6. Blue wire (A5) - Connect to the amplifier's remote turn-on input or the antenna motor control
input.
1. Make sure that the on-board voltage of your vehicle is +12 volts
4. Connect the red wire (A7) to the ACC terminal of the ignition switch.
Note: every time the yellow wire is disconnected from the 12 volt power circuit or the battery
terminal is removed, the device will revert to the factory settings.
7. Connect the rest of the wires according to the diagram.
3. Connect the yellow (A4) wire to the +12 Volt DC power circuit.
5. Connect the black wire (A8) to the metal part of the car body.
2. Remove the fuse from the device before connecting the wires.
Front speakers
B4 Right channel - (gray-black)
B6 Left channel - (white-black)
B3 Right channel + (gray)
Rear speakers
B2 Right channel - (purple-black)
B8 Left channel - (green-black)
B1 Right channel + (purple)
B5 Left channel + (white)
B7 Left channel + (green)
WARNING
DO NOT OPEN
5
A4 Battery + 12V DC
A5 + 12V control wire to control the motorized antenna and
remotely turn on / off amplifiers or other active auxiliary devices.
A8 Minus (ground) - connect to a metal part
+12 VDC - connect to the remote turn-on input of the amplifier or
the antenna motor control input (no more than 100 mA, 12 V).
A7 ACC + 12V DC wire - Connect to a power source that can be
turned on and off from the car ignition switch.
car body or connect to the negative terminal of the battery.
RED
ACC +12V
YELLOW
constant
power
+12V
BLACK
ground
MINUS
BLUE
control
wire
+12V
Radio antenna connection input
5 A
fuse
RCA front – Left (white)
RCA front – Right (red)
Connection
