Audiovox Rampage AV-428 Programming manual

AA
AA
AV-428V-428
V-428V-428
V-428
DETACHABLE FRONT PANEL AM/FM/MPX RADIO
WITH AUTO-REVERSE CASSETTE PLAYER,
CD CHANGER CONTROLS AND QUARTZ CLOCK
OO
OO
OWNER'S MANUWNER'S MANU
WNER'S MANUWNER'S MANU
WNER'S MANUALAL
ALAL
AL
AND INSTAND INST
AND INSTAND INST
AND INSTALLAALLA
ALLAALLA
ALLATION GUIDETION GUIDE
TION GUIDETION GUIDE
TION GUIDE
AV-428
Auto Reverse

22
22
2
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a
special installation kit will be required to mount the radio to the dashboard. These kits are available at electronics
supply stores and car stereo specialist shops. Always check the kit application before purchasing to make sure
the kit works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line at
1-800-645-4994.
UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE
1. Removethedetachablefrontpanelifitisattachedtothechassisbypushingthe“Release”button. Slidethemounting
sleeve off of the chassis. If it is locked into position, use the removal tools (supplied) to disengage it.
2. Checkthedashboardopeningsizebyslidingthemountingsleeveintoit. Iftheopeningisnotlargeenough,carefully
cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening or
cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
3. Locatetheseriesofbendtabsalongthetop,bottom,and sidesof themounting sleeve. Withthesleevefullyinserted
into the dashboard opening, bend as many of the tabs outward as necessary so that the sleeve is firmly secured to
the dashboard.
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting sleeve.
Follow the wiring diagram carefully and make certain all connections of the wiring harness are secure and insulated
withwirenutsorelectricaltapetoinsureproper operationof theunit. After completingthewiringconnections,attach
the front panel and turn the unit on to confirm operation (ignition switch must be “on”). If unit does not operate, re-
checkallwiringuntilproblemiscorrected. Onceproperoperationisachieved,turnofftheignitionswitchandproceed
with final mounting of the chassis.
5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and the spring
clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using the hex
nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either above or below
the radio using the screw and hex nut provided. Bend the strap to position it as necessary.
CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard from the
weight of the radio or improper operation due to vibration.
7. Re-attach the front panel to the chassis and test radio operation by referring to the Operating Instructions for the unit.
INSTALLATION USING KITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with the
installation kit to attach the radio to the mounting plate supplied with the kit.
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
INSTINST INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
ISO INSTALLATION PROCEDURE
This unit has threaded holes in the chassis side panels which may be used with the original factory mounting brackets
of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the dashboard. Please
consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and brackets
as they will be used to mount the new radio.
2. Carefully unsnap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION:DONOTEXCEEDM5X8MMMAXIMUMSCREWSIZE.
LONGERSCREWSMAYTOUCHANDDAMAGECOMPONENTSINSIDETHECHASSIS.
4. Wire the new radio to the vehicle as per step 4 of the Universal Installation Procedure.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
SCREW STUD
PERFORATED STRAP
SCREW
FASTEN THIS END TO
SCREW STUD ON
REAR OF CHASSIS
BEND TOP TABS
UPWARD
MOUNTING SLEEVE
EXISTING DASH OPENING (FILE EDGES TO FIT IF NECESSARY-DO NOT OVERFILE)
NOTE: IF DASH IS SOLID, USE MOUNTING SLEEVE AS A TEMPLATE & CUT OPENING
NUT
BEND BOTTOM TABS
DOWNWARD
RADIO
FASTEN THIS END TO SECURE PART
OF DASHBOARD.
DRILL HOLE IF NECESSARY.
33
33
3
TYPICAL INSTALLATION
MAX. SIZE
M5 x 8
MAX. SIZE
M5 x 8
FACTORY MOUNTING BRACKETS
ISO INSTALLATION
REMOVE THE PLASTIC FRAME FROM THE
FRONT OF THE CHASSIS BY CAREFULLY
UNSNAPPING IT.
Unsnap AT 2 PLACES
EACH ON TOP AND
BOTTOM
PLASTIC FRAME
INSTINST
INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
DETACHABLE
FRONT PANEL
REMOVAL
TOOLS
8:30AM - 7PM
9AM - 5PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON.-FRI.
SATURDAY
DAY TIME ZONE
TT
TT
Toll-Froll-Fr
oll-Froll-Fr
oll-Free
ee
ee Inse Ins
e Inse Ins
e Instt
tt
tallatallat
allatallat
allation Asion As
ion Asion As
ion Assissis
sissis
sistt
tt
tancanc
ancanc
ancee
ee
e
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you do, we're
here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days and hours shown
(U.S.A. and Canada only).
7:30AM - 6PM
8AM - 4PM

44
44
4
RR RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
RR
RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
REFERTOPAGE 5FORSPEAKER WIRING
IMPORTANT
THE BLUE WIRE CAN BE USED TO
REMOTELY ACTIVATE AN AUTO-
MATIC ANTENNA OR AN EXTERNAL
AMPLIFIER (SEE ANTENNA OR AM-
PLIFIER MANUAL)
9 PIN PLUG
(SEE PAGE 5 FOR SPEAKER WIRING)
4 PIN PLUGS
POSITIVE (+) TERMINAL
12V BATTERY
YELLOW
CAR BATTERY
METAL PART OF DASH
(DRILL HOLE IF NECESSARY)
SCREW
BLACK
RED “RADIO” FUSE
+ 12V ACCESSORY
BLUE
FUSEBLOCK
RADIO
IMPORTANT
YELLOWWIREMUSTBECONNECTEDASSHOWN
OR RADIO WILL NOT OPERATE PROPERLY
1-AMP FUSE
EXISTING
ANTENNA
CABLE
ANTENNA AUTOMATIC
ANTENNA
FILTER/FUSE
BOX
(12-AMPFUSE)
ANTENNA SOCKET
ANTENNA PLUG

55
55
5
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
SEE PAGE 4 FOR
RADIO WIRING
GRAY
VIOLET
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
REFER TO PAGE 4
FOR RADIO WIRING
!
!
!
!
WARNING!
THE AMPLIFIERS IN THIS RADIO ARE ONLY DESIGNED FOR USE WITH 4 SPEAKERS.
NEVER COMBINE (BRIDGE) OUTPUTS FOR USE WITH 2 SPEAKERS.
NEVER GROUND NEGATIVE SPEAKER LEADS TO CHASSIS GROUND.
FAILURETOWIREEXACTLYASSHOWNBELOWMAYCAUSEELECTRICALDAMAGETOTHERADIO.
WHITE w/BLACK STRIPE GRAY w/BLACK STRIPE
4-PIN PLUGS
RCA JACKS
LINE OUT
FOR USE WITH
OPTIONAL
EXTERNAL
AMPLIFIERS
RED = RIGHT
WHITE = LEFT
WHITE
LEFT FRONT SPEAKER RIGHT FRONT SPEAKER
LEFT REAR SPEAKER RIGHT REAR SPEAKER
GREEN
9-PIN PLUGS
GREEN w/BLACK STRIPE VIOLET w/BLACK STRIPE
RADIO
HELP!
8:30am - 7:00pm Eastern
9:00am - 5:00pm Eastern
Monday - Friday
Saturday
1-800-645-49941-800-645-4994
1-800-645-49941-800-645-4994
1-800-645-4994
8-PIN DIN SOCKET FOR CONNECTION TO
OPTIONAL CD CHANGER
DIN CABLE (SUPPLIED
WITH CD CHANGER).
6
COMPACT
OPTIONAL CD CHANGER
SEE PAGE 4
FOR RADIO WIRING
NOTE:
CALL 1-800-645-4994 FOR RECOMMENDATIONS
OF MODEL CHANGERS THAT WILL WORK WITH
YOURRADIO.

6
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
11
11
1ON-OFFPOWERBUTTON
Press this button to turn the unit on and off when the
ignition switch is on. When the unit is off, the Liquid
Crystal Display (LCD) panel will normally display the
time-of-day. If the radio is off when the ignition switch is
turnedoff, thePOWERbuttonmust bepressedtoturnon
the radio after the ignition switch is turned on. If the
ignitionswitchisturned off while the radio is on, the radio
will display thetimeof day,andwillcomeonautomatically
when the ignition switch is again turned on.
22
22
2VOLUMELEVELCONTROL
To increase the volume level, rotate the PUSH SELECT-
VOL control clockwise (CW). The volume will increase
and the level will be shown on the display panel from a
minimum of 00 to a maximum of 100. To decrease the
volume level, rotate the PUSH SELECT control counter-
clockwise (CCW). The volume will decrease as shown
on the display panel. This control also includes the
Select button 3for adjustment of the bass, treble,
balance and fader levels as described in 4, 5, 6, and
7.
33
33
3SELECTBUTTON(SEL)
This button is used to select the audio function (bass,
treble, balance, or fade) to be adjusted using the Volume
Levelcontrol2. PressingtheSelectbuttononcewillset
the unit for volume adjustment (VOL will appear on the
display panel). Pressing the button additional times will
select bass adjustment (BAS on display), treble (TRB),
balance (BAL), or fader (FAD). The display will
automatically return to the normal indication 5 seconds
after the last adjustment or when another function is
activated.
44
44
4BASSCONTROL
To adjust the bass level, first select the Bass mode by
pressing the PUSH SELECT button 3so the BAS
indicationappearsonthedisplaypanel. Within5 seconds
of choosing the Bass mode, rotate the Volume Level
control 2CCW or CW to adjust the bass response as
desired. Thelevelwillbeshownonthedisplaypanelfrom
a minimum --10 to a maximum of 10 (00 indicates flat
response). The display will automatically return to the
normal indication 5 seconds after the last adjustment or
when another function is activated.
NOTE: If the BAS or TRE functions are set while the
Equalizer function (EQ) is active, the Equalizer
function will automatically revert to the FLAT
setting.
55
55
5TREBLECONTROL
To adjust the treble level, first select the Treble mode by
pressing the PUSH SELECT button 3so the TRB
indicationappearsonthedisplaypanel. Within5seconds
of choosing the Treble mode, roatate the Volume Level
control 2CCW or CW to adjust the treble response as
desired. Thelevelwillbeshownonthedisplaypanelfrom
a minimum of --10 to a maximum of 10 (00 indicates flat
response). The display will automatically return to the
normal indication 5 seconds after the last adjustment or
when another function is activated.
1
2
3
4
5
6
7
8, 10 9
11
12
34
35
17
18
25
14
15
26
27, 28
BEHIND PANEL
20
24
19
29
13 31 36 37 38 32 33
16
2122 30
AV-428
Auto Reverse
23

7
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
66
66
6LEFT/RIGHTBALANCECONTROL
To adjust the left-right speaker balance, first select the
Balance modeby pressing thePUSH SELECT button 3
so the BAL indication appears on the display panel.
Within 5 seconds of choosing the Balance mode, rotate
the Volume Level control 2CCW to adjust the stereo
balance to the left channel speakers, or CW to adjust it
to the right channel speakers. The balance position will
be shown on the display panel from BAL 10L (full left) to
BAL 10R (full right). When the volume level between the
left and right speakers is equal, BAL L=R will be shown
onthe display panel. The display will automatically return
tothenormalindication5secondsafterthelastadjustment
or when another function is activated.
77
77
7FRONT/REARFADERCONTROL
To adjust the front-rear speaker balance, first select the
FadermodebypressingthePUSHSELECTbutton3so
the FAD indication appears on the display panel. Within
5secondsofchoosingtheFadermode,rotatetheVolume
Level control 2CW or CCW to adjust the front-rear
speaker balance as desired. The fader position will be
shown on the display panel from FAD 10R (full rear) to
FAD 10F(fullfront). Whenthelevelbetweenthefrontand
rear speakers is equal, FAD F=R will be shown on the
display panel. The display will automatically return to the
normal indication 5 seconds after the last adjustment or
when another function is activated.
88
88
8LOUDNESSCONTOUR(LOUD)
When listening to music at low volume levels, this feature
will boost the bass and treble ranges to compensate for
the characteristics of human hearing. Press and hold the
BAND /LOUD button to activate this feature and the
indication LOUD ON will appear on the display panel for
5seconds.Press and hold the button againtodeactivate
the feature, and LOUD OFF will appear on the display
panel for 5 seconds.
99
99
9AUDIOMUTESELECTOR(MUT)
Press this button momentarily to mute the volume from
the system (MUTE will appear flashing on the display
panel). Pressing this button again, adjusting the Volume
Level control 2, or pressing any other button, will return
tothevolumelevel settingin usebeforetheMutefunction
was activated.
blbl
blbl
bl AM/FMBANDSELECTOR( BAND )
Each time the
BAND /LOUD button is pressed, the radio
band is changed. The indications F1, F2, F3 or AM will
appear in the display panel according to your selection.
bmbm
bmbm
bm AUTOMATIC UP/DOWN TUNING ( / )
To select a radio station in the automatic mode,
momentarily press the Up Tuning ( ) button to
advancetheunit tothenextavailablestation,ortheDown
Tuning () button to tune downward to the next
available station. The radio will automatically seek the
next strongest station. If the Local mode (LOCAL) is
active, the radio will seek the next strongest local station
when either button is pressed.
bnbn
bnbn
bn MANUALSEEKTUNING
This function is used to search rapidly upward or
downward for a desired station. By pressing either tune
button for more than 2 seconds, the radio will enter the
MANUAL seek mode as displayed momentarily on the
panel. When either button is pressed and held in this
mode, the radio will tune rapidly up or down and will stop
at the station of choice when the button is released. A
momentary press of either button in this mode will cause
the radio to tune upward or downward one digit at a time.
If tuning is not activated within 5 seconds of entering the
MANUAL mode, the radio will automatically revert to the
default AUTO mode as indicated momentarily on the
panel.
bobo
bobo
boLOCAL/DISTANTSELECTOR(LOC)
This feature is used to select the strength of the signals
at which the radio will stop during Automatic Up/Down
Tuning. Pressing the button will select the Local setting
(LOCAL will appear on the display panel for 5 seconds)
and tuning will select only strong (local) stations for
reception. Pressing the button again will select the
Distant setting (DX will appear on the display panel for 5
seconds) and the tuning will stop at a wider range of
signals, including weaker (more distant) stations.
bpbp
bpbp
bp FMMONOSELECTOR(MONO)
During FM radio operation, this button is used to select
mono or stereo reception of the broadcast signal. Under
normal reception conditions, the unit should be left in the
stereo mode as indicated by ST and the associated
signal strength indicator on the display panel when tuned
toan FM stereo signal. If the stereo signal is too noisy for
comfortable listening, press the MONO button to switch
to mono reception (the ST indication will disappear from
the display panel, and MONO will momentarily appear).
To return to stereo reception mode, press the button
again; STEREO will momentarily appear on the display
panel and the ST indication returns.
bqbq
bqbq
bq PRE-SET SCAN (PS) AUTO-STORETUNING(AS)
Press this button momentarily to scan the stations pre-
setinto thememories onthe3FMbands orthe AM band.
The unit will stop at each pre-set station for 5 seconds
before continuing to the next pre-set station (the pre-set
number on the display panel will flash during Pre-Set
Scan operation). Press the button again momentarily to
stop Pre-Set Scan operation and remain on the selected
frequency.
Pressingandholdingthebuttonforlongerthan2seconds
will activate the Auto-Store Tuning feature which will
automatically scan and enter up to 6 stations into the 6

88
88
8
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
pre-set memories on the band in use. After entering the
stations into memory, the unit will automatically stop at
each station for 5 seconds so each can be heard. If you
have already set the pre-set memories to your favorite
stations, activating the Auto-Store Tuning feature will
erase those stations and enter the new ones. This
feature is most useful when travelling in a new area
where you are not familiar with the local stations.
brbr
brbr
br STATION PRE-SET MEMORIES
To set any of the 6 pre-set memories in each band, use
the following procedure:
1. Turn the radio on and select the desired band.
2. Select the first station to be pre-set using the
Automatic Up/Down bm, or Manual Seek bn Tuning
Controls.
3. Press and hold the pre-set button to be set for
approximately 2 seconds. The pre-set number will
appearon the displaypanelindicating that thestation
is now set into that pre-set memory position. The
station can now be recalled at any time by pressing
that button.
4. Repeat the above procedure for the remaining 5
pre-sets on that band and for the other 3 bands
on the unit.
bs bs
bs bs
bs EQUALIZER( EQ )BUTTON
The
EQ button applies preset sound effects to the unit’s
audio output signal.The
EQ button, when pressed, will
activateoneofthefollowingoperatingmodes(CLASSICS,
POP M, ROCK M, DSP OFF or FLAT). If the Equalizer
functionisactive, as momentarily displayed on the panel,
and the bass and/or treble level is set, the Equalizer
function revertstothetheFLATsetting.Ontheotherhand,
if the Equalizer function is activated, the bass/treble
setting(s) are ignored. Conversely, when the Equalizer
function is not active, the unit returns to the user set bass
and treble levels.
bt bt
bt bt
bt STATION SCAN ( SCN ) BUTTON
When this button is pressed during radio operation, each
station in the current band will be scanned in the upward
direction; each displayed station will flash for 5 seconds
before moving on to the next station. If the local mode is
active, only the stronger, nearby stations in the current
band will be scanned. When the desired station appears,
press the
SCN button again to remain on that frequency.
bubu
bubu
bu LIQUIDCRYSTALDISPLAYPANEL
The Liquid Crystal Display (LCD) panel displays the
frequency, time and activated functions, including a
combination audio level/disc indicator in the form of dual
disc icons ( ) with circular bar graphs depicting the
strength of the audio signal. In addition, the display also
contains a receive signal indicator which depicts the
relative strength of the incoming broadcast frequency.
NOTE: It is a characteristic of LCD panels that, if
subjected to cold temperatures for an extended
periodoftime,theymaytakelongertoilluminate
than under normal conditions. In addition,
the visibility of the numbers on the LCD may
slightly decrease. The LCD read-out will return
to normal when the temperature increases to
a normal range.
clcl
clcl
cl CASSETTEDOOR
Hold the cassette with the exposed tape edge to the right
and insert it fully into the cassette door until the cassette
is engaged and begins playing (TAPE will appear on the
display panel, together with three tape direction arrows).
Whenthecassettereachestheendonthesideofthetape
being played, the unit will automatically change direction
of play as shown by reversal of the three tape direction
arrow indications on the display panel.
NOTE: Observe cassette operation cautions in Care
and Maintenance section of this manual.
cmcm
cmcm
cm&cncn
cncn
cnFAST-FORWARD/REWINDBUTTONS
(/ )These buttons cause the tape to move rapidly
in the direction indicated by the arrows. For example, if
the buttonispushed when the tapeismovingfrom left
to right (>>>>>>
>>>>>>
>>> on the display panel), the tape will fast-
forward. If the button is pressed while the tape is
moving from right to left ( <<<<<<
<<<<<<
<<<on the display panel), the
tape will rewind. To stop fast tape movement, lightly push
theoppositebutton. If thetapeisallowedtofast-forward
orrewindallthewaytotheend,thetapewillreverseand
automatically resume play.
coco
coco
co PROGRAMSELECTOR
Tomanuallyreversetapedirectionandplaytheotherside
(program) of the cassette, lightly push both the Fast-
Forward and Rewind buttons ( and ) at the same
time. Thechange ofdirectionwillbeshown bythearrows
on the display panel.
cp cp
cp cp
cp EJECT BUTTON ( )
Tape playback is stopped and the cassette is ejected by
pressing this button. Radio operation will automatically
resume when the cassette is ejected.
NOTE: Never leave a cassette engaged in the player
when not in use. Doing so can cause damage
to the cassette and/or mechanism of the unit.
Always press the eject button and remove
the cassette before removing the detachable
front panel.
cqcq
cqcq
cq MODESELECTOR(MODE)
During radio or tape play, press this button to select
operation of the optional CD changer as shown by CDC,
the disc number and the track number on the display
panel. Refer to the CD Changer Controls section for
specific operating instructions.

99
99
9
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONS / SETIONS / SET
IONS / SETIONS / SET
IONS / SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
IfthebuttonispressedwhennoCDchangerisconnected
to the unit, no CDC indications will appear on the display
panel. The unit will then return to radio operation. To
returntothetapeoperation(ifatapeisloadedintheunit),
press the button again. During tape play, press this
button to change to radio operation without ejecting the
tape.
crcr
crcr
cr TIME/FREQUENCYSELECTOR(T/F)
Pressing the Time/Frequency (T/F) button will display
the time of day for 5 seconds, after which the display will
automatically return to the radio, tape or CD changer
display, depending on which one was currently active.
To set the correct time of day, refer to the procedure for
Setting the Clock.
cscs
cscs
csTHEFT-DETERRENTLED
Located on the chassis behind the front panel, a light-
emittingdiode(LED)willflashwhenthepanelisremoved.
The flashing light serves as a visual warning to the
would-bethief thattheunit hasbeendisabledbyremoval
of the front panel.
ctct
ctct
ct RESETBUTTON
A RESET button is located on the front of the chassis
(front panel must be removed to access the button). The
re-set circuitry is provided to protect the microprocessor
circuitry and should only be activated under the following
circumstances as it will erase the time and pre-set
memories.
1. Upon initial installation after all wiring is completed.
2. If there is a malfunction of any of the switches on
the unit, pressing the RESET button may clear the
system and return to normal operation.
cucu
cucu
cuFRONTPANELRELEASEBUTTON
This button is used to release the mechanism that holds the
front panel to the chassis. To detach the front panel, press
thebuttonsothattheleftsideofthepanelisreleased. Grasp
the released side and pull it off of the chassis. To re-attach
the panel, position the right side of the panel in place first
andthen press theleftside ofthepanel until themechanism
locks it into place.
dl dl
dl dl
dl DIMMER BUTTON (DIM)
Thisbutton provides control of the panel display brightness;
when pressed once, the display will dim to half its normal
intensity. When pressed again, the display will return to full
brightness intensity.
NOTESONUSEOFFRONTPANEL
1. Make sure the front panel is right-side-up when
attaching it to the chassis as it cannot be attached
when up-side down.
2. Donotpressveryhardonthefrontpanelwhenattaching
it to the chassis. No more than light to moderate
pressure should be needed.
3. When attaching the front panel, make sure the right
side is correctly engaged before pressing the left side
to lock it into position.
4. When taking the front panel with you, please use the
supplied carrying case to protect the panel from dirt
and damage. Make sure there is no dust or dirt on the
electrical terminals on the back of the panel as this
could cause intermittent operation or other
malfunctions.
SETTING THE CLOCK
1. Switch the vehicle ignition and radio on.
2. Momentarily press the Time/Frequency (T/F) Select button cr so that the time is shown on the display panel.
3. Pressand hold the Time/Frequency button untilthetimedisplaybegins flashing. While the display is stillflashing,
press the Up Tuning ( ) button to adjust the hours and then the Down Tuning ( ) button to adjust the
minutes to the correct time.
4. Five seconds after the last hour or minute adjustment is made, the time will be set in the unit and the display
will return to the normal indication.

99
99
9
SPECIFICASPECIFICA SPECIFICASPECIFICA
SPECIFICATT
TT
TIONS / CAIONS / CA
IONS / CAIONS / CA
IONS / CARE ARE A
RE ARE A
RE AND MAND MA
ND MAND MA
ND MAINTENAINTENA
INTENAINTENA
INTENANCENCE
NCENCE
NCE
CACA CACA
CARE ARE A
RE ARE A
RE AND MAND MA
ND MAND MA
ND MAINTENAINTENA
INTENAINTENA
INTENANCENCE
NCENCE
NCE
1010
1010
10
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not
require any maintenance. We recommend that you keep
this manual for reference on the many features found in
this unit as well as how to set the clock.
The optional compact disc changer section also
requires no routine maintenance, but proper under-
standing of its use and handling will help you obtain
maximum enjoyment of its capabilities.
CASSETTECARE
As with any cassette player, the cassette section of this
sound system does require a minimum of maintenance
to keep it in good working condition. The following simple
care and maintenance suggestions should be followed to
prevent malfunctions of the cassette system.
1. Purchase a cassette cleaning kit from your local
retail store. Use it! At least every 20 to 30 hours
of operation you must clean the cassette mecha-
nism. A dirty cassette player will have a poor
sound.
2. Do not use cassettes that exceed 45 minutes of
play on each side.
3. Do not insert a cassette that appears to be broken,
twisted or dirty or with loose or torn labels on it.
4. Always keep your cassettes away from direct sun
light or exposure to subfreezing conditions. If a
cassette is cold, allow it to warm up before use.
5. Donot keepa cassetteintheplayerwhen notin use.
6. Before inserting a cassette in the player, check
that the tape is tightly wound on the reels. Take
up any excess slack using a pencil to turn the
drive hub in the cassette.
HANDLINGCOMPACTDISCS(OPTIONALCDCHANGER)
Dirt, dust, scratches, and warpage can cause skips in the
playback and deterioration of sound quality. Please follow
these guidelines to take care of your compact discs:
!Use only compact discs with the mark .
!Fingerprints, dust, and dirt should be carefully wiped off
the disc’s playing surface (shiny side) with a soft cloth.
Wipe in a straight motion from the inside to the outside
of the disc.
!Never use chemicals such as record sprays,
household cleaners or thinner to clean compact discs.
Such chemicals can irreparably damage the disc’s
surface.
!Discs should be kept in their storage cases when not in
use.
!Do not expose discs to direct sunlight, high temperatures
or high humidity for extended periods.
!Do not stick paper, tape, or labels on the disc surfaces
nor write on them with any type of marker.

SPECIFICASPECIFICA
SPECIFICASPECIFICA
SPECIFICATT
TT
TIONSIONS
IONSIONS
IONS
Size: 7” W x 2” H x 6” D
178 mm x 50 mm x 150 mm
Operating Voltage: 12 volts DC, negative ground
Output Power: 160 watts maximum (40 watts x 4 channels)
Output Wiring: Floating-ground type designed for 4 speaker use.
The amplifiers in this unit are NOT designed for use with 2 speakers.
RCA pre-amp level outputs.
Output Impedance: Compatible with 4 - 8 ohm speakers
Pre-Amp Output: 500 mv.
Tuning Range: AM: 530 - 1,710 KHz. (10 KHz. step)
FM: 87.5 - 107.9 MHz. (200 KHz. step)
Sensitivity: AM: >45 dB.
FM: >15 dB at a S/N of 30 dB
FM Stereo Separation: 25 dB at 1kHz
Tape Frequency Response: 50-10,000 Hz.
Tape S/N Ratio: 50 dB
Wow & Flutter: 0.15% WRMS
*Specifications are subject to change without notice.
SPECIFICASPECIFICA SPECIFICASPECIFICA
SPECIFICATT
TT
TIONS / NOIONS / NO
IONS / NOIONS / NO
IONS / NOTES ON DISCSTES ON DISCS
TES ON DISCSTES ON DISCS
TES ON DISCS
1111
1111
11

1212
1212
12
THISPAGELEFTBLANKINTENTIONALLY

1010
1010
10
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER CONTRNGER CONTR
NGER CONTRNGER CONTR
NGER CONTROLOL
OLOL
OLSS
SS
S
Built into this radio are controls to operate an optional CD
changer. Please check with your Rampage/Audiovox car
stereo specialist for recommendations of the models
that will work with this radio.
Once the changer is installed and properly connected, it
may be necessary to press the RESET button behind the
radio front panel to initialize the complete installation.
Adjustmentoftheaudiofunctions (volume,tone,balance,
and fader) for the CD changer operate in the same
manner as they do for radio play. The following controls
will operate the CD changer when it is installed and
connected to this radio. Refer to the owner’s manual
included with the CD changer for instructions on the
installation and correct loading and use of the CD
magazine.
dmdm
dmdm
dm CDCHANGERPAUSE/PLAYSELECTOR(PAU)
During radio, or tape play, press the MODE button to
select operation of the CD changer as shown by CDC on
the display. Disc play will begin, the disc and track
number will be shown on the display panel, and the
center of the disc icon ( ) will become animated. If
a new magazine has been loaded into the changer, play
will begin from the first track of the first disc in the
magazine. Ifamagazinewasalreadyinthechanger,play
will resume from the track on the disc previously in play.
During CD changer play, pressing the PAU button once
will stop changer play; PAUSE will appear on the display
and the center of the disc icon will remain stationary. To
resume disc play, press the PAU button again and disc
playwill resume fromthepoint atwhichit was interrupted.
dndn
dndn
dn&dodo
dodo
do DISC SELECT (DN & UP)
Thesebuttons are usedtoselect thedesireddisc for play.
To advance to a higher number disc, press the UP button
dodo
dodo
do. Toreturntoalowernumberdisc,presstheDNbutton
dndn
dndn
dn. The number of the disc in play will be shown on the
display panel.
dpdp
dpdp
dp TRACK SELECT ( / )
This button is used to quickly select the beginning of a
particulartrack.WitheachmomentarypressoftheForward
Track Select button ( ), the next higher track number
will be selected as shown on the display panel. Similarly,
witheachmomentarypress ofthe BackwardTrackSelect
button( ),thenextlowertracknumberwillbeselected.
dqdq
dqdq
dqFOWARD/REVERSESEARCH(CUE/REVIEW)
High-speed audible search to any forward or reverse
section of the disc can be made with this feature. Press
and hold the forward (cue) button ( ) to advance
rapidly in the forward direction, or press and hold the
reverse (review) button ( ) to advance rapidly in the
reverse (backward) direction. In either case, the center of
the disc icon will rotate faster when search is active.
drdr
drdr
dr TRACKSCANSELECTOR(SCN)
When the SCN button is momentarily pressed, the SCN
indication will appear on the display panel, and the first
10 seconds of each track on the disc will be played in
order. When a desired track is reached, press the SCN
button again and play of the selected track will continue
(SCN will disappear from the display panel). The Track
Scan mode will also be canceled by activating any other
disc function (Track Select, Repeat or Random).
When the SCN button is pressed and held for more than
2 seconds, the disc scan mode is activated; DSN will
appear on the display and the first 10 seconds of the first
track on each disc will be played in disc order. This mode
is canceled in the same manner as before.
ds ds
ds ds
ds TRACKREPEATPLAYSELECTOR(RPT)
When the RPT button is momentarily pressed, the RPT
indication will appear on the display panel and play of the
current track will be continually repeated until the Track
Repeat mode is canceled by pressing the RPT button
again or by activating the Track Select, Random Play or
Scan functions.
When the RPT button is pressed and held for more than
2 seconds, the disc repeat mode is activated; DRT will
appear on the display and the play of the current disc will
be continuously repeated. This mode is canceled in the
same manner as before.
dtdt
dtdt
dtSHUFFLEPLAYSELECTOR(SHF)
When the SHF button is momentarily pressed, the SHF
indication will appear on the display panel and the tracks
onthediscwillbeplayedinarandom,shuffledorder. The
Track Select buttons dpdp
dpdp
dp will also select tracks in the
shuffled order instead of the normal progression. The
TrackShuffle modecanbecanceledbypressingtheSHF
buttonagainorbyactivatingtheTrackSelect,RepeatPlay
or Scan functions.
When the SHF button is pressed and held for more than
2 seconds, the disc shuffle mode is activated; DSF will
appear on the display and the play of the discs in the
magazine will be played in a random shuffled order. This
mode is canceled in the same manner as before.

CD CHCD CH
CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
IfaproblemshoulddevelopwhileoperatingtheCDchanger,theerrorcode“Err”mayappearonthedisplay
panel. This can indicate a number of problems with the unit, including a mechanical error or an error in the
microprocessorcontrolofthechanger. Iftheerrorcodeshouldappear,tryejectingandre-loadingthemagazine
intothechanger. Whilethemagazineisoutofthechanger,makesurethediscsareclean,undamaged,and
loadedcorrectly(seeOwner’sManualoftheCDchanger). YoumayalsotryactivatingtheRESETbuttonct
on the unit, but this will also erase the time and pre-set memories.
Ifthesuggestedmeasuresdonotsolvetheproblem,contactanapprovedwarrantystationnearyouforfurther
assistance.
1414
1414
14
CD CHCD CH CD CHCD CH
CD CHAA
AA
ANGER ERRNGER ERR
NGER ERRNGER ERR
NGER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES

AUDIOVOXCORPORATION(theCompany)warrantstotheoriginalretailpurchaserofthisproductthat
shouldthisproductoranypartthereof,undernormaluseandconditions,beprovendefectiveinmaterial
orworkmanshipwithin12 monthsfromthedate oforiginalpurchase,such defect(s)willberepaired
orreplacedwithneworreconditionedproduct(attheCompany'soption)withoutchargeforpartsand
repairlabor.
Toobtainrepair orreplacementwithin thetermsof thisWarranty,the productisto bedeliveredwith
proofofwarrantycoverage(e.g.dated billofsale),specificationofdefect(s),transportationprepaid,
to the warranty center at the address shown below.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrectionofantenna
problems, to costs incurred for installation, removal, or reinstallation of the product, or damage to
tapes, compact discs, speakers, accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company,
has suffered or been damaged through alteration, improper installation, mishandling, misuse,
neglect,accident, orby removalordefacement ofthe factoryserial number/barcodelabel(s). THE
EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE
REPAIRORREPLACEMENTPROVIDEDABOVEAND,INNOEVENT,SHALLTHECOMPANY'S
LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE
DURATIONOFTHISWRITTENWARRANTY. ANYACTIONFORBREACHOFANYWARRANTY
HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE
BROUGHTWITHINAPERIODOF30MONTHSFROMDATEOFORIGINALPURCHASE. INNO
CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. NopersonorrepresentativeisauthorizedtoassumefortheCompanyanyliability
other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or
limitationofincidentalorconsequentialdamagesotheabovelimitationsorexclusionsmaynotapply
toyou. This Warranty givesyou specific legalrights and youmay also haveother rights whichvary
from state to state.
12 MONTH LIMITED WARRANTY
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 ! 1-800-645-4994
CANADA: CALL1-800-645-4994 FOR LOCATIONOF WARRANTY STATIONSERVING YOUR AREA 128-4270E
1515
1515
15
WW
WW
WAA
AA
ARRRR
RRRR
RRAA
AA
ANTNT
NTNT
NTYY
YY
Y

© 2003 Audiovox Electronics Corp., Hauppauge, NY 11788
128-6634
Printed in China
1616
1616
16
