Audiovox APS-95BT2 Operating instructions

Factory Settings for Transmitter Buttons
Button Channel System Function
Button # 1
Button # 2
Both Buttons
1
2
3
Remote Arm/Disarm
Remote Emergency Panic
Door Lock/Unlock (Optional)
Pulsed Output
*(Optional Devices)
Switched Output
* (Optional Devices)
* Some of the more common accessories for these channels are;
AS 9075 Remote Car Starter
AS 9256 Remote Trunk Release Relay
AS 9154 Remote Garage Door Interface
AS 9153 Remote Window Roll Up
Model : APS 95 BT2
TRANSMITTER PROGRAMMING GUIDE
The transmitters included in the security system kit are pre-programmed at
the factory, with button # 1 assigned to channel one only. The suggested
program arrangement is listed below. To program channels 2 and 3, please
follow the programming instructions listed on pages two and three of this
manual.

Thesefactoryprogrammedsettingscanbeprioritizedbasedonanindividual's
frequency of use, (i.e. pressing both buttons simultaneously to activate
channel1,arm/disarmetc.)byfollowingthenormalprogramminginstructions
below.
Please note when changing the factory set button assignments, it is
necessary to perform steps 5, 9, and 12 three times using "transmitter A",
followed by one time using "transmitter B".
PROGRAMMING TRANSMITTERS:
It is important to remember that during programming, each individual step
of the procedure must be executed within 15 seconds of the previous step.
When the 15 second time limit is allowed to expire, the system will
automaticallyexitprogrammode. Thisis indicatedbyalong"chirp"fromthe
siren.
Additionally, any time the ignition key is turned off while programming, the
system will immediately exit program mode. This is also indicated by a long
"chirp" from the siren.
TO PROGRAM ADDITIONAL TRANSMITTERS:
1. Enter the vehicle, and turn the ignition key to the "on" position.
2. Move the valet/bypass switch on - off - on - off - on then off.
3. The dash LED will flash once, and the siren will "chirp" once, indicating
the system is ready to accept programming for channel 1 or the arm/
disarm and panic functions.
4. You can assign any of the three transmitter button functions listed below
to channel 1.
a. Pressing button #1 on the keychain transmitter.
b. Pressing button #2 on the keychain transmitter.
c. Pressing both buttons simultaneouslyon the keychaintransmitter.
5. Press and hold the selected choice a, b, or c above, until the siren emits
a long "chirp" to confirm that programming of channel 1 was successful.
6. Move the valet/bypass switch on, then off again.
7. The dash mounted LED will flash 2 times, and the siren will "chirp"
indicating that the system is ready to accept programming for channel
2, or the pulsed ground output for remote trunk release, remote car
starter, etc.
8. You can assign any one of the two remaining button functions listed in
4a, 4b, or 4c above to operate channel 2. You cannot use the button(s)
that operate channel 1, selected in step 5, to operate channel 2.
9. Press and hold the selected choice. The siren will emit a long "chirp" to
confirm that programming of channel 2 was successful.
10. Move the valet/bypass switch on, then off again.
2

11. The dash mounted LED will flash 3 times, and the siren will "chirp"
indicating that the system is ready to accept programming for channel
3. (APS 350)
12. Press and hold the remaining transmitter button function. The siren will
emit a long "chirp" to confirm that programming of channel 3 was
successful.
13. To exit program mode, either turn the ignition key to the off position, or
move the valet switch on then off one additional time. This is indicated
by one short chirp then one long "chirp" from the siren.
NOTE: If programming to a Keyless Entry (non alarm) unit, there will be NO
chirp indication.QUICK REFERENCE:
You can program any individual channel, without reprogramming all
channels, by following the quick reference chart below.
After the desired channel is programmed, turn the ignition key to the off
position to exit programming mode.
BATTERY REPLACEMENT:
The transmitter incorporates a small red LED built into the case. This LED
can be used to indicate battery condition. You will notice a decrease in
transmitter range as the battery condition deteriorates. To replace the
battery...
1. Removethetransmittercoverbyremovingthesmallscrewfromtheback
of the transmitter case.
2. Remove the discharged battery, making note of the orientation of the +
and - contacts and dispose of the battery properly.
3. Install the new (type GP23A) battery, taking care to orient the + and -
contacts properly.
4. Replace the transmitter cover, taking care not to damage the LED or
switches on the circuit board. 3
CHANNEL VALET SWITCH
ON then OFF 3 Times
ON then OFF 4 Times
ON then OFF 5 Times
LED
1
2
3
1 Flash
2 Flashes
3 Flashes

IMPORTANT: To help us expedite your order, please print all of the
information legibly, and mail this form and your payment according to the
instructions below.
1.Name :______________________________________________________
Address:_____________________________________________________
City:___________________ State:________ ZipCode:______________
2. TelephoneNumber:(________ )________________________________
3. Enterthetotalnumberoftransmittersrequiredhere:____________________
4. The cost per transmitter is $ 65.00.
5. Enterthetotalamountenclosedhere:_______________________________
( New York state residents must include the appropriate sales tax. )
6. Method of payment; check one of the boxes below.
qMastercard qVisa qCheck or money order * (do not send cash)
* Make checks payable to Audiovox Corporation
7. CreditCardNumber:___________________________________________
8. Credit Card Expiration Date : __________________________
9. Mail this form and your check, to :
ORDER FORM FOR 2 BUTTON TRANSMITTER
MODEL NO. APS 95 BT2
Audiovox Corporation
150 Marcus Blvd.
Hauppauge, N.Y. 11788
Attn: TRANSMITTER DEPARTMENT
Credit card purchasers can order additional or replacement
transmitters by phone. Simply dial 1 - 800 - 645 - 4994, and
follow the instructions from the operator interface.
(
128-4624C
