MEGATRONIX Megalarm MEGA 2500 User manual

MEGA 2500 OPERATE
1
MEGA 2500
2-WAY LCD 4-CHANNEL
CAR ALARM SECURITY SYSTEM
Operation Manual
MEGATRONIX
CALIFORNIA, U.S.A.

MEGA 2500 OPERATE
2
OPERATION:
TRANSMITTER OPERATION:
Transmitter Button
System Function
Remark
Lock Doors and Arm System
-
Arm and Delete the 2 Stage Shock Sensor
Press twice within 3 seconds
- -
Arm and Noiseless Mode
Press within 3 seconds
-
Arm System and Hidden Alarm Function
Press within 3 seconds
+
Silent Arming / Disarming
Ignition in "off" position.
+ (2-second)
Active Anti Car-Jacking Mode
Ignition in "on" position press and
hold for 2 seconds
Unlock Doors and Disarm System
-
2-Step Door Unlock and Disarm System
Press twice within 3 seconds
(2-second)
Trunk Release (Channel 3)
Press and Hold for 2 seconds
-
Passive Arming By-pass
While the system is disarmed
- -
Remote Control Entry/Exit Valet Mode
While the system is disarmed
Press within 3 seconds
+
Channel # 4 Timer Output
Car Locator
(3-second)
Panic function
Press and Hold for 3 seconds
B.LED INDICATORS:
LED
Status
LED
Status
Off
Disarmed
2 flashes... pause
Zone 2 / Trigger on Trunk/Hood
Slow flash
Armed
3 flashes... pause
Zone 3 / Trigger on Door Switch
Fast flash
Passive arming
4 flashes... pause
Zone 4 / Trigger on Shock Sensor
On (solid)
Valet mode
5 flashes... pause
Zone 5 / Trigger on Ignition Switch
C. CHIRP INDICATORS: D. PARKING LIGHT:
Chirp
Function
Parking light
Function
1 chirp
Arm
1 flash
Arm
2 chirps
Disarm
2 flashes
Disarm
3 chirps
Ajar Warning
3 flashes
Triggered
6 chirps
Car locator
12 flashes
Car locator
E. SYSTEM OPERATING CONDITION:
Siren, Horn
Parking Light
LED
Doors
Starter
Dome Light
1. Arming
1 or 3 Chirps
1 Flash
Slow Flash
Locking
Disable
2. Disarming
2 or 4 Chirps
2 or 3 Flashes
Fast Flash or
Off
Unlocking
Turns on for
30 -second
3. Trigger
Alarming
Flashes
Slow Flash
Disable
Flashes
4. Panic
Alarming
Flashes
Flashes
5. Car-Jacking
Alarming
Flashes
Disable
Flashes
6. Car Locator
6 Chirps
12 Flashes
F. ACTIVE ARMING –LOCK & ARM:
1. Press button on the transmitter.
2. The siren will chirp once and parking light will flash once indicating that the system is now armed. The
vehicle doors will lock upon arming when interfaced with the security system.
AJAR WARNING: If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid ajar. (See
Alarm Feature “I - 4 Programming)
SILENT ARMING / DISARMING: Press the and buttons at the same time on the transmitter will
arm or disarm your security system, No chirp sounds will be heard, arm / disarm confirmation will be
through the vehicles parking lights only.
SHOCK SENSOR BY-PASS: Press the button on the transmitter twice within 3 seconds will arm the
security system and bypass the shock sensor. The system will chirp one additional time to confirm the
sensor bypass mode was activated. The sensor bypass feature is programmed to activate for one arming
cycle only. The security system will return to normal operation during the next arming cycle.
NOISELESS MODE: Press button once. The siren chirps once, the system is now armed.

MEGA 2500 OPERATE
3
Press the button twice more within 3 seconds: The siren chirps once again, the system is now in
Noiseless mode. On this mode, for the zone 4 shock sensor, the trigger timer will reduced from 30
seconds to 15 seconds.
The noiseless feature is programmed to activate for one arming cycle only. The security system will return
to normal operation during the next arming cycle.
HIDDEN ALARM FUNCTION: Press the button first; within 3 seconds press the button to
activate the hidden alarm function. The security system will arm and with “Hidden Alarm Function”. The
siren / horn will be silenced even if the sensor is triggered in the armed status.
G. PASSIVE ARMING: (See Feature “II - 2” Programming):
Active arming / disarming will allow you to control your security system via the remote transmitter. This
security system is equipped with an optional Passive Arming feature, which allows the security system to
arm 30 seconds after the last door is closed. Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you reopen any
door / hood / trunk, the security system LED will stop flashing. It will begin flashing again once the
vehicle all entrances are closed.
3. After 30-second time has elapsed, the security system will automatically “ARM”. The siren will chirp [1]
time and the parking lights will flash [1] time and remain on for 10-seconds.
PASSIVE ARMING WITH PASSIVE DOOR LOCKING: (See Feature “II - 2” Programming)
The vehicle doors will automatically lock after passive arming cycle has been completed.
PASSIVE ARMING BY-PASS: While system disarmed, press button twice security will respond
with [1] chirp and LED will turn “ON”. Security system will remain in this temporally state for as long as
you wish. To exit passive bypass, press transmitter or button and system will return to normal.
H. ACTIVE DISARMING –UNLOCK & DISARM:
1. Press button on the transmitter.
2. The siren will chirp twice and parking light will flash twice and then remain on for 30 seconds indicating
that the security system is now disarmed. The vehicle doors will unlock and dome light wills turns on for
30 seconds upon disarming when interfaced with the security system.
TAMPER DISARM: If alarm triggered, when disarm system, siren chirp 4 times, parking light flash 3 times.
PATHWAY ILLUMINATION (See Alarm Feature “II - 4” Programming): This feature turns the parking
light “ON” for 30 seconds upon a unlock signal and for 10 seconds upon the lock signal.
TWO STEP DOOR UNLOCK: This feature will independently unlock drives door only when disarming
security system. Pushing button on transmitter second time within 3 seconds will unlock entire vehicle.
AUTOMATIC RE-ARM (See Feature “I - 2” Programming): If this feature is selected, the security system
will automatically re-arm itself 60 seconds after disarming with remote transmitter. Automatic rearm will
cancel if any door is opened before the 60 seconds timer has elapsed.
I. DISARMING WITHOUT A TRANSMITTER:
OVERRIDE THE ALARM WITHOUT PASSWORD PIN CODE: (Factory Default Setting):
The Override function may be used if the remote transmitter is lost or inoperative.
1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will sound.)
2. Within 10 seconds push and release the valet switch.
Alarm will stop sounding and enter disarm mode. You can now start and operate the vehicle normally.
OVERRIDE THE ALARM WITH PASSWORD PIN CODE: (Alarm Feature IV - 2Programming):
Unlike valet switch easily found, and defeated, this security system allows the consumer to program a
password pin code, offering a higher level of security.
1. Enter the vehicle and turn the ignition switch to the 'ON’ position. (Alarm will sound.)
2. Within 5 seconds, enter your chosen first 10ths digit by pressing and releasing the valet switch.
3. Within 15 seconds of the last entered 10ths digit, turn the Ignition switch “OFF” then “ON”.
4. Within 15 seconds, enter your chosen second 10ths digit by press and release the valet switch.
5. Turn the ignition switch “OFF” position.
[4] Chirps form siren/horn, [3] flash from parking light and LED will turn off to indicate system disarmed.
Note 1: You must override the alarm within 60 seconds. If not, the system will automatically re-arm.
EXAMPLE: To Override the System With The Password Code 83, you would;
1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will sound.)
2. Within 5 seconds, press and release the valet switch 8 times
3. Within 15 seconds of the last entered 10ths digit, turn the Ignition Switch “Off” then “ON”.
4. Within 15 seconds, press and release the valet switch 3 times
5. Turn the Ignition Switch to “Off” position.
[4] Chirps form siren/horn, [3] flash from parking light and LED will turn off to indicate system disarmed.

MEGA 2500 OPERATE
4
J. VALET MODE: (System in Disarm or Valet mode):
The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to hand your
transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm
functions are bypassed, however the remote panic feature and remote door locks will remain operational.
To use the valet mode, the system must first be disarmed either by using your remote transmitter, or by
operating the Manual override sequence.
Enter Valet Mode:
1. From the disarmed condition, turn the ignition to the “ON” position.
2. Push and hold the valet switch for 2 seconds until the LED turns on. The LED will remain on as long as
the system is in 'valet mode'.
Exit Valet Mode:
1. Return to normal operation, turn ignition 'on'.
2. Push and hold the valet switch for 2 seconds, LED will turn off to indicate system has exited valet mode.
Parking light flash to confirm enter valet mode and two parking lights flashing to confirm exit valet mode.
Remote Valet Mode:
1. Press and release button on transmitter three times within 3 seconds to enter or exit valet mode.
2. One parking light flash will confirm you have entered ‘valet mode’ and two parking light flashes will
confirm you exited ‘valet mode’.
K. CAR LOCATOR:
Press the button to activate car locator function. The siren will chirp 6 times. The parking light will
flash 12 times, for you to easily locate your car.
L. PANIC FUNCTION: (See Alarm Feature V –4 Programming):
The transmitter can be used as a remote panic switch to manually trigger the alarm in case emergency.
1. Press and hold the button for 3 second. The alarm will immediately sound.
2. During panic mode, the normal function of this transmitter button will be suspended. The and
buttons can be used to lock and unlock the doors (if the option is installed), however once the
button is pressed, the vehicle’s starter disable device, (where installed) will be enable allowing vehicle
to start.
3. To stop the alarm, press and hold the button on the transmitter again for 3 seconds. Also if any
transmitter button other than or or button is pressed and released, the panic mode will be
turned off immediately.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds.
M. TRIGGER THE SYSTEM:
When armed, your vehicle is protected as follows:
1. Light impacts will trigger the warn-away signal.
2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the ignition key will trigger the
programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren, horn, parking
lights, and dome light will turn on to alert of an intrusion for 30 seconds. Then it will stop and automatic
reset and re-arm. If the one of sensors or detectors is still active, the alarm system will sound a maximum
of 6 times of 30 seconds cycles.
STOP THE MELODY SOUND ONLY: While triggering the alarm the LCD screen will alert user through
melody sound and flashing trigger icon, press any button on the LCD remote transceiver to stop melody
sound only
NOISE ABATEMENT CIRCUIT: Your system has “Noise Abatement Circuit”. It prevents annoying
repetitive trigger sequences due to faulty door pin switches or environmental condition such as thunder,
jackhammers, airport noise, etc.
Here’s how “Noise Abatement Circuit” works: The alarm triggers five times. Each time the same sensor or
switch is triggering the alarm, the “Noise Abatement Circuit” will interpret this pattern of triggers or false
alarms. After the fifth trigger, “Noise Abatement Circuit” ignores, or by pass, that sensor or switch until the
other sensor or switch is trigger.
“Noise Abatement Circuit” covers doors, hood, and trunk differently: If the alarm is triggered by an open
door for six full cycles (three minutes), the doors will be bypassed until the trigger ceases.
N. ANTI CAR-JACKING:
Warning: If you do not need the carjacking function in this alarm system, be sure to set car-jacking
feature “OFF”. The default setting for this system is all car-jacking “OFF”. (See Alarm Feature I –4
Programming).
ACTIVE ANTI CAR JACKING:
1. Press and hold the transmitter and buttons at the same time for 2 seconds while the vehicle’s
ignition is ON. The parking lights will turns on for 1.5 seconds to indicate the system enters the
car-jacking mode.

MEGA 2500 OPERATE
5
2. Once the system in car-jacking mode, if you are forced from the vehicle, the system will be trigger when
the door is opened and closed while the ignition is “ON”.
PASSIVE ANTI CAR-JACKING:
1. Turn the ignition switch to “ON” position; the system enters the car-jacking mode.
2. Once the system in car-jacking mode, if you are forced from the vehicle, the system will trigger when
the door is opened and closed while the ignition is “ON”.
TRIGGER THE ANTI CAR-JACKING MODE:
a). 50 seconds after the system has been triggered. The siren will start chirping for 15 seconds.
b). During this 15 seconds period of chirping, are being alerted to push the valet switch once to turn off
the car-jacking feature. If not, it will enter the second timer carjacking.
c). 65 seconds after system has been triggered, siren starts alarming and parking light starts flashing.
d). 90 seconds after the system has been triggered:
1. The siren will continue alarming and the parking lights flashing, and
2. The starter disable will activate to prevent the vehicle from starting.
3. It will remain active until the vehicle's battery power is exhausted.
OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR- JACKING:
Turn the ignition switch from OFF to ON, and within 10 seconds push valet switch, the siren will stop and
the system disarmed
Note: If you use password pin code to protect vehicle security, you will need to use it to disarm system.
O. DOME LIGHT CONVENIENCE DELAY & SUPERVISION:
The alarm has a unique feature that will turn on your vehicle dome light as following:
1. Upon disarming, the interior lights will remain on for 30 seconds.
2. If the vehicle is intruded, the interior light will flash for the same duration as the siren.
Note: Turning ON the ignition switch or arming the alarm will turn off the dome light.
P. IGNITION CONTROLLED POWER DOOR LOCKS: (See Feature II –3 Programming):
1. Turn the ignition switch on and close all the vehicle’s doors. After 3 seconds, the system will
automatically lock the central locking system.
2. Turn the ignition switch off. The system will automatically unlock the central locking system.
Q. TRUNK RELEASE (Factory default setting) / CHANNEL 3 TIMER CONTROL
OUTPUT: (See Alarm Feature III –3 Programming):
Press and hold the button on transmitter for two seconds to remote control the trunk release or other
electric devices.
Channel 3 is user-programmable timer output. You may program the built-in timer to send a ground signal
for any time interval between 1 second and 2 minutes. For instance, this timer output may be used to turn
on the headlights, power windows, or sunroof.
Note: Factory default setting at 1-second pulse grounded for trunk release output.
R. CHANNEL 4 TIMER CONTROL OUTPUT: (See Alarm Feature III- 4 Programming)
Press the transmitter and buttons at the same time to active Channel 4 function. Channel 4 is
user-programmable timer output. You may program the built-in timer to send a ground signal for any time
interval between 1 second and 2 minutes. For instance, this timer output may be used to turn on the
headlight, power windows, or sunroof.
Note: Factory defaults setting at momentary output.
S. DRIVER PAGING / LOST AND FOUND: (For two-way transceiver operation only):
It is useful the event that someone wants to page the driver of the parked vehicle or someone cannot find
his LCD remote control transceiver.
Under the ignition switch “off” condition, press and hold the valet switch for 2 seconds to page the driver,
one chirp sound shall be emitted from the vehicle and the paging melody sound continues sounding from
you Remote LCD transceiver and CALL indication flashes on the LCD screen.
T. OUT OF RANGE INDICATION: (See Alarm Feature II –5 Programming):
If this feature is selected, the system will automatically check the range every 30 minutes after armed.
1. If user is within the range, the RANGE icon will display on the LCD screen.
2. If user is out of range, it has five short “bi” sounds and RANGE icon will disappear on the LCD screen.
Note: Programming “out of range indication”will decrease the life expectancy of battery
U. POWER ON MEMONRY:
This security system is equipped with circuitry that will allow the unit to remember its alarm state if the
power is lost and then reconnected.

MEGA 2500 OPERATE
6
LCD REMOTE TRANSCEIVER:
Note: If the system is interfered by stronger radio frequency around, sources of high voltage electric power
or such obstacles like tall buildings and so on, the transmission range may get shorter as the system
uses low output powered frequency.
A. BATTERY REPLACEMENT:
A 1.5V type AAA Alkaline battery powers the Remote Transmitter. When the power of the battery
weakens, an icon shall be displayed on the LCD screen. When the old battery is replaced to new
one, there will be beep sounds indicate the power is up.
Note: Press the button two times when the battery compartment is empty, then insert the new
battery.
REMOTE LCD ICONS WITH FUNCTION:
Door Lock
Your vehicle doors are locked
Door Unlock
Your vehicle doors are unlocked and
the system is disarmed
Armed Mode
Your vehicle is in armed mode
Valet Mode
All the function shall be temporarily on
hold.
Remote Transmission
You are transmitting the signal to
control unit
In –Range Indicator
You are within the remote control
range.
Trunk/Hood Trigger
Trunk or Hood is illegally opened
(Zone 2)
Door Open Warning
Doors are illegally opened (Zone 3)
Shock Sensor Trigger
Trigger on Shock Sensor (Zone 4)
Ignition Trigger
Trigger on Ignition Switch (Zone 5)
Warn Away trigger
Trigger on Shock Sensor (Zone 1)
Low Battery
You have to replace the battery of
remote control.
Vibration Mode
Remote Control vibrates when the
system is triggered
Driver paging / Lose and Found
Someone is paging you in front of your
vehicle
Power Save Mode
Save the battery power
Engine Running
Your vehicle's engine is running
PROGRAMMING OF THE LCD REMOTE TRANSMITTER:
NOTE: Press and hold all four remote control buttons simultaneously until one long beep is heard.
LCD PROGRAMMING MODE has now been entered.
Transceiver Button
System Function
Remark
PROGRAM MODE -
Switching code for 2nd / 1st Car
Operation
Press within 5 seconds
PROGRAM MODE -
Melody / Vibration Mode
Press within 5 seconds
PROGRAM MODE -
Power Save Mode
Press within 5 seconds
LCD screen lamp turns on for 5 seconds.
-+
System’s Status Check
Press within 3 seconds
-+
Clear the Flash Icon and Melody Sound
Press within 3 seconds

MEGA 2500 OPERATE
7
1. Second Vehicle Security Operation: Your remote transmitter can be utilized to control a second
vehicle security system. To program the remote control transmitter to a second vehicle, follow the
instructions for Transmitter programming. All programming parameters be the same except for the
following:
For Regular Remote Control Transmitter:
1. Prior to pushing any button on the transmitter. Press the Select II button first on the transmitter.
2. Once II button is pressed the LED on the transmitter will illuminate for 3.5 seconds to indicate the
second transmitter pin code has built-in.
3. While the LED is illuminated, press any button on the remote control transmitter to control a second
vehicle security system.
For 2-way LCD Remote Control Transceiver:
2nd Car Operation: While the “II”icon display on the LCD screen, you can remote control and
communicate with a second vehicle security system. It has two short “bi” sounds while pressing the
button of the LCD screen transceiver.
1. Press and hold all four remote control buttons simultaneously until one long
beep is heard. Programming has now been entered.
2. Within 5 seconds press & hold button until two beep sounds are heard & the
“II”icon will display on LCD screen indicating 2nd transceiver pin code has built-in.
3. To exit programming mode, take no action for five seconds. The remote control will
generate two long beeps to indicate programming mode has been exited.
Back to 1st Car Operation: You can remote control and communicate with a first vehicle security system.
It has one short “bi” sound while pressing the button of the LCD screen transceiver.
1. Press and hold all four remote control buttons simultaneously until one long
beep is heard. Programming has now been entered.
2. Within 5 seconds press and hold button until one beeping sound is heard.
3. To exit programming mode, take no action for five seconds. The remote control will
generate two long beeps to indicate programming mode has been exited.
2. Vibration / Melody Mode: It is useful when you are in a noisy place and difficult to hear beep sound
from the remote control as the remote control in this mode, vibrates it if your security system is triggered.
1. Press and hold all four remote control buttons simultaneously until one long
beep is heard. Programming has now been entered.
2. Within 5 seconds, press the button to select the mode of vibration or melody, the
icon will displayed on the LCD screen to show the LCD remote transceiver is on
vibration mode.
3. To exit programming mode, take no action for five seconds. The remote control will
generate two long beeps to indicate programming mode has been exited.
3. Power-Save Mode: While the power save mode, the LCD remote transceiver “sleep”until a button is
pushed, extending the life of battery. When power save mode is “Off”, the remote control will wake up
periodically to check for messages from the security module.
1. Press and hold all four remote control buttons simultaneously until one long
beep is heard. Programming has now been entered.
2. Within 5 seconds, press the button to toggle “On”or “Off”. The remote will beep
once for “On”, twice for “Off”. When power save mode is “On”, the icon on
the LCD screens to indicate entry the “power save mode”
3. To exit programming mode, take no action for five seconds. The remote control will
generate two long beeps to indicate programming mode has been exited.
4. Screen Lamp ON: Press the button once, the LCD screen lamp will turns on for 5 seconds
5. System’s Status Check: When you want to check the system’s present status through the LCD
screen, Press the transceiver button first, within 3 seconds press and buttons at the same
time. It responds with one melody sound, the LCD screen should be illuminated.
Note: If it has no responds then you are out of range.
6. Clear the Flash Icon and Melody Sound: Press the button first, within 3 seconds press and
buttons at the same time. It will clear the flash icon and melody sound on the LCD screen transceiver
7. Stop The Trigger Melody Sound: While triggering the alarm the LCD screen will alert user through
melody sound and flashing trigger icon, press any button on the LCD remote transmitter to stop melody
sound only, the remote control buttons will not send a command to the system.

MEGA 2500 OPERATE
8
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
