austriamicrosystems AS1323 Installation and operating instructions

AS1323 - Evaluation Board
Application Note
www.austriamicrosystems.com Revision 1.00 1 - 4
AS1323
Evaluation Board Application Note

AS1323 - Evaluation Board
Application Note
www.austriamicrosystems.com Revision 1.00 2 - 4
General Description
Board Description
Figure 2: Board Description
Figure 1: Board Description
Connector Description
Label Name Description Info
A VBatt Input Voltage
B GND Ground
C GND Ground
Input voltage ranging from 0.7V to 5V.
GND “B” & “C” are connected together.
D SDI Shutdown Input 0: Shutdown mode
1: Normal operating mode
D VOUT Power Output Connector
Jumper Description
Label Name Description Info
F
VBatt
SDI
GND Enable Jumper
Normal operating mode
Use connector SDI “D” for shutdown
Shutdown mode
Measurement Points Description
Label Name Description Info
J GND
G VBatt Power Supply Connectors for
VBATT and Ground.
H Coil External Conductor
I Vout Power Output Connector
Operational sequence
This evaluation board comes with the AS1323 soldered on. The output voltage is set to the default 2.7, 3.0 or
3.3V depending on the evaluation board ordered. For information which part is soldered on your board please
see the ordering information in the datasheet for the chip marking.
1. If not present get the datasheet for the AS1323 from www.austriamicrosystems.com. Drive the IC on the
Demoboard only with the recommended settings and values as described in the datasheet.
2. Connect a +0.7V to 2V power supply (VBatt “A” and GND “B”).
3. Perform measurements at the measurement points “G” to “J”.
If there are questions do not hesitate to contact us. See contact information at the end of the application note.

AS1323 - Evaluation Board
Application Note
www.austriamicrosystems.com Revision 1.00 3 - 4
Layout of evaluation board
Board schematics and layout
Figure 3: Schematics
Figure 4: Top view Figure 5: Bottom view
Assembly List
Label Info Type Manufacturer
CIN 10V 10uF X7R 10% GRM21BR71A106KE51 Murata
COUT 10V 10uF X7R 10% GRM21BR71A106KE51 Murata
L1 10µH, 350mΩ, 1.3A LPS4012-103MLB Coilcraft
