INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases,
a special installation kit will be required to mount the radio to the dashboard. These kits are available at
electronics supply stores and car stereo specialist shops. Always check the kit application before purchasing to
make sure the kit works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line at
1-800-645-4994.
UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE
1. RemovethefrontpanelfromtheunitbypressingtheRELeasebuttonatthetoprightcorner; thenslidethemounting
sleeve off of the chassis. If it is locked into position, use the removal tools (supplied) to disengage it.
2. Checkthedashboardopeningsizebyslidingthemountingsleeveintoit. Iftheopeningisnotlargeenough,carefully
cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening
or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve
fully inserted into the dashboard opening, bend as many of the tabs outward as necessary so that the
sleeve is firmly secured to the dashboard.
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting
sleeve. Follow the wiring diagram carefully and make certain all connections of the wiring harness are
secureand insulated withwire nutsor electrical tapetoinsure proper operationofthe unit. After completing
the wiring connections, turn the unit on to confirm operation (ignition switch must be “on”). If unit does not
operate, recheck all wiring until problem is corrected.
5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and
the spring clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using
the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either
above or below the radio using the screw provided. Bend the strap to position it as necessary.
CAUTION:The rear of the radio must be supported with the strap to prevent damage to the dashboard
from the weight of the radio or improper operation due to vibration.
7. Test radio operation by referring to the Operating Instructions.
INSTALLATION USING KITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with
the installation kit to attach the radio to the mounting plate supplied with the kit.
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
ISO INSTALLATION PROCEDURE
This unit has threaded holes in the chassis side panels which may be used with the original factory mounting
brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the
dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and
brackets as they will be used to mount the new radio.
2. Carefully unsnap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION: DONOTEXCEEDM5X6MMMAXIMUMSCREWSIZE.
LONGERSCREWSMAYTOUCHANDDAMAGECOMPONENTSINSIDETHECHASSIS.
4. Wire the new radio to the vehicle as per step 4 above.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

33
33
3
44
44
4
INSTINST
INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
DAY
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATION
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
8:30AM - 7PM
9AM - 5PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON.-FRI.
SATURDAY
TT
TT
TOLL-FREE INSTOLL-FREE INST
OLL-FREE INSTOLL-FREE INST
OLL-FREE INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION ASSISTION ASSIST
ION ASSISTION ASSIST
ION ASSISTAA
AA
ANCENCE
NCENCE
NCE
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you
do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days
and hours shown (U.S.A. and Canada only).
7:30AM - 6PM
8AM - 4PM
NUT (5MM) EXISTING DASH OPENING
FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE
NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF
MOUNTING SLEEVE AS A TEMPLATE & CUT OPENING
REMOVETHEPLASTICFRAMEFROMTHEFRONTOFTHECHAS-
SISBYCAREFULLYUNSNAPPINGIT.
TYPICAL INSTALLATION
20° MAX.
FRONT PANEL
CAUTION:
FORPROPEROPERATIONOFTHE CDPLAYER,THECHASSIS MUST BE
MOUNTED WITHIN 20° OF HORIZONTAL. MAKE SURETHEUNIT IS
MOUNTED WITHIN THIS LIMITATION.
SIDEVIEW
OF
CHASSIS
UNSNAP ON LEFT AND
RIGHT SIDES
MAXIMUM
SCREWSIZE
M5 x 6
MAXIMUM
SCREWSIZE
M5 x 6
PERFORATED STRAP
MOUNTINGSLEEVE
PLASTICFRAME FACTORY MOUNTING
BRACKETS
BEND BOTTOM
TABS DOWNWARD
BEND TOP
TABS UPWARD
RADIO
SCREW STUD
NOTE: PLASTIC FRAME MUST BE REMOVED (UNSNAP ON LEFT
AND RIGHT SIDES) TO USE REMOVAL TOOLS.
REMOVALTOOLS
FASTEN THIS END TO SECURE
PART OF DASHBOARD.
DRILL HOLE IF NECESSARY.
FASTEN THIS END TO SCREW
STUD ON REAR OF CHASSIS
SCREW
(5MM)
TIME ZONE

55
55
5
RADIO WIRING
RR
RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
REFER TO PAGE 6 FOR SPEAKER WIRING
CONTAINS:
1- 15A FUSE
1- 0.5A FUSE
6
BATTERY
RADIO

SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
66
66
6
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
REFER TO PAGE 5
FOR RADIO WIRING
WARNING!
! NEVERCOMBINE(BRIDGE)OUTPUTSFORUSEWITH1SPEAKER.
! NEVERGROUNDNEGATIVESPEAKERLEADSTOCHASSISGROUND.
! FAILURETOWIREEXACTLYASSHOWNBELOWMAYCAUSEELECTRICALDAMAGETO
THERADIO.
1-800-645-49941-800-645-4994
1-800-645-49941-800-645-4994
1-800-645-4994
8:30am - 7:00pm Eastern
9:00am - 5:00pm Eastern
Monday - Friday
Saturday
HELP!
RADIO
5

SEL
VOL
VOL
RELEJECT
ACD-13
TRACK/SKIP
BAND
MUTE
T/F
T
U
N
I
N
G
77
77
7
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
11
11
1POWER(PWR)ON-OFFBUTTON
Press this button ( ) to turn the unit on and
offwhentheignitionswitchison.Whentheunit
isoff,thetimeofday isautomaticallydisplayed
on the Liquid Crystal Display (LCD) panel
unless the ignition switch is off. If the radio is
off when the ignition switch is turned off, the
POWER button must be pressed to turn on the
radioaftertheignitionswitch isturnedon.Ifthe
ignition switch is turned off while the radio is
on, the radio will come on automatically when
the ignition switch is again turned on.
22
22
2VOLUMECONTROLBUTTONS
To increase the volume level, press the
VOL+ button.Thevolumewillincreaseandthe
levelwill be shown on the display panel from
a minimum of VOL 0 to a maximum of VOL
63. To decrease the volume level, press the
VOL - button. The display will automatically
return to the normal indication 5 seconds
after the last volume adjustment or when an-
other function is activated. These buttons
are also used in conjunction with the SEL
button to adjust the bass, treble, balance and
fader levels as described in 4,5,6,and 7.
33
33
3SELECT(SEL)BUTTON
This button is used to select the audio func-
tion (volume, bass, treble, balance or fade) to
be adjusted using the VOL + and - buttons.
Pressing the Select button once will set the
unit for volume adjustment (VOL will appear
on the display panel, followed by the setting
number). Pressing the button additional times
will select bass adjustment (BAS on display
panel),trebleadjustment (TRE),balance(BAL),
fader (FAd), and volume (VOL) again. The dis-
play will return to the normal indication 5
seconds after the last adjustment or when
another function is activated.
44
44
4BASSCONTROL
To adjust the bass level, first select the Bass
modebypressingtheSEL buttonuntiltheBAS
indicationappearson thedisplay panel. Within
5 seconds of choosing the Bass mode, press
the VOL + or - buttons to adjust the bass
conditions; the unit should be left in the stereo
1
10
917
19
16
2
24 131514 23
3, 4, 5, 6, 7
25
26
27
8, 22 11,21 12,20
18
ACD-17ACD-17
ACD-17ACD-17
ACD-17

77
77
7
88
88
8
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TI0NSI0NS
I0NSI0NS
I0NS
response as desired. The bass level will be
shown on the display panel from a mini-
mumofBAS -7 to a maximumof BAS 7 (BAS 0
represents flat response), with each change
accompanied by a beep tone. The display
will automatically return to the normal indication
5 seconds after the last adjustment or
when another function is activated.
55
55
5TREBLECONTROL
Toadjustthe treble level,first select theTreble
mode by pressing the SEL button until the
TRE indication appears on the display
panel. Within 5 seconds of choosing the
Treble mode, press the VOL + or - buttons
to adjust the treble response as desired. The
treble level will be shown on the display panel
from a minimum of TRE -7 to a maximum of
TRE 7 (TRE 0 representsflat response),with
eachchangeaccompaniedbyabeeptone. The
display will automatically return to the
normal indication 5 seconds after the last
adjustment or when another function is
activated.
66
66
6LEFT/RIGHTBALANCECONTROL
To adjust the left-right speaker balance, first
select the Balance mode by pressing the SEL
button until the BAL indication appears on the
display panel. Within 5 seconds of choosing
theBalance mode,presstheVOL +or -buttons
to adjust the audio balance between the right
channel or left channel speakers, respectively.
The balance position will be shown on the
display panel from BAL 10 (full left) to BAr 10
(full right), with each change accompanied by a
beeptone. Whenthevolumelevelbetweenthe
left and rightspeakers is equal, BAL 0willbe
shown on the display panel. The display will
automatically return to the normal indica-
tion5secondsafter thelast adjustment or when
another function is activated.
77
77
7FRONT/REARFADERCONTROL
To adjust the front-rear speaker balance,
first select the Fader mode by pressing the
SEL button until the FAd indication appears
on the display panel. Within 5 seconds of
choosing the Fader mode, press the VOL + or
-buttons toadjust thefront-rearspeakerlevels
asdesired.The fader position willbe shown on
the display panel from FAF 10 (full front) to
FAr10 (full rear), with each change
accompanied by a beep tone. When the vol-
ume level between the front and rear speak-
ers is equal, FAd 0 will appear on the display
panel.Thedisplaywillautomaticallyreturntothe
normal indication 5 seconds after the last
adjustment or when another function is acti-
vated.
88
88
8LOUDNESSCONTOUR(LOUD)
When listening to music at low volume levels,
thisfeature willboostthebassandtrebleranges
to compensate for the characteristics of
human hearing. Momentarily press the
LOUD/RND button to activate this feature as
indicated by LOUD on the display panel.
Pressing the button again will deactivate the
function and LOUD will disappear from the
display.
99
99
9AM/FMBANDSELECTOR
During radio play, each time the BAND button
is pressed, the radio band changes. The
indications AM or FM will appear on the
display panel according to your selection.
blbl
blbl
bl MANUALTUNINGCONTROL
Turn this knob clockwise to tune upward in
frequency on the band in use, counter-clock-
wise to tune downward in frequency. The fre-
quency to which you are tuned will be shown in
digitalformon the display panel. When tuning
in a station, always adjust the control so that
the correct broadcast frequency is shown on
the display and adjust the control so that you
arereceivingaclearsignal. Iftheradioistuned
off-frequency, you could experience distorted
audio, noise and other reception problems.

99
99
9
bmbm
bmbm
bm FMMONO/INTRO(INT)SELECTBUTTON
During FM radio operation, press this button to
select monoorstereoreceptionofthebroadcast
signal. Under normal reception mode as
indicatedbytheST icononthedisplaypanel
whentunedtoanFMstereosignal. Ifthestereo
signal is too noisy for comfortable listening,
press the MONO/INT select button to switch to
monaural reception (the ST icon will
disappear from the display panel). To return to
stereo reception mode, press the button again
so that the ST indication reappears.
bnbn
bnbn
bn LOCAL(LOC)/REPEAT(RPT)BUTTON
During radio operation, received signals are
usually in stereo mode as indicated by the
ST icon; however, when the signals are
weak or intermittent, it may be worthwhile
activating the Local (LOC) mode by pressing
the LOC/RPT button (LOC appears on the
display). This mode favors access to local
stations whose signals are much stronger,
thereby improving radio reception. Press this
button again to terminate local receive mode;
LOC disappears from the display panel.
bobo
bobo
bo AUDIO MUTE (MUTE)
This button is used to mute the volume from
the system. By pressing the button, a MUTE
indication will appear on the display panel and
the volume will be muted. Pressing the MUTE
button again, or pressing the Volume Control
buttons or Select (SEL) button will return the
volume level to the setting in use before the
Mute function was activated.
bp bp
bp bp
bp MODE BUTTON
This button enables selection of either radio
or disc play. When a CD is loaded, pressing
this button will revert to radio operation; the
disc icon ( ) will still be displayed, indicating
a disc is still loaded in the unit. Pressing the
button again will return to disc play, but the
current track will start from the beginning.
bqbq
bqbq
bq LIQUIDCRYSTALDISPLAYPANEL
FUNCTIONS
The Liquid Crystal Display (LCD) panel dis-
plays the frequency, time, and all activated func-
tions, including five bar graphs which provide a
visual representation of the audio signal level.
NOTE: It is a characteristic of LCD panels
that, if subjected to cold temperatures
for an extended period of time, they
may take longer to illuminate than
under normal conditions. In addition,
the visibility of the numbers on the
LCD may slightly decrease. The LCD
read-outwillreturntonormalwhenthe
temperature increases to a normal
range.
br br
br br
br DISC SLOT
With the label surface facing up, fully insert a
compact disc into the slot until the load
mechanism engages; CdP will appear
together with the fixed disc symbol ( ). The
symbol will then become animated and play
willbeginfromthefirstTRACK(01)onthedisc,
accompaniedby theelapsedtimeoftrackplay.
NOTE: This unit is designed for play of
standard 5" (12cm) Compact Discs
ONLY. Do not attempt to use 3"
(8cm) CD-Singles in this unit, either
with or without an adapter, as
damage to the player and/or disc
can occur. Such damage will not
be covered by the Warranty on this
product.
bsbs
bsbs
bs CDPLAY/PAUSE(
/
)SELECTOR
During disc play, pressing this button will
temporarilystopplayofthedisc(thediscsymbol
( ) will flash on the display panel). Press the
buttonagainto resume playof the discfromthe
point at which it was stopped. Playback will
continue until all tracks on the disc have been
played, after which playback will automatically
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

stop (unless the repeat mode had been
selected).
bt bt
bt bt
bt
FORWARDTRACK/SKIPSELECTOR( )
During disc play, this button is used to quickly
select or skip to the beginning of a particular
track in the forward direction. With each press
of thebutton,thenexthigher TRACK number
will be selected as shown on the display
panel. Press and hold the button to advance
rapidly in the forward direction as indicated by
the elapsed time display.
bubu
bubu
bu BACKWARD TRACK/SKIP SELECTOR
( )
During disc play, this button is used to quickly
selectthebeginning ofaparticular trackinthe
backward direction. With each press of the
button, the next lower TRACK number will be
selected as shown on the display panel.
Press and hold the button to advance rapidly
in the reverse direction as indicated by the
elapsed time display.
cl cl
cl cl
cl REPEATPLAYSELECTOR
Duringdiscplay,pressingtheLOC/RPTbutton
will select the track repeat play mode. RPT
appears on the display panel. Play of the
selected track will continue to repeat until the
TrackRepeat function iscanceled bypressing
thebuttonagainorbyactivatingtheIntro-Scan
(INT) or Random (RND) function so that the
RPT indication disappears.
cmcm
cmcm
cm INTRODUCTION (INT)SCANSELECT
During disc play, press the MONO/INT button
to sample or scan the introduction, or first 10
seconds,ofeachtrackonthedisc. INTappears
on the display, and each track is played in
order. By using this option, you can quickly
choosethetrack(s)onthediscthatyouprefer.
When the desired track is recognized, press
the MONO/INT button again to cancel the INT
mode, or activate the Repeat or Random
function so that INT disappears from the
display.
1010
1010
10
cn cn
cn cn
cn RANDOM(RND)SELECT
During disc play, press and hold the LOUD/
RND button for 2 seconds to play the tracks on
the disc in a random or shuffled order (RND will
appear on the display panel). In Random Play
mode, pressing the Forward Track Select
button ( ) will also select tracks in a ran-
dom order instead of the normal progression.
Pressingthe BackwardTrack Select button( )
willalso selecttracksinrandom order. The Ran-
dom Play mode can be cancelled by pressing
the button again for 2 seconds (RND indica-
tion will disappear from the display panel) or
by activating the Track Intro-Scan (INT) or Re-
peat (RPT) function.
coco
coco
co DISCEJECT ( )BUTTON
When pressed, disc play is stopped, EJ andCd
momentarily appear, and the disc is
automaticallyejected; willdisappear from the
display panel and the unit will revert to radio
operation. If the disc is not removed from the
unit, it will automatically be reloaded within 10
seconds to prevent accidental disc damage.
The icon will remain displayed to indicate a
disc is still loaded in the unit. If the disc eject
button is pressed during radio operation, the disc
is automatically ejected and radio play continues
uninterrupted.
NOTE: Always remove the disc from the
unit when the disc player is not to be
used for an extended period of time
to prevent accidental disc damage
and to preserve disc life.
cpcp
cpcp
cp TIME/FREQUENCYSELECTOR(T/F)
This unit can display either the clock time or
radio frequency/CD player functions. Ordinarily,
the radio frequency or CD player track indica-
tion is displayed, but the display can also show
the time when this button is pressed. The time
will then be displayed for approximately 5 sec-
onds after which it will return to the radio or CD
player function display.
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

1111
1111
11
The correct time-of-day can also be set into the
unit by pressing the Time/Frequency Selector
button. This procedure is outlined later in these
operating instructions.
cq cq
cq cq
cq THEFT-DETERRENTLED
Located on the chassis behind the front panel, a
light-emitting diode (LED) will flash when the
panel is physically removed. The flashing light
serves as a visual warning to the would-be thief
that the unit has been disabled by removal of the
front panel.
crcr
crcr
cr RESETBUTTON
A Reset button is located on the front panel of the
unit in the extreme lower right corner. The Reset
function is provided to protect the microproces-
sor circuitryandshouldonlybeactivatedunderthe
If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3, etc.)
may appear on the display panel. This can indicate a number of problems with the unit, includ-
ing a mechanical error or an error in the microprocessor control of the player. If an error code
should appear, try ejecting and reloading the disc into the player. While the disc is out of the unit,
make sure it is clean, undamaged, and loaded correctly (label surface up). You may also try
activating the RESET button cr cr
cr cr
cr on the unit, but this will also erase the time memory.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD PLCD PL
CD PLCD PL
CD PLAA
AA
AYER ERRYER ERR
YER ERRYER ERR
YER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
SETSET
SETSET
SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
1. Turn the vehicle ignition and radio on.
2. Press and hold the Time/Frequency button cpcp
cpcp
cp for approximately 2 seconds; the time
display will begin to flash.
3. Within 5 seconds of selecting the flashing display, press the VOL + button to adjust the
hours and the AM/PM indication to the desired setting.
4. Press the VOL - button to adjust the minutes to the desired time.
5. Five seconds after the last hour or minute adjustment is made, the time will be set in the
unit and normal operation will resume.
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TI0NSI0NS
I0NSI0NS
I0NS
ERROR CODE /ERROR CODE / ERROR CODE /ERROR CODE /
ERROR CODE /
following circumstances as it will erase the
time memory:
1.Upon initial installation after all wiring is
completed.
2.If there is a malfunction of any of the
switches on the unit, pressing the RE-
SET button may clear the system and
return to normal operation.
cs cs
cs cs
cs
PANELRELEASE(REL)BUTTON
This button ( ) is used to release the
mechanism that holds the front panel to the
chassis. To detach the front panel, press the
button so that the right side of the panel
releasesoutward.Grasp the panelat the right
side and disengage it from the left side of the
chassis. To re-attach the panel, engage the
left side onto the chassis; then gently press in
the right side until it clicks and locks into
place. place.

1212
1212
12
SPECIFICASPECIFICA
SPECIFICASPECIFICA
SPECIFICATT
TT
TIONSIONS
IONSIONS
IONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
Size: 7" W x 2" H x 6-3/4"D
178mm x 50 mm x 170mm
OperatingVoltage: 12voltsDC,negativeground
FuseRatings: Constant (yellow) lead: 15 AMP.
Switched (red) lead: 0.5 AMP.
OutputPower: 160 watts maximum ( 40 watts x 4 channels)
OutputWiring: Floating-groundtypedesignedfor4speakeruse.
OutputImpedance: Compatiblewith4-8ohmspeakers.
TuningRange: AM: 530 – 1,710 kHz.
FM: 87.5–107.9MHz.
Sensitivity: AM: 32dBu.
FM: 3.0 uV
FMStereoSeparation: >30 dB
CDFrequencyResponse: 20 – 20,000 Hz. ±1 dB
CDSignal/NoiseRatio: >60 dB
CDChannelSeparation: >60 dB
CDDistortion: 0.2%
*Specifications are subject to change without notice.

CACA
CACA
CARE ARE A
RE ARE A
RE AND MAND MA
ND MAND MA
ND MAINTENAINTENA
INTENAINTENA
INTENANCENCE
NCENCE
NCE
1313
1313
13
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We
recommend that you keep this manual for reference on the many features found in this unit as
well as how to set the clock.
The compact disc player section also requires no routine maintenance, but proper
understanding of its use and handling will help you obtain maximum enjoyment of its
capabilities. The following points should be observed:
!When cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit.
!The CD player is a precision instrument and will not operate properly in extreme heat or
cold. In case of such conditions, wait until the interior temperature of the vehicle reaches a
normal temperature before using the player.
!If the temperature inside the player gets too hot, a protective circuit will automatically stop
play of the disc. In this case, allow the unit to cool off before operating the player again.
!Never insert anything other than a 5" (12 cm) compact disc into the player as the
mechanism can be damaged by foreign objects.
!Do not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an
adaptor, as damage to the player and/or disc may occur. Such damage will not be covered
by the Warranty on this product.
!When not using the disc player, always remove the compact disc. Do not leave an ejected
disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.
!Do not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside.
!When the vehicle warms up during cold weather or under damp conditions, moisture may
condense on the lens of the disc player. Should this occur, the player will not operate
properly until the moisture has evaporated.
!The unit is designed with a vibration dampening CD mechanism to minimize interruption
of disc play due to normal vibration in a moving vehicle. When driving on very rough roads,
however, occasional sound skips may occur. This will not scratch or damage the disc and
normal play will resume when the rough conditions cease.
HANDLINGCOMPACTDISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound
quality. Please follow these guidelines to take care of your compact discs:
!Use only compact discs with the mark .
!Fingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.
!Never use chemicals such as record sprays, household cleaners or thinner to clean
compact discs. Such chemicals can irreparably damage the disc’s surface.
!Discs should be kept in their storage cases when not in use.
!Do not expose discs to direct sunlight, high temperatures or high humidity for extended periods.
!Do not stick paper, tape, or labels on the disc surfaces nor write on them withanytype ofmarker.

1414
1414
14
NOTES ON DISCS:
Attempting to use non-standard shape discs (e.g.; square, star, heart) may damage
the unit. Be sure to use round-shape CDs only in this unit.
NOTESONCD-Rs(RecordableCDs)/CD-RWs(RewriteableCDs):
1. Be sure to use discs with the following marks only for play in this unit:
2. The unit cannot play a CD-R or CD-RW that is not finalized. (Please refer to
themanualofyourCD-R/CD-RW softwareformoreinformationonthe
finalizationprocess.)
3. Depending on the recording status, conditions of the disc and the equipment
used for the recording, some CD-Rs/CD-RWs may not be played on this unit.
RELIABLEPLAYBACK:
Toensuremorereliableplayback,pleasenotethefollowingrecommendations:
1. Use CD-RWs with speed 1x to 4x.
2. Use CD-Rs with speed 1x to 8x, and write with speed 1x to 2x.
3. Do not play a CD-RW which has been written on more than 5 times.
NOTESONMULTI-SESSIONDISCS:
1. If the first track of the first session is audio CD data, then the unit will play
only the audio CD data.
2. When the first track of the first session is not audio CD data, but an MP3
file is included on the disc, then only the MP3 files will be played back and
other data (including CD data) is skipped.
NONO NONO
NOTES ON DISCSTES ON DISCS
TES ON DISCSTES ON DISCS
TES ON DISCS

FormNo.128-4270E
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser
of this product that should this product or any part thereof, under normal use and
conditions, be proven defective in material or workmanship within 12 months from the
date of original purchase, such defect(s) will be repaired or replaced with new or
reconditioned product (at the Company's option) without charge for parts and repair
labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be
deliveredwithproofofwarrantycoverage(e.g.dated billofsale),specificationofdefect(s),
