AURICA NanoTrim User manual

1
USER´S GUIDE
NanoTrim
1023

2

3
Your Hearing Aid 4
Usage/Safety tips 8
Contra-indications 9
Care for your Hearing Aid 10
Replacing the battery 12
Using of your Hearing Aid 14
Switching ON/OFF 16
Placing and Removing 17
Trimmer controls 19
Maintenance 20
Accessories/Cleaning solutions. . . . . . . . . . . 20
Trouble Shooting 21
Contents 22
Limited Warranty 23
WARRANTY CERTIFICATE 24
Reclamations 25
DISPOSAL 26
Contents
All rights reserved. No part of this document may
be copied, reproduced or distributed in any form
without express written permission from AURICA
or ONKOCET company.

4
Your Hearing Aid is connected by the earhook to the customized ear-
mold that ts comfortably in your ear. This mold was crafted directly
from the ear impression taken by your hearing professional.
Your Hearing Aid may be programmed to match your particular hear-
ing requirements. These parameters have been set by your profes-
sional or the manufacturer and are not adjustable by the wearer. We
are condent that your listening enjoyment will be enhanced by the
attention given to the performance and appearance of your BTE.
This Operating manual, including specications, is a User’s
manual for the Hearing Aid «AURICA NanoTrim».
Read this Operating manual before using the
Hearing Aid «AURICA NanoTrim».
The present Operating manual contains the de-
scription of device, operating principle, technical
characteristics and operating instructions for the
Hearing Aid «AURICA NanoTrim» (further - HA).
Your Hearing Aid
Safety Signs
Refer to user manual/booklet
General safety sign
General prohibitory sign
General warning sign

5
In Your Hearing Aid has implemented a number
of modern technologies:
and drops down the signal level at the transition from one
program to another. Even with the sharp change in the situ-
ation Click Free ensure a smooth and seamless transition to
the new acoustic situation.
TINNI MASK technology
Tinnitus - a disease caused by a wide range of
reasons, and expressed in the emergence of
so-called «noise in ears». This kind of noise com-
plicates the situation of many people with hearing
impairments, exacerbating their problems with
perception and decoding the audio stream. Innovative design
solution of company Aurica – built tinnitus-musker - helps
to eliminate the inconvenience of having to use two different
devices.
CLICK FREE technology
Technologies that are used in NanoTrim, guaran-
tee the user a clear work of the aid and comfort
in any situation. As quickly as possible to adapt
in complicated sound environment allows function
Click Free, which eliminates unpleasant clicks
EVOKE LITE technology
Evoke Lite («light awakening» - in English) - this
is an additional comfort and convenience of
NanoTrim! Multi-key melodies instead of mono-
phonic signal will just be aware of low battery,
and switch programs on and off the device, and a variety of
signals will help you to quickly nd what’s happening.

6
microphone, receiver). Thanks nanocoating 3D PLazma signif-
icantly is improved moisture resistance of apparatus, as water
entering the inside, does not wet the surface of the electronic
components, and simply evaporates over time.
3D PLAZMA technology
The unique technology of 3D Plazma - reliable
protection against moisture and dirt ! Most hear-
ing aids afraid of water. Drops of water or sweat,
falling on the body, penetrate and lead to failure
of the important elements of the device (chip,
FEEDBACK FIGHTER technology
Hearing generate feedback signals. This leads
to annoying whistling that can hear not only the
user, but also the surrounding, which is a strong
irritant. The latest adaptive feedback suppression
Feedback Fighter guarantees the user protection
against acoustic feedback.
you to compensate the feedback. Audioprocesor in real-time
mode conduct analysis of input acoustic signal. Advanced
algorithm allows to accurately determine the occurrence of
feedback. Suppressing signal is generated by method which
allows to reduce or eliminate the occurrence of feedback in
the output signal without the loss of gain.
ADAP TUNE technology
Another problem more which are faced the us-
ers of the hearing aids - an unpleasant whistle,
which is a consequence of feedback. To eliminate
this effect in NanoTrim is realized the function of
AdapTune - a highly efcient system that allows

7
NOISE OFF technology
System of stratied noise reduction Noise Off
minimizes ambient noises and makes the process
of speech perception easier and more comfortable
even with excessive background noise.
SOFT SILENCE technology
Clear sound without interference, without noise
bothers - it is one of the major tasks that must
handle modern hearing aid.
With the help of system Soft Silence in devices
NanoTrim is suppressed as internal noise of
hearing aid (noise of microphone amplier) as external (the
rustling of paper, the hum of the fan, etc.), while it is not
distorted of speech, which greatly reduces fatigue when using
a hearing aid.

8
NanoTrim hearing aids are intended for sound amplication through
the air conduction, to compensate severe hearing loss.
In NanoTrim, modern production technologies are used, Nano
coating that ensures the protection of a device from moisture and
dirt; parts from the world leading manufacturers; shockproof plastic
body. This ensures a high reliability of products and excellent quality
of sound.
Before using the HA, read carefully with the further safety instructions
and other important information.
Usage/Safety Tips
• Protect your HA from mechanic impact.
• Avoid exposure to moisture (rain, sauna, shower, greenhouse etc.).
• Take your HA off when putting on cosmetics and hygiene solutions
on body and hair (hairspray, crème, lotion etc.).
• If you HA got wet, don’t try drying it under high temperatures
(blow dry, microwave oven, stove etc.).
• High temperatures will damage the device, so avoid the direct sun
exposure.
• If you are not using the device for a long time, remove the battery.
• The maintenance of the device must be done only by a specialist
• Take off the device when you are being medically examined (for
example when getting X-Ray or CAT done).
• Keep the batteries separately from medications. You can easily
confuse them with pills.
Please note:

9
• Hearing aids, their parts and batteries need to be kept
away from children, pets and mentally challenged people.
• Be careful with the leaking batteries. The liquid inside
them is harmful for your health.
• If you have swallowed a battery, immediately seek medical
help.
Usage/Safety Tips
Contra-indications
Hearing aid is contra-indicated in following situations:
• Malfunction of vestibular apparatus
• Acute and chronic disease in outer and middle ear
• In the rst months after cerebral meningitis and hearing
improvement surgeries
• Allergic intolerance to ear ttings

10
HA requires careful handling.
The right handling ensures the safe operation of HA.
Everyday care and regular maintenance of your HA significantly
prolongs its lifetime and ensures its effective operation.
Watch the cleanliness of the hearing aid. Wipe it
with a soft cloth regularly (Pic.1).
Never wash your HA with water, cleaning solutions
or other liquids. Remove ear wax from your ears,
because it can worsen the work of HA or even
break the device.
If your HA was exposed to excessive moisture,
dry it with a special kit, removing the battery
beforehand.
To avoid damages keep the HA in a special case.
Caring for your Hearing Aid
Pic. 1

11
Earmold care
Earmold is an important detail of your HA, that’s
why its necessary to keep it clean.
Cleaning of ear molds
Carefully separate the tube from the main body.
Gently wash the mold with warm, soapy water or
place it in a special solution for 15-30 minutes
(Pic.2). After the treatment, the mold have to
be dried completely. If there is still moisture in
the tube or in the mold, use the blowing device
(Pic.3). If the earmold’s tube have lost its
elasticity, became yellowish and cracked, it should
be replaced. Ask a hearing aid specialist about this
matter.
Caring for your Hearing Aid
Never use any spirit solution for cleaning the
earmold. Never treat the hearing aid with the
earmold cleaning solution.
Pic. 2
Pic. 3

12
Attention!
Use the batteries, specially intended for HA!
Using wrong batteries (for watch etc.) can wreck
the device.
Replacing the battery
Pic. 4а Pic. 4b
In this case the warranty doesn’t cover the maintenance!
Gently swing out the battery door with your ngernail and then open
it completely (pic.4a), take a new battery, take the lm off and wait
1minute so the battery could become saturated with oxygen to increase
its energy.
Insert the new battery into the battery compartment with plus(+) sign
on the battery facing the same way as the (+) sign on the edge of the
battery door. This will ensure that the battery door closes properly.

13
Put the battery ONLY in the lid of the battery
compartment.
Note: If the battery is inserted incorrectly, the door will
not close.
Never put too much afford into closing the lid of
the battery compartment.
Lower amplication power and volume , or spontaneous
shutdown indicates a low battery.
Replacing the battery

14
Getting used to your HA
Buying a hearing aid, bare in mind that it will take some time to get
used to new sounds and sensations. How much time this process will
take depends on the individual peculiarities of an organism, on the
level of hearing loss, on the time spent using HA, etc. If you have
started feeling discomfort while using HA , you need to lower the
volume or turn it off and take a break.
While watching TV set the volume to a medium level. If you have
hard time distinguishing sounds, turn the volume up using the volume
regulator. However, you should remember ,that turning the volume
up very high doesn’t always improve your perception of speech,
but can cause sudden fatigue and can provoke the deterioration of
hearing.
In a noisy environment it’s pretty hard to distinguish certain words,
so don’t be shy to ask again.
Using NanoTrim

15
The volume is adjusted with the volume
adjuster – switching from position 1 (minimum
volume) up to position 4 (maximum volume)
(Pic. 5).
Besides, you can change the listening
conditions with the program selection button
(Pic. 6). Switching the programs, you can
choose the listening mode appropriate for
different situations: microphone mode,
telephone mode (telecoil), mic+telecoil and
tinnitus masker mode.
Using NanoTrim
Pic. 5
Pic. 6
The listening parameters are set by an expert
when fitting and adjusting your hearing aid.

16
Switching ON/OFF
Your Hearing Aid has a three-position battery door that acts as an
off/on switch and that allows access to the battery compartment.
To turn the Hearing Aid on, close the battery door fully (pic.7a).
To turn OFF: open the battery door until it clicks, so the battery is
no longer touching the contacts.
Pic. 7а Pic. 7b

17
Placing and Removing
Also make sure that ON/OFF switch is set
to OFF.
To insert, hold the earmold on the outer
side near the tubing with your thumb and
forefinger (pic.8)
The upper part of the earmold must
be directed upwards. The tube mut be
directed to the ear canal.
If expenencing difficultes, pull down the
earlobe or pull the auride back or up and
gently insert the earmold into the ear.
(pic. 9)
The directed upwards завитковая часть
must fit into place. (pic. 10)
Gently insert the canal tip of the earmold
into your ear canal.
Then softly press the earmold into place
with your fingertip.
Carefully place the Hearing Aid behind your
ear with the earhook and earmold tubing
wrapped over the top.
Pic. 9
Pic. 8
Before placing the BTE onto
your ear, be sure the battery
is inserted and the battery
compartment door is closed
securely.
Pic. 10

18
To properly insert ЗАВИТКОВУЮ ЧАСТЬ you need to:
• With the fornger try to place it under the skin crease
• At the same time, at the other hand pull the ear up and back
• After you have inserted the earmold, carefully place the Hearing
Aid behind the ear.
• Try not to twist the tube.
To remove, take the instrument out from behind your ear and
gently pull the earmold outward.
Pulling down on the ear lobe may help loosen the earmold as it
is removed.
Placing and Removing
Attention!
It’s not recommended to pull the earmold tubing,
otherwise it can be damaged, which will require
repair or change of the earmold.

19
Trimmer controls are under the lid of your Hearing Aid (pic.11),
placed on the upper part of the frame. The lid must always be
closed to avoid the penetration of dust and moisture. In case of a
loss of the lid, consult a specialist.
The specialist determines the position of trimmer controls while
examining a patient, in accordance with individual characteristics
of your hearing loss (audiogram).
Trimmers
Pic. 11a
Trimmer controls
Pic. 11b
Attention!
Don’t open the lid of the trimmer compartment
and change the controls position in your HA by
yourself.

20
Maintenance is necessary to avoid expensive and complicated
repairs and to ensure uninterrupted performance of the device.
Free-of-charge maintenance is performed during the warranty
period and is applied only on the parts covered by the warranty
(see “Limited Warranty”).
To obtain maintenance services, contact the specialist from whom
you purchased your HA from.
The same specialist can tell you about the “after warranty”
maintenance service.
Accessories/Cleaning solutions
Care Products:
• BTE cleaning kit
• Drying container
• Drying tablets
Maintenance
Attention!
You can get detailed information about the
accessories and HA cleaning solutions(and their
prices) from a hearing aid specialist.
