Audiovox VODEXL10 A User manual

VODEXL10 A
10.1" OVERHEAD LED BACKLIT
LCD MONITOR WITH
DVD PLAYER
OWNER'S
MANUAL
S
PUSH
®

2
TABLE OF CONTENTS
FCC Statement .......................................................................................3
Important Notice ................................................................................. 4
Warnings ................................................................................................. 4
Congratulations ................................................................................... 5
Safety Precaution ................................................................................ 5
Features .................................................................................................. 5
Controls and Indicators Diagram (Front View)........................... 6
Controls and Indicators Diagram (Side Views)........................... 7
Remote Control Operation ............................................................... 8
Remote Control Functions ................................................................ 8
Turning the Unit On or O .............................................................. 13
Source Menu........................................................................................ 14
System Menu Settings and Adjustments .................................. 16
Picture (Control)................................................................................. 16
WFMM (FM Modulator) .................................................................... 17
Settings .................................................................................................. 18
Default DVD.......................................................................................... 18
Screen Mode ........................................................................................ 18
Monitor Mode...................................................................................... 19
IR Transmitter....................................................................................... 20
Language .............................................................................................. 20
Factory Setting.................................................................................... 20
SETTINGS AND ADJUSTMENTS ..................................................... 21
Using the Setup Menu...................................................................... 21
SYSTEM Setup...................................................................................... 21
TV SYSTEM ............................................................................................ 21
SCREEN SAVER ..................................................................................... 22
TV TYPE .................................................................................................. 22
PASSWORD ........................................................................................... 23
DDFAULT-RESTORE ............................................................................ 23
LANGUAGE SETUP ............................................................................. 24
OSD LANGUAGE ................................................................................. 24
AUDIO LANG ........................................................................................ 24
SUBTITLE LANG ................................................................................... 24
PLAYING DEVICES............................................................................... 25
PLAYING USB MEMORY DEVICES ................................................. 25
Playing MP3 Discs ............................................................................. 26
Selecting of Audio/Photo/Video mode..................................... 26
DVD BASICS......................................................................................... 27
Overhead Dome Lights.................................................................... 28
Accessories ........................................................................................... 29
Wireless Headphones ....................................................................... 29
Wireless Game Package (MVGP1)................................................. 29
HDMI/MHL and USB Port Information........................................ 30
HDMI1..................................................................................................... 30
Smartphones and Tablets................................................................ 30
USB Port................................................................................................. 30
Troubleshooting ................................................................................. 31
Replacement Parts............................................................................. 33
Specications...................................................................................... 33
Warranty ................................................................................................ 34
Notes....................................................................................................... 35

3
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has
been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
-Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any change or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate this
equipment.
Radiation Exposure Statement
This equipment complies with FCC radiation limits set forth for an uncontrolled environment. This equipment should be installed and operated with
minimum distance 4.5in (20cm) between the radiator & your body.

4
Important Notice
Installation of overhead products requires careful planning and preparation. Be extremely careful when working on a vehicle with side curtain air bags.
Do not route wires near any portion of the side curtain air bag assemblies. This includes any anchor points in A, B, C or D pillars of the vehicle. Routing
wires in these areas or running wires by the side curtain air bags can prevent the side curtain air bag from fully deploying which can result in personal
injury to vehicle occupants. If you have any questions regarding wire routing in a vehicle, please contact Audiovox Technical Support at 1-800-225-6074.
When connecting power and ground in a mobile video installation ensure that the ACC wire is fused at the point where it is connected to the vehicle
ACC wiring. Failure to do so can result in damage to the vehicle if a short circuit develops between the vehicle connection point and the mobile video
product.
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle
information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play,
the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park” or when the vehicle's parking
brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the parking brake is not
applied must be installed to the rear of the driver's seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle.
Warnings
• Do not use any solvents or cleaning materials when cleaning the video monitor.
• Do not use any abrasive cleaners, they may scratch the screen.
• Use only a lightly dampened lint free cloth to wipe the screen if it is dirty.
• Lock the LCD screen in the fully closed position when not in use.
• Before putting on headphones always adjust the volume setting to the lowest position.
• Remember to leave the dome light switch in the o or auto positions when the vehicle is unattended, as the dome lights, if left on, can drain
the vehicle's battery.
• Do not put pressure on the screen.
• Caution children to avoid touching or scratching the screen, as it may become dirty or damaged.
Patented: Refer to www.voxxintl.com/company/patents

5
Congratulations
Congratulations on your purchase of the AUDIOVOX VODEXL10 A DVD
Player with drop-down video / monitor. The VODEXL10 A has been
designed to give you and your family many years of video entertainment
in the mobile environment. Please read the directions that follow to
familiarize yourself with the product to ensure that you obtain the best
results from your equipment.
Note: Installation options vary, see the individual owner's manuals for
each component in your system to obtain a full understanding of each
component's operation.
Safety Precaution
For safety reasons, when changing video media, it is recommended that
the vehicle is not in motion, and that you do not allow children to unfasten
seat belts to change video media or make any adjustments to the system.
System adjustments can be accomplished using the remote control, while
seat belts remain fastened. Enjoy your AUDIOVOX entertainment system
but remember the safety of all passengers remains the number one
priority.
FEATURES
• 10.1”TFT (Thin Film Transistor) Active Matrix LCD (Liquid Crystal
Display) Monitor
• LED Backlighting
• Built-in DVD Player
• Auto-On With Disc Insertion
• HDMI / MHL Inputs
• OSD (On Screen Display) for Control of Picture Quality and Functions
• Selectable (M1 and M2) IR Receive and Transmit Codes (See page 9)
• Switchable Dual Channel IR Infrared Transmitter (See page 19)
• Nine Source Input*
(DVD, USB, HDMI 1, HDMI 2, Media, AV, AUX, DTV, Game)
*Note: The DTV and Game modules are optional equipment and can
be purchased separately.
• Dome Lights with Built-in Three Way Switch
• Built-in 100 Channel Wireless FM Modulator
• Last Position Memory for DVD
• Screen Mode Selection (4:3, 16:9)
• Full Function Remote Control
• Backlit Controls
• AV Output via RCA Jacks
• Plays DVD, CD and MP3 Discs
• Game Port Ready
• Mobile DTV Ready

6
CONTROLS AND INDICATORS DIAGRAM FRONT VIEW
1. POWER ( ) Button
This button is used to turn the system on/o.
2. Play/Pause (u/II ) Button
This button is used to start playback of a disc or pause a disc.
3. UP / DOWN / LEFT / RIGHT (pqt u) Cursor Buttons
These cursor buttons are used to navigate menu selections on the
screen.
4. HOME/MENU Select Button
This button is used to display and select options on the system menu.
Press and hold for 3 seconds to access the System Menu.
5. Source/Select (S) Button
Press this button to display the Source OSD screen. Use the cursor
buttons to highlight the desired source. Press the Source/Select button
to access the desired source.
6. STOP (n) Button
-Press the STOP button once: Stops playback.
-Pressing the PLAY button again will resume normal playback from
where movie was stopped.
-Press the STOP button twice and then press the PLAY button to start
playback from the beginning of the DVD.
7. EJECT ( )Button
This button is used for ejecting a disc from the disc compartment.
8. Dome Lights
Provide additional interior illumination.
9. Infrared Transmitter/Remote Sensor
(Location)
10. Screen Release
Push this button to release the screen from the locked position.
11. Ventilation Openings
12. LCD Cut O Switch
Used to turn o the LCD backlight when the LCD is in the closed
position.
13. LCD Panel
S
PUSH
1
2 3 4 5 6 7
10
8
9
11
12
13
8

7
CONTROLS AND INDICATORS DIAGRAM SIDE VIEWS
1. DVD Disc Insertion Slot
For loading and removing discs. When a disc is inserted, the unit will automatically turn ON and switch to DVD source. Insert a disc with
label side facing up.
Note: The disc slot indicator is red when a disc is inserted and green when the disc slot is empty.
2. AUX IN
These jacks are used to supply external audio and video inputs to the unit. (Yellow - Video, White - Left Audio, Red - Right Audio).
3. USB INPUT
For connection of a USB memory device. This input will also charge a USB device that contains a battery. See page 30 for
more information.
Note: The USB input supplies up to 1 Amp of charging current. Devices such as tablets may require more than 1 Amp of charging current
and it is recommended to connect the device to a vehicle power outlet for full charging capabilities. When the unit is in DVD/USB mode,
1 Amp charging is not available.
4. HDMI/MHL 1 INPUT
For connection of devices with HDMI/MHL outputs. See page 30 for more information.
Note: Requires a HDMI/MHL enabled device and a special HDMI/MHL adapter. Contact your HDMI/MHL device supplier for the adapter.
5. THREE POSITION DOME LIGHT SWITCH
ON - Turns on the dome lights.
OFF - The dome lights will not turn on in this position.
AUTO - Automatically turns on the dome lights in conjunction with the vehicle's interior illumination.
1
2345

8
REMOTE CONTROL OPERATION
Initial Use
When purchased, the remote control has a battery installed with a Pull Tab
to prevent battery discharge. Remove the Pull Tab before attempting to
use the remote control.
Battery Replacement
1. Remove the battery holder.
2. Insert one CR2025 battery into the battery holder. Be sure to observe
the correct polarity.
3. Align the battery holder with the remote control and insert. Push it in
until the holder clicks.
CR2025
REMOTE CONTROL FUNCTIONS
1
3
2
4
5
6
7
8
9
10
12
14
11
13
15
16
17
18
19
20 21
22
23
24
25
26
27
28
29
30
31
32

9
* Function control is available on the unit and the Remote Control.
** Function not available in this model.
1. POWER*
Press this button to turn the unit ON and OFF.
2. SOURCE*
Press to display the Source OSD for DVD, USB, HDMI 1, HDMI 2, Media, AV, AUX, DTV and Game.
3. MONITOR SELECT
M1 Button – Set the remote control code to allow control of the unit in M1 mode.
M2 Button – Set the remote control code to allow control of the unit in M2 mode.
4. SCAN BACKWARD ( )
Press to search in a backward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 times and normal speed.
5. SCAN FORWARD ( )
Press to search in a forward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 times and normal speed.
6. TV Mode Select
Switches certain function keys on the remote control for monitor functions.
7. PREVIOUS ( )
Press to return to the previous chapter or track.
8. NEXT ( )
Press to skip to the next chapter or track.
9. PLAY (u)*
Press to activate the play mode while a disc is loaded into the disc compartment.

10
10. SYSTEM MENU
Allows the user to access the system menu. Press the tor ucursor buttons to select PICTURE, WFMM (FM Modulator) and SETTING.
11. CURSOR (pqt u)
Use the cursor buttons to access menu selections on the screen.
12. DISPLAY
Press once to display current disc information of Title, Chapter & Time. Press again to display Subtitle, Audio & Angle while the disc is playing. Press
and hold 3 to 4 seconds on the display key to enter the edit mode, press cursor(tu) buttons to edit the Title, Chapter, & Time.
13. OK
Used to execute a selected setting or menu option.
14. SETUP
Allows the user to access the Setup Menu when the unit is in DVD mode. Use the pq tor ucursor buttons to select options such as language,
video, rating, Misc.
15. REPEAT
Allows the user to repeat a selected title, chapter, or track.
16. A-B REPEAT
Allows user to repeat the playback from point A to point B.
Press A-B button On-Screen Display DVD player
Once Repeat A Mark the beginning of the section to repeat (Set point A)
Twice A-B Mark the end of the section to repeat (Set point B)
3 times AB O Cancel the A-B repeat function
17. SUBTITLE
Press to display and select the subtitle language in DVD mode. Each time this button is pressed, the subtitle language changes.
Note: The type and number of languages for subtitles vary from disc to disc.

11
18. NUMBERS
Allows the user to enter the numbers 0-9 for selection of the tracks, titles, chapters or password setting.
19. ZOOM
Press this button to enlarge the picture when playing a DVD disc. Press repeatedly to change the zoom from Zoom 2, Zoom 3, Zoom 4, Zoom 1/2,
Zoom 1/3, Zoom 1/4, and Zoom OFF.
20. AUDIO
Press to display and select audio language in DVD mode. Each time this button is pressed, the language changes.
Note: The available languages vary from disc to disc.
21. FM MODULATOR CHANNEL SELECT (C)
The unit has a 100 channel built-in wireless FM Modulator. The FM Modulator can be set from 88.1 MHz to 107.9 MHz in 0.2 MHz steps, i.e. 88.1, 88.3,
88.5, 88.9, 90.1 etc. Pressing the Cbutton will display the FM Modulator frequency setting OSD. Use the cursor buttons to select the frequency. Refer
to the SYSTEM MENU SETTINGS AND ADJUSTMENTS for more details.
22. FMM ON/OFF
Turns the FM Modulator power on/o.
23. IRT ON/OFF
Turns the Infrared Transmitter on/o for IR wireless headphones.

12
24. PIX ( Picture Select )**
No function on this model.
25. VOLUME DOWN (-) or UP (+)**
No function on this model.
26. MUTE
Press this button to mute the audio for the wireless FM Modulator, IR headphones and audio output.
Pressing the button again restores the audio to the previously set level.
27. DISC MENU
In DVD mode, press once to access the Root Menu and then press again to resume to previous screen. For MP3 or photo view mode, press once to
return to Audio/Photo/Video option menu.
Note: Press and hold 3 to 4 seconds to view in small icon in photo display. Long press hold only active in photo view mode.
28. STOP (n)*
Press to stop playback. (Playback will resume from the point it is stopped).
Press twice to stop playback fully. (Playback will resume from the beginning of the disc).
29. PAUSE (II)*
Press to pause playback.
30. DVD Source**
No function on this model.
31. DVD Mode Select Button
Switches certain function keys on the remote control for DVD function.
32. EJECT ( )*
Press this button to eject the disc.

13
TURNING THE UNIT ON OR OFF
1. Push in the Screen Release button to unlock the LCD screen. The screen will drop down slightly.
2. Pivot the screen downward until a comfortable viewing angle is reached. The hinge friction will hold the screen in position while the system is in use.
3. Press the power button on the unit or the remote control to turn the system on and o. When in use, the internal backlighting will illuminate the
controls.
4. After the unit has been turned on and is displaying a picture, adjust the viewing angle by pivoting the screen to optimize the picture quality.
5. Remember to turn the unit o and pivot the LCD screen to the locked position when not in use.
S
PUSH Screen Release
Power
ON/OFF
Button

14
SOURCE MENU
The VODEXL10 A System is capable of accessing nine source inputs. To select or change a source, press the source, S, button on the front panel or the
SRC button on the remote control. The source OSD will appear on the screen as shown in the gure below. Use the pqtor ucursor buttons on
the front panel or the pqtor ucursor buttons on the remote control to highlight a source. Press the Source, S, button on the front panel or the OK
button on the remote control to select the desired source.
Note: If a source is grayed out, that source is not available or not installed such as DTV or Game.
DVD
The DVD source input is used to play DVDs, Audio CDs and MP3 discs.
USB
The USB source input is used to play MP3 les, JPEG les (Photos) and MPEG I, II les. See page 30 for more information.
HDMI 1 & HDMI 2
The HDMI inputs allow the user to enjoy high-denition digital images and high-quality sound by connecting a HD device such as a Blu-ray player or
smartphone with an HDMI output to the system. The HDMI inputs also allow the user to connect with a Mobile High-Denition Link (MHL) mobile phone.
Plug in the HDMI/MHL device with a special adapter available from your mobile phone provider. See page 30 for more information.
Notes:
• This source requires an HDMI/MHL enabled device and a special HDMI/MHL adapter. Contact your HDMI/MHL device supplier for the adapter.
• Phone functionality (phone calls, texting, etc.) may be limited while using the adapter.
• HDMI content is copy protected and is not available on the AV output of the VODEXL10 A System.
APPLICABLE HDMI FEATURE
- Input audio signal: 2 channel.
- Input video signal: 480p, 576p, 720p, 1080i, and 1080p.
Note: MHL is only available on HDMI1.

15
MEDIA
The Media source allows for the user to connect an Apple device (e.g. iPod, iPhone, iPad) to the VODEXL10 A System to play audio and video content. A
special Apple adapter is required for this connection. See your Apple or electronics dealer for the specic adapter required. Connect the adapter to the
Apple device, and connect the Audio, Video, and USB connectors into the VODEXL10 A System. With the Media source selected, the desired video and
audio content can be displayed on the VODEXL10 A System.
Notes:
• The USB input supplies up to 1 Amp of charging current. Devices such as tablets may require more than 1 Amp of charging current and it is
recommended to connect the device to a vehicle power outlet for full charging capabilities.
• The Apple device will not display the desired audio and video content on the Apple device screen. The desired audio and video content will only be
displayed on the VODEXL10 A System.
AV
An external video source, video game system, or other audio/video devices can be connected to the AV input. This AV input connection is normally
performed when the unit is installed. Turn the video source component on with its power button or remote control and it is now ready to play the audio
and video signals from the source connected to the AV input.
Note: If a DTV module is installed, this input will not be available and the AV source will be grayed out.
AUX
An external video source, video game system or other audio/video devices may be connected to the system via the AUX input. Plug the RCA plugs from
the external source into the RCA jacks on the side of the unit. Turn the external source component on with its power button or remote control and it is
now ready to play the audio and video signal from the source connected to AUX.
DTV
The optional DTV (Digital TV) input is used for a digital TV module. If the digital TV module is not installed, the DTV Source will be grayed out on the
source selection screen and cannot be selected. Check with your installer for availability.
GAME
The optional MVGP1 Wireless Game Package consists of 2 game controllers and a game module containing 54 games, 6 of which are two player games.
If the MVGP1 Wireless Game Package is not installed, the Game Source will be grayed out on the source selection screen and cannot be selected. Check
with your installer for availability.

16
SYSTEM MENU SETTINGS AND ADJUSTMENTS
The System Menu contains features and options that let the user customize the system. For example, the user can change the Picture, FM Modulator, OSD
language, source default, screen mode display, and the monitor mode.
Using the System Menu
1. Press the SYSTEM MENU button on the remote control. The system menu main page will appear on the screen.
2. Use the pqtor ucursor buttons to select an item in the sub menu, then press OK to select.
3. Press the System Menu button to exit the System Menu.
Note: The System Menu can be controlled via Remote Control or the Home button on the front panel of the unit (Items selected in the menu will have a
yellow background).
PICTURE (CONTROL)
When watching a program, the picture quality can be adjusted to the user’s preferences.
1. Press the System Menu button on the remote control (or press and hold the Home/System menu button on the front panel for 3 seconds) and the
Picture Control Menu will be displayed. The menu contains the on screen picture “adjustment bar” for BRIGHTNESS, CONTRAST, COLOR, TINT (for
NTSC only) or RESET.
PICTURE WFMM SETTING
EXIT
BRIGHTNESS
CONTRAST
COLOR
TINT
RESET
16
16
16
0
2. Use the pqtor ucursor buttons on the remote control or the front panel to adjust the selected adjustment bar for picture quality.
Note: The System Menu will time out after 5 seconds if no buttons are pressed.

17
WFMM (FM MODULATOR)
The FM Modulator allows the user to listen to audio through the vehicle’s radio.
ON - Turns the wireless FM Modulator on if audio playback through your vehicle’s radio is preferred.
OFF - Turns the wireless FM Modulator o.
FREQUENCY - Allows the user to select the wireless FM Modulator frequency. The unit has a 100 channel built-in wireless FM Modulator. The FM
Modulator can be set from 88.1 MHz to 107.9 MHz in 0.2 MHz steps, i.e. 88.1, 88.3, 88.5, 88.9, 90.1 etc.
PICTURE WFMM SETTING
ON
FREQUENCY
OFF
EXIT
88.10
88.90
89.70
90.50
91.30
88.30
89.10
89.90
90.70
91.50
88.5088.70
89.3089.50
90.1090.30
90.9091.10
91.7091.90
To choose an FM frequency for audio playback through your vehicle’s radio:
1. Press the SYSTEM MENU button to access the System Menu. The System Menu screens appears.
2. Use the ucursor button to highlight wireless FM modulator (WFMM).
3. Use the qcursor button to highlight the FREQUENCY Submenu.
4. Use the pqtor ucursor buttons to select a frequency not used by a radio station in the area. Press OK to select the highlighted frequency.
There are a total of 5 FM CHANNEL pages containing frequencies from 88.1 MHz to 107.9 MHz in 0.2 MHz steps. To access the additional FM Channel
pages, use the tor ucursor buttons to highlight the on screen left and right arrows and press OK. Once the frequency has been selected, tune the
vehicle’s radio to the selected frequency.
5. Press the DVD button to restore the remote control to DVD functions.
Note: The wireless FM modulator will perform well in most applications. However, in certain geographical areas the quality of the wireless signal may be
less than optimal, resulting in static or strong local station bleed through. If this is a consistent problem, an FMDIRB (hard wired FM connection) can be
installed by your dealer.

18
SETTINGS
DEFAULT DVD
This allows the user to set the system default source to DVD on or o. If source default
is set to ON, every time the unit is turned o then on, the unit will power up
and automatically switch the source to DVD. If source default is set to OFF and
the unit is turned o then on, the unit will power up in the source that was
last selected.
1. Press the System Menu button.
2. Use the ucursor button to highlight SETTING.
3. Use the qcursor buttons to highlight DEFAULT DVD.
4. Use the tor ucursor buttons to select to select ON or OFF.
5. Press OK to conrm the setting.
Note: The unit is set to source default DVD on as the default mode of operation.
Selection of Source default can only be made from within the system menu.
SCREEN MODE
This allows the user to change the screen format (aspect ratio 16:9, 4:3).
To select the screen aspect ratio format:
1. Press the System Menu button.
2. Use the ucursor button to highlight SETTING.
3. Use the qcursor button to highlight SCREEN MODE.
4. Use the tor ucursor buttons to select 16:9, 4:3.
5. Press OK to conrm the setting.
Note: If the screen mode is set to 4:3, the unit it will default to 16:9 when power is
cycled. HDMI 1, 2 and MHL can not be switched to 4:3 screen mode.
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:9 4:3
M1 M2
ON OFF
EXIT
ENGLISH
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:9 4:3
M1 M2
ON OFF
EXIT
ENGLISH

19
MONITOR MODE
MONITOR MODE SETTINGS
The VODEXL10 A System has an option that allows the user to select from two IR transmit and receive codes (M1 or M2). This feature can be used when using two
VODEXL10 A systems in the same installation or if the vehicle has RSA (Rear Seat Audio) that uses an “A” channel headset. The VODEXL10 Asystem comes factory
set to M1. When in the M1 mode, the unit will respond to remote commands when M1 is selected on the remote control and will transmit audio on the A channel.
When in the M2 mode, the unit will respond to remote commands when M2 is selected on the remote control and will transmit audio on the B channel.
Note: Use 2-channel IR headphones set to CH B when the monitor is set to M2 mode.
Selecting a Monitor Mode (M1 or M2)
1. Power ON the unit and wait until M1 or M2 appears on the OSD. M1 or M2 will appear on the screen for 4 ~ 5 seconds.
2. Press the System Menu button on the remote control to display the System Menu to change the monitor code from M1 to M2.
3. Use the tor ucursor buttons to select the Setting sub menu.
4. Use the por qcursor buttons to select the Monitor Mode sub menu.
5. Use the tor ucursor buttons to select the desired Monitor Mode (M1 or M2).
6. Press OK to conrm the setting. The following screen will appear.
7. Use the por qcursor buttons to select Monitor Mode (M1 or M2).
8. Press OK to conrm the setting.
9. Press the System Menu button on the remote control to exit the System Menu Mode.
Note: If no action is taken, this menu will disappear in 10 seconds.
WARNING
SETTING THE MONITOR TO THE M2 MODE WILL
REQUIRE USING 2-CHANNEL HEADPHONES.
USE THE DOWN KEY ON THE REMOTE CONTROL
TO SELECT M2 AND PRESS OK TO SET THE
MONITOR TO M2 MODE
TO REMAIN IN THE M1 MODE PRESS OK
M1
M2
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:
94
:3
M1 M2
ON OFF
EXIT
ENGLISH

20
IR TRANSMITTER
This allows the user to turn the IR Transmitter ON or OFF. The IR Transmitter
must be set to ON for the wireless headphones to be operational.
1. Press the System Menu button.
2. Use the ucursor button to highlight SETTING.
3. Use the qcursor button to highlight IR TRANSMITTER.
4. Use the tor ucursor buttons to select ON or OFF.
5. Press OK to conrm the setting.
LANGUAGE
This allows the user to return the on-screen display language. The user can
select English, Spanish, French, or German for the on-screen display language.
To select the screen aspect ratio format:
1. Press the System Menu button.
2. Use the ucursor button to highlight SETTING.
3. Use the qcursor button to highlight LANGUAGE.
4. Use the tor ucursor buttons to select the desired language.
5. Press OK to conrm the setting.
FACTORY SETTING
This allows the user to return the system to the factory default settings.
1. Press the System Menu button.
2. Use the ucursor button to highlight SETTING.
3. Use the qcursor button to highlight FACTORY SETTING.
4. Press OK to conrm the setting.
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:9 4:3
M1 M2
ON OFF
EXIT
ENGLISH
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:9 4:3
M1 M2
ON OFF
EXIT
ENGLISH
PICTURE WFMM SETTING
DEFAULT DVD
SCREEN MODE
MONITOR MODE
IR TRANSMITTER
LANGUAGE
FACTORY SETTING
ON OFF
16:9 4:3
M1 M2
ON OFF
EXIT
ENGLISH
