Philips CEM2100 User manual

Register your product and get support at
CEM2100 a
b
c
d
e
f
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
CEM2100_QSG_05_V1.0
EN Quick start guide
183mm
53mm
1
2
CEM2100_QSG_05_V1.0.indd 1 2012-3-9 15:35:14

Turn on
To turn on the unit,
 Press .
To turn off the unit,
 press and hold until the unit is turned off.
Select country/region
1Press to turn on the unit.
»[SELECT OPERATING REGION] is displayed.
2Rotate to select an option:
 [USA] (United States)
 [LATIN] (Latin America)
 [EUROPE] (Western Europe)
 [RUS] (Russia)
 [M-EAST] (Middle East)
 [ASIA]
 [JAP] (Japan)
 [AUST] (Australia)
3Press 
Set clock
1Press MENU
2Rotate to set hour.
3Press 
4Rotate to set minute.
5Press 
Listen to radio
1Press SOURCE repeatedly to select radio mode.
2Press BAND or / repeatedly to select band: [FM1], [FM2], [FM3], [AM1], or [AM2] .
3Press and hold or 
4Press or to tune to a radio station manually.
»The radio station is broadcast.
 To search for a radio station automatically, press or .
Store stations automatically
1In Radio mode, press and hold DBB until [STORE - - -] is displayed.
2Press 
»The six strongest stations of the selected band are saved in preset channel automatically.
Store stations manually
1Tune to a station that you want to store.
2Press a numeric button for 3 seconds.
»The station is saved in the selected channel.
Play from USB
1Slide the USB socket cover marked to the left.
2Insert the USB device into the USB socket.
»The unit starts playing from the USB
device automatically.
Insert a card
1Press to release the panel.
2Insert the card into the card slot.
3Close the front panel.
»The unit starts playing from the card
automatically.
Reset
You can reset the unit to its default setting.
1Detach the front panel.
2Press the reset button by using a ball-point pen
or a similar tool.
»Preset adjustments such as preset channels and
sound adjustments are erased.
RESET
What’s in the box
Main unit
(with a sleeve)
Remote
control
Front panel Trim plate Carrying case
ISO male connector Screw
x 1 pc
Rubber cushion Disassembly tools
x 2 pcs
User manual Quick start guide
9
7
1Connect the supplied male connector to the unit.
2Check the car’s wiring carefully and connect them
to the supplied male connector.
1 Green/black strip Left speaker (Rear)
2 White/black strip Left speaker (Front)
3 Gray/black strip Right speaker (Front)
4 Purple/black strip Right speaker (Rear)
e Red Ignition key +12V DC when
ON/ACC
f Blue Motor/electric antenna relay
control lead
g Blue/white 
hBlack Ground
i Yellow To the +12V car battery
which is energized at all
times
3 
applicable.
Connector Connect to
1 ANTENNA Antenna
2 FRONT LINE OUT R
(Socket)
Front right
speaker
3 FRONT LINE OUT L
(Socket)
Front left speaker
4 REAR LINE OUT R
(Socket)
Rear right speaker
5 REAR LINE OUT L
(Socket)
Rear left speaker
6 OE REMOTE
(Purple)
OE Remote
7TELMUTING(Blue)To cellular phone
system
8 REAR AUX LINE
OUT R (Socket)
Rear Aux right
9 REAR AUX LINE
OUT L (Socket)
Rear Aux left
Connect wires: ISO male connectors
ÁQuick start guide
