Audiovox Prestige 128-8601 User manual

128-8601
1 of 8
Model APS-45N
Owner'sManual
FEATURES:
2 Four Button, RF Transmitters
Four Channel Code Learning Receiver
Remote Panic InAll Modes
Built-In Parking Light Output
LED Status Indicator
IgnitionDoorLocking/Unlocking
Horn Output
OPTIONS:
Remote Trunk Release
Remote Power Window Control
Remote Garage Door Interface
Remote Engine Starter
Starter Interrupt
Siren
Access Guard / 2 Step Unlock
Illuminated Entry
Page 1
4 Button Remote Keyless Entry System
With Two Auxiliary Outputs

128-8601
2 of 8
Your Keyless Entry System has many features and available options some of which must
be selected at time of installation. For your reference, the list on the back page of this
manual shows what features and options have been installed with this particular sys-
tem. Consult your installing dealer for options that may have been installed and are not
listed.
REMOTE DOOR LOCKING - ACTIVE
1. Turn the engine off, exit the vehicle, and close all doors.
2. Press and release the lock button of your key chain transmitter one time, the doors will
lock, the parking lights will flash once, the vehicle's horn (or optional siren) will chirp once
and the dash mounted LED will begin to flash slowly confirming the system is locked.
SILENT LOCKING - ACTIVE
1. Turn the engine off, exit the vehicle and close all doors.
2. Press and hold the lock button of your key chain transmitter for two seconds, the doors
will lock, the parking lights will flash once and the dash mounted LED will begin to flash
slowly confirming the system is locked. The horn or optional siren will not chirp.
BACKUP PASSIVE OPERATION (AUTOMATIC)
If the passive arming feature has been selected:
Turn the engine off, exit the vehicle and close all doors.
The dash mounted LED will immediately begin to flash rapidly indicating that the 30 second
passive arming timer has begun.
If any entry point is opened during the 30 second arming cycle, arming will be suspended.
When all entry points are closed, the arming cycle will begin again.
At the end of the 30 seconds, the parking lights will flash once, the vehicle's horn (or optional
siren) will chirp once, and the dash mounted LED will begin to flash slowly confirming the
system is armed. If the horn (or optional siren) did not sound when arming, then the chirps
have been turned off. Please refer to the section titled "Eliminating the Arm/Disarm
Chirps" later in this manual. Passive door locking is a selectable feature. The doors may or
may not lock passively dependent upon the setup during installation.
PROTECTION WHILE THE SYSTEM IS ARMED
If the optional Starter Interrupt relay has been installed, then whenever the system is armed,
the vehicle starter circuit is disabled, even with the ignition key, the vehicle will not start.
Whenever the system is armed, the dash mounted LED will slowly flash. This serves as a
visual deterrent to a potential thief. This LED is a very low current light emitting diode and will
not cause the battery to drain even if left unattended for long periods of time.
UNLOCKINGTHESYSTEM
As you approach the vehicle, press and release the unlock button on the keychain transmitter,
the doors will unlock, the parking lights will flash two times, the vehicle horn (or optional
siren) will chirp twice and the dash mounted LED will turn off. If you have the optional entry
illumination circuit installed, the interior light will turn on for 30 seconds or until the ignition key
is switched on.
Note: If the passive arming mode was selected at time of installation, the dash mounted
LED will start flashing rapidly indicating that the system is rearming. Opening any
door will suspend the automatic arming.
SILENTUNLOCKING
1. As you approach the vehicle, press and hold the unlock button of your key chain
transmitter for two seconds, or until the system responds.
The doors will unlock, the parking lights will flash twice and the dash mounted LED will turn
off, confirming that the system is disarmed. The vehicle horn (or optional siren) will not
chirp. If you have the optional entry illumination circuit installed, the interior light will turn on
for 30 seconds or until the ignition key is switched on.
Page 2

128-8601
3 of 8
Page 3
Note: If the passive arming mode was selected at time of installation, the dash mounted
LED will start flashing rapidly indicating that the system is rearming. Opening any
door will suspend the automatic arming.
OPTIONAL ACCESS GUARD ( Two Step Unlock )
If the optional 2-step unlock feature was installed, then only the driver's door will unlock after
the first press of the unlock button. If you want to unlock all doors, you can simply press the
unlock button of the keychain transmitter a second time.
Note: Two Step unlocking is an optional feature that must be wired upon installation.
VALET / PROGRAM / MANUAL OVERRIDE SWITCH
The valet switch allows you to temporarily prevent the system from arming, eliminating the
need to hand your keychain transmitter to parking attendants or garage mechanics. When
the system is in the valet mode, it will not passively arm or activate the starter interrupt
circuit. However, all keyless entry features, as well as the remote panic feature will remain
operational. To enter the valet mode:
1. Start with the valet switch in the "off" position
2. Turn the ignition switch to the "on" position.
3. Flip the valet switch to the "on" position.
The dash mounted LED will turn on solid (not flashing) indicating that the valet mode has
successfully been entered.
To return to the normal mode of operation, move the valet switch to the "off" position at any
time the ignition switch is in the on position.
Note: In the event that you lose your keychain transmitter or the transmitter fails to operate
the keyless entry system, the valet switch can be used to override the optional Starter
Interrupt, and therefore allow the engine to be started. To override system:
1. Open the door with the vehicle's door key.
2. Turn the ignition switch to the on position.
3. Flip the valet/override switch to the on position. LED will turn on solid.
The system will disarm, allowing the engine to be started and the vehicle to be operated
normally. Always remember to move the valet switch to the off position to allow the passive
arming and optional starter interrupt features to be operable the next time you park the
vehicle.
ELIMINATING THE LOCK/UNLOCK CHIRPS
You can selectively eliminatethe normallock andunlock chirpsby holdingthe transmitter button
slightly longer when locking and unlocking. This will prevent the horn/siren chirps for one
lock or unlock cycle. If you find this inconvenient and wish to eliminate these chirps perma-
nently,
1. Start with the valet switch in the off position.
2. Turn the ignition switch "on" then "off".
3. Within 10 seconds of turning off the ignition, flip the valet switch on, "off", "on", "off",
"on", "off".
4. If the chirps were on before you started, the siren will emit 2 short chirps indicating
that the chirps are now off. If the chirps were off before you started, the siren will
emit one short chirp indicating that the chirps are now on.
REMOTEPANIC OPERATION
The lock or unlock button of your keychain transmitter also serves as a panic button and will
cause the vehicle horn (or optional siren) to sound on demand. To use the panic feature, you
must be within the system's maximum operating range. In an emergency situation, to use the
panic feature, press and hold the lock or unlock button of your keychain transmitter for 3
seconds. This will cause the lights to flash, the vehicle horn (or optional siren) to sound, and
if the optional interior illumination circuit was installed, the interior lights to flash. The panic
mode will continue for 30 seconds and then reset.

128-8601
4 of 8
Page 4
To disengage the panic feature before the 30 seconds are up, press and hold either the lock
or unlock button of your keychain transmitter for 3 seconds or press the option button
momentarily. The doors can be unlocked or locked while in "panic" mode by momentarily
pressing the lock or unlock button respectively.
ADDITIONAL REMOTE FUNCTION CHANNEL 2
The system has an additional output, (Channel 2) , that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are:
Remote Trunk Release
Remote Window Close
To operate the accessory associated with Channel 2, press and hold the option button of
your keychain transmitter for four seconds.
NOTE: You may access the Channel 2 command regardless of whether the system is
"locked" or "unlocked", but not when the ignition switch is in the on position. This
is to prevent the output from accidentally opening the vehicle's trunk when the
vehicle is in motion.
ADDITIONAL REMOTE FUNCTION CHANNEL 3
The system has an additional output, (Channel 3), that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are:
Remote Engine Start
Remote Window Close
Remote Garage Door Interface
To operate the accessory associated with Channel 3, simply press the Option button of your
keychain transmitter which was configured and programmed for this function.
NOTE: The channel 3 output will remain active for as long as the transmitter button is
pressed. Certain accessories may take advantage of the extended output capability
of this channel. To discontinue the output, simply release the transmitter button.
IGNITIONDOORLOCKING/UNLOCKING
The system is capable of being programmed for the added safety and security of ignition
controlled door locking and unlocking. These features are separate, so the unit may be
programmed for one, or both, or neither.
When the ignition door locking feature is programmed, the system will cause all door locks
to lock whenever the ignition switch is turned from the off to on position, (providing that all
doors are closed at that time). All doors will lock approximately 3 seconds after the vehicle's
ignition switch is turned on. This is a nice feature for maintaining the personal safety of the
occupants of the vehicle, in an effortless and automatic manner.
When the ignition door unlocking feature is programmed, the system will cause all door locks
to unlock whenever the ignition switch is turned from the on to off position. All doors will
unlock immediately after the vehicle's ignition switch is turned off. If 2 Step unlock was
installed, only the driver's door will unlock.
As stated these features are programmed separately, so you may chose to use one, both,
or neither. Please consult with your dealer to consider your options.
TWO STEP UNLOCK (ACCESS GUARD)
By pressing the unlock button of the keychain transmitter as you would normally, (Please see
the section titled "Unlocking The System", earlier in this manual), the system will disarm, and
only the driver's door will unlock. If however, you should then decide instead that you
want all doors to unlock, you can simply press the unlock button a second time and all doors
will unlock.

128-8601
5 of 8
Page 5
PROGRAMMING TRANSMITTERS:
At times it may become necessary to program replacement or additional transmitters for
use with your system. To do this:
1) With the system unlocked or disarmed, turn the ignition key to the on position.
2) Press and release the Program/Override push-button switch three times
The unit will flash the parking lights and or beep the horn once to indicate that the system
is in the transmitter program mode. The LED will also flash one time pause, one time
pause, etc... indicating that you are in the transmitter program mode of the unit’s channel 1
or single button program mode.
3) Press and hold the lock button of each additional transmitter you wish to operate your
system.
NOTE: The unit is capable of storing up to 4 transmitters. If a fifth transmitter is added, the
first transmitter programmed will be bumped out. This unit will also program all 4 buttons of
your transmitter when the lock button is operated while in the program mode. Once all
transmitter have been programmed, turn the ignition switch off to exit the program mode.
If you require priority programming for multiple vehicle operation please read on.
The system allows priority button programming in case you intend to operate two vehicle
with one transmitter. In this instance you will program the default button combination,
(One Button Programming), for the main vehicle you drive, and a different combination for
the second vehicle so you are not unlocking, locking, or starting both vehicles when they
are within range of each other.
To prioritize transmitters after programming the transmitter into the first vehicle:
Enter the transmitter program of the second vehicle as above by:
1) With the system unlocked or disarmed, turn the ignition key to the on position.
2) Press and release the push-button switch three times
The unit will flash the parking lights and or beep the horn once to indicate that the system
is in the transmitter program mode. The LED will also flash one time pause, one time
pause, etc... indicating that you are in the transmitter program mode of the unit’s channel 1
or single button program mode.
3) Press and hold any combination of buttons of your transmitter that was not used for
your primary vehicle.
If, for instance you can press & hold the lock & unlock buttons simultaneously, for
controlling Lock function of the second vehicle.
4) Press and release the program push-button switch once to advance to channel 2,
unlock.
Here you can press and hold the lock & start buttons simultaneously, for controlling the
unlock function of the second vehicle.
5) Press and release the program push-button switch once to advance to channel 3,
start.
Here you can press and hold the start & option buttons simultaneously, for controlling the
start function of the second vehicle.

128-8601
6 of 8
DELETING TRANSMITTERS FROM YOUR SYSTEM:
It may be necessary to delete a lost transmitter or to reprioritize a transmitter that is
programmed to your system. To remove a transmitter that has been programmed in your
system:
1) Enter the transmitter program mode of channel 1 as indicated above.
2) Press and hold any transmitter button that has not been programmed into channel 1
until you hear a chirp, then release and immediately press the same button a second time
until you hear a long chirp followed by a short chirp. This action erases the transmitter.
If the transmitter you wish to erase has been lost or stolen then following the information
below will successfully remove the transmitter.
NOTE: For this procedure, you must have all transmitters you wish to remain pro-
grammed in your system available.
1) Enter the transmitter program mode of channel 1 as indicated above.
2) Press and hold the lock button of each transmitter you wish to operate the lock
function of your unit making sure you occupy all 4 transmitter slots. In other words, you
have three transmitters you wish to remain programmed. Press and hold the lock button
of transmitter one until a long chirp is heard, then press and hold the lock button of
transmitter two, then press and hold the lock button of transmitter three, followed by
pressing and holding the lock button of transmitter one again. This action fills all 4
receiver slots.
3) Advance to receiver channel 2 by pressing the push-button switch one time.
4) Press and hold the unlock button of each transmitter you wish to operate the unlock
function of your vehicle, again making sure all 4 transmitter slots are filled.
4) Advance to receiver channel 3 by pressing the push-button switch one time.
5) Press and hold the unlock button of each transmitter you wish to operate the start
function of your vehicle, again making sure all 4 transmitter slots are filled.
If you are uncomfortable about the programming of additional transmitters as outlined in
the processes above please contact your installation center or call the technical service
number listed on the back of the transmitter for help.
BATTERYREPLACEMENT
The transmitter incorporates a small LED visible through the
case which is used to indicate battery condition. You will
notice a decrease in transmitter range as the battery con-
dition deteriorates. Transmitter battery replacement is
recommended at least every 10 to 12 months, depending
upon how frequently the transmitter is used.
To replace the battery in the 91P Transmitter
1) Carefully pry apart the case using the edge of a coin as shown.
2) Remove the rear cover to access the discharged battery paying attention to the proper
polarity orientation.
3) Carefully remove and properly dispose of the discharged battery.
4) Insert the new battery, than carefully snap closed the transmitter case.
5) If you accidently dislodge the circuit board from the transmitter housing, be certain that
the rubber membrane is seated properly, and the buttons are properly exposed from the
front view of the case, then insert the circuit board, and return to step #4.
91P Uses 2 x CR2016 Lithium Battery

128-8601
7 of 8
ORDER FORM FOR 91P
Attention: Transmitter Ordering Department
Important: To help us expedite your order, please print all of the information
legibly
and mail this form and your payment according to the instructions
below.
Note: Transmitter model number found on back of case.
1) Transmitter Model Number_____________________
2) Name: _______________________________________
3) Address: ______________________________________
4) City: ________________ State: _____ Zip Code: ________
5) Telephone Number: (_____) _______________
6) Total Number Of Transmitters Required:
Cost Per Transmitter is: $65.00
Multiply By Number Of Transmitters X ______
7) Enter Total Amount Enclosed _________________
(New York State Residents must include the appropriate sales tax)
8) Method of Payment:
Mastercard VisaCheckor MoneyOrder(donot sendcash)
Make Checks Payable To Audiovox Corporation
Credit Card Number: _________________________________
Credit Card Expiration Date: ____ / _____ / _____
9) Mail this form along with your payment to:
Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y., 11788
Attn.:TRANSMITTERDEPARTMENT
Credit card purchasers can order additional or replacement
transmitters by phone. Simply dial 1 - 800 - 645 - 4994, and
follow the instructions from the operator interface.

128-8601
8 of 8
Page 6
APS-45N
SYSTEMFUNCTIONSATAGLANCE
LED INDICATORS:
RAPID FLASHING = PASSIVE ARMING
SLOW FLASHING = ARMED
OFF = DISARMED
ON SOLID = VALET MODE
OPTIONAL VEHICLE HORN OR SIREN CHIRP INDICATION:
1 CHIRP = LOCK / ARM
2 CHIRPS = UNLOCK / DISARMED
CONTINUOUS = PANIC MODE
ALARM PARKING LAMP INDICATIONS:
1 FLASH = LOCK / ARM
2 FLASHES = UNLOCK / DISARM
CONTINUOUS FLASH = PANIC MODE
© 2009 Audiovox Electronics Corp., Hauppauge, NY 11788 128-8601
Option Button
Option Button
Option Button
Option Button
Option Button
Option Button
Unlock 2
Unlock 2
Unlock 2
Unlock 2
Unlock 2
Unlock 2
Lock 1
Lock 1
Lock 1
Lock 1
Lock 1
Lock 1
