Audiovox Platinum+ APS 687C User manual

128-8783b
1 of 28
1
Model APS-687C
Installation Manual
Vehicle Security System
with Remote Start
Rev B: New FormatAdd Timing PASD & Light Blue + DBI Lock, Lock, Lock 5/2013
If booklet format, pages 26-30, Programming & Wiring Diagram shall be foldout or seperate 5 sheets
front & back.
PATENTED: www.voxxintl.com/company/patents
Table Of Contents:
BeforeYou Begin Page 2
Wire Harnesses Quick View Page 3 - 4
InstallationOfTheMajor Components Page 5
6 Pin Power Harness Wiring Page 6
4PinAlternate IgnitionHarness Wiring Page 7
12PinAccessory Input/OutputHarnessWiring Page 8 -11
5PinAuxChannelOutputHarness Page 11 - 12
Door Lock Harness Wiring Page 13 -15
3PinInput/OutputHarness Wiring Page 15
4PinAuxiliary OutputHarnessWiring Page 16
2PinTransponderHarnessWiring Page 16 -17
TelematicPortInformation Page 17
5PinAntenna Harness Page 17
DBIPortInformation Page 17
Time StartProgram Page 17-18
Diesel Engine Settings Page 18
TachRate Setting Page 19 -27
EngineMonitoring Selections,(VoltageTach,DBI, Hybrid,) Page 18 -19
DiagnosticsAccess &Information Page 19
Multi CoilPackAdaptorOptional Page 19 - 20
TestingYourInstallationHoodPinSafety Page 20
ManualOverrideSafetyTestingandOperation Page 20 - 21
NeutralSafetySwitchTesting Page 21 - 23
CompletingYourInstallation Page 23
ProgrammingTransmitters Page 24
ProgrammingAlarm FeatureBank 2 Page 24 - 25
ProgrammingRemote StartFeature Bank3 Page 26 - 27
CircuitWiring Layout Page 28

128-8783b
2 of 28
2
Before You Begin
PROFESSIONAL INSTALLATION IS
STRONGLYRECOMMENDED
Rolldown windowtoavoid lockingthe keysinthe vehicleduring
installation.
Avoidmounting componentsorrouting wiresnearhotsurfacesor
nearmoving partslike thesteeringwheelasit mayprevent proper
operationof thevehicle.
Tapeorloomwires underthe hoodand dashfor protectionas well
appearance.
Usegrommetswhen routingwiresthroughmetalsurfacestoprevent
chafingandshorting.
Usea DigitalMulti Meterfor testingand verifyingcircuits. DONOT
USEA"TEST LIGHT" OR "COMPUTER SAFE PROBE" as these
cansetoff airbags ordamage sensitive vehiclecomputers and
electronics.
For technical support go to www.prestigecarsecurity.com
or call 1 800 225 6074
This device complies with FCC Rules Part 15 Operation is subject to the following two conditions
(1) This device may not cause harmful interference and
(2) This device must accept any interference that may be received, including interference that may cause
undesired operation.
NOTE:The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifica-
tions to this equipment. Such modifications could void the user’s authority to operate the equipment

128-8783b
3 of 28
3
12 Pin Main Wiring Harness #1123751
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
Yellow/Black (+)OutputToControl FactoryAlarm
Green/Orange TachometerInput
Black Chassis Ground
Gray/Black NegativeInhibitShutdownInput(-)
LightBlue Ground OutputWhile Running(-) 300mA
Green/Yellow Diesel WaitToStartInput
Grey ShutdownInput(-)
NoConnection
Brown PositiveInhibitShutdownInput(+)
Brown/Black BrakeShutdownInput(+)
White ParkingLight Output
White Parking Light Input
5 Pin Aux Channel Output Harness #1123762
LightBlue/Green Channel5 Output (-)300mA
5 Pin Antenna Harness Part # 1123905
DarkBlue Channel 3Output(-)300mA
Green/Black Channel4Output (-)300mA
4
5LightBlue/Black Channel6 Output(-)300mA
Blue/Red Channel7Output (-)300mA
3 Pin Accessory Output Harness #1123310
1
2
3
Green/White DomeIlluminationOutput (-)300mA
Blue/Black ExternalActivationTriogger Input
Black/White HornOutput (-)300mA

128-8783b
4 of 28
4
6 Pin Power / Start Harness #1123742
1
2
3
4
5
6
Purple Accessory(+)
Blue Ignition1(+)
Red Battery 2 - 12V (+)
Red/White Battery 1 - 12V (+)
Yellow StarterOutput
Green Ignition2(+)
4 Pin 3rd Ignition / Start Harness #1123743
1
2
3
4
Orange/Black ParkingBrake Input(-)
N/C N/C
Red/Black Ignition3Input
Pink Ignition3Output
4 Pin Alternate Output Harness #1122585
1
2
3
4
Black/Blue FactoryDisarm /Pulse BefforeStart(-)
Black/Green FactoryArm /PulseAfterStart(-)
Black/Red PulseAfterShutdown(-)
Black/Yellow PulseDuring Crank(-)
3 Pin Door Lock Output Harness #1122906
1
2
3
Red (-)Lock / (+) Unlock
Green (+)Lock / (-) Unlock
Red/Black (-)2ndUnlock
2 Pin Transponder Output Harness #1123292
1
2Red Battery(+) 100mA
Black (-)OutputWhileRunning 100mA

128-8783b
5 of 28
5
This Remote Start/Alarm System is designed to be used with Automatic Transmission- Fuel Injection
Gas or Diesel Vehicles Only!
INSTALLATION OF THE MAJOR COMPONENTS:
CONTROLMODULE: PART # 1365034
Selectamounting location inside the passenger compartment(upbehind the dashboard). The mounting
location selected must be within 24" of the ignition switch wiring harness to allow connection of the 6 pin
main wiring harness. Be certain that the chosen location will not interfere with proper operation of the
vehicle. Avoid mounting the module to or routing the wiring around the steering shaft/column, as the
moduleorwiring maywraparoundorblock thesteeringwheelpreventingproper control ofthevehicle. The
modulewillbe secured after allwiringis completed which willallowcomplete access until thejobis done.
Do Not Mount The Module In The Engine Compartment, as it is not waterproof.
HOOD PIN SWITCH: PART#1363699
The pin switche included in this package is intended for protecting the hood area of the vehicle. In all
cases,theswitch must be mounted toagrounded metal surface. When the pinswitchis activated, (hood
open), itwillsupplyagroundtotheinputwireactivating the alarm. In addition, the hood switch is required
for the safety shut down of the remote start unit. If the vehicle is being worked on, this hood switch
prevents the remote start activation even if the RF command to start is issued. This switch must be
installed in all applications. Failure to do so may result in personal injury or property damage.
THEPUSH-BUTTONPROGRAMSWITCH/LED/RECEIVER/ANTENNAASSEMBLY: PART #1181202
The Superheterodyne ReceiverAntennaAssembly provided with this unit allows routing from below the
dashboardfor maximum operatingrange. Choosealocationabovethe belt line(dashboard)ofthevehicle
for best reception. Special considerations must be made for windshield glass as some newer vehicles
utilize a metallic shielded window glass that will inhibit or restrict RF reception. In these vehicles, route
theantenna toward a rearwindow location for best reception. Secure the antennawith double stick tape
provided.
WARNING!! This unit is tobe used in vehicleswith AUTOMATIC TRANSMISSIONS only! Although this
combinationAlarm/Remote Start unit is a sophisticated system with many advanced features, IT MUST
NOT beinstalled into a vehicle withamanually operated transmission. Doing somayresult in serious
personalinjuryandpropertydamage.

128-8783b
6 of 28
6
IMPORTANT!
DONOTPLUGTHESIXPINMAIN POWERHARNESSORTHEMULTIPININPUT/OUTPUTHARNESS
INTO THE CONTROL MODULE UNTIL ALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE.
AFTER SELECTING YOUR TARGET WIRES AS DEFINED BELOW, DISCONNECT THE NEGATIVE
BATTERYCABLEFROMTHE VEHICLE BATTERYPRIORTOMAKINGANYCONNECTIONS.
Note: Do not remove the fuse holders from this wire harness. Fuses must be used and located
as close as possible to the power source for adequate protection of the vehicle.
WIRING THE 6 PIN MAIN POWER HARNESS: PART #1123742
Note: Do not remove the fuse holders from this wire harness. Fuses must be
used and located as close as possible to the power source for adequate pro-
tection of the vehicle.
1 VIOLET Wire: Accessory Output
Connect this wire to theAccessory wire from the ignition switch. This wire will show + 12 volts when the
ignition switch is turned to the "ACCESSORY" or "ON" and "RUN" positions, and will show 0 volts when
the key is turned to the "OFF" and "START" or "CRANK" positions.
2 BLUE Wire: Ignition 1 Output
Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the
ignition key is turned to the "ON" or "RUN" and the "START" or CRANK" positions, and will have 0 volts
when the key is turned to the "OFF" and "ACCESSORY" positions.
ForDieselApplications,this wire must be connected to the ignition circuitthatpowerstheglowplugsif the
vehiclerequiresglowplugpre-heating.(See selectablefeatureBank3#11)
3 Fused RED WIRE: + 12 Volt Battery 2 Source
Locatethevehiclebatterywire(s)at the ignition switch. Verification:These wires will register voltageinall
positions of the ignition switch. Connect the Red wire to the vehicle's battery wire. This wire provides
power for the start relay and the accessory relay.
4 Fused RED/WHITE WIRE: + 12 volt Battery 1 Source
Locatethevehiclebatterywire(s)at the ignition switch. Verification:These wires will register voltageinall
positions of the ignition switch. Connect the Red w/White wire to the vehicle's battery wire. This wire
provides power for the control circuit as well as the ignition 1 and ignition 2 relays.
5 YELLOW Wire: Starter Output
Careful consideration for the connection of this wire must be made to prevent the vehicle from
starting while in gear. Understanding the difference between a mechanical and an electrical
Neutral Start Switch will allow you to properly identify the circuit and select the correct installa-
tion method. In addition you will realize why the connection of the safety wire is required for
all mechanical switch configurations.
Failureto make this connection properlycan result in personal injuryand property damage.
Inallinstallations it is the responsibilityofthe installing technician to testtheremote start unit and ensure
that the vehicle cannot start via RF control in any gear selection other than park or neutral.
Inbothmechanicalandelectricalneutralstartswitch configurations,theconnectionof theYellowwire will
bemadeto the low currentstartsolenoid wire of theignitionswitch harness. This wire willhave+12 volts
when the ignition switch is turned to the start (crank) position only. This wire will have 0 volts in all other
ignition switch positions.
NOTE: This wire must be connected to the vehicle side of the starter cut relay (when used). For the
electrical neutral switch configuration, this connection must be made between the starter inhibit relay,

128-8783b
7 of 28
7
( when used ) and the neutral safety switch as shown in the following diagram.
Failure to connect this wire to the ignition switch side of the of the neutral safety switch can result in
personalinjuryandpropertydamage.
SEENEUTRALSTARTSAFETYTESTFORFURTHERDETAILS.
YELLOWSTART WIRE DETAIL
6 GREEN Wire: Ignition 2 Output
Connect this wire to the ignition 2 wire from the ignition switch. This wire will show + 12 volts when the
ignition key is turned to the "ON" or "RUN" position and is some cases the "START" or CRANK" position.
This wire will show 0 volts when the key is turned to the "OFF" and "ACCESSORY" positions.
NOTE:Seeprogramminginformation(Bank3 Selection #2) concerning this wire to allowoutputduringthe
"START"mode.
WIRING THE 4 PINALTERNATE IGNITION HARNESS PART #1123743
Note: Do not remove the fuse holders from this wire harness. Fuses must be
used and located as close as possible to the power source for adequate pro-
tection of the vehicle.
1 ORANGE/BLACK Wire: ParkingBrakeInput
Thiswire isusedonlywhenthe turbotimermode,Bank 3,feature#16 isselectedON. Thisinput insures
thatthevehicleparkingbrakeisappliedwheneverthevehicleissetupforandtheturbotimercircuitisused.
Thisinputmustswitchtogroundwhenthevehicle'sparkingbrakeisapplied.ConnecttheOrange/Blackwire
tothenegative output of the vehicle'sparkingbrakeswitch.
2N/C
This cavity of the connector is empty
3 RED/BLACK Wire: + 12 Volts Input
Note:TheRed/BlackandPinkaredrycontactsandmaybeusedfornegativeswitchingwhennecessary.
Connecting the Red/Black to chassis ground will result in Pink being ground when the R/S is activated.
Thisinputistobeconnectedtoaseparate,(OtherthanthewireRedorRed/Whiteisconnectedto),constant
on+12voltsourcewhichwillsupply+12voltpowertotheadditionalignitionoutput,(Pink),wire. Connect
this wire to a separate + 12 Volt source.
4 PINK Wire: Additional Ignition Output
Thiswirecanbeusedasanadditional+12VoltignitionoutputsuppliedbytheRed/Blackwire. Thisoutput
canbeselectedto beonoroffduring thestartcycle. (Seefeaturebank 3selection#8) Connectthis wire
to the third ignition circuit in the vehicle and set the selectable feature # 8 of Bank 3 according to the way
inwhich the vehicle's ignitionswitch operates.

128-8783b
8 of 28
8
WIRING CONNECTIONS: 12 Pin Accessory Input/Output Harness PART # 1123751
1 Yellow/Black Wire: + 12 Volt Alarm By - Pass Output
Note: You must disconnect the ignition input of the alarm from any other wire that it is presently connected
to in the vehicle.
Thiswireprovidesa+12Voltoutputwhentheignitionkeyisturnedtothe“ON”position,and0Voltswhentheignition
key is “OFF” or when the vehicle is running under the control of the remote starter.
This wire should be connected to the ignition input of the alarm system.
This output will allow you to remote start the vehicle while leaving the alarm armed, and to lock/unlock the doors
while running under control of the remote start unit.
2Green w/ Orange Wire: Tachometer Input Signal
This wire will continually monitor the engine's tach rate while the unit is under power of the Remote Start
module. This wire will be routed to the vehicle ECM tach input or through the firewall into the engine
compartmentand connect to the negative side of the ignition coil. This Remote Start unit learns the tach
rate of the vehicle and in most cases will operate properly from one multi coil pack regardless of the
numberof cylinders. If the vehicle hasa single coil unitfor each cylinder,itmay be necessary toconnect
this wire to more than one cylinder for proper tach reference. See Multi Coil Pack Adaptor wiring detail
shownlaterin this manual for additionalinformation.
Note: ForHybrid mode selection, Bank 3feature selection 5, this connectionis not required, the unitwill
start the vehicle and run the allotted time based on feature selection and crank duration.
3 Black Wire: Chassis Ground Source
ConnecttheBlackwiretoaknownvehicle ground source or to a solid clean metal part of thechassis. Be
certain to remove any paint or grease and secure this wire with a self tapping screw and ring terminal.
4 Gray w/ Black Wire: Negative Inhibit Input 2
Anytimethegrayw/blacktracerwireisgrounded,theRemoteStarterwillstopoperating,evenifthesignal
isreceivedfromthetransmitter.
Ifthebrakelightswitchinthevehicleswitchesgroundtothebrakelightcircuit,connectthe Grayw/Black
tracewiretotheoutputofthebrakelightswitch.Ifthebrakelightswitchinthe vehicleswitches+12Volts,
do not use the Gray w/ Black wire; see Brown w/ Black tracer wire.
5 Light Blue Wire: Ignition 3 / Ground While Running Output
This wire provides a 300mA ground output that becomes active 3 seconds before the Remote Start Unit initial-
izes, and remains grounded while running plus an additional 2 seconds after the Remote Start Ignition 1 turns
off. In all of the applications described below, a relay will be required. The Light Blue wire can be used to
accommodate the following situations:
A. Sensor By Pass:
If there is a Non Plug in Sensor used with the alarm system and it is not shunted during the Remote
Startactivation period, thenvibrationornoisefromthe running vehiclecancausethealarm to trigger. In
thiscase,connect the Light Blue Wiretoterminal #86 of a externalrelay. Connectterminal# 85 of the
relay to a fused + 12 volt battery source. Cut the sensor's trigger wire and connect one end of the cut
wire to terminal #30 and the other end of the cut wire to terminal #87a. Just before the Remote Start

128-8783b
9 of 28
9
unit is activated, the relay contacts will open, preventing the sensor's operation until the Remote Start
unit shuts off.
B. Additional Ignition Output:
Some vehicle's may require more than three ignition outputs to start and keep the vehicle's engine
running. If this is the case, connect the Light Blue wire to terminal #86 of an external relay. Connect
terminal#85 to afused+12voltsource. Dependent on thevehicle'srequirement,connectterminal#30,
toafused + 12 volt source,orto ground, and connect terminal87to the vehicle to supplytheadditional
ignitionsource.
C. GM VATS Key Override:
If the vehicle has the General Motors VATS system installed, you will need to bypass the system while
the vehicle is operating under the control of the Remote Start Unit. To DoThis:
1.Measuretheresistance of the resistor pellet on theignitionkey then select a resistor within 5%ofthe
key'svalue from the resistor pack supplied.
2. Locate the pair of VATS wires in the vehicle, usually a pair of thin gauge wires running from the
ignition switch to the VATS control module.
NOTE: These wires are typically White w/ Black trace and Violet w/Yellow trace, however in later model
Cadillacs, they are run through an orange sleeve, and are either both Black, both Yellow, or both White
wires. Consultthefactory service manual for additional information.
3. Connect the Light Blue Wire from the Remote Start Unit to terminal #86 of an external relay.
Connect terminal #85 of the relay to a fused + 12 volt battery source.
4. Cut (#1) wire (as shown), and connect the ignition switch side of the cut wire to terminal #87a of the
relay. Connect the other side of the (#1) wire to terminal #30.
5.Connect the previously selected resistor from terminal #87 to the second (#2) wire(as shown).
NOTE:The above information andfollowingdiagram is for the GMVATS system only.
D. Anti-Grind Starter Circuit Connection:
This wire, when connected to a starter inhibit relay, as shown in the diagram below, will prevent the
customerfrom engaging the starterwhile the vehicle isrunning under control ofthe remote start.

128-8783b
10 of 28
10
Configured in this way, while the remote start is controlling the vehicle, the light blue wire has ground on it
allthe time. This ground willcause the relayto energize preventing currentflow through thenormally
closed contacts. This will prevent a customer who inadvertently turns the ignition switch to the start
position, from sending current to the starter.
6 Green/Yellow Wire: Diesel Wait To Start Input
The Green/Yellow wire of the 12 pin connector will connect to a diesel vehicles glow plu wire. When the unit receives
a start command, this wire must go to + 12 then to ground to allow the crank sequence to begin. When ignition #1
is activated by the remote start unit, the glow plug circuit gets energized, (+ 12 volts), when the glow plug circuit of
the vehicle drops the + 12 volts, which effectively grounds the wait to start input, then 500mS later the starter will
engage. This wire can also be connected to the Glow Plug Bulb wire in the vehicle if this bulb wire gets + 12 volts
when the ignition comes on and drops low when the glow plug circuits temperature is reached. Be sure to fuse the
wire with a 1 Amp Fuse when connecting to a high current circuit such as a factory glow plug wire. The fuse should
be installed as close to the high current wire as possible. If you are installing this unit in a Gasoline vehicle, this wire
is not used.
7 Gray Wire: Negative Inhibit Input 1
ConnecttheGRAYwiretothepreviouslymountedhoodpinswitchprovided.Thiswirewillberoutedthrough
the firewall into the engine compartment. It is necessary to use an existing grommet when passing wires
throughthefirewalltopreventshortcircuiting.ThisisanimportantsafetyfeatureoftheSystem,failuretouse
thisfeaturecanresultinseriousinjury.Routethewiretothepinswitchandconnectitusingaspade connector
8 Brown Wire: Positive Inhibit Input 1
Any time + 12 Volts is applied to the Brown wire, the Remote Starter will stop operating, even if the signal
isreceivedfromthetransmitter.
Ifthevehiclehasafactoryinstalledhoodpinswitchandthatswitchprovides+12Voltstoanunderhoodlight,
the Brown wire can be connected to the existing pin switch.

128-8783b
11 of 28
11
9 Brown w/ Black Wire: Positive Inhibit Input Plus Trigger When Armed
TheBrownw/ BlackTracewireprovidesan instantshutdownfortheRemoteStartControl modulewhenever
itgets+ 12 volts also triggersthe alarm when armed. If theBrakelights switch in the vehicleswitches + 12
voltsto the brake lightcircuit, connect the Brownw/ Black trace wire to the outputside of the brakeswitch.
This will allow the Remote Start to shut down if an attempt is made to operate the vehicle without the key
while running under the control of the Remote Start. In most vehicles, in order to shift into gear, the brake
pedal must be depressed. The brake input will in turn cause the remote start unit to shut off.
10 No Connection
11 White Wire: Parking Light Flasher Output
This wire is the normally open contact of the on board parking light flash relay. Connect this wire to the
vehicle's parking light feed wire. This is the wire that gets switched on, either (+) or (-), when the vehicle's
parking light switch is activated.
12 White Wire: Parking Light Flasher Input
Thiswireisthecommoncontactoftheonboardparkinglight flasher relay. Ifthevehicleyouareworkingon
has +12 volt switched parking lights, connect this wire to a fused + 12 volt source. (Max. 15Amps)
NOTE: Ifthe vehicle's parking lightsare ground switched, connectthis wire to chassisground.
Parking Light Wiring Detail
5 Pin Aux Channel Output Harness Part # 1123762
1 Dark Blue Wire : Delayed 300 mA Pulsed Output/Channel 3
Thedarkbluewirepulses togroundviaanindependentRF channel from the keychain transmitter. This is
a transistorized, low current output, and should only be used to drive an external relay coil.
Thisoutputisactivatedbythesametransmitterbuttonthatisusedtoactivatetheremotestartfunction.Press

128-8783b
12 of 28
12
andholdthetrunk/keybuttontoactivatethistrunkreleaseoutput,orpressandreleasethetrunk/keybutton
two times within 2 seconds to activate the remote starter.
WARNING: Connecting the dark blue wire to the high current switched output of the trunk release
circuits and some remote start trigger inputs, will damage the control module.
Connect the dark blue wire to terminal 86 of a 30 A automotive grade relay, connect terminal 85 to a fused
+12volt source and wirethe remaining relay contacts to perform theselected function desired.
2 Green w/ Black Trace Wire: 300 mA Latched Channel 4 Output
TheGreenw/BlackTracewiresuppliesa 300mAswitchedoutputwheneverchannelfourofthereceiveris
accessed. Pressing the pre-programmed transmitter button(s) will access channel four and will remain
active, for up to 20 seconds, as long as the transmitter button(s) is held.
This is a low current output and must be connected to a relay to supply power to the device you intend to
control.
Note: Thiswire also can be used for defrost activation as dictated bythe setting of feature # 1 of Bank 3.
Anytimethe vehicle is running under control of the Remote Startand Channel 4 is activated, then
dependentontheselectionofthisfeature, Green/Black will be activated as a pulse for 1second,or
for10 minutes. Note this wire will notoperate when the vehicle is running underthe power of the
ignitionkey,only while under the controlof the remote startorifnot used for defrostthen an output
willoccuras indicated above.
WARNING: Connecting the green/black to a high current circuits, will damage the control module.
Connectthe green/black to terminal 86 of a 30Aautomotive relay.
Connect terminal #85 of the relay to a fused + 12 volt source, and wire the remaining relay contacts to
performtheselected function of channel 4.
3 Lt Blue/Green Wire : Delayed 300 mA PULSED OUTPUT / CHANNEL 5
Thelight blue/green wirepulsestoground viaanindependentRFchannel fromthekeychaintransmitter.This
is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/green to a high current circuits, will damage the control module.
Connectthe green/black to terminal 86 of a 30Aautomotive relay.
Connect terminal #85 of the relay to a fused + 12 volt source, and wire the remaining relay contacts to
performtheselected function of channel 5.
4 Lt Blue/Black Wire : (-) 300mA Selectable Output Channel 6
Thelightblue/black wire pulsestogroundviaan independent RFchannelfromthekeychaintransmitter.This
is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/black to the high current circuits, will damage the control module.
Connect the light blue/black to terminal 86 of a 30Aautomotive relay.
Connect terminal #85 of the relay to a fused + 12 volt source, and wire the remaining relay contacts to
performtheselected function of channel 6.
5 Blue/Red Wire : Delayed 300 mA PULSED OUTPUT / CHANNEL 7
Theblue/red wire pulses toground via an independentRF channel from thekeychain transmitter.Thisisa
transistorized, low current output, and should only be used to drive an external relay coil.

128-8783b
13 of 28
13
WARNING: Connecting the light blue/red to the high current circuits, will damage the control module.
Connectthe light blue/green to terminal 86 ofa 30Aautomotiverelay.
Connect terminal #85 of the relay to a fused + 12 volt source, and wire the remaining relay contacts to
performtheselected function of channel 7.
3 Pin Door Lock/Unlock Harness: (WhiteConnector)300mA Part#1122906
1 Red Wire: (-) Lock or (+) Unlock
TheRedwire provides a (-) Negative Pulsewhenlocking and a (+) Positive Pulsewhenunlocking.
2 Green: (+) Lock or (-) Unlock
TheGreenwireprovides a (+) Positive Pulse whenlockinganda (-) Negative Pulse when unlocking
3 Red/Black: (-) Second Unlock
TheRed w/Black tracewirewillprovide apulsedgroundonly, andwillonlyprovidean outputwhentheunlock
buttonofthetransmitterispressedasecond time after a first unlock command was issued. This is used for
secondstep unlock or alldoors unlock in atwo step circuit. In thisarrangement, Red is usedto control the
drivers door unlock relay, and the Red/Black will be used to control unlock of all other doors.
3 Wire Ground Switched Door Lock Circuits:
In this application, the Red wire of the door lock harness provides a ground pulse during the arming se-
quence,orpulsed ground lock output. Connect theRedwire to the low currentgroundsignal wire from the
factory door lock switch to the factory door lock relay.
TheGreenwireofthedoorlockharnessprovidesagroundpulseduringthedisarmingsequence, or pulsed
ground unlock output. Connect the Green wire to the low current ground signal wire from the factory door
unlock switch to the factory door unlock relay. See the following diagram for Wiring Detail.
3 WireGround Switched Door Lock/Unlock Wiring Detail
Driver Priority Unlocking:
FordriverPriority Unlocking the Red/Black wirewillbe connected to unlock all doors,andthe red, or green
willbeused to unlock thedriversdoordependentuponthedoor unlock polarity. Pleasereviewthereference
diagrambelow and wire according tothe vehicle type you areworking on.

128-8783b
14 of 28
14
Negative Switch Driver Priority
3 Wire Positive Switched Door Locks:
In this application, the Red wire of the door lock harness provides a + 12 volt pulse during the disarming
sequence,orpulsed12volt unlock output. Connect the Red wire to thelowcurrent12volt signal wire from
the factory door unlock switch to the factory door unlock relay.
TheGreenwire ofthedoorlockharnessprovidesa+12 voltpulseduringthearming sequence, orpulsed12
volt lock output. Connect the Green wire to the low current 12 volt signal wire from the factory door lock
switch to the factory door lock relay. See Below For Wiring Detail.
3 Wire Positive Switched Door Lock/Unlock Wiring Detail
Driver Priority Unlocking:
FordriverPriorityUnlocking the Red/Black wire will beconnectedtounlock all doors, and the red,orgreen
willbeused to unlockthedriversdoordependent upon thedoorunlockpolarity. Pleasereview the reference
diagramfollowingand wire according to thevehicletype you are working on.

128-8783b
15 of 28
15
Entry Illumination Detail
Positive Switch Driver Priority
NOTE: Resistive Circuits, Multiplex Circuits As Well As 4 Wire Polarity Reversal and 5 Wire
Alternating 12 Volt Door Lock Control Circuits
Theseapplicationsrequiretheuse of additional components which may includerelays,fixedresistors,orfor
convenience, a Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supplement and or the
Audiovoxfaxbackserviceforinformationonyour particular vehicle for properly connecting to these types of
circuits.
3PinInput/OutputHarness: Part#1123310
Dark Blue/Black Trace Wire: External Trigger Input
The Dark Blue/Black trace wire allows the remote start unit to be activated from an external source. The
intent of this wire is to allow the unit to be controlled from a "POSSE/CAR-LINK" paging system or similar
device.Whenthis wire receives a groundpulse, the unit will startthe vehicle. Connect this wiretoa ground
pulsed output from the controlling circuit.
Green w/ White Trace Wire: Entry Illumination Ground Output
This wire provides a 30 second ground output (300 mA Max.) whenever the remote is used to unlock the
doors. This wire should be connected to an external relay, and wired to the vehicles interior entry lighting
whenevertheoptional Interior Illumination circuit is desired.Seebelow for relay wiring details.
Black w/ White Trace Wire: 300 mA Horn Output
The black w/ white trace wire is provided to beep the vehicle’s horn. This is a transistorized low current
output, and should only be connected to the low current ground output from the vehicle’s horn switch.
If the vehicle uses a +12 VDC horn switch, then connect the black w/ white trace wire to terminal 86 of the
AS 9256 relay ( or an equivalent 30Amp automotive relay ), and connect relay terminal 85 to a fused +12
VDC battery source. Connect relay terminal 87 to the vehicle’s horn switch output, and connect relay
terminal 30 to a fused +12 VDC battery source.

128-8783b
16 of 28
16
WIRING THE 4 PIN AUXILIARY OUTPUT HARNESS Part#1122585
The auxiliary 4 pin connector provides low current outputs to control various functions in the vehicle during
differentstagesof the Remote Startunit's operation. Understandingtheseoutputsand the timeinwhichthey
occur will allow you to determine if they are needed for the particular vehicle you are working on as well as
how to use them.
1 Black w Blue Trace Wire: Pulsed Ground Output Before Start
The Black w/ Blue Trace wire will provide a 1 second 300 mA pulsed ground output 1.5 second before the
remotestartunit activatesas well as when thetransmitter is used todisarm the system. Typicaluse for this
output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm
when the remote start unit engages or when the system is used to unlock the doors. This will also activate
when the transmitter is used to disarm/unlock the system
NOTE: Thisoutputcan be selected tooperatelike the door lock outputas set in alarm featuresetting #1 by
selecting feature #17 in Bank 3 for 2 Chirps.
2 Black w/ Light Green Trace Wire: Pulsed Ground Output After Start
TheBlackw/LightGreenTracewirewillprovidea1second300mApulsedgroundoutputafterthevehicleis
startedunder control of the remote startunit. Typically this wire willbeusedtore-lockthevehicledoorsifthe
doorsunlockautomatically when the factory anti-theft systemisdisarmed. This wire will also activate when
the transmitter is used to arm/lock the system.
3 Black w/ Red Trace Wire: Pulsed Ground OutputAfter Shutdown
TheBlackw/RedTracewirewillprovidea1second300mApulsedgroundoutput after the remote start unit
shuts down. This output will occur regardless of whether the circuit times out or is manually terminated.
Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the
ignition circuit transitions to off.
4 Black w/ Yellow Trace Wire: Ground Output During Start (Crank)
The Black w/ Yellow Trace wire will provide a 300 mAground output while the starter output of the remote
start unit is active. This output can be used to activate the Crank Low/Bulb Test wire found in some GM
vehicles. This wire is also referred to as the ECM wake up wire in some vehicles.
NOTE: Theoutputsabove are low current outputsandmust be used with a relayifthe circuit's requirement
is more than 300 mA.
2 Pin Transponder Control Output: (Yellow Connector) Part # 1122392
a: When selected for while remote start on, the Black wire will be active at the same time ign. 3 becomes
active, and will remain active all the time the unit is operational under the control of the remote start.
b: When selected for output during the start sequence, the Black wire will be active at the same time Ign.
3 becomes active, and will remain active until the vehicle has started. This will be used for one time read
transpondercircuits.
c: When the unit is selected for until ignition off, the Black wire will become active at the same time ign. 3
becomesactive and will remain active even after the key take overand until the ignition in the vehicle is
turned off. This will allow the unit to be used for continuous read transponders circuits.

128-8783b
17 of 28
17
1 Black: 250mA Output (-)
The black wire switches on when the remote start is activated and will stay on as programmed in the
remotestartfeature Bank3 Feature 12.
2 Red: 250mA Output (+) 12 Volts Constant
Thisoutput is intended to allowthe control of atransponder bypass interface module ortransponder
bypass relay.
Additional Harnesses And Connectors For The System
4 Pin Upgrade Telematic Module: Connector Port)
Red = + 5 Volts / Black = Ground / White = Data TX / Yellow = Data RX
Connect the 4 pin harness found in the Telematic one way or CArlink II kits to the mating port on the
controllingcircuit.
NOTE: Ifusing theTWO WAYTelematicmodule,only Ground, TX, andRX are usedon this port,the + 12
volt supply for the two way module must be sourced separately or the unit will not operate.
5 Wire Antenna/Receiver Program Push-Button Switch/LED Connector: Part # 1123906
Plugthe previously routedantennaconnectorfrom theantennareceiverassembleinto thematingconnector
ofthecontrol module. This connectorsupplies12volts,groundand RF datainputandoutput,LEDcathode,
andValet Enableto and from the antennareceiver and the remotestartmodule. Becertainthis connector
is firmly seated making good contact to the control unit.
4 PIN IN VEHICLE DATABUS PORT (DBI Port) (ConnectorPort)
The 4 pin port located on the side of this module is for proprietaryAudiovox data bus interface modules.
Thesemodulesare used to accessavarietyoffeaturesin the vehicle whichcanbeassimpleas door trigger
inputs,tomorecomplex door locks outputs, or transponderinterfacesforremotestarting. DONOTconnect
anythingtothisportotherthan theAudiovoxIDB modules or damage totheRemoteStartmodulewilloccur.
All installation instructions for the IDB modules will be packaged with the individual component along with
theproper4pinwiring harness requires to access the data transmit &receiveaswellas the proper voltage
levelsfortheinterface.
TIMED START PROGRAM:
The Remote Start unit has the ability to start the vehicle automatically at timed intervals. This feature is
useful in extremely cold climates where starting the engine is the only means to keep the battery charged
andfluids warm. The operator has theoption to have theunit start every 2 or4 hours for amaximum of 48
hours. Factory preset is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:
1. Start By Holding the Push Button Switch found on the windshield mount receiver on.
2.While Holding the PushButton Switch TurnThe Ignition Switch OnThen Off
3a) Within 10 seconds of turning the ignition switch off, Release and then Push On and release the Push
Button Switch 2 times holding it on the second time until the siren and or lights flash and chirp 2 times
indicating that the 2 Hour Start Interval has successfully been set.
or

128-8783b
18 of 28
18
3b) Within 10 seconds of turning the ignition switch off, (Step 2) Release
and then Push On and release the Push Button Switch 4 times holding it on the fourth time until the siren
and or lights flash and chirp 4 times indicating that the 4 Hour Start Interval has successfully been set.
NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is manually changed. To
change,theabovesequencewillhavetobefollowed.
TIMEDSTARTOPERATION:
To begin thestarttimer,within 10 seconds of turning offtheignitionswitch,activatetheRFcommandto start
2 times. (Press the start button four times). The lights will flash and the siren will chirp 4 times. Indicating
timedintervalmode has beeninitiated.Thevehiclewill automatically startevery2or4 hours asprogrammed.
To cancel the timed start mode start the vehicle either by RF or by the ignition key.
DIESELENGINE SETTINGS:
NOTE: When selecting Diesel operation, (Bank 3 Feature #11), over gasoline, the only change is to the
ignition circuits. When Diesel is selected, the ignition circuits will power up 10, 15, or 20 seconds before
the start circuit. The intent of this feature is to allow the glow plug warming required by some diesel
engines. If your vehicle is a instant start diesel, it is not necessary to activate this feature.
ALSO: When selecting Diesel mode, be certain that the intended vehicle has a true tach reference and be
certain to connect the tach input wire. Also note, if the "Diesel Wait to Start" input is connected,
(Green/Yellow) this wirewill takeprecedence over the Diesel selectionof bank 3 feature11.
Monitoring The Vehicle's Engine: (ProgramFeature#5Bank3)
There are 4 ways that the remote start monitors the engine running, one or the other must be selected for
your application for the remote start to operate correctly.
1)VOLTAGE SENSESETTING:
The unit will monitor the voltage level of the battery during remote start, wait for the voltage to drop while
cranking,thenlook for the voltage leveltogo above the level itwasbefore the vehicle began tocrank which
indicates the vehicle is running. Feature #14 of Bank 3 must be set for preset time or the voltage sense
feature will not operate indicated by the parking lights flashing 7 times.
2)TACH RATESETTING:
1. Turn the ignition key to the On position.
2. Press and release the valet/program push button switch 3 times.
3. Immediately turn the ignition key Off.
4. Press and hold the valet/program push button switch, then start the vehicle using the key.
5. When the unit senses the tach signal, the parking lights will begin to flash.
6.Releasethevalet/programpushbuttonswitch. Theparkinglightswillturn on for three seconds to indicate
that the learned tach signal is stored and the unit is out of the tach learn mode.
NOTE: Iftheunit fails to learntachrateduetoanimproper tachometer connection orapoortachsource,the
parking lights will not flash. To correct this situation, locate and connect the Green/Orange wire to
the proper tach signal, and then repeat the tach learn routine.

128-8783b
19 of 28
19
3) DBI TACH SETTING
Selectingthis setting in the optionmenu indicates that youhavea DBI module andhave determined that a
tach signal is available for the vehicle you are connecting to. The unit will look at the DBI data port for the
tach signal. If the vehicle fails to start, or the unit flashes 7 times, recheck the DBI manual to insure that
tachis available foryour vehicle. If not the tach connection wire, Green/Orange must be used.
4)HYBRID SETTING:
Selectingthissetting in the option menuallowsfor Hybrid vehicles. Also feature #14of Bank 3 must beset
for preset time or the Hybrid feature will not operate indicated by the parking lights flashing 7 times.
CRANKAVERAGING:
WhenFeature14Bank3issetforcrankaveraging,theremotestartunitconstantlymonitorsandlearnsthe
cranking patterns of the vehicle each time the car is started with the key. The vehicle must be started
atleast 4 times with the key for the crank averaging circuit to begin it's monitoring the vehicle's engine.
DIAGNOSTICS:
Enter Bank 3 and turn on selectable feature # 9 as described on the front pages of this manual.
NOTE: Diagnosticmodeisatemporary mode. Once you have accessed the diagnostic mode,theunitwill
pausefortwosecondsthenbegintoflashthe last stored shut down code. This code will be displayed three
times in succession, then the unit will automatically exit the diagnostic on mode.
Theparkinglights will flash a numberoftimes indicating the reason for thelastremote start shutdown. The
light flash indications are as follows:
1 Flash Run timer expired
2 Flashes Low or no tach signal (RPM)
3 Flashes Positive inhibit wire activation
4 Flashes NA
5 Flashes RF shutdown, Remote signal received, or manual start trigger wire reactivated.
6 Flashes High tach signal (RPM)
7 Flashes Tach signal has not been learned
8 Flashes Negative inhibit wire
Multi Coil PackAdaptor: (Optional)
The multi coil pack adapter, is designed for use with vehicles that do not respond to single coil tach
programming. Althoughthe tachresolution of this circuit isdesigned to interface directwith most vehicles,
there may be an occasion where the following circuit may be required. Construct the adaptor as shown
below.
To use the adaptor, the Green/Black wires must connect to the negative side of the ignition coil(s).
1. For vehicles utilizing independent coils per cylinder, connect the three Green/Black leads to alternate
coils.Toachieve optimum performance the coil signals mustbeevenlydistributed. Thisisaccomplished
by first mapping out the firing order of the engine in groups of as indicated below. Draw a circle around
any of the columns. The Green/Black wires should be connected to the negative (-) terminal of the
respectivecylinder number which appearsin any of thecircles.
2. For vehicles utilizing 2 cylinder firing per coil pack, connect Green/Black to the tach side of each coil
pack. For 8 cylinder, four coil systems, connect to any of the three coils.
3. Connect the Yellow wire to a +12 volt ignition 1 source. This wire will have +12 volts with the ignition in
the on and start position and have 0 volts with the ignition in the off position.
4. Connectthe Green wireto the (Green)or (Orange/Green) tach input of theAudiovoxremote startunit.

128-8783b
20 of 28
20
TESTINGYOURINSTALLATION:
WARNING!! The following procedure must be performed after the installation of any Remote Start Device. It is the
responsibility of the installing technician to complete these tests. Failure to test the unit in the following manner
may result in personal injury, property damage, or both.
HOODPINSAFETYSHUT DOWN:
The intent of the hood pin safety shut down is to prevent the Remote Start unit from being activated while a
mechanic or vehicle owner is performing normal routine vehicle maintenance.
To test the integrity of this circuit:
1. With the drivers window in the down position, start the vehicle using the RF transmitter.
2. Reach inside the car and pull the hood release.
3. Raise the hood and confirm that the remote start unit shuts down.
If the unit fails this test, recheck your pin switch connection to the Gray/Black wire of the Remote Start Unit.
DONOTRELEASETHIS VEHICLETOTHECONSUMERUNTIL YOUCONFIRMTHE
OPERATIONOFTHEHOODPIN SAFETYSHUTDOWNFEATURE.
REMOTESTART OVERRIDEMODE/MANUALSHUT DOWN:
The intent of the remote start override / manual shut down circuit is to allow the vehicle operator to prevent
operation of the Remote Start Unit regardless of the RF transmitter operation.
To Enter The Remote Start Override Mode:
1) With the system disarmed/unlocked, and the ignition switch off Press and Hold the pushbutton switch
located on the receiver unit on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED begins to flash two short flashes followed by one long flashes and continues this pattern until
returned to normal mode of operation.
The action above puts the unit into the Remote Start Override mode or vehicle service mode and will not start
from the RF transmitter or any other input.
To Exit Remote Start Override Mode:
1) With the system disarmed, press and hold the PBLED on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED turns off indicating that the R/S unit is fully functional one again.
