Audiovox Pursuit Series User manual

128-8699
1 of 12
Page1
Model PRO 9644i
Owner’s Manual
3 Button Remote Security System with Starter Disable
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need to
manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such situa-
tions. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected. Valet
Switch manual override is pre-selected from the factory, however, the system can be
configured for "Custom Code" operation. Confirm the override mode selected on the last page
of this manual and familiarize yourself with the section on it's operation.
FEATURES :
2 Three Button Programmable RF Transmitters
Separate Lock/Unlock Transmitter Buttons
Five Channel Receiver (capable of accepting 4 transmitters)
Code Hopping Technology
Selectable Manual Override Mode
Remote Panic in all modes (Improved)
Protected Valet
User Programmable Manual Override Code
7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
True Last Door Arming ( hardwire only )
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Smart Disarming
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter Or Selectable Through Software
Car Horn Activation for alarm response
Additional Negative Trigger Input
RF Inhibit with ignition on
Parking Light Flasher
OPTIONS:
6ToneMulti-Tone Siren
Remote Trunk Release ( must have electronic trunk release )
Remote Keyless Entry ( must have power door locks )
Illuminated Entry
Multiple Vehicle Capable
Headlight Illumination during Arming and or Disarming
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Plug In Electronic Shock Sensor
Interior Illumination Upon Disarm

128-8699
2 of 12
Page2
YOUR " CODE HOPPING " TRANSMITTERS
The transmitters included with your new security system use the most advanced and
secure form of radio frequency transmission available on any current automotive security
system. Some of today’s sophisticated auto thieves use a device known as a code grabber,
which will receive and store the signal from your keychain transmitter, and re-transmit at a
later time to disarm your system.
Your anti code grabbing transmitters will change their signal every time the button is pressed,
so when a thief grabs then re-transmits your signal, the alarm system will not respond.
If your transmitter button is pressed more than fifty times while it is out of range of the vehicle
(children playing with your keys), the transmitter will not operate when you return to the
vehicle, and will need to be re-aligned to the receiver. To do this, simply press the Lock button
two times within a one second time period. The system will now respond to that transmitter
each time a button is pressed.
NOTE: Your system has the option of using a siren, the vehicle horn, or both for the
sounding device. Where the siren is referenced below, the horn or both may in
fact chirp, or beep.
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and release the Lock button on the keychain transmitter.
Red dash mounted LED begins to flash slowly.
Parking Lights flash one time.
Siren sounds one chirp.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood
lid ajar. Simply close the opened entry point to provide full protection. If
the siren "chirped" three times, sometime after arming, the exclusive
delayed dome light learn circuit has been programmed and the system
detected a open entry point after the learned delay expired. Again, clos-
ing the hood, trunk, or doors will correct the problem and you do not need
to disarm the system to make the correction. If the siren/horn did not
sound when arming, then the chirps have been turned off and you should
refer to the section titled "ELIMINATING THE ARM/DISARM CHIRPS" in
this manual.
Vehicles horn beeps one time.
If the horn beeps three times, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection. If the horn did
not sound when arming, then the chirps have been turned off, and you
shouldrefer to thesection titled" ELIMINATING THEARM/ DISARM CHIRPS"
in this manual.
Doors Lock - Optional
HeadlightIllumination - Optional
The vehicle’s headlights turn on for approximately 30 seconds, illuminating
the path as you leave the vehicle.
SILENT ARMING - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.

128-8699
3 of 12
Page3
2. Press and hold the Lock button on the keychain transmitter for 2 seconds.
Red dash mounted LED begins to flash slowly.
Parking Lights flash one time.
Siren will not sound.
If the siren "chirped" three times, sometime after arming, the exclusive
delayed dome light learn circuit has been programmed and the system
detected a open entry point after the learned delay expired. Closing the
hood, trunk, or doors will correct the problem and you do not need to
disarm the system to make the correction.
Vehicles horn will not beep.
If the horn beeps three times, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection.
Doors Lock - Optional
HeadlightIllumination - Optional
The vehicle’s headlights turn on for approximately 30 seconds, illuminating the
path as you leave the vehicle.
ARMING THE SYSTEM - PASSIVE ( AUTOMATIC )
1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid, and trunk lid.
Red dash mounted LED begins to flash rapidly, indicating 30 second passive
arming has begun.
2. Opening any protected entry point during the 30 second passive arming cycle will immedi-
ately suspend automatic arming, and the 30 second passive arming cycle will re-start
when all doors are closed. At the end of the passive arming cycle;
Red dash mounted LED begins to flash slowly.
Parking Lights flash one time.
Siren sounds one chirp
If the siren did not sound when arming, then the chirps have been turned off,
and you should refer to the section titled "ELIMINATING THEARM / DISARM
CHIRPS"in thismanual.
Vehicles horn beeps one time.
If the horn did not sound when arming, then the chirps have been turned off,
and you should refer to the section titled "ELIMINATING THEARM / DISARM
CHIRPS"in thismanual.
Doors Lock - Optional
Door locking during passive arming is a selectable feature. The alarm can be
programmed to allow the doors to lock only when arming using the keychain
transmitter, and they will not automatically lock during passive arming.
PROTECTION WHILE THE SYSTEM IS ARMED
Opening any protected door, hood, or trunk lid will cause the alarm to immediately
sound. The alarm will continue to sound for 30 seconds, then stop and continue to
monitor all protected entry points. If the thief left a door opened, the alarm will sound
for six 30 second cycles, remain armed, and ignore that triggered zone.
Whenever the system is armed, the red dash mounted LED indicator will slowly flash.
This serves as a visual deterrent to the potential thief. The LED is a very low current

128-8699
4 of 12
Page4
bulb, and will not cause the vehicle’s battery to drain, even when left unattended for
extended periods.
Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30
second alarm cycle, attracting visual attention to the vehicle.
Whenever the system is triggered, the vehicle’s horn will beep for the full 30 second
alarm cycle, attracting added attention to the vehicle.
Optional - Whenever the system is triggered, the interior courtesy lights will flash for
the full 30 second alarm cycle.
Whenever the system is armed, the vehicle’s starting circuit will be bypassed. If the
thief should choose to ignore the siren, the vehicle can not be started
Optional - Any strong impact to the vehicle’s glass will cause the alarm to trigger for
the full 30 second alarm cycle.
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock button on the keychain trans-
mitter.
Red dash mounted LED turns off.
If passive arming was selected during the installation, then the LED will start
flashing rapidly, indicating that the system is re arming automatically. Open
any door to suspend the automatic arming.
Parking Lights flash two times.
If the parking lights flashed three times, then the alarm was triggered in your
absence. Before turning the key on, examine the LED to identify which zone
was triggered.
Siren sounds two chirps.
If the siren sounds 4 chirps, then the alarm was triggered in your absence.
Beforeturningthe keyon,examine theLEDand refertothe INTRUSIONWARN-
ING SIGNALS section of this manual to identify which zone was triggered.
If the siren did not sound when disarming, then the chirps have been turned
off, and you should refer to the section titled " ELIMINATING THE ARM /
DISARMCHIRPS "in thismanual.
Vehicle's horn beeps two times.
If the horn beeps four times, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was trig-
gered.
If the horn did not sound when disarming, then the chirps have been turned
off, and you should refer to the section titled " ELIMINATING THE ARM /
DISARMCHIRPS "in thismanual.
Doors Unlock - Optional
Two Step Doors Unlock - Optional
If, when the Unlock transmitter button was pressed and released, only the
drivers door unlocked, then you have the two step unlock option installed.
Pressing the unlock button a second time will unlock all other doors.
HeadlightIllumination - Optional
The vehicle’s headlights turn on for approximately 30 seconds, illuminating
the path to the vehicle.

128-8699
5 of 12
Page5
Courtesy Lights - Optional
Interior courtesy lights turn on for 30 seconds, or until the ignition key is
switched on.
SILENT DISARMING
1.As you approach the vehicle, press and hold the Unlock button on the keychain transmitter
for 2 seconds.
Red dash mounted LED turns off.
If passive arming was selected during the installation, then the LED will start
flashing rapidly, indicating that the system is re-arming automatically. Open
any door to suspend the automatic arming.
Parking Lights flash two times.
If the parking lights flashed three times, then the alarm was triggered in your
absence. Before turning the key on, examine the LED to identify which zone
was triggered.
Siren will not sound.
If the siren sounds 4 chirps, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was trig-
gered.
Vehicles horn will not beep.
If the horn beeps four times, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was trig-
gered.
Doors Unlock - Optional
Two Step Doors Unlock - Optional
If, when the Unlock transmitter button was pressed and released, only the
drivers door unlocked, then you have the two step unlock option installed.
Pressing the unlock button a second time will unlock all other doors.
HeadlightIllumination - Optional
The vehicle’s headlights turn on for approximately 30 seconds, illuminating
the path to the vehicle.
Courtesy Lights - Optional
Interior courtesy lights turn on for 30 seconds, or until the ignition key is
switched on.
WHILETHE SYSTEMIS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security
system, simply press and release any transmitter button other than the disarm button. This
action will turn off the siren yet leave the vehicle fully armed and protected. This feature is
particularly useful if you are aware of children playing near your vehicle that may accidently
trigger your security system. In this case you can cancel the siren sounding without disarm-
ing your system.

128-8699
6 of 12
Page6
INTRUSIONWARNINGSIGNALS
This system will inform you if an intrusion attempt has occurred while you were away from
the vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the parking
lights will flash 3 times when disarming the system. Enter the vehicle, and observe the red
dash mounted LED to identify which zone was triggered.
If the LED is flashing one time...pause...one time...pause...etc., then an intrusion
attempt was made to the OPTIONAL shock sensor, or an accessory triggering
device that may have been added to the system.
If the LED is flashing two times...pause...two times...pause...etc., then an intrusion
attempt was made to a hood or trunk pin switch that was added to the system, or
to a light activated entry point if the alarm was installed using the voltage sensing
feature.
If the LED is flashing three times...pause...three times...pause...etc., then an
intrusion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory, and will only be
erased when the ignition key is turned on.
PUSHBUTTONLED/VALET/OVERRIDE/PROGRAMMINGSWITCH:(PBLED)
ThePBLED switchallowsyou totemporarilybypass allalarmfunctions, eliminatingtheneed
tohandyourtransmitter to parking attendants or garagemechanics.Whenthesystem is in
valetmode,all alarmfunctionsare bypassed, howevertheremote panic featureandremote
doorlockswill remain operational.Tousethevalet mode,thesystemmust first bedisarmed
eitherby usingyourkeychaintransmitter,orbyactivatingyourpersonalized manualoverride
code.
1. Enterthevehicle,and turntheignitionkey totheonposition.
2. PressandholdthePBLED switchuntiltheLEDturnsonsolid. Thesystemwillremaininthe
valetmode.
3. Toreturntonormal operation,pressandreleasethe PBLEDswitchany timetheignition is
on.
NOTE: Alwaysremembertoreturnthevehicle to the valet off position. This will ensure that
thevehicleremains protectedatall times.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHEPBLEDOVERRIDESWITCH
Your Security System can be disarmed without the use of the keychain transmitter. This is
necessary, sinceyouwill need theabilityto operateyourvehicleif thetransmitteris lost orits
batteryfails.If your systemhasbeenselected for ValetSwitchmanualoverride as indicated
onthelastpage of this manual,tobypassthe alarm system;
1. Openthevehicledoor. Thealarmwill sound.
2. Turntheignition key totheonposition.
3. Within5seconds,press and release the PBLEDoverrideswitch.
Thealarmsystem willstopsounding andenterthe (bypassed)mode. Youcannow startand
operatethe vehiclenormally.
Typicallythisoverridemode is usedonlyifthe transmitterhasbecomeinoperative.
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows the con-
sumer to program a personal override code, offering a higher level of security. To take
advantageofthis option,programmablefeature# 10 mustbeselected for theCustomCode

128-8699
7 of 12
Page7
Option. Consultyourinstallation center for programmingdetails.Thesystem comes from
the factory with a pre-programmed override code of 11. To change this default override
code,dothefollowing:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.Turnthe ignition switch totheonposition.
2. Within10seconds,press and releasethePBLEDswitch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesirenorhornwillbeep and the lights will flash one time.)
4. Within10seconds, begintoenter yourchosen10ths digitbypressingandreleasingthe
PBLEDswitchfrom 1upto9 times.
5. Within10secondsofthelastentered10ths digit, turn the ignition switch off then on.
6. Within10seconds,begin toenteryourchosen units digitbypressing and releasingthe
PBLEDswitchfrom 1upto9 times.
7. Finishbyturningtheignition switch to the off position.
Ifthenew code was accepted,theunitwill report back thenewlyenteredcode, by flashing
theLED, firstindicatingthe 10thsdigit,pause andthenthe unitsdigit.Theunitwillreportthe
new code three times with a one second pause between each code, then the system will
beginarming. IftheLEDflashpatternreportsthepreviouslystoredcode, thenewcode was
notenteredcorrectly. Pleaserepeatsteps 1through7aboveconsideringthefollowing.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0
(Zero),ornodigitenteredin any place, units or tenths.
NOTE: If15secondsof inactivity expire, or if the ignition switch is turned off for more then
5 seconds during any of the above steps, the unit will revert back to the last
successfully stored code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the
following:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.
2. Turntheignitionswitch to the on position.
3. Within10seconds,press and releasethePBLEDswitch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesirenorhornwillbeep and the lights will flash one time.)
5. Within10seconds,begin topressand release thePBLEDswitch to setthetenths digit.
(Aspertheexample,pressand release 5 times to set the tenths digit to5)
6. Within10seconds ofthelastpressof thepushbutton,turntheignition switchoffthenon.
7. Within10seconds, begintopressandrelease thePBLEDswitchtoset theunits digit.
(Aspertheexample,pressand release 2 times to set the units digitto2).
8. Turntheignitionswitch to theoffposition. Immediatelyobserve the LED flashpattern.
YouwillnotetheLEDflashingfivetimes,pause,andthenflashtwotimes,pause.Thispatternwillbe
repeatedthreetimesindicatingthenewcode(52)hasbeenacceptedandstoredinmemory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this
indicates that the code has not been changed. You will have to repeat steps 1
through7abovebeing certain to note thefollowing:
Acceptabledigits10ths orunitsare 1 through9.The unitwillnotrecognize a0(Zero), orno
digitenteredin any place, unitsortenths.
NOTE: If15secondsofinactivityexpire,oriftheignitionswitchisturnedoffformorethen5seconds
duringanyoftheabovesteps,theunitwillrevertbacktothelastsuccessfullystoredcode.

128-8699
8 of 12
Page8
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHECUSTOMCODEOVERRIDE
Assumingtheoverride codeprogrammedhas notbeenchanged,and thedefaultoverride
codeof11isinthesystem's memory.
1) Enterthe vehicle and turntheignitionswitchto the on position.
NOTE:Thesirenwill sound.
2) Within5 seconds, pressandreleasethe PBLED switch1time.
3) Within5 seconds, turn the ignition switch off then on.
4) Within5 seconds, pressandreleasethe PBLED switch1time.
5) Turnthe ignition switch off then on and start the vehicle.
NOTE: Ifyouhave changedtheprogrammedoverride codethensubstituteyour newcode
tenths for step 2 above, and units for step 5 above.
ELIMINATING THENORMAL ARM/DISARMCHIRPS
You can selectively eliminate the normal arm & disarm chirps by holding the transmitter
buttonslightlylongerwhenarming or disarming. This will preventthesirenchirpsforone
arm or disarm cycle. If you find this inconvenient and wish to eliminate these chirps
permanently,
1.Turntheignitionswitch'on"then'off".
2.Within10secondsofturningofftheignition,pressandrelease thePBLED switch3 times.
3.Ifthechirps were on before youstarted,thesirenwillemit 2 short chirps indicatingthat
thechirpsarenowoff. Ifthechirps were off before you started, the siren will emit one
shortchirpindicatingthatthechirpsarenowon.
NOTE: If the vehicle battery is disconnected then reconnected, the unit will return to the
defaultsettingofchirpson. Repeattheaboveproceduretoeliminatethearm/disarm
chirps.
REMOTEPANIC OPERATION
The Lock or Unlock button on your keychain transmitter also functions as a panic switch for
use in emergency situations. To use remote panic,
1. Press and hold the Lock or Unlock button on the keychain transmitter for 3 or more
seconds. The alarm will immediately sound.
2. To stop the alarm, press and hold the Lock or Unlock button on the transmitter again for
3 seconds. If the button is not pressed, the alarm will automatically stop after 30 sec-
onds. Also if any transmitter button other than the Lock or Unlock button is pressed and
released, the Panic mode will be turned off immediately. The normal function of this
transmitter button will be suspended during the Panic sounding period.
NOTE: While in the Panic mode, pressing and releasing the Lock, or the Unlock buttons will,
if the option is installed, lock and unlock the doors respectively. While in the panic
mode, anytime the unlock button is pressed, the panic feature will continue for the
allotted 30 seconds, however, the security system will be disarmed allowing the
vehicle to start.
OPTIONAL DEVICE OUTPUT (CHANNEL 3)
Controlled By: Option Button, Both Lock & Unlock Button, Both Option & Lock
Button, or Both Option and Unlock Button.
This security system is equipped with an output which will activate when the appropriate
transmitter button is depressed for four seconds. Optional devices that may be connected to
this channel are:

128-8699
9 of 12
Page9
Remote Electric Trunk Release
Remote Car Starter
Remote Window Closure
Remote Garage Door Interface
NOTE: In addition there may be a second optional feature connected to your system that
when the same transmitter button is pressed and released 2 times within 3 seconds
(double pressed), the second optional feature will activate. This output is typically
used for a remote start option and will likely prevent inadvertent activation of the
remote start device if young children are playing with the hand held transmitter.
If your vehicle is not equipped with an electronic trunk release switch, or other option listed,
this feature may have been connected to another accessory. Please ask your dealer for
further information.
ADDITIONAL REMOTE FUNCTION (CHANNEL 4)
Controlled By: Option Button, Both Lock & Unlock Button, Both Option & Lock
Button, or Both Option and Unlock Button.
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are:
Remote Car Starter
Remote Window Closure
Remote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the appro-
priate transmitter button(s) as indicated above.
ADDITIONAL REMOTE FUNCTION (CHANNEL 5)
Controlled By: Option Button, Both Lock & Unlock Button, Both Option & Lock
Button, or Both Option and Unlock Button.
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are:
Remote Car Starter
Remote Window Closure
Remote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.

128-8699
10 of 12
Page10
PRO9644i
SYSTEM FUNCTIONSATAGLANCE
DASHLEDINDICATORS
RAPIDFLASHING = PASSIVEARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ON SOLID = VALETMODE
3FLASH...PAUSE = INTRUSION ZONE 3
2FLASH...PAUSE = INTRUSION ZONE 2
1FLASH...PAUSE = INTRUSION ZONE 1
SIRENAND/ORHORNCHIRPINDICATORS
1 CHIRP * = ARM
2 CHIRPS * = DISARM
3 CHIRPS = ARM/DOOR OPENED
4 CHIRPS = DISARM/INTRUSION
* These chirps are optional, and can be de - activated.
PARKINGLAMPINDICATORS
1 FLASH = ARM
2 FLASHES = DISARM
3 FLASHES = DISARM/INTRUSION
Your System Has These Features Activated
Remote Keyless Entry
Illuminated Entry
Auto Lock with ignition key
Auto Unlock with ignition key
Headlight Illumination during arm & disarm
Passive Arming
No Lock in passive mode
Hardwire doors, hood, and trunk
Custom Code Override
Valet Switch Override

128-8699
11 of 12
Page11
THISPAGELEFTBLANKINTENTIONALLY

128-8699
12 of 12
Page12
© 2009 Audiovox Electronics Corporation, Hauppauge, N.Y. 11788 128-8699
