Auriol 71479 User manual

Z31130
FUNK-WETTERSTATION
Bedienungs- und Sicherheitshinweise
RADIO-CONTROLLED WEATHER STATION
Operation and Safety Notes
RÁDIÓVEZÉRELT IDŐJÁRÁSÁLLOMÁS
Kezelési és biztonsági utalások
BEZDRÁTOVÁ METEOROLOGICKÁ STANICE
Pokyny pro obsluhu a bezpečnostní pokyny
STACJA METEO STEROWANA RADIOWO
Wskazówki dotyczące obsługi i bezpieczeństwa
DALJINSKA VREMENSKA POSTAJA
Navodila za upravljanje in varnostna opozorila
METEOSTANICA
Pokyny pre obsluhu a bezpečnostné pokyny

GB Operation and Safety Notes Page 7
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 48
HU Kezelési és biztonsági utalások Oldal 90
SI Navodila za upravljanje in varnostna opozorila Stran 132
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 174
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 214
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 255

3
A
7
8
9
17
19
15
13
11
10
20
16
18
14
12
1 2 3 4 5
22232627 25 24 21
6

4
B
28
30
32
31
29
33

5
C
40
34 35 36 37 38 39

6
D
42
43
44
45
41
Table of contents

7GB
Table of contents
Intended use..........................................................................................Page 9
Parts description ................................................................................Page 9
Technical data.......................................................................................Page 11
Included items......................................................................................Page 12
Safety
General Safety Information.........................................................................Page 13
Safety Instructions for Batteries ...................................................................Page 14
Before use
Setting up the devices..................................................................................Page 15
Preparing to use the outdoor sensor...........................................................Page 16
Preparing the weather station for use.........................................................Page 17
Operation
Receiving the DCF radio time signal...........................................................Page 19
Setting the 12/24 hour mode/°C/°F/time zone/time/date/
language manually......................................................................................Page 21
Setting the alarm time..................................................................................Page 22
Activating/deactivating the alarm function...............................................Page 23
Switching off the alarm signal.....................................................................Page 24

8 GB
Intended use/Parts description
Table of contents
SNOOZE function .......................................................................................Page 24
Preparing to use the weather forecasting function.....................................Page 24
Selecting the location...................................................................................Page 26
Selecting the location manually ..................................................................Page 27
Lunar phases.................................................................................................Page 38
Reading the barometric pressure for the last 12 hours .............................Page 39
Setting the channel.......................................................................................Page 39
Displaying temperature and temperature trend.........................................Page 40
Displaying the humidity and humidity trend...............................................Page 40
Displaying the maximum/minimum temperature/humidity.....................Page 41
Temperature and frost alarm.......................................................................Page 42
Activating/deactivating the the temperature and frost alarm..................Page 42
Background lighting.....................................................................................Page 43
Battery state display.....................................................................................Page 43
Changing the batteries ................................................................................Page 43
Troubleshooting .................................................................................Page 44
Cleaning and care.............................................................................Page 45
Disposal.....................................................................................................Page 45
Information
Declaration of Conformity...........................................................................Page 46

9GB
Intended use/Parts description
Radio-controlled weather station
Intended use
The weather station displays the indoor and outdoor temperatures in Celsius (°C) or
Fahrenheit (°F) and their maximum and minimum values. It also displays the indoor and
outdoor humidity (%RH) as well as their maximum and minimum values. Additional
display values of weather station include the weather forecast, the time in 12/24-hour
clock modes and the date. The weather station displays the sunrise and sunset times
for that day and the lunar phase as well. In addition, the weather station has two
different alarm functions. The device is not intended for commercial use.
Parts description
Weather station:
1Date display
2Month display
3Alarm 1
4SNOOZE display
5Radio tower symbol
6DST display (summer time)
7Time display
Table of contents

10 GB
Parts description/Technical data
Parts description
8Alarm 2
9Day of week display
10 Sunrise/time of sunrise
11 Tide display
12 Location
13 Lunar phase
14 Sundown/time of sundown
15 Temperature trend (indoor)
16 Humidity trend (indoor)
17 Humidity (indoor)
18 Comfort indicator (maximum/minimum)
19 Inside temperature (°C/°F)
20 Battery state display
21 Humidity trend (outdoor)
22 Humidity (outdoor)
23 Temperature and frost alarm (maximum/minimum)
24 Temperature trend (outdoor)
25 Outdoor temperature (°C/°F)
26 Battery state display (outdoor sensor)
27 Selected channel
28 Barometric pressure bar display
29 Barometric pressure display of the last hour
30 Absolute/relative barometric pressure
31 Barometric pressure trend

11GB
Parts description/Technical data
32 Weather forecast
33 SNOOZE/LIGHT button
34 MODE button
35 + button
36 – button
37 Channel button (CH)
38 HISTORY button
39 CITY button
40 Battery compartment
Outdoor sensor:
41 Control LED
42 Mount
43 RESET button
44 Channel selector switch
45 Battery compartment
Technical data
Weather station:
Temperature measurement range: 0 to +50°C
+32 to +122°F
Temperature resolution: 0.1°C
Parts description

12 GB
Included items/Safety
Technical data/Included items
Humidity measurement range: 20%–95%
Humidity resolution: 1%
Radio signal: DCF
Batteries: 3x AA, 1.5V
Dimensions: 130 x 130 x 60mm (B x H x D)
Outdoor sensor:
Temperature measurement range: –20 to +65°C
–4 to +149°F
HF transmission signal: 433MHz
HF transmission range: max. 25 metres over open ground
Batteries: 2x AA, 1.5V
Dimensions: 46 x 105 x 28mm
Included items
Immediately after unpacking, check that the delivery is complete and that the product
and all its parts are in perfect condition.
1 Weather station
1 Outdoor sensor
3 Batteries AA, 1.5V

13GB
Included items/Safety
2 Batteries AA, 1.5V
1 Operating instructions
Safety
Please read all safety information and instructions. Failure to comply with the safety
information and instructions may result in an electric shock, fire and/or severe injuries.
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A SAFE PLACE FOR
FUTURE REFERENCE!
General Safety Information
DANGER OF LOSS OF LIFE OR ACCIDENT
TO INFANTS AND CHILDREN! Never allow children to play
unsupervised with the packaging material. The packaging material
represents a danger of suffocation. Children frequently underestimate the dangers.
Children should be kept away from the product at all times.
DANGER TO LIFE! Batteries can be swallowed, which may represent a danger
to life. If a battery has been swallowed, medical help is required immediately.
Children or other individuals who do not know or have no experience of handling
this device, or whose physical, sensory or mental abilities are restricted, must
Technical data/Included items

14 GB
Safety/Before use
Safety
not use the device without supervision or instruction by an individual responsible
for their safety. Children must never be allowed to play with the device.
Do not use the device if it is damaged. Damaged devices represent a danger
of death!
Please note that the guarantee does not cover damage caused by incorrect
handling, non-compliance with the operating instructions or interference with
the device by unauthorised individuals.
Never take the device apart. Improper repairs may place the user in considerable
danger. Repairs should only be carried out by specialist personnel.
Safety Instructions for Batteries
Remove the batteries from the device if they have not been used for a long period.
CAUTION! DANGER OF EXPLOSION! The batteries must never be
recharged!
When inserting the battery, ensure the correct polarity! This is shown in the
battery compartments.
If necessary, clean the contacts on the batteries and on the device before
inserting them.
Remove spent batteries from the device immediately. There is an increased
danger of leaks!
Batteries must not be disposed of in the normal domestic waste!

15GB
Safety/Before use
Every consumer is obliged to dispose of batteries properly in accordance with
the regulations!
Keep batteries away from children. Do not throw batteries into a fire. Never
short-circuit them or take them apart.
Always replace all the batteries at the same time.
Use only batteries of the same type.
If the batteries in your device have leaked, remove them immediately to prevent
damage to the device!
Avoid contact with the skin, eyes and mucous membranes. In the event of contact
with fluid leaking from a battery, thoroughly flush the affected area with water
and/or seek the advice of a doctor!
Before use
Setting up the devices
CAUTION! When choosing where to position the weather station, make sure
that it is not exposed to direct sunlight, vibrations, dust, heat, cold or moisture. Do
not place the devices close to sources of heat, e.g. radiators. Otherwise they may
be damaged.
Do not place the devices on valuable or sensitive surfaces unless these are
appropriately protected. Otherwise they may be damaged.
Safety

16 GB
Before use
Before use
Do not place the devices near sources of interference such as television sets,
computers, thick walls, thermopane windows etc. Otherwise the transmission
of radio waves between the devices may be impaired.
Please ensure that neighbouring devices are not operated at the same frequency
of 433MHz. Such devices may cause interference to the radio connection.
Do not place the devices next to or on metal plates. Otherwise the quality of
radio wave transmission may be reduced.
Do not install the devices in buildings made of reinforced concrete, e.g. airports,
high-rise buildings, factories or cellars. Otherwise the transmission of the radio
waves between the devices may be severely impaired.
In open spaces do not place the devices more than 30 metres apart, as otherwise
transmission of the radio waves may be interrupted. Otherwise the quality of
radio wave transmission may be interrupted.
Preparing to use the outdoor sensor
Remove the battery compartment cover from the back of the outdoor sensor.
Remove the battery safety strip. The outdoor sensor is now ready for operation
and the control LED 41 lights up briefly.
Note: If you use more than one outdoor sensor (max. 3), you can receive data
at the weather station from all the individual outdoor sensors. Set a different
channel for each of the sensors using the channel selector switch 44.
Close the battery compartment cover.

17GB
Before use
Installing the Outdoor Sensor:
Note: You will need an electric drill for this step.
Find an appropriate place for the outdoor sensor.
Note: Please ensure that you install the outdoor sensor within a radius of 30m
from the weather station. Check that there are no obstacles between the outdoor
sensor and the weather station. Otherwise there may be interference of the
transmission of data.
For wall mounting:
Hang the outdoor sensor with the mount 42 on one screw.
Preparing the weather station for use
Removing the battery safety strip:
Open the battery compartment 40 on the back of the weather station.
Pull out the battery safety strip.
Then close the battery compartment.
As soon as the battery safety strip has been removed, the weather station starts to
receive the radio signal.
Before use

18 GB
Before use/Operation
Before use
Note: Do not move the weather station while it is receiving the signal. This may
disrupt reception.
Connecting the weather station with the outdoor sensor and the
DCF radio signal:
After removal of the battery safety strip the weather station attempts to establish a
connection with the outdoor sensor. This process can take a few minutes. On successful
connection with the outdoor sensor, the selected channel symbol 27 appears in the
LC display with the channel of the outdoor sensor (if necessary you can change the
channel of the outdoor sensor as shown in the section “Setting the channel”). If the
connection with the outdoor sensor is not established automatically, this can be done
manually by pressing RESET button 43 of the sensor.
As soon as the weather station has established a connection with the outdoor sensor
it automatically begins to receive the DCF radio signal. This process takes several
minutes and is indicated in the LC display by a flashing radio tower symbol 5.
When the DCF radio signal is being successfully received, the radio tower symbol
is shown permanently in the display. If at the time of putting the device into opera-
tion it is not possible to synchronise with the atomic clock, you can also carry out
the clock adjustments manually (“Setting the 12/24 hour mode/°C/°F/time
zone/time/date/language manually”).

19GB
Before use/Operation
Radio signal (DCF):
The DCF signal (time signal transmitter) consists of time pulses emitted by one of
the most accurate clocks in the world close to Frankfurt/Main, Germany – this
varies by 1 second in a million years.
In ideal conditions, your weather station can pick up this signal over a distance of
up to approx. 1,500km around Frankfurt/Main. Reception of the radio signal
generally takes approx. 3–10 minutes.
Reception can be considerably impaired by obstacles (e.g. concrete walls) or sources
of interference (e.g. other electrical devices). In the event of reception problems,
change the position of the weather station (e.g. to somewhere near a window).
Operation
Receiving the DCF radio time signal
After a connection with the outdoor sensor is established or 3 minutes after the battery
safety strip is removed, the weather station automatically begins to search for the
DCF radio signal. The search is shown in the LC display by the radio tower symbol 5
flashing.
Note: In buildings made of reinforced concrete the reception of the radio signal
may be severely impaired (see “Setting up the devices”).
Before use

20 GB
Operation
Operation
In order to correct any deviations from the exact time, the clock is automatically
synchronised with the DCF radio signal every day at 1:00, 2:00 and 3:00. If the
synchronisation occurs at 3:00, the weather station will not conduct any further
synchronisation with the DCF radio signal on this day. If the synchronisation with
the DCF signal does not succeed, the radio tower signal goes out. In this case, the
weather station attempts to conduct a synchronisation with the DCF radio signal at
4:00 and 5:00. If the synchronisation at 5:00 still does not succeed, the weather
station will not conduct any further synchronisation with the DCF radio signal on
this day.
Reception of the DCF radio signal can also be started manually on the weather station.
Press the + or – button 35, 36 at the same time. The weather station attempts to
receive the DCF radio signal. This process takes several minutes and is indicated
in the LC display by a flashing radio tower symbol.
If the connection with the DCF radio signal cannot be established, the search is
stopped.
Note: If the clock of the weather station cannot receive the DCF radio signal due
to errors, too great a distance from the transmitter or similar reasons, it is possible
to set the time manually. If reception of the DCF signal is successful, the manual
settings are overwritten.
