and
any sample rate up to 192KHz. The D1 USB input can accept a USB
audio stream from your computer or other USB source device. The D1
optical input can accept optical (PCM stereo) streams from any optical
(TOSLINK) source, such as TVs, Apple TV®, DVD/BluRay players, CD
players, etc.
Note: optical sources must be set to PCM Stereo.
The D1 output can be connected to any gear with an analog audio
input, such as powered speakers, a boombox, stereo system, etc.
Power for the D1 is provided via the USB bus.
Note: when using the D1 with the optical output of your computer, the
USB port on the computer can provide power. The D1 will sense that
an optical input is present, and give that input priority.
USB power is “double regulated” to ensure that no USB bus power
variations aect your output.
The D1 also contains a high-performance headphone amplier.
Note: When headphones are plugged in, the analog output will be
muted.
D1
Output Level Power Headphone
Left
Right
Optical Input USB Input
Analog Output
DAC/Headphone Amp

D1 setup guide
67
Quick Setup
The following diagrams show the most common congurations for D1
Setup.
USB from your computer
Step 1 -- connect the D1 to your computer USB port.
For PC, the D1 should be recognized automatically.
For Mac, under System Preferences/Sound, select “Audioengine D1”
Step 2 –- connect the analog output of your D1 to any audio input of
your active speakers, stereo, etc.
For advanced setup tips visit: audioengineusa.com
Headphones
Optical Source
D1
Computer A5+ Powered Speakers
AV Receiver
OR
➊ ➋
Audioengine D1 - Cong A
Analog Output Analog Input
D1 DAC A5+ or AV Receiver
Analog Audio Output
➋
Computer D1 DAC
USB Audio Input
➊
USB Input
USB
➋
➋
D1
Computer
Headphones
Headphone Output
Headphones
➊
➋
Audioengine D1 - Cong B
Computer D1 DAC
USB Audio Input
➊
USB Input
D1 DAC
USB Headphone
OR
A5+ Powered Speakers
➋
D1
TV
Blu-Ray/DVD/CD Player
➊
➌
External AC Power
➌
USB Input
D1 Input Power Supply*
*USB AC power supply sold separately Audioengine D1 - Cong C
Analog Output Analog Input
D1 DAC A5+ or AV Receiver
Analog Audio Output
➋
Optical Audio Input
➊
Optical Output Optical Input
TV/Blu-Ray/DVD D1 DAC

D1 setup guide
89
Troubleshooting
• I have connected my D1 as shown in the manual, but there is no
music output.
1. Check to see that the power light is lit. If not, try another USB
output on your computer.
2. Ensure that D1 is selected as your output device under Control
Panel (PC) or System Preferences/Audio (Mac).
3. Try another USB cable.
• I have connected my D1 to my TV/DVD/BluRay, but there is no sound
output.
1. Be sure that D1 is also connected to a USB power adapter, and
that the power light is lit.
2. Be sure that your TV/DVD/BluRay digital audio is set to “PCM
Stereo”.
• Only one channel plays through my D1.
1. Check the RCA cables between your D1 and your sound system.
2. Check your audio player to ensure that the balance is centered.
Break-In Period
Your DAC will sound great out of the box and will get better over time.
However, give it 40 to 50 hours break-in time before doing any critical
listening.
Specications
Electrical
Full Scale output 2.0V RMS
Frequency Response 10 Hz - 25 kHz, +/- 0.5db
S/N Ratio (DC to 20 kHz) >110 dB
THD+N (1 kHz FS 96 kS/s) <0.0025%
Interface
Input Data Rate up to 192KS/s
Input Bit Depth up to 24 bits
USB type 1.1 or above
Power Requirements 130 mA
For additional specications go to: audioengineusa.com

D1 setup guide
10 11
Contact Us
If you have any questions or feel you may need service, contact the
reseller where you purchased your product or feel free to email us
directly at: [e-mail] or call toll-free in the United
States: [phone]
About Audioengine
Audioengine designs and builds innovative audio products with all
your music in mind. Great sound, simple but elegant designs, high-
quality materials, and truly useful features are what Audioengine
is about. We sincerely hope you get as much enjoyment from our
products as we’ve had creating them! For information about our other
products go to:
www.audioengineusa.com
Information for Users on Disposal of Old
Equipment [European Union]
This symbol indicates that the electrical and electronic
equipment should not be disposed as general household
waste at its end-of-life. Instead, the product should be
handed over to the applicable collection point for the
recycling in accordance with your national legislation.
By disposing of this product correctly, you will help
to conserve the environment and human health that
could otherwise be caused by inappropriate waste handling of this
product. For more information about collection point and recycling
of this product, please contact your your household waste disposal
service or the shop where you purchased the product. Penalties may
be applicable for incorrect disposal of this waste, in accordance with
national legislation.
[Other Countries outside the European Union]
If you wish to dispose of this product, please do so in accordance with
applicable national legislation or other rules in your country for the
treatment of old electrical and electronic equipment.
Attention:
This symbol is
only valid in the
European Union.

© 2011 Audioengine Corp. All Rights Reserved.
Copyright Notice
Audioengine and Audioengine D1 are trademarks of Audioengine Ltd.
Audioengine, Ltd.
[e-mail]
www.audioengineusa.com
