ausdom S5 User manual

User’s Manual
Wireless Earphone
MODEL: S5

EN-1
2. Package Contents
Thank you for purchasing the AUSDOM S5 wireless
earphone. The earphone provides light-weight, rich sound and
soft-comfortable earbuds construction. The feature friendly
buttons design that makes it easy to operate the play, stop and
skip audio functions and answer a call with hands-free. Built-in
rechargeable battery provides more music playing and
standby time. Through wireless 4.2 to communicate with your
wireless-enabled devices, it brings you a powerful bass sound
and amazing audio enjoyment.
Note: Please read the user’s manual carefully before using,
and keep it properly for future reference.
1. Introduction
3. Product Overview
- Wireless earphone *1
- Micro USB charging cable*1
- Storage bag*1
- User’s manual*1
- Ear tips*2 pairs(S/L)
1
6
4
5
7
3
2
89

EN-2
4. Features
5. Neckband Style and Ear Manner
1.Ear tips
2.Neckband wearing
3.Magnetic position
4.Function Button (Power On/Off/Pause/Play/talk)
5.Volume+/Prev
6.Volume-/Next
7.LED Indicator
8.Micro USB Charging Port
9.Microphone
-Wireless technology with bluetooth 4.2 version.
-Neckband and real lightweight design with added support
for working out；
- High-tech silicone materials with nano coating to make it more
sweatproof and slight waterproof.
- Magnetic design can clip together easily, be tangle-free storage.
- Powerful bass for an enhanced wireless music experience
- Built-in microphone and easy controls make hands-free
calling a breeze.
- Up to 6 hours playtime.
Micro USB Charging Cable Storage bag

EN-3
Style 1:
Enjoy music at home/office
Style 2:
For sports use
6. Charging the Battery
Ear tips*2 pairs
(S/L)
Use the supplied micro USB charging cable to recharge the
battery. It takes about 1.5 hours for charging. The earphone
LED turns to solid red during charging and when the battery is
fully charged the LED turns off.
Please kindly note that can’t use the wireless function when
charging. When the battery is low, the LED flashes red. At the
same time the earphone also provides a low battery warning
tone.
Note: It is strongly recommended fully charging for the first
use. Playtime varies according to volume level and audio
content.

EN-4
7. Pairing with Wireless Devices
7-1 Pairing the earphone with a computer
Before pairing the earphone with your computer,
please make sure your computer or laptop has the
built-in Wireless feature. If not, you must purchase a
Wireless dongle, preferably version 2.1 or above.
1. Make sure the earphone is off.
2. Start the Wireless program in the computer.
3. The “Search new device” screen will be displayed.
4. Do not place both devices more than one meter away from
each other.
5. Press and hold the power button on the earphone until it
powers on but don't let go just yet. Continue holding down on
the power button until you see the LED indicator flashes blue
and red alternately, which means your earphone is in "pairing
mode" waiting to be paired with your device. You will hear
“Pairing”.
6. As soon as the system detects the new device and select “
AUSDOM S5".
7. If your computer ask you to enter the PIN code, please
enter 0000 (4 zero).Once successfully paired,the blue LED
will flash every five seconds. . You will hear "Connected".
Micro USB Charging Cable
Laptop for Power Supply

EN-5
8. Taking and Answering a Call
8-1 Taking a call
1. Make sure the earphone is pairing to the mobile phone. Dial
through the mobile phone and press the call button on the
phone.
2.To end a call, press the function button once again or also
end the call directly by the phone.
8-2 Answering a call
Make sure the earphone is pairing with your phone. Please
refer to chapter 7. Pairing with Wireless Devices.
1.When a call rings, the earphone will sound the prompt voice.
2.Press the function button on your earphone or the answer
key on your phone to answer the call.
3.To end a call, press the function button once again or also
end the call directly by the phone.
7-2 Pairing the earphone with a phone
1. Make sure the earphone is off.
2. Do not place both devices more than one meter away from
each other.
3. Press and hold the power button on the earphone until it
powers on but don't let go just yet. Continue holding down on
the power button until you see the LED indicator flashes blue
and red alternately, which means your earphone is in "pairing
mode" waiting to be paired with your device. You will hear
“Pairing”.
4.Start Wireless function on your phone and search for new
devices.
5.Select the “AUSDOM S5” to pair. Once successfully
paired,the blue LED will flash every five seconds.
Note: The earphone will power off if not paired within 10
minutes.
7-3 Connecting to paired devices
The earphone will pair with the last paired device automatically
when powered on. But for some computers or laptops you will
need to manually pair every time.

EN-6
Wireless Connection
Hello
lncoming Call
Dial Phone Number
9. LED Indicator
10. Control Instructions
Description
Status
Flashing Blue
No Light
Solid Red
Blue flashes every five
seconds
Blue and Red
Alternately
Flashing Red
Power on/Standby
Power off
Charging
Pairing completed
Pairing mode
Low battery
Function
Power on
Operation
When the headphone is off, press and hold
the function button 3 seconds. And the
LED flashes blue for 1 seconds quickly and
sounds “power on”. Then flashes blue for
standby.
Power off
When the headphone is on, press and
hold the function button 3 seconds. And
the LED flashes red for 2 seconds and
sounds “power off”.
Pairing mode
Press and hold the function button for 5
seconds, then the LED flashes in red and
blue, you will hear “paring”.
Increase volume Press the volume up ( ) button.

EN-7
11. Take Care Your Earphone
- Store the earphone with power off and in a dry environment.
- If you don’t use the earphone for a long period, charging the
battery every 2 months for 1-2 hours.
- Don’t charge the battery beyond the rating.
- Keep the temperature at 0˚C-40˚C during charging.
- Don’t put the earphone on combustible substances (bed and
carpet) during charging.
- Don’t disassemble and replace the built-in battery on
yourself, this will cause damage the earphone.
- Use a dry cloth for cleaning if needed.
Note:
- There will be a prompt tone when the volume reaches the
maximum level.
- You can only pair and connect one device every time. To
switch Wireless device, disconnect the earphone from the
current device (disable the Wireless feature) before
connecting to another.
Press next track ( ) button for about 1.5s.
Press previous track ( ) button for about
1.5s.
End a call When a call is ended, press the function
button.
Decrease volume Press the volume down ( ) button.
Answer a call When a call rings, press the function
button .
Pause/restart
media playback Press the function button
Skip to next
track
Play media Press the function button
Skip to
previous track

EN-8
Avoid exposing to
liquids and rain
Avoid exposing to
extremely temperature
Avoid soak in
the water
12. Protecting your Hearing
The earphone is held close to your ears, so loud sounds pose
a potential hearing risk. It is highly recommended that setting
low volume level before putting on the earphone and avoiding
exposing yourself continuously to high volumes.
13. Troubleshooting
Q: The earphone cannot be powered on.
A: The battery may be flat. Please recharge the battery and try
again. Refer to chapter 6. Charging the Battery.
Q: Why doesn’t the earphone pair with the mobile
phone?
A: Please check the followings.
- Check that the earphone is charged and is in pairing mode.
- Make sure that the mobile phone's Wireless function is on.
- Make sure that the two devices are in the effective pairing
- Avoid dropping the earphone from high places or on hard
surfaces.
- Avoid exposing the earphone to extreme temperature.
(Recommended Storage temperature is -40˚C-70˚C.)
- The earphone is NOT waterproof. Avoid exposing the
earphone to rain or getting liquids into any button port or other
openings.
- Please don’t twist or bend the earphone. This may cause
permanent deformation.

EN-9
14. Warranty
The S5 is covered by a 1-year manufacturer warranty. For
more information, visit www.ausdom.com/warranty .
range.
- Make sure that there is no obstacle between the earphone
and the mobile phone, such as electronic equipment and a
wall.
- Furthermore, you can try restarting the earphone and pairing
it with the mobile phone again.
Q: There is some noise.
A: Wireless is a radio technology, so it is sensitive to obstacles
between the earphone and the pairing device. Please make
sure that there is no obstacle between the two devices.
Q: I can't hear sound.
A: Please check the followings.
- Try increase the volume.
- Make sure that the Wireless function is on and whether the
two devices are connecting and in the range.
- Make sure the earphones are close enough to your device,
and there is no obstacle between them.
Q: My mobile phone or computer cannot find the
earphone.
A: Please check that the earphone is in pairing mode. Refer to
chapter 7. Pairing with Wireless Devices. Sometimes when
the earphone is connected too many Wireless devices, it
cannot search and pair effectively. Or your mobile phone and
computer are already connected to many other devices. Try
removing some connections before searching the earphone.

EN-10
Note: Features and technical specifications are subject to
change without notice, we apologize for any inconvenience.
15. Specifications
Microphone
Spec.
Microphone Unit
Directivity
S.P.L
Operating Voltage
Impedance
Frequency
Response
Speaker Diameter
Impedance
S.P.L
THD
Frequency
Response
Wireless Version
Wireless Distance
Transmission
Range (Hz)
Support Profile
Pairing Name
Battery Type
Charging Port
Speaker
Spec.
Wireless
Spec.
Running Time
Charging Time
Operating
Temperature
Battery Spec.
Φ4.0*1.5mm
Omni-direktional
-42dB
2V
2.2KΩ
20Hz-20KHz
Φ10mm
16Ω
95dB
＜3%
20Hz-20KHz
4.2
10m
2.402GHz-2.48GHz
HSP/HFP/A2DP/AVRCP
Built-in 110mah
rechargeable lithium
battery
AUSDOM S5
Micro USB 5V/1A
About 6 hours
talking/About 8 hours
playing
About 1.5 hours
-10˚C-45˚C

WARRANTY CARD
ATTENTIONS:
- Please read the return procedures and warranty policy
carefully on www.ausdom.com/warranty before sending items
back to point-of-purchase.
- Please fill the card and send it to your reseller together with
the product if your product's warranty is valid.
S.N:
Date of Purchase:
Product Model:
RMA Number:
Return Reason:
Customer Name:
TEL:
E-mail:
Address:

For more information, please visit our official website
www.ausdom.com
Your valuable comments and suggestions on improving
AUSDOM products are welcomed!
