Austin Hughes CyberView MU-IP1613 User manual

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com
back
back
dedicated KVM switch and rackmount screen technology
User Manual - KVM Rear Kit Version
for LCD Console Drawer
Matrix Cat6 KVM
Matrix Cat6 KVM -MU1602 / 1603 / 1604
-MU3202 / 3203 / 3204
-MUIP1613 / 1624
-MUIP3213 / 3224
Designed and manufactured by Austin Hughes 751

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com
Legal Information
First English printing, May 2022
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■ Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■ Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■ When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■ When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■ Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■ If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■ Observe all precautions and warnings attached to the equipment.
■ If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■ Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fi re or electrical shock.
■ Only qualifi ed service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■ If any part of the equipment becomes damaged or stops functioning, have it checked by qualifi ed service personnel.
What the warranty does not cover
■ Any product, on which the serial number has been defaced, modifi ed or removed.
■ Damage, deterioration or malfunction resulting from:
□ Accident, misuse, neglect, fi re, water, lightning, or other acts of nature, unauthorized product modifi cation, or
failure to follow instructions supplied with the product.
□ Repair or attempted repair by anyone not authorized by us.
□ Any damage of the product due to shipment.
□ Removal or installation of the product.
□ Causes external to the product, such as electric power fl uctuation or failure.
□ Use of supplies or parts not meeting our specifi cations.
□ Normal wear and tear.
□ Any other causes which does not relate to a product defect.
■ Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifi cations made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■ Re-position or relocate the receiving antenna.
■ Increase the separation between the equipment and receiver.
■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected.

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com
Contents
< Part. 1 > Matrix Cat6 IP KVM
1.1 Package contents P.1
1.2 KVM port & Cat6 dongle connection P.2
1.3 IP & Remote console connection P.3
1.4 Connect to IP console P.5
1.5 IP Console Firmware Update P.9
1.6 KVM Cascade P.10
1.7 Specifi cations P.11
< Part. 2 > Matrix Cat6 KVM
2.1 Package contents P.12
2.2 KVM port & Cat6 dongle connection P.14
2.3 Remote console connection P.15
2.4 KVM Cascade P.17
2.5 Specifi cations P.18
< Part. 3 > Matrix Cat6 KVM Usage
3.1 KVM Button P.19
3.2 Password P.20
3.3 KVM OSD P.21
3.4 KVM Hotkey & Remote Console Hotkey P.22
MU-1602 MU-1603 MU-1604
MU-3202 MU-3203 MU-3204
MU-IP1613 MU-IP1624
MU-IP3213 MU-IP3224

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.1
Matrix Cat6 IP KVM
back
-MUIP1613
-MUIP3213
Cascade
-MUIP1624
1Power
Remote Console 1
1
Remote Console 1
2
Power
• Receiver box for remote console x 1
• Power adapter w/ power cord ( for receiver ) x 1
• CE-6 6ft Combo KVM cable for receiver box x 1
KVM Rear Kit
-MUIP1613 / -MUIP3213
-MUIP1624 / -MUIP3224
-MUIP3224
Cascade
< Part 1 > Matrix Cat6 KVM
< 1.1 > Package Contents

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.2
Matrix Cat6 IP KVM
< 1.2 > KVM port & Cat6 dongle connection
Resolution Support Frequency
( Hz )
1920 x 1080 60
1600 x 1200 60
1440 x 900 60
1280 x 1024 60
1024 x 768 60 / 70 / 75
Cat6 Dongle
Cat6 KVM port
Drawer KVM Rear Kit
CAT 5 / 6 cable
max. 40 meters
CAT 5 / 6 cable
max. 40 meters
Servers
Servers
DG-100S
DG-100C
DG-100SD
DG-100P
DG-100H
USB
USB-C
DP
USB
HDMI
USB
DVI-D
USB
VGA
DG-100P
DP-USB dongle
DG-100H
HDMI-USB dongle
DG-100SD
DVI-USB dongle
DG-100S
VGA-USB dongle
DG-100C
USB-C dongle

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.3
Matrix Cat6 IP KVM
Resolution Support Frequency
( Hz )
Max. Cat6 Cable
Length ( M )
1920 x 1080 60 50
1920 x 1200 60 50
1600 x 1200 60 100
1440 x 900 60 100
1280 x 1024 60 150
1024 x 768 60 / 70 / 75 150
Remote Console
For remote console, max. cable length is
subject to the resolution.
Please refer to the tables below.
< 1.3 > IP & Remote console connection
Drawer KVM Rear Kit
Receiver
IP Console
Resolution Support Frequency
( Hz )
1920 x 1080 60
1920 x 1200 60
1600 x 1200 60
1280 x 1024 60
1024 x 768 60

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.4
Matrix Cat6 IP KVM
CE-6
Combo
KVM cable
Local computer
( Optional setup )
Cat6 cable
up to 150m
VGA
Power KB
Mouse
Local
Computer Remote I/O
Front
Remote
LED
Local
LED
Rear
Select button
Receiver
12V DC Power
Adapter
Monitor
VGA
cable
Remote
Console
The receiver provides a hotkey function for remote console. Please refer to P.21
Front
How to use a receiver to connect a remote console
Drawer KVM Rear Kit

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.5
Matrix Cat6 IP KVM
Please make sure to follow the below steps to setup your KVM IP properly.
I. Confi gure the target server
The target server is the server that connected to the IP KVM Switch. Before use IP remote access, you need to
turn off mouse acceleration of all target servers. Please refer to below for Windows operating system.
Mouse setting
From the Control Panel, double-click the Mouse icon to open the Mouse Properties dialog box.
1. Move the pointer speed slider to the default of 50%.
( the middle of the slider or the sixth tick from the left ).
2. Uncheck “Enhance pointer precision”.
3. Uncheck “Automatically move pointer to the default button in a dialog box” & “Display pointer trails”.
4. Windows enables mouse acceleration by default. Make sure you are logged in to windows to check mouse
synchronization.
5. Mouse acceleration can only be turned off on a per Windows user basis. If you log in to Windows with a
diff erent user name, then you will have to confi gure mouse properties separately for that user as well.
< 1.4 > Connect to IP console

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.6
Matrix Cat6 IP KVM
Change display scaling setting 100%
1. Open Settings.
2. Click on System.
3. Click on Display.
4. Under the “Scale and layout” section, select the scale 100%.

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.7
Matrix Cat6 IP KVM
II. Logging in to IP KVM
The default IP address is as below:
IP address: 192.168.1.22
Subnet mask: 255.255.255.0
Gateway: 192.168.1.1
IP KVM model with single IP port:
- Default address 192.168.1.22
IP KVM model with dual IP ports:
- The 1st IP address 192.168.1.22
- The 2nd IP address 192.168.1.23
To log in to the IP KVM do as follows:
1. Open the browser on the client, in the address bar, enter the default IP KVM address ( 192.168.1.22 )
2. In login dialog box, enter the user name and password, then click Login, the default user name is
super and the default password is pass.
3. The IP KVM GUI is displayed, and the navigation bar is on left-side.

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.8
Matrix Cat6 IP KVM
The setting is enough for intranet.
If the users access KVM GUI via internet, please ask MIS for assistance and
download IP KVM user manual from the link :
www.austin-hughes.com/support/usermanual/cyberview/UM-CV-IP.pdf
III. Confi gure Remote Console Resolution
The IP remote console displayed on the HTML5-based browser support multiple types of resolution, with a
maximum of 1,920 x 1,200.
Click Remote Console and then Resolution, the Remote Console Video page is displayed, select the same
resolution as target servers, click Apply to save the resolution.
IV. Launch remote console
Click Control and then Remote console, the Remote console Preview is displayed, then Click Connect, the
remote console opens in a separate windows.
When fi rst start, the local mouse is not synchronized with the remote mouse, it appears at a distance to each
other, press the Mouse Sync once ( positioning top left corner ), the mouse will align.

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.9
Matrix Cat6 IP KVM
< 1.5 > IP Console Firmware Update
Firmware Update Steps
1) Download the latest IP KVM fi rmware from the link
http://www.austin-hughes.com/resources/software/kvm-switch
2) Login the IP KVM
3) Click < Maintenance >
4) Click < Update Firmware >
5) Click < Browse > to select the firmware file
6) Click < Update >

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.10
Matrix Cat6 IP KVM
Cascade
< 1.6 > KVM Cascade
■ Cascade up to 8 levels, 256 servers
■ Cascading multiple KVM with CMC-8 cascade cable.
Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602.
When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other
Expansion KVM switches (e.g. level 2 to 8).
The slave matrix KVM will be as a port expansion module of the master matrix KVM, the original
remote console on Expansion KVM will be sacrifi ced and disabled.
MU-1602
MU-1602
MU-1602
MU-1602
MU-3202
MU-3202
MU-3202
Master KVM
To cascade OUT port
Drawer KVM Rear Kit
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
CMC-8
■ 8ft Matrix KVM cascade cable
Expansion KVM
level 2
Expansion KVM
level 8
Expansion KVM
level 7
Expansion KVM
level 6
Expansion KVM
level 5
Expansion KVM
level 4
Expansion KVM
level 3

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.11
Matrix Cat6 IP KVM
< 1.7 > Specifi cations
-MUIP1613 -MUIP1624
-MUIP3213 -MUIP3224
▀KVM Port
Number of ports : 16 or 32
Connector : RJ-45
Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via
Cat6 / Cat5 cable
▀Local Console : Nil for LCD console drawer version
▀Cat6 Remote Console
Number of remote port : 1
Monitor port : DB15-pin VGA
Keyboard & mouse port : 2 x USB type connector for keyboard & mouse
Remote I/O : RJ45 via Cat5 / Cat5e / Cat6 cable up to 500 feet
Resolution support : 16:9 - max. 1920 x 1080
16:10 - max. 1920 x 1200
4:3 - max. 1600 x 1200
▀IP Remote Console
Number of IP console : 1 for -MUIP1613 / -MUIP3213
2 for -MUIP1624 / -MUIP3224
User management : 15-user login, 1 x active user
Browser : Chrome, Firefox, Edge, etc.
Security : TLS 1.3, AES, LDAP, Active Directory (AD), HTTP(s)
IP Access : RJ45 Ethernet per IP console
Resolution support : 4:3 - max. 1600 x 1200
▀Expansion : Up to 256 servers by 8-level cascade
▀Compatibility
Hardware : HP / IBM / Dell PC, Server and Blade Server
SUN / Mac
OS Support : Windows / Linux / Unix / Mac OS
▀Power
Input : AC power adapter
Consumption : Max. 34W
▀Compliance
EMC : FCC & CE
Safety : CE / LVD & UKCA
Environment : RoHS3 & REACH
▀Environmental Operating Storage / Non-operating
Temperature : 0 to 55°C degree -20 to 60°C degree
Humidity : 20~90%, non-condensing 5~90%, non-condensing
Altitude : 16,000 ft 40,000 ft
Shock : - 10G acceleration (11ms duration)
Vibration : - 10~300Hz 0.5G RMS random vibration

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.12
Matrix Cat6 KVM
< Part 2 > Matrix Cat6 KVM
< 2.1 > Package Contents
• Receiver box for remote console x 1
• Power adapter w/ power cord ( for receiver ) x 1
• CE-6 6ft Combo KVM cable for receiver box x 1
KVM Rear Kit
-MU1602 / -MU3202
• Receiver box for remote console x 2
• Power adapter w/ power cord ( for receiver ) x 2
• CE-6 6ft Combo KVM cable for receiver box x 2
back
KVM Rear Kit
-MU1603 / -MU3203
• Receiver box for remote console x 3
• Power adapter w/ power cord ( for receiver ) x 3
• CE-6 6ft Combo KVM cable for receiver box x 3
back
KVM Rear Kit
-MU1604 / -MU3204
back
back
back
back
back

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.13
Matrix Cat6 KVM
-MU1602
-MU3202
-MU1603
-MU3203
Power
Remote Console 1
Cascade
Remote Console 1
Remote-2
-MU1604
-MU3204
Remote Console 1
Remote-2
Remote-3
CascadePower
CascadePower

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.14
Matrix Cat6 KVM
< 2.2 > KVM port & Cat6 dongle connection
Resolution Support Frequency
( Hz )
1920 x 1080 60
1600 x 1200 60
1440 x 900 60
1280 x 1024 60
1024 x 768 60 / 70 / 75
Cat6 Dongle
Drawer KVM Rear Kit
Cat6 KVM port
CAT 5 / 6 cable
max. 40 meters
CAT 5 / 6 cable
max. 40 meters
Servers
Servers
DG-100S
DG-100C
DG-100SD
DG-100P
DG-100H
USB
USB-C
DP
USB
HDMI
USB
DVI-D
USB
VGA
DG-100P
DP-USB dongle
DG-100H
HDMI-USB dongle
DG-100SD
DVI-USB dongle
DG-100S
VGA-USB dongle
DG-100C
USB-C dongle

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.15
Matrix Cat6 KVM
Resolution Support Frequency
( Hz )
Max. Cat6 Cable
Length ( M )
1920 x 1080 60 50
1920 x 1200 60 50
1600 x 1200 60 100
1440 x 900 60 100
1280 x 1024 60 150
1024 x 768 60 / 70 / 75 150
Remote Console
For remote console, max. cable length is subject to the resolution.
Please refer to the tables below.
< 2.3 > Remote console connection
Drawer KVM Rear Kit

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.16
Matrix Cat6 KVM
Drawer KVM Rear Kit
VGA
Power KB
Mouse
Local
Computer Remote I/O
Front
Remote
LED
Local
LED
Rear
Select button
Receiver
12V DC Power
Adapter
CE-6
Combo
KVM cable
Local computer
( Optional setup )
Monitor
VGA
cable
Remote
Console
The receiver provides a hotkey function for remote console. Please refer to P.21
Front
Cat6 cable
up to 150m
How to use a receiver to connect a remote console

UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.comP.17
Matrix Cat6 KVM
Cascade
CMC-8
■ 8ft Matrix KVM cascade cable
MU-1602
MU-1602
MU-1602
MU-1602
MU-3202
MU-3202
MU-3202
Master KVM
To cascade OUT port
Drawer KVM Rear Kit
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
Standalone KVM
■ Cascade up to 8 levels, 256 servers
■ Cascading multiple KVM with CMC-8 cascade cable.
< 2.4 > KVM Cascade
Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602.
When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other
Expansion KVM switches (e.g. level 2 to 8).
The slave matrix KVM will be as a port expansion module of the master matrix KVM, the original
remote console on Expansion KVM will be sacrifi ced and disabled.
Expansion KVM
level 2
Expansion KVM
level 8
Expansion KVM
level 7
Expansion KVM
level 6
Expansion KVM
level 5
Expansion KVM
level 4
Expansion KVM
level 3
This manual suits for next models
9
Table of contents
Other Austin Hughes Network Hardware manuals
