Audiovox ACD-24 User manual

128-5780D
1 of 16
ACD-24ACD-24
ACD-24ACD-24
ACD-24
DETACHABLE FRONT PANEL AM/FM/MPX RADIO WITH
COMPACT DISC PLAYER, CD CHANGER CONTROLS AND
QUARTZ CLOCK
OWNER'S MANUAL

128-5780D
2 of 16
11
11
1
INSTINST INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a special
installation kit will be required to mount the radio to the dashboard. These kits are available at electronics supply
stores and car stereo specialist shops. Always check the kit application before purchasing to make sure the kit
works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line (1-800-645-4994).
UNIVERSALINSTALLATIONPROCEDUREUSINGMOUNTINGSLEEVE
1. Remove the detachable front panel if it is attached to the chassis by pushing the “Release”button. Slide the
mounting sleeve off of the chassis. If it is locked into position, use the removal tools (supplied) to disengage it.
2. Checkthedashboardopeningsizebyslidingthemountingsleeveintoit. Iftheopeningisnotlargeenough,carefully
cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening
or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
3. Locatetheseriesofbendtabsalongthetop,bottom,andsidesofthemountingsleeve. Withthesleevefullyinserted
into the dashboard opening, bend as many of the tabs outward as necessary so that the sleeve is firmly secured
to the dashboard.
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting sleeve.
Followthewiringdiagramcarefullyandmakecertainallconnectionsofthewiringharnessaresecureandinsulated
with wire nuts or electrical tape to insure proper operation of the unit. After completing the wiring connections,
attachthefrontpanelandturntheunitontoconfirmoperation(ignitionswitchmustbe“on”). Ifunitdoesnotoperate,
re-check all wiring until problem is corrected. Once proper operation is achieved, turn off the ignition switch and
proceed with final mounting of the chassis.
5. Carefullyslidethe radiointothe mountingsleevemaking sureitis right-side-upuntilit isfullyseated andthespring
clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using
the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either above
or below the radio using the screw and hex nut provided. Bend the strap to position it as necessary.
CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard from the
weight of the radio or improper operation due to vibration.
7. Re-attach the front panel to the chassis. Establish a location for the remote input jack (usually the underside of
the dashboard) if it is a feature of the radio. Anchor it in place using two self-tapping screws (M5x6). Do
not over-tighten screws. Test radio operation by referring to the Operating Instructions for the unit.
INSTALLATIONUSINGKITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with the
installation kit to attach the radio to the mounting plate supplied with the kit.
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
ISOINSTALLATIONPROCEDURE
Thisunithasthreaded holes inthechassisside panels whichmaybeused with theoriginalfactorymounting
brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the
dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and
brackets as they will be used to mount the new radio.
2. Carefully un-snap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION: DONOTEXCEEDM5X6MMMAXIMUMSCREWSIZE.
LONGERSCREWSMAYTOUCHANDDAMAGECOMPONENTSINSIDETHECHASSIS.
4. Wire the new radio to the vehicle as per step 4 above.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

128-5780D
3 of 16
INSTINST INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
22
22
2
8:30AM - 7PM
9AM - 5PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON. - FRI.
SATURDAY
DAY
TT
TT
TOLL-FREE INSTOLL-FREE INST
OLL-FREE INSTOLL-FREE INST
OLL-FREE INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION ASSISTION ASSIST
ION ASSISTION ASSIST
ION ASSISTAA
AA
ANCENCE
NCENCE
NCE
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you
do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days
and hours shown (U.S.A. and Canada only).
7:30AM - 6PM
8AM - 4PM
FASTEN THIS END TO SCREW
STUD ON REAR OF CHASSIS
NUT (5MM)
FASTEN THIS END TO SECURE PART OF DASH-
BOARD. DRILL HOLE IF NECESSARY.
SCREW
(5MM)
DETACHABLE
FRONT PANEL
EXISTING DASH OPENING
FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE
NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF
MOUNTINGSLEEVEASA TEMPLATE &CUTOPENING
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
NUT (5MM)
REMOVE THE PLASTIC FRAME FROM THE FRONT OF THE
CHASSIS BY CAREFULLY UN-SNAPPING IT.
TYPICAL INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATION
20° MAX.
FRONT PANEL
CAUTION:
FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS
MUST BE MOUNTED WITHIN 20° OF HORIZONTAL. MAKE
SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.
SIDE VIEW
OF
CHASSIS
UN-SNAP AT 2 PLACES
EACH ON TOP AND BOTTOM
MAXIMUM
SCREW SIZE
M5 x 6
MAXIMUM
SCREW SIZE
M5 x 6
PERFORATED STRAP
RADIO
SCREW STUD
MOUNTING SLEEVE
PLASTIC FRAME FACTORY MOUNTING
BRACKETS
REMOVAL TOOLS
BEND BOTTOM
TABS DOWNWARD
BEND TOP
TABS UPWARD

128-5780D
4 of 16
33
33
3
33
33
3
RADIO WIRING
RADIO WIRINGRADIO WIRING
RADIO WIRINGRADIO WIRING
RADIO WIRING
REFER TO PAGE 4 FOR SPEAKER WIRING
BLACK
EXISTING
ANTENNA
CABLE
"RADIO"OR
"ACCESSORY"FUSE
ANTENNA AUTOMATIC
ANTENNA
CAR
FUSEBLOCK
IMPORTANT
THEBLUEWIRECANBEUSED
TO REMOTELY ACTIVATE AN
AUTOMATICANTENNAORAN
EXTERNAL AMPLIFIER (SEE
ANTENNA OR AMPLIFIER
MANUAL)
ANTENNASOCKET
ONREAROFRADIO
POSITIVE (+) TERMINAL
12 VOLT BATTERY
CARBATTERY
METAL PART OF DASH
(DRILLHOLEIF
NECESSARY)
SCREW
RED
RADIO
IMPORTANT
THISWIREMUSTBECONNECTED
AS SHOWN OR RADIO WILL NOT
OPERATEPROPERLY
SEEPAGE4FOR
SPEAKERWIRING
14 PIN PLUG
MATING 14 PIN SOCKET
BLUE
YELLOW
33
33
3
REMOTEINPUTJACK
FILTER/FUSE
BOX
CONTAINS:
ONE1-AMPFUSE
ONE10-AMPFUSE

128-5780D
5 of 16
44
44
4
SPESPE SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
REFERTOPAGE3 WARNING!
lTHEAMPLIFIERSINTHISRADIOAREONLYDESIGNEDFORUSEWITH4 SPEAKERS.
lNEVERCOMBINE(BRIDGE)OUTPUTSFORUSEWITH2SPEAKERS.
lNEVERGROUNDNEGATIVESPEAKERLEADSTOCHASSISGROUND.
lFAILURETOWIREEXACTLYASSHOWNBELOWMAYCAUSEELECTRICALDAMAGETO
THERADIO.
RCA
JACKS
LINEOUT
FORUSEWITH
OPTIONAL
EXTERNAL
AMPLIFIERS
RED=RIGHTREAR
WHITE=LEFTREAR
WHITEw/BLACKSTRIPE
WHITE
LEFTFRONTSPEAKER RIGHTFRONTSPEAKER
LEFTREARSPEAKER RIGHTREARSPEAKER
GREEN
GRAYw/BLACKSTRIPE
9-PINPLUGS
GREENw/BLACKSTRIPE VIOLETw/BLACKSTRIPE
RADIO
8:30am - 7:00pm Eastern
9:00am - 5:00pm Eastern
Monday - Friday
Saturday
1-800-645-49941-800-645-4994
1-800-645-49941-800-645-4994
1-800-645-4994
HELP!
GRAY
VIOLET
4-PINPLUGS
SEEPAGE3FOR
RADIOWIRING
8-PIN DIN SOCKET FOR CONNECTION
TO OPTIONAL CD CHANGER
6
COMPA CT
DINCABLE
(SUPPLIEDWITH
CDCHANGER).
OPTIONAL
CDCHANGER
NOTE:
CHECKWITHYOURRAMPAGE/AUDIOVOXCARSTE-
REO SPECIALIST OR CALL 1-800-645-4994 FOR
RECOMMENDATIONSOFTHEMODELSTHATWILL
WORKWITHYOURRADIO.
REMOTEINPUT INPUTJACKFOR
USEWITHEXTERNALCDPLAYER,
CASSETTE PLAYER, OR MP3
PLAYBACK

128-5780D
6 of 16
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
1ON/OFF POWER BUTTON
Press this button to turn the unit on or off. If the unit
is off and the ignition switch is "on", the unit will turn
on automatically when a disc is inserted, or when
the "MODE" switch or "BAND" switch is pressed.
2VOLUME / LEVEL CONTROL
To increase the volume level, press the button.
The volume will increase and the level will be shown
on the display panel from a minimum of “VOL 00” to
a maximum of “VOL 39”. To increase the volume
quickly, keep the button pressed. To decrease the
volume level, press the button. Keep the button
pressed to decrease the volume quickly. The display
will automatically return to the normal indication
5 seconds after the last volume adjustment or when
anotherfunction is activated. These buttons arealso
used in conjunction with the ''AUDIO SELECT" (SEL)
button3to adjustthebass, treble, balance,and fader
levels as described in 4, 5, 6and 7.
3AUDIO SELECT (SEL) BUTTON
This button is used to select the audio function
(volume,treble, bass, balance, or fade)to beadjusted
using the Volume/Level Control 2. Pressing the
"SEL" button will select bass (“BAS” on the dis-
play), treble ("TRE"), balance (“BAL”), fader
(“FAD”) or volume (“VOL”). The display will au-
tomatically return to the normal indication 5 sec-
onds after the last adjustment or when another func-
tion is activated. The unit will produce a single beep
tone whenever the button is pressed.
4BASS CONTROL
To adjust the bass level, first select the Bass mode
by pressing the "SEL" button 3so that the “BAS”
indication appears on the display panel. Within 5
seconds of choosing the Bass mode, press the
or button of the Level Control 2to adjust the
bass response as desired. The bass level will be
shown on the display panel from a minimum of -12
to a maximum of +12 (0 is flat response). The
display will automatically return to the normal
indication 5 seconds after the last adjustment or
when another function is activated.
5TREBLECONTROL
To adjust the treble level, first select the Treble mode
by pressing the "SEL" button 3so that the “TRE”
indication appears on the display panel. Within 5
seconds of choosing the Treble mode, press the
or button of the Level Control 2toadjust the
treble response as desired. The treble level will be
shown on the display panel from a minimum of
-12 to a maximum of +12 (0 is flat response). The
display will automatically return to the normal
indication 5 seconds after the last adjustment or
when another function is activated.
6LEFT/RIGHT BALANCE CONTROL
To adjust the left-right speaker balance, first select
the Balance mode by pressing the "SEL" button 3so
that the “BAL” indication appears on the display
panel. Within 5 seconds of choosing the Balance
mode, press the or button of the Level
Control 2to adjust the balance as desired. The
55
55
5
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

128-5780D
7 of 16
balance position will be shown on the display panel
from “BAL.L 16” (full left) through “BAL.R 16” (full
right). When the volume level between the left and
right speakers is equal, “BAL 00” will be shown on
the display panel. The display will automatically
return to the normal indication 5 seconds after the
last adjustment or when another function is activated.
7FRONT/REARFADERCONTROL
To adjust the front-rear speaker balance, first select
the Fader mode by pressing the "SEL" button 3so
thatthe “FAD”indication appearson the displaypanel.
Within 5 seconds of choosing the Fader mode, press
the or button of the Level Control 2to adjust
the front-rear speaker balance as desired. The fader
position will be shown on the display panel from
“FAD.R 16” (full rear) through “FAD.F 16” (full front).
When the level between the front and rear speakers
is equal, “FAD 00” will be shown on the display
panel. The display will automatically return to
the normal indication 5 seconds after the last
adjustment or when another function is activated.
8LOUDNESS CONTOUR (LOUD)
When listening to music at low volume levels, this
feature will boost the bass and treble ranges to
compensate for the characteristics of human
hearing. Press the "LOUD" button to activate this
feature and the indication "LOUD" will appear on the
display panel. Pressing the button again will
deactivate the feature (the "LOUD" indication will
disappear from the display panel).
9AUDIO MUTE (MUTE)
This button is used to mute the volume from the
system. By pressing the button,a flashing "MUTE"
indication will appear on the display panel and the
volume will be muted. Pressing the Mute button
again, or activating the Volume Control 2Select
("SEL") button 3 "LOUD"button, or Equalizer ("EQ")
button will return the volume level to the setting in
use before the Mute function was activated.
bl AM/FM BAND SELECTOR (BAND)
During radio operation, each momentary press of
this button will change the radio band. The indication
“AM1”, “AM2”, “FM1”, “FM2”, or “FM3” will appear on
the display panel according to your selection.
During disc play, pressing this button will stop play
of the disc and switch to radio operation without
ejecting the disc. During this time, the IN
indication will remain on the display panel to show
that a disc is still loaded in the unit. Press the
"Mode" button cr to return to disc play from the
beginning of the last track in play.
bm MANUAL UP/DOWN TUNING (+ / -)
AUTOMATIC SEEK TUNING
Each time the + button is tapped, the radio will
tune one frequency step higher. Similarly, each tap
of the - button will tune one frequency step
lower. To manually tune in a station, tap the button of
the appropriate direction until the desired frequency
is reached.
Pressing either button for longer than 2.0 seconds
and then releasing will activate the Automatic Seek
Tuning function. The radio will seek the next available
station and stop at that frequency. The Seek function
can be stopped by pressing the button again or ac-
tivating any other tuning function.
bn AUTO-STORE TUNING (AS)
PRE-SET SCAN TUNING (PS)
During radio operation, press this button momen-
tarily to scan the 6 stations pre-set into the memo-
ries of that band. The unit will stop at each pre-set
station for 5 seconds before continuing to the next
pre-set station. During this time, the pre-set station
number ("CH") in the band will flash. Press the but-
ton again momentarily to stop Pre-Set Scan op-
eration and remain on the selected frequency.
The station number ("CH") stops flashing.
Pressing the button for longer than 2 seconds will
activate the Auto-Store Tuning feature which will
automaticallyscan the band and enter upto 6strong
stations into the 6 pre-set memories (the indication
“AST” will flash on the display panel to show that
Auto-Store Tuning is in progress). After entering the
stations into the memories, the unit will automatically
stop at each station for 5 seconds so each can be
heard. If you have already set the pre-set memories
to your favorite stations, activating the Auto-Store
feature will erase those stations and enter the new
strong stations. This feature is most useful when
travelling in a new area where you are not familiar
with the local stations.
bo STATION PRE-SET MEMORIES
To set any of the 6 pre-set memories in each band,
use the following procedure:
1. Turn the radio on and select the desired band.
2. Select the first station to be pre-set using the
Manual Up/Down or Automatic Seek Tuning
Controls bm.
3. Press the pre-set button ("1-6") to be set and
continue to hold it in. After approximately 2
seconds, the pre-set number will appear on the
display panel, indicating that the station is now
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
66
66
6

128-5780D
8 of 16
77
77
7
set into that pre-set memory position. The station
can now be recalled at any time by pressing
that button.
4. Repeat the above procedure for the remain in
pre-sets on that band and for the other 4 bands
on the unit.
bp LIQUID CRYSTAL DISPLAY PANEL
FUNCTIONS
The Liquid Crystal Display (LCD) panel displays the
frequency, time, and all activated functions, including
five bar graphs which provide a visual representation
of the volume level and the left and right channel
balance levels. The volume level is represented by
three thin bar graphs. As the volume is increased,
the number of illuminated segments will increase.
The left and right channels are represented by the
wider bar graphs. As the strength of the signal ap-
plied to either the left or right channel increases, the
number of illuminated segments will increase.
NOTE: It is a characteristic of LCD panels that, if
subjected to cold temperatures for an
extended period of time, they may take longer
to illuminate than under normal conditions. In
addition, the visibility of the numbers on the
LCD may slightly decrease. The LCD
read-out will return to normal when the
temperature increases to a normal range.
bq DISC SLOT
With the label surface facing up, gently insert the
disc into the slot until the soft-loading mechanism
engages and disc play begins. The indication
illuminates and becomes animated, the IN
symbol lights, and the track number and elapsed
time will appear on the display panel.
CAUTION: This unit is designed for play of
standard 5" (12cm) Compact Discs
ONLY. Do not attempt to use 3" (8cm)
CD-Singles in this unit, either with or
without an adaptor, as damage to the
player and/or disc can occur. Such
damage will not be covered by the
Warranty on this product.
br TRACK SELECT
These buttons are used to quickly select the beginning
of a particular track. With each momentary tap of
the Forward Track Select button (+), the next
higher track number will be selected as shown on the
display panel. Similarly, with each momentary tap of
the Backward Track Select button ( -), the next
lower track number will be selected.
bs CUE/REVIEW FUNCTIONS
High-speed audible search to any section of the
disc can be made by the Cue and Review functions.
Press and hold the Cue button (+) to advance
rapidly in the forward direction or the Review button
(-) to advance rapidly in the backward direction.
During either function, the elapsed time within each
trackwill automatically beshown onthe display panel.
bt CD TRACK ONE POSITION (TOP) SELECTOR
During disc play, press this button to return to begin-
ning of first track on disc. Disc counter will return to
zero and "TRACK" number 01 will appear on dis-
play panel.
bu REPEAT PLAY SELECTOR (RPT)
During disc play, press this button to repeat the play
of the selected track (“RPT” will appear on the
display panel). Play of the track will continue to
repeatuntil the buttonis pressedagain andthe “RPT”
indication disappears from the display panel. Repeat
Play mode will also be cancelled by activating the
Random Play cl or Track Scan cm functions.
cl RANDOM PLAY SELECTOR (RND)
During disc play, press this button to play the tracks
on the disc in a random or shuffled order (“RND”) will
appearon thedisplay panel). In RandomPlay mode,
pressing the Forward Track Select (+) or Back-
ward Track Select ( -) will also select tracks in a
randomorderinsteadofthenormalprogression. Addi-
tionalpresses willselect tracksin random order. The
Random Play mode can be cancelled by pressing
the button again (“RND”) indication will disappear
fromthedisplaypanel)or by activatingtheRepeatPlay
bu or Track Scan cm functions.
cm TRACK SCAN (SCN)
During disc play, press this button to play the first 10
seconds of each track on the disc (“SCAN” will ap-
pear on the display panel). When a desired track is
reached, press the Scan button again to cancel
the function and play of the selected track will
continue. Track Scan mode will also be can-
celled by activating the Repeat Play bu or Ran-
dom Play cl functions.
cn DISC EJECT ( )
Disc play is stopped, the disc is ejected and the unit
will change to radio operation by pressing this button.
If the disc is not removed from the unit and the button
is pressed again, the disc will be re-loaded and
begin playing.
77
77
7
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

128-5780D
9 of 16
If the disc is not removed from the disc slot within 15
seconds of being ejected, it will automatically be re-
loaded into the unit to prevent it from being acci-
dentally damaged. Play of the disc can be resumed
byusingthe CDModeSelector cr to chooseCDplayer
function.
co TIME/FREQUENCY SELECTOR (T/F)
This unit can display the clock time, radio frequency or
CD player functions on the display panel. Pressing
the Time/Frequency Selector button when the ra-
dio frequency or CDplayer track indication is shown
will change the display to show the time. The time
displaywill automaticallyreturn to theradio frequency
or CD player function indication after 5 seconds.
cp FM MONO/STEREO SELECTOR (MONO)
During FM radio operation, this button is used to
select mono or stereo reception of the broadcast
signal. Under normal reception conditions, the unit
should be left in the stereo mode, as indicated by
"ST " on the display panel when listening to an FM
stereo signal. If the stereo signal is too weak for
comfortable listening, press the button to switch to
mono reception (the "ST " indication will disappear
from the display panel). To return to the stereo
reception mode, press the button again so that the
"ST " indication returns.
cq EQUALIZER SELECTOR (EQ)
The "EQ" button applies preset sound effects to
the unit's audio output signal. The "EQ" button,
when pressed, will activate one of three operating
modes ("ROCK, CLAS, or POP"). When the "EQ"
function is active, the bass and treble levels cannot
be changed. When the "EQ" function is not active,
the unit returns to the user-set bass and treble lev-
els.
cr MODE SELECTOR (MODE)
This button is used to select the radio, or the playback
mode for the CD player or remote CD changer (if in-
stalled). Each press of the button will select a dif-
ferent mode as indicated on the display panel.
DuringCDplayer operation,thisbutton maybeused to
changeto radioor remote CD changer mode("CDC")
without ejecting the disc (the IN indicationwill
remain on the display panel to show that a disc is still
loaded in the unit). Press the button again to return to
integral CD player mode and resume play of the disc
from the point at which it was stopped.
cs & ct DISC SELECT (CD+ & CD-)
These buttons are used to increase or decrease
selection of a desired disc for play in the remote CD
changer. To advance to a higher number disc, press
the "CD+" button cs. To return to a lower number
disc, press the "CD-" button ct. The number of the
disc in play will be shown on the display panel.
cu FRONT PANEL RELEASE BUTTON
This button is used to release the mechanism that
holds the front panel to the chassis. To detach the
frontpanel, press thebutton sothatthe leftside of the
panel is released. Grasp the released side and pull it
off of the chassis.
To re-attach the panel, position the right side of the
panel in place first and then press the left side of the
panel until the mechanism locks it into place.
dl THEFT-DETERRENT L.E.D.
The theft-deterrent Light Emitting Diode (L.E.D.) is
locatedbehindthefrontpanelandisaccessiblewhen
the front panel is removed. The flashing light serves
as a visual warning to the would-be thief that the unit
has been disabled by removal of the front panel.
dm RESET BUTTON
A "RESET" button is located on the front of the
chassis (front panel must be removed to access the
button). The "RESET" circuitry is provided to protect
the microprocessor circuitry and should only be
activated under the following circumstances as it will
erase the time and pre-set memories:
1. Uponinitialinstallationafterallwiringiscompleted.
2. After the position of the frequency step switch on
the bottom of the chassis has been changed.
3. If there is a malfunction of any of the switches on
the unit, pressing the "RESET" button may clear
the system and return to normal operation.
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
88
88
8

128-5780D
10 of 16
SETSET
SETSET
SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
1.Turn the vehicle ignition and radio “on”.
2. Press the Time/Frequency Selector button co to display the time.
3. While the time is being displayed, press the Time /Frequency Selector button co together with the
ManualDown Tuning button( -)to adjustthe hours or the ManualUp Tuning button (+ ) toadjust
the minutes to the correct time.
4. Five seconds after the last hour or minute adjustment is made, the time will be set in the unit and normal
operation can resume.
99
99
9
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONS / SETIONS / SET
IONS / SETIONS / SET
IONS / SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
NOTES ON USE OF FRONT PANEL
1. Make sure the front panel is right-side-up when
attaching it to the chassis as it cannot be
attached when up-side down.
2. Do not press very hard on the front panel when
attaching it to the chassis. No more than light
to moderate pressure should be needed.
3. When attaching the front panel, make sure the
right side is correctly engaged before pressing
the left side to lock it into position.
4. When taking the front panel with you, please
use the supplied carrying case to protect the
panel from dirt and damage. Make sure there
is no dust or dirt on the electrical terminals on
the back of the panel as this could cause
intermittent operation or other malfunctions.
Engage right
side first
ATTACHING THE FRONT PANEL
Release Button
DETACHING THE FRONT PANEL
NOTESONUSEOFREMOTEINPUTJACK
The remote input jack provides the user option of
applying an external audio source to the radio.
Theaudiojackiscompatiblewithmost"Walkman"
CD and cassette players, or an MP3 digital audio
playback unit. When the external source is
connected,onlythatmediaisplayedbytheradio;
nootherinputsources(radioorCD)areoperative.

128-5780D
11 of 16
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
Size: 7" W x 2" H x 6-5/16" D
178 mm x 50 mm x 163 mm
Operating Voltage: 12 volts DC, negative ground
Output Power: 140 watts maximum
( 35 watts x 4 channels)
Output Wiring: Floating-ground type designed for 4 speaker use.
Front and rear channels CANNOT be combined (bridged)
for use with 2 speakers.
RCA low-level outputs (rear channels).
Output Impedance: Compatible with 4 ohm speakers.
Low-Level Output: 2.0 volts (2,000 mv.)
Tuning Range: AM:530 - 1,720 KHz. (10 KHz. step)
FM:87.5 - 107.9 MHz. (200 KHz. step)
Sensitivity: < 70 V
FM Stereo Separation: > 20 dB
CD Frequency Response:20 - 20,000 Hz. +0 / -3 dB
CD Signal/Noise Ratio: 85 dB
CD Channel Separation: 65 dB
CD Distortion: 0.2%
*Specifications are subject to change without notice.
SPECIFICASPECIFICA SPECIFICASPECIFICA
SPECIFICATT
TT
TIONSIONS
IONSIONS
IONS
1010
1010
10
CD-RANDCD-RWPLAYBACKCAPABILITY
This model can play most CD-R and CD-RW media that contains audio programs.
Playbackof bothCD-RandCD-RW dependsontheconditionsof therecording equipment
andtheCD-R orCD-RW disc quality. Insome cases,aCD-R orCD-RW disc cannotbe
played on this unit.

128-5780D
12 of 16
1212
1212
12
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
Built into this radio are controls to operate an
optional CD changer. Please check with your
Rampage/Audiovox car stereo specialist or call
1-800-645-4994 for recommendations of the
models that will work with this radio.
Adjustmentoftheaudiofunctions(volume,tone,
balance,andfader)fortheCDchangeroperatein
thesamemannerastheydofor radio play. The
following controls will operate the CD changer
when it is installed and connected to this radio.
Refertotheowner’smanualincludedwiththeCD
changer for instructions on the installation and
correct loading and use of the CD magazine.
dn CDCHANGERMODESELECTOR(MOD)
During radio or CD play, press this button to
select operation of the CD changer as shown
by CDC on the display panel. Disc play will
begin and the disc and track number will be
shown on the display panel. If a new magazine
has been loaded into the changer, play will
begin from the first track of the first disc in the
magazine. If a magazine was already in the
changer, play will resume from the track on the
disc previously in play.
do &dp DISCSELECT (CD+ & CD-)
These buttons are used to select the desired
disc for play. To advance to a higher number
disc, press the CD+ button do. To return to a
lower number disc, press the CD- button dp.
The number of the disc in play will be shown on
the display panel.
dq TRACKSELECT (+ / -)
The Track Select functions are used to quickly
accessthebeginningofaparticulartrack. Each
time the Forward Track Select (+)
in side of the button is pressed, the next higher
1111
1111
11
CD CHCD CH CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
tracknumberwillbeselectedasshownondisplay
panel. Similarly, each time the Backward
Track Select ( -) side of the button is
pressed, the next lowertrack number will be
selectedasshownonthedisplaypanel.
dr CUE/REVIEWFUNCTIONS (+ / -)
High-speed audible search to any section of
the disc can be made by the Cue and Review
functions. Press and hold the Cue (+) side
of the button to advance rapidly in the forward
direction(thediscplaysymbolwillrotatefoward
on the display panel) or the Review ( -) side
ofthebuttontoadvancerapidlyinthebackward
direction(thediscsymbolwillrotatebackwards
on the display panel).
ds TRACK/DISCSCANSELECTOR(SCAN)
When the SCAN button is pressed, the SCAN
indication will appear on the display panel, and
thefirst10secondsofeachtrackonthediscwill
be played in order. When a desired track is
reached, press the SCAN button twice with a
one second interval between presses and play
of the selected track will continue (SCAN will
disappear from the display panel). The Track
Scan mode will also be canceled by activating
any other disc function (Track Select, Cue/
Review, Repeat or Random Play).
When the SCAN button is pressed twice,
the DISCandSCANindicationswillappearon
thedisplaypanelandthefirst10secondsofeach
trackoneachdiscinthemagazinewillbeplayed.
Whenadesireddiscisreached,presstheScan
button again and play of the selected disc will
continue(DISC and SCAN will disappear from
thedisplaypanel). TheDiscScanmodewillalso
becanceledbyactivatinganyotherdiscfunction
(DiscorTrackSelect,Cue/Review,RepeatPlay
etc.).

128-5780D
13 of 16
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
1212
1212
12
dt DISC/TRACK REPEAT PLAY (RPT)
When the Repeat button is pressed, the RPT
indication will appear on the display panel and
play of the selected track will be continually
repeated until the Track Repeat mode is
canceled by pressing the Repeat button again
orbyactivatingtheDiscSelectdo anddp,Scan
ds or Random Play du functions.
When the Repeat button is pressed twice
the DISC and RPT indications will appear on
the display panel and play of the selected disc
willbecontinuallyrepeateduntiltheDiscRepeat
mode is canceled by pressing the Repeat
button again or by activating the Scan ds or
Random Play du functions.
du DISC/TRACKRANDOMPLAY(RND)
When the Random button is pressed, the RND
indication will appear on the display panel and
thetracksonthediscwillbeplayedinarandom,
shuffled order. The Track Select button dp will
also select tracks in the shuffled order instead
of the normal progression. The Random Track
modecanbecanceledbypressingtheRandom
buttonagain or by activatingtheDisc Select do
and dp, Scan ds or Repeat Play dt functions.
When the Random button is pressed again,
the DISC and RND indications will appear on
thedisplaypanelandthetracksonthediscwillbe
played in a random, shuffled order. After all
tracksonthedischavebeenplayed,anewdisc
willbeselectedandallthetracksonthisdiscwill
berandomly played. This will continueuntil the
RandomDiscmodeiscanceledbypressingthe
Random button again or by activating the Scan
ds orRepeat Play dt functions.
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S

128-5780D
14 of 16
CD PLCD PL CD PLCD PL
CD PLAA
AA
AYER AYER A
YER AYER A
YER AND CD CHND CD CH
ND CD CHND CD CH
ND CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
1313
1313
13
If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3,
etc.) may appear on the display panel. This can indicate a number of problems with the unit,
including a mechanical error or an error in the microprocessor control of the player. If an error
code should appear, try ejecting and re-loading the disc into the player. While the disc is out of
the unit, make sure it is clean, undamaged, and loaded correctly (label surface up). You may
also try activating the RESET button dm on the unit, but this will also erase the time and pre-set
memories.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD PLCD PL
CD PLCD PL
CD PLAA
AA
AYER ERRYER ERR
YER ERRYER ERR
YER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
If a problem should develop while operating the CD changer, the following error codes may
appear on the display panel.
ER-1: Indicates that there is no magazine loaded in the CD changer.
ER-2: Indicates a problem with the magazine eject function.
ER-3: Indicates an error in the disc loading function.
ER-4: Indicates an error in the disc un-loading function.
ER-5: Indicates an error in the magazine position.
ER-6: Indicates an error in the laser pick-up position.
ER-7: Indicates an error in the laser focus on the disc.
In any of the above situations, try ejecting the CD magazine from the changer and make sure
the discs are clean, undamaged, and loaded correctly (refer to the Owner’s Manual of the CD
changer). Re-load the magazine and check for proper operation. You may also try activating
the RESET button dm on the unit, but this will also erase the time and pre-set memories.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES

128-5780D
15 of 16
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We
recommend that you keep this manual for reference on the many features found in this unit as
well as how to set the clock.
The compact disc player section also requires no routine maintenance, but proper
understanding of its use and handling will help you obtain maximum enjoyment of its
capabilities. The following points should be observed:
lWhen cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit.
lTheCDplayerisa precision instrument and will not operateproperly in extreme heator cold.
In case of such conditions, wait until the interior temperature of the vehicle reaches a normal
temperature before using the player.
lIf the temperature inside the player gets too hot, a protective circuit will automatically stop
play of the disc. In this case, allow the unit to cool off before operating the player again.
lNeverinsert anything other thana5"(12 cm) compactdisc intothe playerasthemechanism
can be damaged by foreign objects.
lDonot attempt touse 3"(8cm) CD-Single discs inthisunit, either with orwithoutan adaptor,
as damage to the player and/or disc may occur. Such damage will not be covered by the
Warranty on this product.
lWhen not using the disc player, always remove the compact disc. Do not leave an ejected
disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.
lDo not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside.
lWhen the vehicle warms up during cold weather or under damp conditions, moisture may
condense on the lens of the disc player. Should this occur, the player will not operate
properly until the moisture has evaporated.
lThe unit is designed with a vibration dampening CD mechanism to minimize interruption of
disc play due to normal vibration in a moving vehicle. When driving on very rough roads,
however, occasional sound skips may occur. This will not scratch or damage the disc and
normal play will resume when the rough conditions cease.
HANDLING COMPACT DISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound
quality. Please follow these guidelines to take care of your compact discs:
lUse only compact discs with the mark .
lFingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.
lNeverusechemicalssuchas record sprays, household cleaners or thinner to cleancompact
discs. Such chemicals can irreparably damage the disc’s surface.
lDiscs should be kept in their storage cases when not in use.
lDonotexposediscstodirectsunlight,hightemperaturesorhighhumidityforextendedperiods.
lDonotstickpaper,tape,orlabelsonthediscsurfacesnorwriteonthemwithanytypeofmarker.
CACA CACA
CARE ARE A
RE ARE A
RE AND MAND MA
ND MAND MA
ND MAINTENAINTENA
INTENAINTENA
INTENANCENCE
NCENCE
NCE
1414
1414
14

128-5780D
16 of 16
Form No. 128-4270E
AUDIOVOXCORPORATION(theCompany)warrantstotheoriginalretailpurchaserof
this product that should this product or any part thereof, under normal use and
conditions, be proven defective in material or workmanship within 12 months from the
date of original purchase, such defect(s) will be repaired or replaced with new or
reconditioned product (at the Company's option) without charge for parts and repair
labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be
deliveredwithproofofwarrantycoverage(e.g.dated billofsale),specificationofdefect(s),
transportation prepaid, to the warranty center at the address shown below.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrection
of antenna problems, to costs incurred for installation, removal, or reinstallation of the
product,ordamagetotapes,compactdiscs,speakers,accessories,orvehicleelectrical
systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the
Company, has suffered or been damaged through alteration, improper installation,
mishandling,misuse,neglect,accident,orbyremovalordefacementofthefactoryserial
number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY
ACTION FORBREACH OFANY WARRANTYHEREUNDERINCLUDINGANYIMPLIED
WARRANTYOFMERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30
MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES
FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. NopersonorrepresentativeisauthorizedtoassumefortheCompany
any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusionorlimitationofincidentalorconsequentialdamagesotheabovelimitationsor
exclusions may not apply to you. This Warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
12 MONTH LIMI12 MONTH LIMI
12 MONTH LIMI12 MONTH LIMI
12 MONTH LIMITED WTED W
TED WTED W
TED WAA
AA
ARRRR
RRRR
RRAA
AA
ANTNT
NTNT
NTYY
YY
Y
©2000 Audiovox Corporation l Hauppauge, NY 11788 128-5780D
U.S.A.: AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 • 1-800-645-4994
CANADA:CALL1-800-645-4994FORLOCATIONOFWARRANTYSTATIONSERVINGYOURAREA
