Auto Mate 4105A User manual

OWNER'S GUIDE
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
www.automatecarsecurity.com MODEL
4105A
The company behind AUTOMATE®Auto
Security and Remote Start Systems is Directed.
Since its inception, Directed has had one
purpose, to provide consumers with the finest
vehicle security and accessories available. The
recipient of nearly 100 patents and Innovations
Awards in the field of advanced electronic
technology.
Quality Directed products are sold and serviced
throughout North America and around the
world.
Call [phone] for more information
about our products and services.
Vista, CA 92081
G4105A ML 2016-05
©2016 Directed. All rights reserved.

i
© 2016 Directed. All rights reserved.
Congratulations
Congratulations on the purchase of your state-of-the-art keyless entry
and remote start system. Reading this Owner’s Guide prior to using
your system will help maximize the use of your system and its many
features. For more information please visit us online (see back cover
for URL). For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600. (U.S. only) or
1-800-361-7271 (Canada only). Additional support is also available
at: http://support.directed.com
Important Information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
This product is designed for fuel-injected, automatic trans-
mission vehicles only. Installing it in a standard transmis-
sion vehicle is dangerous and is contrary to its intended
use. If your vehicle is equipped with a manual transmis-
sion cease use of this product and immediately return the
vehicle to an authorized Directed dealer.
G4105 2016-06

ii © 2016 Directed. All rights reserved.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an authorized
Directed dealer.
Replacement remote controls
Please see your authorized dealer or visit us at www.directedstore.com
to order additional remote controls. Remote control part numbers are
found on the back of the device.

Contents
Congratulations ................................................................................................i
Important Information .........................................................................................i
Government Regulations and Safety information ...........................................i
Your Warranty..........................................................................................ii
Replacement remote controls ......................................................................ii
Remote Control .................................................................................................3
Remote Control Functions ...................................................................................3
Standard Configuration .............................................................................3
Using the System .............................................................................................6
Locking....................................................................................................6
Unlocking ................................................................................................6
Disabling (optional) Starter Disable ............................................................6
Panic Mode .............................................................................................6
Remote Start.............................................................................................7
Key Takeover............................................................................................8
Safety Features.........................................................................................9
Pit Stop....................................................................................................9
Car Finder .............................................................................................10
Optional Starter Anti-Grind Circuitry .........................................................10
Disabling the Remote Start System/Garage Mode ......................................10
Remote Start Diagnostics .........................................................................11
Pairing a Remote Control .................................................................................12
Programming Options......................................................................................13
Rapid Resume Logic .......................................................................................13
Battery Information..........................................................................................14
Replacing the Battery ..............................................................................14
Battery Disposal .....................................................................................14
Patent Information ...........................................................................................15
Government Regulations ..................................................................................16
Warning! Safety first .......................................................................................17
Installation .............................................................................................17
Remote Start Capable .............................................................................17
Interference............................................................................................18
Upgrades ..............................................................................................18
Water/Heat Resistance ...........................................................................18
Limited lifetime consumer warranty ....................................................................19

3
© 2016 Directed. All rights reserved.
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
AUX
AUX
Used to perform:
Locking
Unlocking
Remote Start
Silent mode/Auxiliary channel*
* On some remote controls, the
AUX
AUX
icon may exist instead of the
icon. This guide uses the icon throughout, but function-
ality is the same regardless of which one of these icons is used
with your system.
Remote Control Functions
The remote buttons are used to send commands to the system. The but-
tons indicated below are for standard configuration.
Standard Configuration
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
Button
The lock function is controlled by pressing
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
on the remote control
for one second. When held for approximately two seconds, Panic is
activated.

4© 2016 Directed. All rights reserved.
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
Button
The unlocking function is controlled by pressing
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
on the remote con-
trol for one second. You can also turn Panic off with this button.
Button
Silent Mode™and an optional auxiliary function are controlled by
pressing . Silent Mode works by pressing for less than one
second before locking or unlocking. An optional auxiliary function such
as trunk release may be controlled by pressing and holding for
approximately two seconds.
AUX
AUX
Button
The remote start function of your system is controlled by pressing this
button for one second.
AUX
AUX
and Buttons
Car Finder is controlled by pressing these two buttons.
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
and
AUX
AUX
and Buttons
When simultaneously pressed these buttons control the optional rear
window defogger during remote starting. The parking lights flash three
times to confirm activation. Once activated, the defogger will turn on
whenever the vehicle is remote started.
The parking lights flash twice when the defogger is deactivated. The
defogger does not turn on when the vehicle is remote started.
Important note: Defogger is an optional feature. Additional parts and
labor may be required. See your Directed dealer for details.

5
© 2016 Directed. All rights reserved.
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
and
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
Buttons
Timer Mode is activated when these buttons are pressed simultaneously.
When you activate Timer Mode the parking lights flash four times, after a
one second delay the engine starts. To turn the engine off, without exiting
Timer Mode, press the
AUX
AUX
.
The system remains in Timer Mode and will start every three hours for a
maximum of six starts unless cancelled by turning on the ignition, or by
activating any of the shutdown inputs to the system.
The parking lights flash four times indicating Timer Mode is exited.

6© 2016 Directed. All rights reserved.
Using the System
Locking
Pressing
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
for one second locks the system (if the door locks are con-
nected). The horn honks and the parking lights flash once to confirm
the system is locked. The Failsafe®Starter Disable also activates and
prevents the vehicle’s starter from cranking.
Important note: Horn honk and Failsafe are both optional features.
Unlocking
Pressing
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
for one second unlocks the doors (if connected). The horn
honks twice and the parking lights flash twice to confirm unlocking of
the system. The Failsafe Starter Disable (if connected) is deactivated.
Disabling (optional) Starter Disable
If your remote control is lost or damaged, you can manually override
the Starter Disable. To do this, you must have the vehicle's ignition key
and know where the Valet button is located. Be sure to check with the
installer for the location of the Valet button.
To override the Starter Disable, turn the ignition on and press and re-
lease the Valet button within 10 seconds. The vehicle should now start.
If it does not start, you may have waited too long; turn the ignition off
and repeat the process.
Location of Valet button: ____________________
Panic Mode
If you are threatened in or near your vehicle, you can attract atten-

7
© 2016 Directed. All rights reserved.
tion by triggering the system with your remote control. Press
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
for
approximately two seconds to enter Panic Mode. In Panic Mode, the
horn will honk and the parking lights will flash for 30 seconds. To stop
Panic Mode at any time, press
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
, or
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
on the remote control.
Note: In order for Panic Mode to be effective, the vehicle’s horn (or
optional siren) and the vehicle's parking lights must be connected.
Remote Start
This feature allows you to remotely start and run your vehicle for a
programmable period of time. This makes it possible to warm up the
engine, and adjust the interior temperature of the vehicle with the cli-
mate control system. If interior heating or cooling is desired, the climate
controls must be preset, and the fan blower must be set to the desired
level prior to remote starting the vehicle.
Satmode,
bank selector
AUDIO
PWR
12
REWFF
PLAY/PROG NR
3456
DISC- DISC+
11:53
XM1-1 CH-001
CH
VOL
SCAN SOUND
AM/FM
CD/AUX
SAT
RADIO
SEEK
SKIP
RPT
DISP -
MODE
A.SEL
RDM
TUNE
AUTO
OFF
DUAL
A/C MODE
Channel control
Category
Control
Text selector.
Hold for 10secto toggle
channelor category
tune modes.
Toggles
Scan mode
Bank and
present
indicator
Channel
and text
indicator
Preset 1-6.
Hold until beepto
savetoapreset.
CATEGORY
Tune mode
indicator
MODE
DUAL
OFF
AUTO
MAP/
GUIDE MENU SETUP
INFO ZOOM CANCEL AUDIO
AUTO
MODE
A/C
LOAD
DISC
TAPE AM/FM DISP
MODE
SCAN RPT A.SEL/RDM-SEEK +
1234 56
DISC- DISC+
VOL
PWR
PUSH
TUNE
SOUND
PUSH
XM1-1
VOL
CH
CHANNEL
CATEGORY
NAME
TITLE
:
:
:
:
1
CH
2
CH
3
CH
6
CH
5
CH
4
CH
MODE SCAN SOUND
001-HITS1
POP
MUSICNAME
MUSIC TITLE
Channel control
Category
Control
001 014 018
040 065 115
Toggles between
channel and
category modes
Bank and
present
indicator
Upper display
text mode
selector
Sat mode
and bank
selector
Preset 1-6.
Press until
beepto save
to a preset.
Channeland text
Indicator fields
Toggles
Scan mode
Tune mode
indicator
ANTENNA
SC OUTPUT
Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda Bus Compatible Translator
Headunit bus cableSiriusConnect Cable
HON-SC1
Honda Bus
Compatible
Translator
Warning! (1) Never remote start your vehicle
when the keys are in the ignition, except when
performing Valet®Takeover, and (2) Never start the
vehicle if it is not in PARK.
To remote start the vehicle:
1. Make sure the parking brake is set. Press the
AUX
AUX
button on the
remote control once* (or the amount of times the system has been
programmed to activate the remote start).
2. The parking lights flash to confirm that the vehicle is attempting to
start. In gasoline vehicles the engine will start four seconds after
the parking lights flash, in diesel vehicles the engine starts after the
WAIT-TO-START timer has expired.
3. Once the vehicle has started, it will run for the pre-programmed
period of time (12, 24, or 60 minutes) or until a shutdown input
is triggered.

8© 2016 Directed. All rights reserved.
* The factory setting is one press but this can also be programmed for
two or three presses maximum (see your authorized Directed installer
for the amount of presses programmed).
Record the number of presses to activate remote start here:____
If the engine fails to start, refer to "Disabling the Remote Start System"
and "Remote Start Diagnostics" sections of this guide.
Satmode,
bank selector
AUDIO
PWR
12
REWFF
PLAY/PROG NR
3456
DISC- DISC+
11:53
XM1-1 CH-001
CH
VOL
SCAN SOUND
AM/FM
CD/AUX
SAT
RADIO
SEEK
SKIP
RPT
DISP -
MODE
A.SEL
RDM
TUNE
AUTO
OFF
DUAL
A/C MODE
Channel control
Category
Control
Text selector.
Hold for 10secto toggle
channelor category
tune modes.
Toggles
Scan mode
Bank and
present
indicator
Channel
and text
indicator
Preset 1-6.
Hold until beepto
savetoapreset.
CATEGORY
Tune mode
indicator
MODE
DUAL
OFF
AUTO
MAP/
GUIDE MENU SETUP
INFO ZOOM CANCEL AUDIO
AUTO
MODE
A/C
LOAD
DISC
TAPE AM/FM DISP
MODE
SCAN RPT A.SEL/RDM-SEEK +
1234 56
DISC- DISC+
VOL
PWR
PUSH
TUNE
SOUND
PUSH
XM1-1
VOL
CH
CHANNEL
CATEGORY
NAME
TITLE
:
:
:
:
1
CH
2
CH
3
CH
6
CH
5
CH
4
CH
MODE SCAN SOUND
001-HITS1
POP
MUSICNAME
MUSIC TITLE
Channel control
Category
Control
001 014 018
040 065 115
Toggles between
channel and
category modes
Bank and
present
indicator
Upper display
text mode
selector
Sat mode
and bank
selector
Preset 1-6.
Press until
beepto save
to a preset.
Channeland text
Indicator fields
Toggles
Scan mode
Tune mode
indicator
ANTENNA
SC OUTPUT
Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda Bus Compatible Translator
Headunit bus cableSiriusConnect Cable
HON-SC1
Honda Bus
Compatible
Translator
Warning! It is unsafe to operate a vehicle's motor in a
garage or other closed off area. Such operation can
create a buildup of harmful gas. Breathing the exhaust
from the vehicle is hazardous and may lead to injury
or death.
Key Takeover
When you are ready to drive the vehicle:
1. Unlock the doors.
2. Enter the vehicle. Do not step on the foot brake.
3. Insert the key, turn it to the RUN (not START) position. Step on the
foot brake. The remote start is disabled and the parking lights turn
off.
4. Disengage the parking brake and begin driving.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.

9
© 2016 Directed. All rights reserved.
Safety Features
The following safety features will disable the remote start when acti-
vated or not allow the engine to start if not properly set before starting.
• Foot Brake is depressed.
• Hood is opened.
• Garage Mode is ON (see Disabling the Remote Start System).
• The pre-programmed run time (12, 24 or 60 minutes) has elapsed.
• Remote Start activation procedure is repeated.
• Parking brake is disengaged.
• Engine over-rev protection (Tachometer mode only).
•
Pit Stop
This remote start can keep the engine running during short trips away
from the vehicle.
To enable Pit Stop Mode:
1. Park in a well ventilated area.
2. With the engine running, set the transmission in the park position
and ensure the parking brake is set.
3. Press and release the
AUX
AUX
button once (or the amount of times the
system has been programmed to activate the remote start), the
parking lights turn on to confirm.
4. Turn off the ignition and remove the key, the engine continues
running.
5. Exit and secure the vehicle, the engine runs for the programmed
runtime.
Important: This feature will not work if the brake pedal is being pressed.

10 © 2016 Directed. All rights reserved.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Car Finder
Car finder allows you to locate your vehicle, by having the system flash
the parking lights.
To activate:
1. Press and release the
AUX
AUX
and buttons at the same time.
2. The parking lights flash slowly several times, allowing you to lo-
cate your vehicle.
Optional Starter Anti-Grind Circuitry
This system includes an anti-grind circuit that can prevent damage to
the starter motor if the key is turned to the start position while the remote
start is ON.
Note: Anti-grind circuitry only works if an optional relay has been add-
ed and the vehicle is remote started.
Disabling the Remote Start System/Garage Mode
Garage Mode is a safety feature that disables the remote start system if
the vehicle is parked in a garage, being serviced, or used by someone
unfamiliar with remote start systems.
When Garage Mode is ON, any attempt to start the engine, activate
Timer Mode, or enter Pit Stop mode is denied and remote start diag-
nostics flashes the parking lights nine times.

11
© 2016 Directed. All rights reserved.
Turn Garage Mode ON or OFF:
1. Turn the ignition on then off.
2. Within 10 seconds, press and release the Valet button once.
3. The parking lights flash:
• Nine times quickly when turning on.
• Nine times slowly when turning off.
Remote Start Diagnostics
For user safety, the system must be properly configured or remote start
will not activate. A Remote Start Fault may be caused by any of several
configuration issues. If the remote start fails to activate, refer to the table
below for the command type and parking light flashes that will identify
the configuration issue and solution.
Light Flash Problem Solution
5 flashes Brake is on Release the foot brake
6 flashes Hood is open Close the hood
8 flashes Neutral safety is disconnected Set the parking brake or move
the shifter to the park position
9 flashes Garage Mode is ON Turn Garage Mode OFF

12 © 2016 Directed. All rights reserved.
Pairing a Remote Control
Your system comes with the remote controls already programmed, how-
ever, if you are replacing or adding additional remote controls, they
must be paired to the system prior to operating the system. To pair the
remote, you need to know where the Valet button is located. If the horn
honk is not connected, the main unit LED needs to be visible for visual
confirmation. If you cannot locate or access the main unit, it is recom-
mended that you visit your authorized dealer to pair the remote. The
system is capable of accepting up to four remote controls.
1. Turn key to the ON position
2. Within 10 seconds, press and release the Valet button once.
3. Within 10 seconds, press and hold the Valet button. The LED on
the module flashes one time and the horn (if connected) honks to
confirm entry into remote pairing. Do not release the Valet button.
4. Press the
AUX
AUX
AUX
Your1-way remote coin cell battery can be changed by using a small at blade screwdriver to pry case apart. Replace battery and then snap case together.
button on the remote control. The horn honks to con-
firm the remote has been paired.
5. Release the Valet button.
6. Turn the key to OFF position. The horn sounds one long honk (if
connected) to confirm that remote pairing has exited.
The programming routine exits if any of the following occurs:
• The ignition is turned off.
• There is no activity for 30 seconds.
• The Valet button is pressed too many times.

13
© 2016 Directed. All rights reserved.
Programming Options
Feature options will control your system's normal operation. Some op-
tions may require additional parts and installation labor. The following
is a list of the programmable options with the factory settings in bold.
• 12 minute to 60 minute runtime. Your system can be programmed
to allow the vehicle to run for up to 60 minutes when remote
started. This can be set up to minute increments by your installer.
• Parking lights flashing or constant. Your system can be programmed
to flash the parking lights or have them come on constantly during
the remote start operation.
• Ignition controlled door locking ON or OFF. With this feature on,
the doors will lock three seconds after the ignition key is turned on,
and will unlock when the ignition key is turned off.
Important: The door lock option must be installed for the ignition
controlled door lock feature to work.
Rapid Resume Logic
This Directed system stores its current state to non-volatile memory. If the
power to the system is disconnected and then reconnected, the system
recalls the stored state from memory.

14 © 2016 Directed. All rights reserved.
Battery Information
The remote control* is powered by two 3V, CR2016 batteries. When
the battery begins to weaken, operating range is reduced and the LED
on the remote control dims.
* Some remote controls are powered using a single coin cell battery
(CR-2032), so please verify which type and quantity is used before
replacing.
Replacing the Battery
1. Use a small flat blade (flat-head) screwdriver and insert it into the
slot located along the bottom of the remote, near the key ring.
Carefully pry open the case.
2. Remove the old batteries from the holding clip. Orient the new
batteries for the correct polarity and insert into the holding clip.
3. Reposition the case parts, then snap together by pressing firmly
and evenly on the front and back.
Battery Disposal
Directed cares about the environment. If you need to dispose
of the battery, please do so in accordance with your munici-
pal requirements for battery disposal.

15
© 2016 Directed. All rights reserved.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.

16 © 2016 Directed. All rights reserved.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with the Industry Canada Radio Standards Specification
RSS 210. Its use is authorized only on a no-interference, no-protection basis; in
other words, this device must not be used if it is determined that it causes harm-
ful interference to services authorized by IC. In addition, the user of this device
must accept any radio interference that may be received, even if this interference
could affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.

17
© 2016 Directed. All rights reserved.
Warning! Safety first
Please read the safety warnings below before proceeding. Improper use of the
product may be dangerous or illegal.
Installation
Due to the complexity of this system, installation of this product must only be performed
by an authorized Directed dealer. If you have any questions, ask your retailer or contact
Directed directly at 1-800-753-0600.
Remote Start Capable
When properly installed, this system can start the vehicle via a command signal from
the remote control. Therefore, never operate the system in an enclosed area or partially
enclosed area without ventilation (such as a garage). When parking in an enclosed or
partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the "Disabling the Remote Start System/Garage Mode" procedure in
this guide. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote control devices to assure that the system does not unintentionally remote
start the vehicle. IT IS RECOMMENDED THAT THE USER INSTALL A CARBON MONOX-
IDE DETECTOR IN THE LIVING AREAS ADJACENT TO THE VEHICLE. ALL DOORS LEAD-
ING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED
VEHICLE STORAGE AREA MUST BE CLOSED AT ALL TIMES. These precautions are the sole
responsibility of the user.
Use of this product in a manner contrary to its intended mode of operation may result in
property damage, personal injury, or death. (1) Never remotely start the vehicle with the ve-
hicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user
must also have the neutral safety feature of the vehicle periodically checked, wherein the
vehicle must not remotely start while the car is in gear. This testing should be performed by
an authorized Directed dealer in accordance with the Safety Check outlined in the product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to fix the problem.
After the remote start module has been installed, contact your authorized dealer to have him
or her test the remote start module by performing the Safety Check outlined in the product
installation guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit
