AUSTRALIAN MONITOR AMIS SC2 Reference manual

AMISSC2
2 Way Stereo Converter
Introduction
The Australian Monitor Installation Series SC2, 2 Way Stereo Converter
converts consumer level signals to professional level & vice versa. Input 1
will convert a pair of professional balanced XLR signals to a consumer
level stereo RCA signal & input 2 will convert a consumer level stereo RCA
signal to a pair of professional level balanced XLR signals. Each stereo
path has its own volume control & the AMIS SC2 is powered by a supplied
12 VDC power supply. As part of the AMIS Contractor Tools range, the
AMIS SC2 is an inexpensive stereo converter that has a multitude of uses in
a wide variety of installations.
Description
Front Panel
•Power LED: This LED indicates the unit is “on”
•Input 2 RCA to XLR Level: This controls the level of the input 2 stereo
RCA’s to output 2 stereo XLR’s.
•Input 1 XLR to RCA Level: This controls the level of input 1 stereo
XLR’s to output 1 stereo RCA’s.
•Input 2 Stereo RCA’s: These -10dB RCA inputs are for connection
from consumer level source output, such as a cassette deck or CD
player.
•Output 1 Stereo RCA’s: These -10dB RCA inputs are for connection to
consumer level source output, such as a cassette deck or video
recorder.
Back Panel
•12VDC Power input: This input accepts power from the supplied
12VDC power supply. Note that the tip is Negative.

•Output 2 Balanced XLR Outputs: These +4dB balanced outputs are
for connection to professional mixing consoles, recording
equipment signal processors etc.
•Input 1 Balanced XLR inputs: These +4dB balanced inputs are for
connection from any professional level source, such as a mixing
console.
Specifications
Maximum Output Level: Balanced; +20dBu, Unbalanced; +14dBu
Maximum Input Level: Balanced; +24dBu, Unbalanced; +24dBu
Noise Floor: -86dBu
THD: .003%
Gain: Balanced In; -8dB Unbalanced In; +20dB
Dimensions: 143mm x 93mm x 45mm
Weight: 527g
