Page 1
Model APS-510b
Owner’sManual
5 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected.
Valet Switch manual override is pre-selected from the factory,however, the system
can be configured for "Custom Code" operation. Confirm the override mode selected on the
last page of this manual, and familiarize yourself with the selection on it's operation.
FEATURES :
2 Five Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Five Channel Receiver
Code Hopping Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override Code
7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Starter Disable
Additional Engine Immobilizer Output (optional relay required)
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi Tone Siren
RF Inhibit with ignition on
Parking Light Flasher
Plug In Dual Stage Shock Sensor
OPTIONS:
Remote Trunk Release ( must have electronic trunk release )
Remote Keyless Entry ( must have power door locks )
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Two Step Unlock Configurable
Headlight Illumination During Arming, Disarming, Or Both
Interior Illumination Upon Disarm
Taken fromAPS510a includes PBLED added 05/16/06
07SP transmitter added 05/07

128-8124
2 of 12
Page 2
YOUR“ CodeHopping “TRANSMITTERS
The transmitters included with your new security system use the most advanced
and secure form of radio frequency transmission available on any current
automotive security system. Some of today’s sophisticated auto thieves use a
device known as a code grabber, which will receive and store the signal from your
keychain transmitter, and retransmit at a later time to disarm your system.
Your anti code hopping transmitters will change their signal every time the button
is pressed, so when a thief grabs then retransmits your signal, the alarm system
will not respond.
If your transmitter button is pressed more than fifty times while it is out of range of
the vehicle ( children playing with your keys ), the transmitter will not operate when
you return to the vehicle and will need to be realigned to the receiver. To do this,
simply press the lock button two times within a one second time period. The
system will now respond to that transmitter each time a button is pressed.
NOTE: Your system has the option of using a siren, the vehicle horn, or both for
the sounding device. Where the siren is referenced below, the horn or
both may in fact chirp, or beep.
ARMING THESYSTEM-ACTIVE
1. Turn off the engine, exit the vehicle and close all doors, hood lid and trunk lid.
2. Press and release the Lock button on the keychain transmitter.
;Dash mounted LED begins to flash slowly.
;Parking Lights flash one time.
;Siren sounds one chirp.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full protec-
tion. If the siren "chirped" three times, sometime after arming, the ex-
clusive delayed dome light learn circuit has been programmed and the
system detected a open entry point after the learned delay expired.
Again, closing the hood, trunk, or doors will correct the problem and you
do not need to disarm the system to make the correction. If the siren/
horn did not sound when arming, then the chirps have been turned off
and you should refer to the section titled "ELIMINATING THE ARM/DIS-
ARM CHIRPS" in this manual.
Doors Lock - Optional
Headlight Illumination - Optional
SILENTARMING-ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and hold the Lock button on the keychain transmitter for 2 seconds.
;Dash mounted LED begins to flash slowly.
;Parking Lights flash one time.
;Siren will not sound.
If the siren "chirped" three times, sometime after arming, the exclusive
delayed dome light learn circuit has been programmed and the system
detected a open entry point after the learned delay expired. Closing the
hood, trunk, or doors will correct the problem and you do not need to
disarm the system to make the correction.

128-8124
3 of 12
Page 3
Doors Lock - Optional
Headlight Illumination - Optional
ARMINGTHE SYSTEM-PASSIVE (AUTOMATIC )
1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid and
trunk lid.;Dash mounted LED begins to flash rapidly, indicating 30 second
passive arming has begun.
2. Opening any protected entry point during the 30 second passive arming cycle
will immediately suspend automatic arming and the 30 second passive
arming cycle will restart when all doors are closed. At the end of the passive
arming cycle;
;Dash mounted LED begins to flash slowly.
;Parking Lights flash one time.
;Siren sounds one chirp
If the siren did not sound when arming, then the chirps have
been turned off, and you should refer to the section titled
"ELIMINATING THEARM / DISARM CHIRPS" in this manual.
Doors Lock - Optional
Door locking during passive arming is a selectable feature.
The alarm can be programmed to allow the doors to lock only
when arming using the keychain transmitter and they will not
automatically lock during passive arming.
PROTECTIONWHILE THESYSTEMISARMED
;Opening any protected door, hood, or trunk lid will cause the alarm to
immediately sound. The alarm will continue to sound for 30 seconds,
then stop and continue to monitor all protected entry points. If the thief
left a door opened, the alarm will sound for six 30 second cycles,
remain armed and ignore that triggered zone.
;Whenever the system is armed, the dash mounted LED indicator will
slowly flash. This serves as a visual deterrent to the potential thief.
The LED is a very low current bulb and will not cause the vehicle’s
battery to drain, even when left unattended for extended periods.
;Whenever the system is triggered, the vehicle’s parking lights will flash
for the full 30 second alarm cycle, attracting visual attention to the
vehicle.
;Optional - Whenever the system is armed, the vehicle’s starting circuit
will be bypassed. If the thief should choose to ignore the siren, the
vehicle can not be started.
;Any mild impact to the vehicle’s glass will cause the alarm to sound a
short series of warning tones.
;Any strong impact to the vehicle’s glass will cause the alarm to trigger
for the full 30 second alarm cycle.

128-8124
4 of 12
Page 4
DISARMINGTHESYSTEM
1. As you approach the vehicle, press and release the Unlock button on the key-
chain transmitter.
;Dash mounted LED turns off.
If passive arming was selected during the installation, then the LED
will start flashing rapidly, indicating that the system is rearming auto-
matically. Open any door to suspend the automatic arming.
;Parking Lights flash two times.
If the parking lights flashed three times, then the alarm was trig-
gered in your absence. Before turning the key on, examine the LED to
identify which zone was triggered.
;Siren sounds two chirps.
If the siren sounds 4 chirps, then the alarm was triggered in your
absence. Before turning the key on, examine the LED and refer to the
INTRUSION WARNING SIGNALS section of this manual to iden-
tify which zone was triggered.
If the siren did not sound when disarming, then the chirps have
been turned off, and you should refer to the section titled “ELIMI-
NATING THE ARM / DISARM CHIRPS“ in this manual.
Doors Unlock - Optional
Note: If the optional 2 step door unlock circuit is installed, when the unlock
transmitter button is activated, the drivers door only will unlock, press-
ing the unlock button a second time will cause all doors to unlock. If
your transmitter has a separate lock unlock buttons, pressing the
unlock button anytime after the first unlock command will cause all
the vehicle doors to unlock.
Headlight Illumination - Optional
Illuminated Entry Upon Disarm
SILENTDISARMING
1. As you approach the vehicle, press and hold the Unlock button on the keychain
transmitter for 2 seconds.
;Dash mounted LED turns off.
If passive arming was selected during the installation, then the LED will
start flashing rapidly, indicating that the system is rearming automatically.
Open any door to suspend the automatic arming.
;Parking Lights flash two times.
If the parking lights flashed three times, then the alarm was triggered in
your absence. Before turning the key on, examine the LED to identify which
zone was triggered.
;Siren will not sound.
If the siren sounds 4 chirps, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was
triggered.
Doors Unlock - Optional

128-8124
5 of 12
Page 5
Note:If the optional 2 step door unlock circuit is installed, when the unlock
transmitter button is activated, the drivers door only will unlock, pressing
the unlock button a second time will cause all doors to unlock. If your
transmitter has a separate lock/unlock buttons, pressing the unlock
button anytime after the first unlock command will cause all the vehicle
doors to unlock.
Headlight Illumination - Optional
Illuminated Entry Upon Disarm
WHILETHE SYSTEMISSOUNDING
If during a triggered state, you wish to shut off the siren without disarming your
security system, simply press and release any transmitter button other than the
disarm button. This action will turn off the siren yet leave the vehicle fully armed
and protected. This feature is particularly useful if you are aware of children play-
ing near your vehicle that may accidently trigger your security system. In this case
you can cancel the siren sounding without disarming your alarm.
INTRUSIONWARNINGSIGNALS
This system will inform you if an intrusion attempt has occurred while you were
away from the vehicle. If an intrusion attempt has occurred, the siren will chirp 4
times and the parking lights will flash 3 times when disarming the system. Enter
the vehicle and observe the dash mounted LED to identify which zone was trig-
gered.
nIf the LED is flashing one time...pause...one time...pause...etc., then an
intrusion attempt was made to the shock sensor, or an accessory
triggering device that may have been added to the system.
oIf the LED is flashing two times...pause...two times...pause...etc., then
an intrusion attempt was made to a hood or trunk pin switch that was
added to the system, or to a light activated entry point if the alarm was
installed using the voltage sensing feature.
pIf the LED is flashing three times...pause...three times...pause...etc.,
then an intrusion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory and will
only be erased when the ignition key is turned on.
PUSH-BUTTONLED/VALET/OVERRIDE/PROGRAMMINGSWITCH:(PBLED)
ThePBLEDswitchallowsyoutotemporarilybypassallalarmfunctions,eliminatingtheneed
tohand yourtransmitter toparking attendantsor garagemechanics. Whenthesystemisin
valetmode, allalarmfunctionsarebypassed, howevertheremotepanic featureandremote
doorlocks willremainoperational.Touse thevalet mode,thesystemmustfirst bedisarmed
eitherbyusing yourkeychain transmitter,or byactivatingyour personalizedmanual over-
ridecode.
1. Enterthevehicle,andturntheignitionkeytotheon position.
2. PressandholdthePBLEDswitch untilthe LEDturnsonsolid. Thesystemwillremain in
thevalet mode.
3. Toreturn tonormal operation,press andrelease thePBLED switchany timethe ignition
ison.
NOTE: Alwaysremembertoreturnthevehicleto thevalet offposition. Thiswill ensurethat

128-8124
6 of 12
Page 6
thevehicle remainsprotected atall times.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHEPBLEDOVERRIDESWITCH
YourSecuritySystem canbe disarmed withoutthe use ofthe keychain transmitter. Thisis
necessary,sinceyou willneedthe abilityto operate yourvehicle if thetransmitter islostor
its battery fails. If your system has been selected for Valet Switch manual override as
indicatedonthelastpage ofthis manual,to bypassthealarmsystem;
1. Open thevehicledoor. Thealarm willsound.
2. Turntheignitionkeytotheon position.
3. Within5seconds, pressand releasethePBLED overrideswitch.
Thealarm systemwillstopsoundingand enterthe (bypassed)mode. Youcannowstartand
operatethe vehiclenormally.
Typically thisoverridemodeisusedonlyifthetransmitter hasbecome inoperative.
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows the con-
sumer to program a personal override code, offering a higher level of security. To take
advantageof thisoption, programmablefeature #10mustbeselectedfortheCustomCode
Option. Consultyourinstallationcenter forprogrammingdetails. Thesystem comesfromthe
factorywith apre-programmed overridecode of11.To changethis defaultoverride code,do
thefollowing:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.Turn theignitionswitch tothe onposition.
2. Within10seconds,pressand releasethe PBLEDswitch, 3times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesirenor hornwillbeep andthe lights willflash onetime.)
4. Within10seconds,begintoenteryourchosen10thsdigitbypressingandreleasingthe
PBLEDswitch from1upto9times.
5. Within10seconds ofthelast entered10thsdigit, turnthe ignition switchoff then on.
6. Within10seconds,beginto enteryour chosenunitsdigit bypressing andreleasing the
PBLEDswitch from1upto9times.
7. Finishbyturning theignition switchtothe offposition.
Ifthenew codewas accepted, theunit willreportback thenewly entered code,by flashing
theLED, firstindicating the10ths digit,pause andthen theunits digit.The unitwillreportthe
new code three times with a one second pause between each code, then the system will
beginarming. Ifthe LEDflashpatternreportsthepreviouslystoredcode,thenewcodewas
notenteredcorrectly. Please repeatsteps1through 7above consideringthefollowing.
NOTE: Acceptabledigits 10thsorunitsare1through9. Theunitwillnotrecognizea0 (Zero),
ornodigit enteredin anyplace,units ortenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then
5 seconds during any of the above steps, the unit will revert back to the last
successfully stored code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the
following:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.
2. Turntheignitionswitchto theon position.
3. Within10seconds,pressand releasethe PBLEDswitch, 3times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.

128-8124
7 of 12
Page 7
(Thesirenor hornwillbeep andthe lights willflash onetime.)
5. Within10seconds,begintopressandreleasethePBLEDswitchtosetthetenthsdigit.
(Asperthe example,pressand release5times toset the tenthsdigit to5)
6. Within10 secondsofthelastpress ofthepushbutton,turnthe ignitionswitchoffthenon.
7. Within10 seconds,begintopressand releasethePBLEDswitchto settheunitsdigit.
(Asperthe example,pressand release2 times toset theunitsdigit to2).
8. Turntheignitionswitchto theoff position. Immediatelyobserve theLED flashpattern.
YouwillnotetheLEDflashingfivetimes,pause,andthenflashtwotimes,pause.Thispatternwillbe
repeatedthreetimesindicatingthenewcode(52)hasbeenacceptedandstoredinmemory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this
indicates that the code has not been changed. You will have to repeat steps 1
through7above beingcertain tonotethe following:
Acceptabledigits 10thsor unitsare 1through 9.The unitwill notrecognize a0 (Zero),or no
digitenteredinanyplace, unitsor tenths.
NOTE: If15secondsofinactivityexpire,oriftheignitionswitchisturnedoffformorethen5seconds
duringanyoftheabovesteps,theunitwillrevertbacktothelastsuccessfullystoredcode.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHECUSTOMCODEOVERRIDE
Assumingtheoverridecodeprogrammed hasnot beenchanged,andthedefault override
codeof11 isinthe system'smemory.
1) Enterthe vehicleandturn theignition switchtotheonposition.
NOTE:The sirenwillsound.
2) Within5 seconds,pressandreleasethePBLEDswitch 1time.
3) Within5 seconds, turnthe ignition switchoff then on.
4) Within5 seconds,pressandreleasethePBLEDswitch 1time.
5) Turnthe ignition switchoff then onandstart thevehicle.
NOTE: Ifyouhave changedthe programmedoverridecode thensubstitute yournewcode
tenths for step 2 above, and units for step 5 above.
ELIMINATINGTHENORMAL ARM/DISARM CHIRPS
You can selectively eliminate the normal arm & disarm chirps by holding the transmitter
buttonslightlylonger when armingor disarming. Thiswillprevent thesirenchirps for one
arm or disarm cycle. If you find this inconvenient and wish to eliminate these chirps
permanently,
1.Turnthe ignition switch'on" then 'off".
3.Within 10secondsofturningoff theignition,pressandrelease thePBLEDswitch3times.
4.Ifthe chirpswereon before youstarted, the sirenwill emit 2shortchirps indicatingthat
the chirps are now off. If the chirps were off before you started, the siren will emit one
shortchirpindicating thatthechirps arenowon.
NOTE: If the vehicle battery is disconnected then reconnected, the unit will return to the
defaultsetting ofchirpson. Repeattheabove proceduretoeliminatethearm/disarm
chirps.
REMOTEPANICOPERATION
TheARM or DISARM button on your keychain transmitter also functions as a panic
switch for use in emergency situations. To use remote panic,
1. Press and hold theARM or DISARM button on the keychain transmitter for 3 or
more seconds. The alarm will immediately sound.
2. To stop the alarm, press and hold the ARM or DISARM button on the transmit-
ter again for 3 seconds. If the button is not pressed, the alarm will automati-
cally stop after 30 seconds. Also if any transmitter button other than the ARM

128-8124
8 of 12
Page 8
or DISARM button is pressed and released, the Panic mode will be turned off
immediately. The normal function of this transmitter button will be suspended
during the Panic sounding period.
3. During the panic mode, the Lock and Unlock buttons can be used to lock and
unlock the doors, (if the option is installed), however once the unlock/disarm
button is pressed, the vehicle's starter inhibit device, (where installed) will be
disabled allowing the vehicle to start.
NOTE: While in the Panic mode, pressing and releasing the ARM or DISARM
buttons will, if the option is installed, lock and unlock the doors respectively.
While in the panic mode, anytime the DISARM button is pressed, the panic
feature will continue for the allotted 30 seconds, however, the security
system will be disarmed allowing the vehicle to start.
ADDITIONALREMOTEFUNCTION( CHANNEL3)
This security system has an additional features that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are; Remote Trunk Release Remote Car Starter
Remote Window Closure Remote Garage Door Interface
Operation of the optional accessory or accessories, can be controlled by pressing
and holding the programmed button on the keychain transmitter for four seconds,
or by pressing and releasing the programmed button on the transmitter two times
in succession. Check with your installation center for more information on what
accessories were installed and how they are accessed.
ADDITIONALREMOTEFUNCTION( CHANNEL4)
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are: Remote Trunk Release Remote Car Starter
Remote Window Closure Remote Garage Door Interface
To activate the optional accessory, press the programmed button on the keychain
transmitter for up to 8 seconds for continuous output, or press and release for
momentary activation. The optional accessory will immediately engage. Check
with your installation center for more information on the optional accessory that
may have been installed and how it is accessed.
ADDITIONALREMOTEFUNCTION( CHANNEL5)
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are; Remote Trunk Release Remote Car Starter
Remote Window Closure Remote Garage Door Interface
To activate the optional accessory, press the programmed button on the keychain
transmitter for up to 8 seconds for continuous output, or press and release for
momentary activation. The optional accessory will immediately engage. Check
with your installation center for more information on the optional accessory that
may have been installed and how it is accessed.

128-8124
9 of 12
Page 9
IGNITIONCONTROLLEDLOCKUNLOCK:(UnlockDriversOnly,orUnlockAllDoors)
Your security system has a selectable safety feature that allows the vehicle doors
to lock when the ignition switch is turned on, (Providing all doors are closed), and
to unlock the doors when the ignition switch is turned off. In addition, the unlocking
of the doors is further selectable, in a two step unlock configuration, to unlock only
the drivers door or all doors.
TELEMATICUPGRADE:
This system has the ability to have a telematic upgrade module connected to it.
This is a upgrade that can give you control of certain functions of your vehicle from
a Telephone, or in some cases a computer interface. Please check with your
installation center for most recent Telematic Upgrades. If you had a Telematic
Upgrade installed, the manual supplied with the upgrade unit will provide a op-
erators manual advising of the features of the system and means available to
control these features of your vehicle.

128-8124
10 of 12
Page 10
APS-510b
SYSTEM FUNCTIONSATAGLANCE
DASHLED INDICATORS
RAPIDFLASHING = PASSIVEARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ONSOLID = VALET MODE
3FLASH...PAUSE = INTRUSIONZONE3
2FLASH...PAUSE = INTRUSIONZONE2
1FLASH...PAUSE = INTRUSIONZONE1
SIRENCHIRPINDICATORS
*1CHIRP = ARM
*2CHIRPS = DISARM
3CHIRPS = ARM/DOOROPENED
4CHIRPS = DISARM/INTRUSION
* These chirps are optional, and can be de - activated.
PARKING LAMP INDICATORS
1 FLASH = ARM
2FLASHES = DISARM
3FLASHES = DISARM/INTRUSION
Your System Has These Features Activated
Starter Disable
Remote Keyless Entry
Auto Lock with ignition key
Auto Unlock with ignition key
Passive Arming
No Lock in passive mode
Hardwire doors, hood, and trunk
Custom Code Override
Valet Switch Override
IlluminatedEntry UponDisarm

128-8124
11 of 12
Page 11
THISPAGE LEFTBLANK INTENTIONALLY

128-8124
12 of 12
Page 12
© 2007 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788
128-8124
