Audiovox Prestige Platinum APS 995 User manual

Model APS-995
Owner’sManual
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
w1 Two Way 3 Button Remote Control And 1 One Way 4 Button Remote Control
wSix Channel Code Learning Programmable Receiver
wExternal Superheterodyne Receiver Antenna
wSingle Or Two User Programmable W/Separate Control Outputs
wSingle Button Lock/Unlock or Separate Button Lock/Unlock or Both
wRemote Keyless Entry With Optional Access Guard (must have power door
locks)
wSelectable Manual Override Mode
wNew Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
wSmart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
wSelectable Automatic Timed Start Mode
wAdjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off,CityMode)
wSafe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
wRemote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
wImproved Custom Code Override, User Selectable and Programmable
wProtected Push Button Valet/Override Switch
w7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
wIntrusion Alert With Memory
wInstant Siren Activation
4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable

Page2
wStarter Disable Output
wAdditional Engine Immobilizer Output, (Optional Relay Required)
wTrue Last Door Arming (Hardwire Only)
wDefective Zone By-Pass
wDefective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared)
w6 Tone Mini Siren (New AS-9903)
wCar Horn Output For Additional Alarm Response (Improved Timing To Mini-
mize RF Interference.)
wAdditional Negative Trigger Input (Hood & Trunk)
wRF Inhibit With Ignition On
wParking Light Flasher (Relay On Board)
wPlug In Dual Stage Shock Sensor (Pre-detect, Full Trigger, and “City Mode”)
wAudible Arm, Disarm, Defect, And Tamper Chirp Indications
wHeadlight Control Output
wIlluminated Entry Control Output
wActive or Passive Arming Selectable
wProgrammable Auto Lock On / Off
wProgrammable Auto Unlock On / Off/Drivers Door/All Doors
wProgrammable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec
L/ Dbl. U/L
wProgrammable Active or Passive Door Locks
wUser Programmable Permanent Chirp Delete
wOn Command RF Chirp Delete from Transmitter Or Selectable Through
Software
OPTIONS :
wRemote Trunk Release (must have electronic trunk release)
wRemote Keyless Entry (must have power door locks)
wMultiple Vehicle Capable
wRemote Power Window Roll Up
wRemote Garage Door Interface
CAUTION! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous car-
bon monoxide fumes which can be harmful or fatal if prolonged expo-
sure occurs. DO NOT remote start the vehicle if it is garaged.
YOUR“ANTICODEGRABBING“TRANSMITTERS
The transmitters included with your new security system use the most advanced
and secure form of radio frequency transmission available on any current automo-
tive security system. Some of today’s sophisticated auto thieves use a device known
as a code grabber, which will receive and store the signal from your keychain
transmitter, and re transmit at a later time to disarm your system.
Your Keeloq Code Hopping transmitters will change their signal every time the
button is pressed, so when a thief grabs then retransmits your signal, the alarm
system
will not respond.

Page3
If your transmitter button is pressed more than fifty times while it is out of range of
the vehicle (children playing with your keys), the transmitter will not operate when
you return to the vehicle, and will need to be re aligned to the receiver. To do this,
simply press button 1 two times within a one second time period. The system will
now respond to that transmitter each time a button is pressed.
NOTE: This system is custom configurable and can be set up to operate with a
number of options controlled from any transmitter button or button com-
bination. For reference, we will describe operation assuming that your
system is programmed for separate lock and unlock buttons. Also refer-
ence will be made to the icons as shown on the buttons below.
NOTE: Concerning the LCD based remote, where lock is mentioned, use button
#1, where unlock is mentioned, use button #2, where trunk/start is mentioned,
use button #3. The Red Button is used to acquire status of the system.
See "System Status" described later in this manual.
Consult your installation center if your system has been configured differently.
NOTE: Your system has the option of using a siren, the vehicle horn, or both for
the sounding device. Where the siren is referenced below, the horn or
both may in fact chirp, or beep.
ARMINGTHESYSTEM-ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and release button Lock/Arm button on the keychain transmitter.
þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren sounds one chirp.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection. If the siren did not sound when arming, then the chirps
have been turned off, and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Lock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when arming, as an added convenience, the system
will turn on the headlights when the system is armed.
SILENT ARMING - ACTIVE (Must be activated during programming)
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and hold button the Lock/Arm button on the keychain transmitter for 2
seconds.
þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren will not sound.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection
oDoors Lock - Optional

Page4
Note: If the optional Headlamp illumination feature has been added, and has
been selected for operation when arming, as an added convenience, the
system will turn on the headlights when the system is armed.
ARMINGTHE SYSTEM-PASSIVE(AUTOMATIC)
1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid,
and trunk lid.
þThe dash mounted LED begins to flash rapidly, indicating 30 second
passive arming has begun.
2. Opening any protected entry point during the 30 second passive arming cycle
will immediately suspend automatic arming, and the 30 second passive arm-
ing cycle will restart when all doors are closed. At the end of the passive
arming cycle;
þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren sounds one chirp
If the siren did not sound when arming, then the chirps have
been turned off, and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Lock - Optional
Door locking during passive arming is a selectable feature.
The alarm can be programmed to allow the doors to lock only
when arming using the keychain transmitter, and they
will not automatically lock during passive arming.
PROTECTIONWHILE THESYSTEMISARMED
þOpening any protected door, hood, or trunk lid will cause the alarm to
immediately sound. The alarm will continue to sound for 30 seconds,
then stop and continue to monitor all protected entry points. If the thief left
a door opened, the alarm will sound for six 30 second cycles, remain
armed and ignore that triggered zone.
þWhenever the system is armed, the red dash mounted LED indicator will
slowly flash. This serves as a visual deterrent to the potential thief. The
LED is a very low current bulb, and will not cause the vehicle’s battery to
drain, even when left unattended for extended periods.
þWhenever the system is triggered, the vehicle’s parking lights will flash for
the full 30 second alarm cycle, attracting visual attention to the vehicle.
þOptional - Whenever the system is armed, the vehicle’s starting circuit will
be bypassed. If the thief should choose to ignore the siren, the vehicle can
not be started.
þAny mild impact to the vehicle’s glass will cause the alarm to sound a
short series of warning tones.
þAny strong impact to the vehicle’s glass will cause the alarm to trigger for
the full 30 second alarm cycle.
Note: If the optional interior illumination circuit was installed, the interior light will
flash as well for the full 30 second alarm cycle.

Page5
DISARMINGTHESYSTEM
Note: If the optional 2 step door unlock circuit is installed, when the unlock transmit-
ter button is activated, the drivers door only will unlock, pressing the unlock
button a second time will cause all doors to unlock.
Note: If your transmitter has been configured with single button Lock/Unlock as
shown, to activate the all door unlock feature operate the Lock/Unlock button
a second time within 3 seconds of the first unlock command.
1. As you approach the vehicle, press and release the Unlock/Disarm button on the
keychain transmitter.
þThe dash mounted LED turns off.
The LED will start flashing rapidly, indicating that the system is
rearming automatically. Open any door to suspend the automatic
arming.
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was trig-
gered in your absence. Before turning the key on, examine the
LED to identify which zone was triggered.
þSiren sounds two chirps.
If the siren sounds 4 chirps, then the alarm was triggered in your
absence. Before turning the key on, examine the LED and refer to
the INTRUSION WARNING SIGNALS section of this manual to
identify which zone was triggered.
If the siren did not sound when disarming, then the chirps have
been turned off, and you should refer to the section titled “ELIMI-
NATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Unlock - Optional
o2 Step Doors Unlock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when disarming, as an added convenience, the sys-
tem will turn on the headlights when the system is disarmed.
SILENT DISARMING (Must be activated during programming)
Note: If the optional 2 step door unlock circuit is installed, when the unlock transmit-
ter button is activated, the drivers door only will unlock, pressing the unlock
button a second time will cause all doors to unlock.
Note: If your transmitter has been configured with single button Lock/Unlock as
shown, to activate the all door unlock feature operate the Lock/Unlock button
a second time within 3 seconds of the first unlock command.
1. Press and hold button the Unlock/Disarm button on the keychain transmitter for 2
seconds.
þRed dash mounted LED turns off.
The LED will start flashing rapidly, indicating that the system is
rearming automatically. Open any door to suspend the automatic
arming.
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was trig-
gered in your absence. Before turning the key on, examine the
LED to identify which zone was triggered.

Page6
þSiren will not sound.
If the siren sounds 4 chirps, then the alarm was triggered in your
absence.Beforeturningthe keyon,examinetheLED and refertothe
INTRUSION WARNING SIGNALS section of this manual to identify
which zone was triggered.
oDoors Unlock - Optional
o2 Step Doors Unlock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when disarming, as an added convenience, the system
will turn on the headlights when the system is disarmed.
WHILETHESYSTEMISSOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security
system, simply press and release any transmitter button other than the Unlock/Disarm
button. This action will turn off the siren yet leave the vehicle fully armed and protected.
Thisfeatureisparticularlyusefulif you are awareofchildrenplayingnearyourvehiclethat
may accidently trigger your security system. In this case you can cancel the siren
sounding without disarming your alarm.
INTRUSIONWARNINGSIGNALS
This system will inform you if an intrusion attempt has occurred while you were away
from the vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the
parking lights will flash 3 times when disarming the system. Enter the vehicle and
observe the red dash mounted LED to identify which zone was triggered.
If the LED is flashing one time...pause...one time...pause...etc., then an intru-
sion attempt was made to the shock sensor, or an accessory triggering device
that may have been added to the system.
If the LED is flashing two times...pause...two times...pause...etc., then an
intrusion attempt was made to a hood or trunk pin switch that was added to the
system, or to a light activated entry point if the alarm was installed using the
voltage sensing feature.
If the LED is flashing three times...pause...three times...pause...etc., then an
intrusion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory, and will only be
erased when the ignition key is turned on.
VALETSWITCH
The valet switch allows you to temporarily bypass all alarm functions, eliminating the
need to hand your transmitter to parking attendants or garage mechanics. When the
system is in valet mode, all alarm functions are bypassed, however the remote panic
feature and remote door locks will remain operational. In addition, the parking lights will
flash to indicate locking and unlocking. To use the valet mode, the system must first be
disarmed either by using your keychain transmitter, or by activating your personalized
manual override code.
1. Enter the vehicle, and turn the ignition key to the on position.
2. Press and hold the valet push-button switch until the dash mounted LED
turns on solid. The system will remain in the valet mode.
3. To return to normal operation, press and release the push-button switch any
time the ignition is on.
NOTE: Always remember to return the system to normal operation. This will ensure
that the vehicle remains protected at all times.

Page7
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHEVALET SWITCHMANUAL OVERRIDE
Your Security System can be disarmed without the use of the keychain transmitter.
This is necessary, since you will need the ability to operate your vehicle if the
transmitter is lost or its battery fails. If your system has been selected for Valet
Switch manual override as indicated on the last page of this manual, to bypass
the alarm system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet push-button switch.
The alarm system will stop sounding and enter the (bypass) mode. You can now
start and operate the vehicle normally.
Typically this override mode is used only if the transmitter has become inopera-
tive.
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows
the consumer to program a personal override code, offering a higher level of
security. To take advantage of this option, programmable feature # 10 must be
selected for the Custom Code Option. Consult your installation center for
programming details. The system comes from the factory with a pre-programmed
override code of 11. To change this default override code, do the following:
1. Disarm the system by use of the transmitter, or by use of the emergency
override sequence. Turn the ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and
releasing the push-button switch from 1up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off
then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and
releasing the push-button switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
If the new code was accepted, the unit will report back the newly entered code, by
flashing the LED, first indicating the 10ths digit, pause and then the units digit.
The unit will report the new code three times with a one second pause between
each code, then the system will begin arming. If the LED flash pattern
reports the previously stored code, the new code was not entered correctly. Please
repeat steps 1 through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not
recognize a 0 (Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert
back to the last successfully stored code.

Custom Code Programming Example:
To Change the code from the factory preassigned code of 11 to “52” you would do
the following:
1. Disarm the system by use of the transmitter, or by use of the emergency
override sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
5. Within 10 seconds, begin to press and release the push-button switch to set
the tenths digit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 seconds of the last press of the push-button, turn the ignition switch
off then on.
7. Within 10 seconds, begin to press and release the push-button switch to set
the units digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash
pattern.
You will note the LED flashing five times, pause, and then flash two times, pause.
This pattern will be repeated three times indicating the new code (52) has been
accepted and stored in memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered,
this indicates that the code has not been changed. You will have to repeat
steps 1 through 7 above being certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0
(Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert
back to the last successfully stored code.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHECUSTOMCODEOVERRIDE
Assuming the override code programmed has not been changed, and the default
override code of 11 is in the system's memory.
1. Enter the vehicle and turn the ignition switch to the on position.
Note: The siren will sound.
2. Within 5 seconds, press and release the push-button switch 1 time.
3. Within 5 seconds, turn the ignition switch off then on.
4. Within 5 seconds, press and release the push-button switch 1 time.
5. Turn the ignition switch off then on and start the vehicle.
Note: If you have changed the programmed override code then substitute your
new code tenths for step 2 above, and units for step 5 above.
Page8

ELIMINATINGTHE NORMALARM /DISARM CHIRPS
As explained earlier in the manual, you can eliminate the chirps selectively any
time you arm or disarm the system simply by holding the ARM or DISARM button
for two seconds. If you find the normal arming and disarming chirps annoying,
they can be turned off permanently, eliminating the need to hold the ARM / DIS-
ARM button for 2 seconds. To do this,
1. Turn the ignition key on then off.
2. Within 10 seconds, press and release valet switch three times.
3. If the chirps were on before you started, then you will hear two chirps indicat-
ing they have been turned off.
If the chirps were off before you started, then you will hear one chirp indicating
they have been turned on.
NOTE: Whenever the chirps are bypassed, the 4-chirp intrusion indicator
and 3 chirp defective zone indicator will always operate. Since these are
important warnings to you that something has happened, they cannot be
eliminated.
REMOTEPANICOPERATION
The Lock or Unlock button on your keychain transmitter also functions as a panic
switch for use in emergency situations. To use remote panic,
1. Press and hold the Lock or Unlock button on the keychain transmitter for 3 or
more seconds. The alarm will immediately sound.
2. To stop the alarm, press and hold the Lock or Unlock button on the transmitter
again for 3 seconds. If the button is not pressed, the alarm will automatically
stop after 30 seconds. Also if any transmitter button other than the Lock or
Unlock button is pressed and released, the Panic mode will be turned off
immediately. The normal function of this transmitter button will be suspended
during the Panic sounding period.
3. During the panic mode, the Lock and Unlock buttons can be used to lock and
unlock the doors, (if the option is installed), however once the unlock/disarm
button is pressed, the vehicle's starter inhibit device, (where installed) will be
disabled allowing the vehicle to start.
NOTE: While in the Panic mode, pressing and releasing the Lock or Un-
lock buttons will, if the option is installed, lock and unlock the doors respectively.
While in the panic mode, anytime the Unlock button is pressed, the panic feature
will continue for the allotted 30 seconds, however, the security system will be
disarmed allowing the vehicle to start.
R.F.SHOCK SENSORMODE SELECTION
The way in which your alarm system reacts to threatening vibrations, created by
attempts to enter the vehicle by breaking a window, is adjustable by the transmitter
immediately after arming. There are 4 modes of operation that can be selected
by the operator.
1. Normal Operation (default mode)
In this mode, any strong vibrations will cause the siren to sound (full
detect) for 30 seconds. Any lesser vibration will cause the siren to emit
about 6 short warn away chirps, (pre-detect).
2. Stage 1 (Omit pre-detect)
In this mode, the warn away chirps created by the lesser vibration will be
deleted. If strong vibration occurs, the siren will sound.
Page9

3. Stage 2 (Omit pre & full detect)
In this mode, both the pre-detect stage, and the full trigger stage of the sensor
are defeated. The unit will not react to vibration of any magnitude.
4. Stage 3 (City Mode)
In this mode, the pre-detect chirps will change from six pre-warning tones to
a full 10 seconds of warning chirps.
The full detect trigger duration will be reduced from 30 seconds to 15 seconds.
NOTE: Setting the stage of the shock sensor will be effective for one arming cycle
only. Once the system has been disarmed, the very next arming cycle will
cause the sensor to default to the normal operation stage.
To change or adjust the shock sensor, press and release the ARM button of you
keychain transmitter.
1.Within 2 seconds of arming, press and release the ARM button 1 time, to
defeat the pre-detect stage of the shock sensor. (The lights will flash and the
siren will chirp once.)
2.Within 2 seconds of step 1, press and release the ARM button 2 times, to
defeat the pre and full detect stages of the shock sensor. (The lights will
flash and the siren will chirp twice.)
3.Within 2 seconds of step 1, press and release the ARM button 3 times to
enter the "City Mode" of operation. (The lights will flash and the siren will chirp
three times.)
SAFETY(RedHandled )CONTROLSWITCH
The control switch allows you to temporarily disable the remote starting function
of your APS-995. To disable the unit, move the red handled control switch to the
off position.
The control switch also allows you to select between 2 hour start up and 4 hour
start up when using the automatic start up timer mode. The factory preset start up
time for this mode is every 4 hours. To select between 2 or 4 hour start-up timer:
1. Begin with the control switch in the on position
2. Turn the ignition switch on then off
3. Within 10 seconds, move the control switch off, on, off, on (2 switch cycles) to
select a 2 hour start timer. After 10 seconds expire, the parking lights will
flash and the siren will chirp 2 times confirming that the two hour start cycle is
set. Or, within 10 seconds move the control switch off, on, off, on, off, on,
off, on (4 switch cycles) to select a 4 hour start timer. The parking lights will
flash and the siren will chirp 4 times confirming that the 4 hour start timer is
set.
REMOTESTARTINGTHEVEHICLE
The APS-995 WILL NOT start the vehicle if any one of the following conditions exists:
1. The Vehicle Hood Is Opened.
2. The Gear Selector Is In Any Gear Other Then Park.
3. The Brake Is Depressed.
4. The Safety Control Switch Is In The Off Position.
WARNING! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
Page10

To Remote Start The Vehicle:
Press and release the programmed channel of your keychain transmitter two times
within 2 seconds. The vehicle will start and remain running for the pre-programmed
5, 10, 15, or 20 minutes. As a visual indication, the parking lights will flash or turn
on depending on the programming set up by your installation center.
When you arrive at your vehicle, disarm the alarm system by pressing and releas-
ing the arm/disarm button of your keychain transmitter. Enter the vehicle and turn
the ignition key to the on position.
CAUTION! Do not turn the key to the start position. This will cause the
starter motor to engage with the already running engine which could result in
damage. Step on the brake pedal to disengage the remote start unit. The vehicle
will continue to run but now on it's own power.
NOTE: The engine will stop running before the expiration of the pre-programmed
run timer if you complete any of the following:
1. Press and release the programmed channel of your keychain transmitter two
times within 2 seconds.
2. Depress the brake pedal.
3. Open the hood.
4. Move the red handled control switch to the off position.
5. Race the engine to above 4000 RPM.
OPERATINGONAUTOMATICSTARTUPTIMERMODE
The APS-995 has the ability to automatically start the vehicle every 2 or 4 hours over
a 48 hour period. This feature is especially useful in cold climates where the only
means to keep the engine and engine fluids warm is to periodically start the en-
gine.
CAUTION! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
TOBEGINTHEAUTOMATICSTARTUPTIMER
1.Turn the ignition key on then off.
2.Within 10 seconds, activate the RF start command two times. (Push the
programmed channel button of your keychain transmitter 4 times).
The parking lights will flash and the siren will chirp 4 times indicating the timed start
mode is activated.
The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the pre-
programmed time (5,10,15 or 20 minutes), and then shut off. This will continue for
48 hours.
NOTE: The automatic start up timer can also be initiated from the keychain trans-
mitter. To do this:
1.Start the vehicle using the keychain transmitter by pressing and releasing the
second channel transmitter button 2 times.
2.Shut off the vehicle using the keychain transmitter by pressing and releasing
the second channel transmitter button 2 times.
3. Within 10 seconds of step 2, activate the RF start command two times. (Push
the second channel button of your keychain transmitter 4 times).
The parking lights will flash and the siren will chirp 4 times indicating the timed start
mode is activated.
Page11

CANCELINGTHEAUTOMATICSTARTUPTIMER
To cancel the automatic start up timer do one of the following;
1. Start the vehicle manually with the use of the ignition key and depress the brake
pedal.
2. Remote start the vehicle using your keychain RF transmitter.
OPTIONALDEVICEOUTPUT(CHANNEL3)
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installa-
tion center for other configurations not listed above that may have been programmed
to operate a specific feature of your system.
This security system is equipped with an output which will activate when the appro-
priate transmitter button is depressed for 4 seconds. Optional devices that may be
connected to this channel are;
oRemote Electric Trunk Release
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
NOTE: In addition there may be a second optional feature connected to your sys-
tem that when the same transmitter button is pressed and released 2 times
within 3 seconds (double pressed), the second optional feature will acti-
vate. This output is typically used for a remote start option and will likely
prevent inadvertent activation of the remote start device if young children are
playing with the hand held transmitter.
If your vehicle is not equipped with an electronic trunk release switch, or other option
listed, this feature may have been connected to another accessory. Please ask your
dealer for further information.
ADDITIONALREMOTEFUNCTION(CHANNEL4)
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installa-
tion center for other configurations not listed above that may have been programmed
to operate a specific feature of your system.
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are; oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
Page12

ADDITIONALREMOTEFUNCTION(CHANNEL5)
ControlledBy: oTrunk/KeyButtonoOptionButtonoLock+Unlock ButtonsoLock
+ Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons o
Unlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are;
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
ADDITIONALREMOTEFUNCTION(CHANNEL6)
Channel 6 is an alternate output that can be controlled by the unlock button of the
transmitter, or by and independent button or combination of buttons. For your vehicle
this output is
ControlledBy: oTrunk/KeyButtonoOptionButtonoLock+Unlock ButtonsoLock
+ Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons o
Unlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are;
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
ADDITIONALREMOTEFUNCTION(CHANNEL7)
Channel 7 is an alternate output that can be controlled by the unlock button of the
transmitter, or by and independent button or combination of buttons. For your vehicle
this output is
ControlledBy: oTrunk/KeyButtonoOptionButtonoLock+Unlock ButtonsoLock
+ Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons o
Unlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
Page13

Page14
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel
are; oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
System Status:
The LCD based remote control, Model # 3BCR, supplied with your system indicated
the status of your vehicle's system whenever the "Red" button is operated based on
the last completed function of the system. If the Red button along with button #1 is
operated together, the transmitter will send a status request signal to the vehicle and
the vehicle will send a update to the transmitter. Also when this transmitter is used
to operate a function of the remote start, or security system, the LCD will indicate the
function operation completed by lighting a icon on the LCD display screen. The
specific Icons indicate the following:
When Disarmed, Press the Arm/Lock button to Lock and Arm the System. The Lock
Icon will flash in the vehicles windshield on the LCD Screen, and the word ARM will
display in the front bumper area.
When Armed, Press the Disarm/Unlock button to Unlock and Disarm the System.
The Unlock Icon will flash in the vehicles windshield on the LCD Screen.
When the Trunk Release Button Has Been Operated the trunk open icon will
flash on the LED Screen.

Page15
When the Remote Start Function has been Operated, The three exhaust bars
turn "ON", on the LED screen. Once the vehicle is running, the three bars will
flash all the while the vehicle is running.
When Panic Mode has been activated and the system is armed the vehicle's
lights and the word ARM will flash on the LED screen. If the system is dis-
armed, and the Panic Mode is activated, only the lights will flash on the LCD
screen.
When ever the vehicle is operated from the two way transmitter, the unit will
beep responsive to the function executed at the vehicle. 1 beep when armed, 2
beeps when disarmed, etc... at times It may be inconvenient or too noisy to
hear the beep tones, so the system allows you to set the unit for vibrate mode.
To toggle on or off beep tones/vibrate, press the red button and button 3
simultaneously.
The unit will vibrate and the mute icon will be displayed, indicating vibrate is on, or
the unit will beep and no icon displayed, indicating beep tones are active.
If the alarm system has been triggered, the icon displayed on the transmitter LCD
will indicate the which zone has been activated, as well sound the beep tones, or
vibrate dependent upon the setting as shown above. The following trigger pat-
terns will be displayed.
Triggered and the entry attempt was made to one of the vehicle doors.

Triggered and entry attempt was made to the vehicles hood or trunk.
Triggered and entry attempt was made to the vehicles glass, or the vehicle has
been hit or bumped hard enough to cause a response from the vibration detector.

ADDITIONALICONSTHATMAYBEDISPLAYEDARE:
If the arm/disarm chirp tones have been turned off at the vehicle, when you arm,
or disarm, the display will indicate this as shown, and there will be no arm/
disarm chirps at the transmitter. This is true if the transmitter is set for vibrate
mode.
When the vehicle is armed, and a door is opened, or ajar, the transmitter will chirp
3 times, the lights will flash, and then the display will flash as shown. When the
door is closed or the zone clears, the transmitter will chirp 1 time, and the display
will clear.
When the vehicle is armed, and the hood or trunk, is opened or ajar, the transmit-
ter will chirp 3 times, the lights will flash, and then the display will flash as shown.
When the hood or trunk is closed, or the zone clears, the transmitter will chirp 1
time, and the display will clear.
When the vehicle is armed, and the vibration sensor input is active, the transmit-
ter will chirp 3 times, the lights will flash, and then the display will flash as shown.
When the input or the zone clears, the transmitter will chirp 1 time, and the display
will clear.

ADDITIONALREMOTEFEATURES:
The two way remote control unit allows you to access information from the
vehicle, light the display, and toggle the transmitter from the mute to vibrate. To
Access these features, do the following:
Pressing this button for 1 second and releasing
will turn the backlighting of the display on for 3
seconds. If the battery is low, the transmitter will
emit a beep tone.
Pressing these two buttons simultaneously for 1
second will send a update request to the vehicle.
The vehicle will transmit system status which will
then be displayed in the LCD panel. When the
battery is replaced, this button combination
should be used when in range of the vehicle to
insure transmitter is updated.
Pressing these two buttons simultaneously will
allow you to turn the pager mode on and off. This
is for future upgrades which will become
available for the APS-995.
Pressing these two buttons simultaneously will
toggle the transmitter between vibrate mode or
beep mode. Use this function in a noisy environ-
ment where you may not hear the beep tones, or
in a environment where noise cannot be toler-
ated, library, lecture hall, theatre, etc...
NOTE: Your APS-995 is shipped with two transmitters, 1 two way,
shown above, and 1 one way, shown right. The two way unit is
programmed from the factory with button 1 for lock and unlock,
button 2 for trunk release and remote start, and button 3 for
channel 3 option. The one way transmitter is programmed as per
the icons shown on the button pad.
Although this is the default programming from the factory, this can
be changed for you to any configuration you prefer. Please refer to

APS 995
SYSTEM FUNCTIONS AT A GLANCE
DASHLEDINDICATORS
RAPIDFLASHING = PASSIVE ARMING/ACTIVE
REARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ON SOLID = VALET MODE
3FLASH...PAUSE = INTRUSION ZONE 3
2FLASH...PAUSE = INTRUSION ZONE 2
1FLASH...PAUSE = INTRUSION ZONE 1
SIRENCHIRPINDICATORS
1 CHIRP * = ARM
2 CHIRPS * = DISARM
3 CHIRPS = ARM/DOOR OPENED
4 CHIRPS = DISARM/INTRUSION
* These chirps are optional, and can be de - activated.
PARKINGLAMPINDICATORS
1 FLASH = ARM
2 FLASHES = DISARM
3 FLASHES = DISARM /INTRUSION

©2001AudiovoxElectronicsCorp.,150MarcusBlvd.,Hauppauge,NY11788
128-6165
