5. Connect the black wire (A8) to the metal part of the car body.
Note: every time the yellow wire is disconnected from the power circuit or the battery terminal
is removed, the device will return to the factory settings.
3. Connect the yellow (A4) wire to the +12 or 24 volt DC power supply.
4. Connect the red wire (A7) to the ACC terminal of the ignition switch.
7. Connect the rest of the wires according to the diagram.
2. Remove the fuse from the device before connecting the wires.
1. Make sure your vehicle's on-board voltage is +12 or 24 volts.
6. Blue wire (A5) - Connect to the amplifier's remote turn-on input or the antenna motor control
input.
Front speakers
B7 Left channel + (green)
B6 Left channel - (white-black)
B8 Left channel - (green-black)
Rear speakers
B2 Right channel - (purple-black)
B4 Right channel - (gray-black)
B5 Left channel + (white)
B3 Right channel + (gray)
B1 Right channel + (purple)
WARNING
DO NOT OPEN
5
Radio antenna connection input
RCA front – Left (white)
RCA front – Right (red)
+12 VDC - connect to the remote turn-on input of the amplifier or
the antenna motor control input (no more than 100 mA, 12 V).
A8 Minus (ground) - connect to a metal part of the car body or
connect to the negative terminal of the battery.
A7 ACC + 12/24 Volt DC wire - connect to a power source that
can be turned on and off from the car ignition switch.
A4 Battery + 12/24 Volt DC
A5 + 12V control wire to control the motorized antenna and
remotely turn on / off amplifiers or other active auxiliary devices.
RED
ACC +12V/24V
YELLOW
constants
power
+12V/24V
BLACK
ground
MINUS
BLUE
control
wire
+12V
10 A
fuse
Connection
