AUNE S18 User manual

R
S18 32BIT DSD Hi-Fi数字转盘
An intergral Hi-Fi Digital Transport

Preface
Thanks a lot for choosing S18 digital transport product made by aune
company and we feel very proud of that. We hope S18 could bring Hi-Fi music
experience and fun to you. You are suggested to read this manual first before you
could use all functions of S18 properly.
22
Dear customers:
This manual book is made by chlorine-free bleaching paper. Such production method reduces
poisonous substance to be drained to water channel and protect our environment thereof.

23
View of front panel and name of each part
2.8 inch display
Power indicator
Remote control receiving window
Power button
Main menu button
Up button: In playing mode, it chooses last song or fast backward;
in file browsing mode, it chooses previous one
1.7
1.8
1.9
1Press power supply button for two seconds to turn on power and use the same way to shut off power.
NOTE
1.1 1.4 1.6 1.7 1.8 1.91.2 1.51.31.1 1.4 1.6 1.7 1.8 1.91.2
1.1
1.2
1.3
1.4
1.5
1.6
1
1.51.3
2
2In playing mode, it enters master menu; on menu page , it returns to previous menu.
Down button: in playing mode, it chooses next song or fast
forward; in file browsing mode, it chooses next one
OK/Play/Pause: In playing mode, it chooses play or pause;
in file browsing mode, it chooses OK.
SD card socket

View of rear panel and name of each part
2.1
2.2
2.3
IIS output
AES digital output
Coaxial output
2.4
2.5
2.6
Optical output
Backup WAN connection (not used temporarily)
AC input
24
2.62.52.42.32.22.1

Introduction of button operation
3.1
3.2
3.3
3.4
3.5
3.6
MUTE
Power off
HOME
Cycle mode
Return
Number
Up
Left
Right
Play/Pause
Next
Stop
Background light
Extended function
button
Name of button
No. Mode of file browsing
MUTE
Power off
Return to main menu
Return to previous menu
Choose previous one
Page up
Page down
OK
Choose next one
Stop playing
Turn on/off background light
Power off
Enter into main menu
Switching playing mode
Enter into catalogue/folder of songs
Choose song directly after inputting
number of song
Previous song/Fast backward
Next song/Fast forward
Play/Pause
Stop playing
Turn on/off background light
View of remote controller
and name of each part
3.7
3.8
3.9
4.1
4.2
4.3
4.4
4.5
Mode of playing
Add to favorites when browsing songs; delete songs in
favorites
3.1 3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
4.1
4.2
4.3
4.4
4.5
25

Introduction Specifications
16Bit/44.1K 1KHZ/0DB Digital Jitter：1.2NS(P-P) THD+N：-98.285DB
24Bit/44.1K 1KHZ/0DB Digital Jitter：3.8NS(P-P) THD+N：-137.5DB
24Bit/192K 1KHZ/0DB Digital Jitter：3.4NS(P-P) THD+N：-138.9DB
Play function：Memory play, setting of main menu, songs selection of playing state
Output：Optical/Coaxial RCA/Coaxial BNC/AES digital output/IIS output
Medium：SD card (supports maximum 128G)
Font：Chinese/English/Traditional Chinese
Size of product：248 X 211 X 60 (mm)
Weight：3.5 (kg)
Components：Main unitx1/Power cablex1/Manual x1
S18 is a pure digital transport with high
performance, high fidelity and multi-
format. It supports as high as 32Bit
musical format and DOP output of DSD,
the core of it uses non-synchronous
clock technology. It is a hifi digital
transport with low distortion.
26

Operation introduction
of display interface
5.1
5.2
5.35.7
5.8
5.5
5.6
5.4
37/324
44.1K 16BIT WAV
02 36
04:08
If I Necer See
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
27
List of songs
Length of time being played already
No. / Total number of songs
Current sampling rate
Cycle mode: Random play 、folder play 、single song play 、all cycle
Playing state of songs: Play 、pause 、stop
Length of songs
Format of songs

Display interface
Introduction of operation
Recently played songs
My favorites
System settings
Browsing songs
Recently played songs List of recently played songs
My favorites Add favorite song to folder
Favorite song 2
If I Neccer See You
NATURE BOY
FirstWe Take Manhattan
LOST IN THE STARS
Brid On A Wire
Joan Of Arc
Open folder to display each
favorite single song
Will enter into display interface by
default after turn on transport, and
can switch to main menu after press
menu button.
Recently played songs
If I Neccer See You
NATURE BOY
FirstWe Take Manhattan
LOST IN THE STARS
Brid On A Wire
Joan Of Arc
My favorites
Favorite song 1
Favorite song 3
Favorite song 4
Favorite song 2
Recently played songs
My favorites
System settings
Browsing songs
28

Display interface
Introduction of operation
All files
cypress661111Fan/
GEFFEN24725HELLFREEZES
FirstWe Take Manhattan
ODINCd03FAIRYTALESRAD
Brid On A Wire
Joan Of Arc
All songs
LONG DADDY GREEN
NATURE BOY
FirstWe Take Manhattan
LOST IN THE STARS
Brid On A Wire
Joan Of Arc
Browsing songs
List of all files displaying folder and
each single song
List of all single songs
Songs are presented in form of single song or folder
Format of song:
WAV : 16Bit | 24Bit | 32Bit - 44.1K / 48K / 88.2K / 96K / 176.4K / 192K WAV + CUE
FLAC : 16Bit | 24Bit - 44.1K / 48K / 88.2K / 96K / 176.4K / 192K FLAC + CUE 0-8
Compressed Grade
APE: 16Bit/44.1K APE + CUE (Fast/Normal)
DSD Format: DSF / DSD64 - DFF /DSD64 - SACD ISO / DSD64 DoP Digital Output
ALAC: 16Bit/44.1K
AAC
Browsing songs
All files
All songs
Can select all songs or files to browse
Recently played songs
My favorites
System settings
Browsing songs
29

System settings
Start playing after turning on
Display settings
Language settings
Playing mode
ON
a
b
ON
OFF
系统设置
ON
All cycle
a ON：Playing state
b OFF：Pausing state
a
b
c
d
Random play
Folder
Cycle of single song
Cycle of all songs
Starting play after turning on
Playing mode
All cycle
At playing interface, when use remote
controller to operate, cycle mode key 3.4
is valid for work. Icon will also change
accordingly as switching current playing
mode directly.
Playing interface
37/324
44.1K 16BIT WAV
02 36
04:08
If I Necer See
Display interface
Introduction of operation
Start playing after turning on
Display settings
Language settings
Playing mode
30

Display interface
Introduction of operation
System settings
Starting play after turning on
Display settings
Language settings
Playing settings
Display settings
Brightness adjustment
Time of background light
4
Consta
4
1-5 shifts to adjust brightness
Constant light, 5 seconds,
10 seconds, 15 seconds,
20 seconds, 30 seconds,
6 shifts for option for time
of background light.
Constant light
System settings Language settings
简体中文
繁体中文
English
Starting play after turning on
Display settings
Language settings
Playing settings
31

System settings
Turn the power off automatically
Internet
System settings
System settings
System upgrading
System information
Resetting to factory settings
System settings
Time of turning the power off
automatically
00.0
MASK:255.255.255.0
GATEWAY:192.168.1.1
IP:192.168.1.128
ON
Internet
DHCP
After connecting with
internet
开
After setting time of shutting-down,
system will shut down automatically
System settings
After connecting with internet
After setting time of shutting-down,
system will shut down automatically
Function of internet is not opened
temporarily
Display interface
Introduction of operation
32

System settings
System settings
System upgrading
System information
Resetting to factory settings
System settings
System settings
System upgrading
System information
Resetting to factory settings
Confirming upgrading
After confirming upgrading,
system will restart and
automatically search for
upgrading pack to upgrade.
System settings
System settings
System upgrading
System information
Resetting to factory settings
System settings
System settings
System upgrading
System information
Resetting to factory settings
Confirming initialization
After confirming initialization,
system will restart and reset
to factory settings.
Resetting to factory settings Confirming initialization
System upgrading Confirming upgrading
Display interface
Introduction of operation
33

System settings
System settings
System upgrading
System information
Resetting factory settings
System settings
Hardware version：1.00
Total space：3.6GB
Used space：0.3GB
Copyright reserved by：aune
After confirming upgrading,
system will restart and
automatically search for
upgrading pack to upgrade.
Display interface
Introduction of operation
34

Operation introduction
35
Application of digital
transport
DIGITAL
COAXIAL
Connect the digital output(AES/OPT/COAX)
of S18 with the digital input (AES/OPT/COAX)
of DAC directly when playing, then DAC could
bring out beautiful music.

36
Notes
1 . When turn off transport, pls press the power button on front panel first, then press the
main power switch on back panel. If turn off the main power switch directly, transport would
lost the previous settings.
2 . During updating, power is forbidden to shut down.
3 . Internet connection is backup connection and not opened to users temporarily.
a . As per usage connecting transport together with PC, pls refer to guidance of service and
support on aune website.

37
Using Q/A
1. As per mode of playing
It has 4 types according to position of playing
1) Playing all songs
From browsing songs->all songs, it will switch to this mode after selecting songs for playing.
Characteristics of mode: Play all songs in SD card.
2) Playing songs in file folder
From browsing songs->all songs, it will switch to this mode after selecting for playing.
Characteristics of mode: Play songs in selected file folder.
3) Playing songs in favorites
From my favorites->my favorite song, it will switch to this mode after selecting songs for playing
4) Playing songs that have been played recently
In recently playing mode, it will switch to this mode after selecting songs for playing.
Note: In this mode, only songs have been played recently in list could be played.
2. As per favorites
Favorites, namely playing list, has 4 lists at present. When songs are put into favorites, they could be
saved and added to according list. Songs added to favorites could be played in mode 1 and mode 2.
The whole folder could be added to playing list in mode 2.
Note:
Same songs could be added to favorites repeatedly, at present, they will not be screened out.
Delete songs in favorites:
From my favorites->my favorite songs, enter into according playing list, press multi-function button to
delete. There will be no tips as do such operation.
Number of songs could be added to favorites:
At present 800 songs could be added to each playing list.

3. As per save settings
Turntable supports to save settings without power on . Considering lifetime of flash inside, save would
only work as using remote controller and button on front panel at present, and save would not valid when
shut down power directly.
In addition, when turn off turntable using remote controller or button on front panel. Pls not shut down
main power until background light is off. This is mentioned in manual and remind user again here.
4. As per CUE
S18 supports flac/ape/wav associated with CUE file, but a few issues below must be paid attention to:
1) One folder could only be put into one CUE file. After entering into folder, each song could be seen
directly.
2) At present, CUE only supports ASCII format and will open UTF-8 format to user later. If normal
display can not be obtained, pls use notebook of windows to open CUE file and save as ASCII format.
3) Flac file either has no SEEK register or a far distance between start-and-end point.
Compared with APE, WAV, start-and-end time point of CUE file will be farther. If requires a high
performance, pls convert into WAV or APE because APE and WAV do not have such problem. Later
algorithm would be optimized as much as possible.
5. As per SACDISO file
1) S18 supports ISO file with DSD64 format. If S18 can not play it, pls use footbar to open it and check its
property is DSD64 or not.
2) SACD ISO and CUE display alike, they display name of each song directly. One folder is only allowed
to put into one ISO file and file type will be shown on interface of playing.
6. As per layer of folder and length of file name
1) The maximum layer of file folder S18 could support is no more than 7. Otherwise they will be filtered
out. So pls not exceed this figure to play songs.
2) The maximum length of file name is no more than 100 characters. If it is Chinese character, it should
be less than 50. Otherwise, they can not be recognized.
Using Q/A
38

7. As per SD card
At present S18 only supports FAT32 format. Format of 64G and 128G card are exFAT by default and
windows does not support to initialize 64G card or above with FAT32 format, it needs the third software,
for example, DiskGenius to do this.
8. As per CUE
Because S18 uses single chip and has limited speed, so at present, S18 could support fast and normal
compressed grade only. It will support high compressed grade later after optimizing.
9. As per upgrading
1) Normal upgrading
Menu: System setting->upgrade (At present on the 2nd page from the bottom, it can page up) wait unit
to restart after confirming and enter into upgrading picture. On upgrading picture press UP to confirm
upgrading and press DOWN to cancel upgrade. It will start automatically after finishing upgrading.
2) Upgrading with combination key
In case power is off during normal upgrading or unit can not start after upgrading, pls enter into
upgrading interface as following method:
Turn off unit first, then press power and menu button on the front panel at same time. After power and
background light are on, release the button. The other steps of upgrading are same as normal
upgrading. After upgrading is finished, unit enter into standby picture.
3) Deleting settings by force (including favorites/recently played contents)
Turn off unit first, then press BACK+DOWN to power on. Release the button after 2 seconds and start
unit again. At this time all settings have been cleared off. At first time doing such operation and turn off
unit, it needs 20-30 seconds to initialize favorite folder. Pls shut down power only after turn off unit
and wait until background light is out. Such operation is like clearing CMOS, when some failures
come nowhere.
Using Q/A
39

40
