User’s Manual
TRUE WIRELESS EARPHONE
MODEL:TW01

1
Thank you for purchasing the AUSDOM TW01
wireless earphone. The earphone provides
light-weight, rich sound and soft-comfortable
earbuds construction. The feature friendly
buttons design that makes it easy to operate the
play, stop and skip audio functions and answer a
call with hands-free. Built-in rechargeable battery
provides more music playing and standby time.
Through wireless 5.0 to communicate with your
wireless-enabled devices, it brings you a
powerful bass sound and amazing audio
enjoyment.
Note: Please read the user’s manual carefully
before using, and keep it properly for future
reference.
Introduction
Package Contents
- Wireless earphone *2
- Charge Warehouse*1
- Micro USB charging cable*1
- User’
s manual*1
- Ear tips*3 pairs(S/M/L)
Note:One of them is already equipped with earphones

OVERVIEW
Choose Ear Tips
LED MFB
It is recommended you try middle EarTips
first, it fits most people
Pogo Pins
Small Middle Large
2

3
The earphones was
worn as shown
Right ear
Micro USB interface for charging

4
How to Pair
Take out both two Earphones then re-insert
them into the case to activate the earphones.
Notes: If Earphones fail to be charged, pls
charge the case via USB cable
(for details, pls follow the bleow steps).
Put both Earphones into charging case to
activate them then take out, both Earphones
will auto power on and pair with each other.
After the LED for left Earphones turns blue and
red, right Earphones turns blue. Search TW01 on
mobilephone and connect it.
(For first time pairing)

5
(Notes: If fail to connect, pls try the following
steps by hands.)
1. Press and hold both Earphones for 3s to
power off
2.Press and hold two Earphones for 15s ( LED
blue ---red and blue blinks alternatively --- red
and blue blink twice at the same time)
3. Press and hold two Earphones for 2s again to
power on (LED blue), Or put the earphone back
into the charging case and take it out.
Two Earphones will auto pair with each other.
When LED on left Earphone turns blue and red,
right Earphone turns blue, it means both sides
connected successfully
Search for TW01 on mobilephone and connect it
L R

6
Dual earphone usage mode: Take the left and
right earphones directly from the charging
compartment and put on the ear, the earphone
will automatically connect and enter the pairing
state.
Single earphone (drive) usage mode: Take the left
(L) earphone directly from the charging compart-
ment and put it on the ear to use it directly
(provided that the dual earphones are successful-
ly paired with the mobile phone).

Method 2: Power off earphones and hold MFB
7
FUNCTIONS
Method 1: take earphones out from the charging
case and they will auto power on (LED solid
blue) (Make sure there has power in charging
case)
for 2s to power on (LED glows solid blue)
Power-on
1. Put earphones back into the charging case, it
2, Hold MFB for 3s (red LED will turn on for 1s)
Hold
Hold
will auto power off (red LED will turn on for 1s)

Press and Hold MFB for 2s to reject the
incoming call
Reject Call
Press MFB to answer the incoming call and
press again to end it
Answer Call
Hold
Short Press
During calling, press and hold MFB for 2s to
switch audio output between mobilephone and
earphones
Switch Audio Output
Hold
8

During calling, double press MFB to switch mute
on/off
During playing, double press MFB on right
Earphone to next song, double press MFB on
left Earphone to last song
Skip Track Forward /backward
When listening to music, press MFB once to play
/ pause.
Play/ Pause
Double Press
Double Press
Short Press
9
- Wireless earphone *2
- Charge Warehouse*1
- Micro USB charging cable*1
- User’
s manual*1
- Ear tips*3 pairs(S/M/L)
Note:One of them is already equipped with earphones

When standby, press and hold MFB for 2s to
activate voice assistant (like siri)
Voice Assistant
Insert the earphones into the charging case
LED will be solid red when charging, after full
charged,turn to blue for 1min then turn off
Charge the Earphones
Please charge the case via USB cable,
Red LED flashes when charging, turn to solid
red when full charged , When low battery, blue
LED flashes
Charge the case
Hold
10

Model: TW01
Operation Range: 10m (with no obstacle)
Bluetooth version: V5.0
Charging time: approx 2hr
Music time: approx 5hr
Battery type: Li-ion
Bluetooth profiles: HFP/HSP/A2DP/AVRCP
Battery capacity (earphones): 3.7V/ 50mAH
Battery capacity (charging case): 3.7V/ 600mA
Input parameter (charging case): 5V 600mAh
(All technical data shall be subject to practical
performance.)
Notes: Please arrange using time properly as
your hearing may be damaged by using the
device for a long time.
PRODUCT PARAMETER
11

1. Before using the Earphones, please read the
manual carefully and keep it for future
references..
2. The Earphones need to be fully charged prior
to first-time use.
3. If the Earphones is left unused for over two
weeks, please recharge it periodically.
TIPS
4. Please use the chargers made by qualified
manufacturer.
5. If the Earphones cannot be found by your
phone, please check whether it is in pairing
mode; if left unconnected for a long while, the
Earphones will exit pairing mode, please
re-enter the mode, if a procedure error of
your phone occurs, reboot it; if a procedure
error of the Earphones occurs, reboot or reset
it.
12

1. Never disassemble or modify your Earphones
for any reasons to avoid any damages and
danger.
2. Do not store the Earphones in extreme
temperatures (under 0 to 45 )
3. Avoid using the indicator close to the eyes of
children or animals.
4. Do not use this Earphones during a thunder
storm to avoid irregular function and
increased risk of electricshock
5. Do not use harsh chemicals or strong
detegents to clean the Earphones
6. Keep the Earphones dry.
WARNING
13

WARRANTY CARD
ATTENTIONS:
- Please read the return procedures and warranty policy
carefully on https://www.ausdom.com/CustomeCare/Warran-
ty.html before sending items back to point-of-purchase.
- Please fill the card and send it to your reseller together with
the product if your product's warranty is valid.
S.N:
Date of Purchase:
Product Model:
RMA Number:
Return Reason:
Customer Name:
TEL:
E-mail:
Address:

For more information, please visit our official website
www.ausdom.com
Your valuable comments and suggestions on improving
AUSDOM products are welcomed!
