aurafitness BS20 User manual
Model: BS20
Please read this manual before using the scale and keep it for future reference.
Download the Fitdays App from the Apple Store or Google Play.
Remove the plastic sheet from the battery cover.
Place the scale on a hard flat surface.
Measure with bare feet and make full contact with the sensors.
Turn on the smart app and connect to the scale before measuring.
Follow the instructions below and make sure
your posture is correct before measuring.
All fingers must line up
with the electrode pad.
Thumbs should not be
to close to each other.
Ensure that all fingers
touch the electrode pad.
Arms not straight. Arms close to waist.Keep your arms straight
at 45 degrees or at a
90 degree angle.
Aura Full Body Analysis Scale uses bio-electrical impedance analysis (BIA)
technology to help you conveniently measure body weight, body balance,
body fat rate, visceral fat, body water, skeletal muscle rate, muscle mass, bone
mass, protein, BMR, body age and more.
Product size: 300x300x26mm
LED screen display: 68x109mm
Weight unit: Kg/lb/st
Weight limit: 5kg-180kg
Weight division: 0.1kg/0.2Ib
Power Supply: 4 x 1.5V AAA batteries
Operating temperature: 10-40
Operation humidity: 40%-80% RH
WARNING
THANK YOU FOR YOUR PURCHASE!
PRODUCT SPECIFICATIONS
DO NOT use with medical implants such as pacemakers.
DO NOT stand on the edge of the scale or jump on it.
DO NOT overload the scale (Max.180kg/440lb/28st).
DO NOT drop the scale or drop objects on it as this may damage the sensors.
DO NOT immerse the scale in water or use chemical cleaning agents. Clean
the scale with a slightly damp cloth.
Not recommended for pregnant women, infants, toddlers or children under 10
years of age.
Any measurement obtained using this device is for reference only and should
not be considered as a medical opinion.
DO NOT use to diagnose or treat any medical condition. You should consult
your primary care physician before making changes to your diet, exercise plan
or physical activities.
Always place the scale on a hard, dry and flat surface before measurement.
Make sure your feet are dry before stepping on the scale.
Connect the batteries in accordance with the correct polarities indicated.
Remove batteries if the scale will not be used for a lengthy period of time.
DO NOT use the device if damaged. The continuous use of a damaged unit
may cause injury or improper results.
Please check the device before each use.
Ensure that the batteries installed are functional.
Be careful when using on the wet and slippery surface.
The batteries in the scales are exhausted.
Insert new batteries (see the "Replacing the Batteries” chapter).
The scale is overloaded.
More than 180kg are on the scales.
An error has occurred during the reading. Step o the scale,
wait 5 seconds and then step on again to restart the process.
Sensor feetSensor feet
Sensor feet
Electrode sensors
Electrode sensors Electrode sensors
Connecting wire
Measuring hand bar
Sensor feet
PRODUCT OVERVIEW
INDICATION SYMBOLS
INSTALL THE FITDAYS APP
INSTRUCTIONS FOR USE
Scan the QR Code or download the Fitdays
app from the Apple Store or Google Play.
Download and install the Fitdays app
on your device.
The App icon will appear on your phone or
tablet after the installation is completed.
Open the Fitdays app on your device.
Register your account by email or login with social media account.
Add your personal data and confirm.
1 2 3
bluetooth
location
Make sure Bluetooth is on. Make sure Bluetooth Authorization, GPS and
Localisation are allowed on your device.
In the back of scale, pull out the insulation sheet, then place the scale
on a hard flat surface. Step onto the scale with a single foot
to activate it. Wait until the display shows “0.0lb”.
Pair the scale through Bluetooth. Make sure the scale is on when pairing.
Leave the app on its main screen, it will connect automatically.
4
5
6
The app will show
your data within
a few seconds.
8
You could also
click “Device”
and find the scale
via bluetooth ID:
Aura Curve.
7
TROUBLESHOOTING BLUETOOTH ISSUES
BLUETOOTH FAILS TO CONNECT
Reset the scale by taking out one battery for 5 seconds
and putting it back in.
If the regular connection to Bluetooth failed, please try the below steps:
Reset the Bluetooth connection. Ensure Bluetooth and
GPS (Android only) are enabled on your device.
Under the "Account" section, select the “Device”. Slide it left to delete
the current device. Tap "+" on the top right to enter pairing mode.
Step onthe scale with single foot to activate it. After a few seconds of
loading, the scale name will appear, tap and confirm it. Step on the
scale again to complete the pairing.
Make sure the scale, Bluetooth and GPS (Android only) on your phone are on.
Check the system version of your smart phone, it must be iOS 8.0 or
higher/Android 6.0 higher.
When bluetooth is succesfully connected the bluetooth icon will display on
the scale and the word “Connected” will display on the app.
If fail to connect via Bluetooth, please click Account > Device to find the scale
ID: Aura Curve.
BODY FAT DATA NOT DISPLAYING
Step onto the scale with bare feet.
Make sure your feet and the scale are both dry.
A full scale reading take about 20 -30 seconds. Please remain on the scale
until the scale reads out all the data.
Bluetooth might not be turned on.
Bluetooth might be paired with a dierence scale.
INCORRECT WEIGHT DATA
Check whether the scale is on a hard, flat surface.
Check each sensor foot on the back of the scale to make sure that nothing is
stuck to the bottom of it.
INCORRECT MUSCLE - FAT RATIO
The body parameter settings are incorrect, check to make sure you entered
the correct gender, height, and age.
Check if Athlete Mode is activated.
HOW TO RESET THE SCALE
Step on the scale to turn it on. Let it automatically drop to 0.0kg to calibrate.
THE SCALE DOESN’T TURN ON
Check if the insulation sheet has been pulled out.
Check if the batteries have run out and change them if necessary.
FREQUENTLY ASKED QUESTIONS
How to get the most accurate result?
Stand completely still on the scale.
Weigh in at the same time each day to ensure the most accurate results.
Ensure that the scale is placed on a hard flat surface.
Check your profile information (gender, age, height) and make sure all the
data is accurate.
Ensure the scale legs are balanced
Scale should display "0.0lb" prior to reading.
Weigh in barefoot and make sure each foot is perfectly aligned with the scale
electrode sensors.
How do I restart my scale?
Remove the batteries.
Reinsert the batteries and wait for 5 seconds.
Your scale is now recalibrated and ready to use.
How do I change language?
Fitdays APP > Account > Settings > Language
How do I change the measure units?
Fitdays APP > Account > Settings > Switch unit
For more information, please check FQA from Fitdays APP.
Account > Settings > FAQ
Waste electrical products should not be disposed of with
household waste. Please recycle appropriately. Check with your
local authority or retailer for recycling advice.
Place the scale far away
from children in case of
falling or crashing.
Do not expose the scale
to heat or fire, it can
cause an explosion.
NOTES
Model: BS20
Made in China
THANK YOU FOR PURCHASING THE
AURA FULL BODY ANALYSIS SCALE
Table of contents
