4100ES Network Display Units with SPS Power Supplies for 4120 Network
* Additional listings may be applicable; contact your local Autocall product supplier for the latest status.
UL, ULC Listed*
4100ES Fire Control Panels
AC4100-0036 Rev. 19 3/2018
Features
Compatible with 4120 Network.
NDU provides annunciation for up to 12,000 network points:
• The basic Network Display Unit (NDU) is a special purpose master
controller for 4120 networks that includes a 4120 modular network
interface card
• Combining a basic NDU with a Voice Command Center (VCC) provides
an additional separate Network node within the same cabinet for
control of Network level Emergency Voice/Alarm Communications
Equipment
Master Controller (top) bay:
• Master controller assembly with operator interface
• Enhanced CPU with dual configuration programs, convenient service
port access, and capacity for up to 12,000 points
• System power supply (SPS) and charger (9 A total) with on-board
programmable auxiliary output
• Operator interface that is conveniently color coded with raised
switches providing high confidence feedback
• Available with InfoAlarm Command Center expanded content user
interface (refer to data sheet AC4100-0045 )
• Construction that is optimized for easy installation, upgrade, and
maintenance
• Glass door (ordered separately) provides view of available operator
controls visible behind locked door
Standard addressable interfaces include:
• Remote annunciator module support via RUI (remote unit interface)
communications port
NDU field installed option modules include:
• DACT and City Connection
• Service modems for remote panel status inquiry
• RS-232 ports for printers or maintenance terminals
• Alarm relays and expansion power supplies
• SafeLINC Internet Interface
• Battery brackets for seismic area protection
For NDU with VCC:
• Optional features are similar to a networked fire alarm control panel
and an extensive list of modules are available for; initiating, notification,
and user interface
Listed to:
• UL 864, Fire Detection and Control (UOJZ), Smoke Control Service
(UUKL), Releasing Device Service (SYZV)
• UL 1076, Proprietary Alarm Units - Burglar (APOU)
• UL 2017, Process Management Equipment (QVAX), Emergency Alarm
System Control Units (FSZI)
• UL 1730, Smoke Detector Monitor (UULH)
• UL 2572, Mass Notification Systems (PGWM)
• CAN/ULC-S527 Control Units for Fire Alarm Systems (UOJZ7), Releasing
Device Service (SYZV7)
• ULC/ORD-C1076 Proprietary Burglar Alarm Units and Systems (APOU7)
• ULC/ORD-C100 Smoke Control System Equipment (UUKL7)
Figure 1: Network One-Line
Diagram Showing an NDU with VCC
Introduction
The 4100ES Network Display Unit
The 4100ES Network Display Unit is a 4120 network level annunciator
and manual system/point controller. It provides alphanumeric
annunciation for up to 12,000 Network points and/or point lists and
can be programmed to function as the network master controller for
Alarm Silence, Trouble Acknowledge, and System Reset. is a network
level annunciator and manual system/point controller. It provides
alphanumeric annunciation for up to 12,000 Network points and/or
point lists and can be programmed to function as the network master
controller for Alarm Silence, Trouble Acknowledge, and System Reset.

4100ES Network Display Units with SPS Power Supplies for 4120 Network
Page 2 AC4100-0036 Rev. 19 3/2018
4120 Network Overview
When connected to other 4120 network nodes, individual fire alarm
control panels become components of a distributed intelligence system.
Each panel that directly connects to the 4120 network is called a
network “node” and is capable of performing individual supervision and
control on its locally connected devices but has the ability to inform
the 4100ES NDU (as well as other network control panels) of point
status and panel condition. This allows system information to reach
the proper location for appropriate system response. Multiple 4100ES
NDUs (separately packaged) can be connected to a 4120 network to
duplicate common information at separate locations, or direct selected
information by type such as troubles, alarms, control, etc.
NDU with VCC Internal Module Bay Reference
Figure 2: NDU with VCC Internal Module Bay Reference
(exact layout is determined by specific system requirements)
NDU Module Bay Description
The NDU Master Controller Bay (top) includes a special purpose
system power supply with battery charger (SPS), the master controller
board, a 4120 modular network interface card, and operator interface
equipment similar to that used on the standard fire alarm control
modules. Slots 1 and 2 are available for single slot panel mounted
modules.
The NDU with VCC includes an expansion bay with separate master
controller board, 4120 modular network interface card, and a standard
SPS. This results in two separate network nodes residing within the same
cabinet.
In this bay (typically the second expansion bay), Slots 1 and 2 are
available for single slot panel mounted modules and optional LED/switch
modules can also be mounted.
The Battery Compartment (bottom) accepts two batteries, up to 50
Ah, to be mounted within the cabinet without interfering with module
space.
Refer to NDU with VCC Internal Module Bay Reference for typical three
bay cabinet module location.
Standard Module Details
NDU (top bay) master controller & motherboard includes a
master controller, master controller motherboard, 4120 Modular
NIC, and SPS power supply
• The master controller mounts in slot 4 of a two slot motherboard
(slots 3 and 4 of the master controller bay) and provides one RUI+
communications channel (Class B or Class A), available at slot 4. A 4120
modular network interface card is mounted in slot 3.
• The NDU bay RUI+ communications output (configurable for isolated
or un-isolated operation) supports up to 31 devices per master
controller at up to 2500 ft (762 m) for single run, or 10,000 ft (3048 m)
total if wiring is Class B and T-tapped. If more distance is required, up
to four total RUI channels are supported per master controller (up to
three A100-1291 RUI expansion modules may be added). A100-1291
provides un-isolated RUI communications.
• System power supply (SPS) is rated for 9 A total; includes battery
charger, one 2 A aux power output selectable for detector reset, door
holder, or coded output operation and expansion slot for one city
circuit (A100-6031 or A100-6032) or alarm/supv/tbl relay (A100-6033)
option. See data sheet AC4100-0031 for details.
• Outputs are power-limited, except for the battery charger
Note: SPS IDNet channel, NACs and aux relay are disabled in NDU bay.
VCC (expansion bay) includes a master controller, master
controller motherboard, 4120 Modular NIC and SPS power supply
with IDNet communication channel
• The master controller mounts in slot 4 of a two slot motherboard
(slots 3 and 4 of the master controller bay) and provides one RUI+
communications channel (Class B or Class A), available at slot 4. A 4120
modular network interface card is mounted in Slot 3.
• The VCC bay RUI+ communications output (configurable for isolated or
un-isolated operation) supports up to 31 devices per master controller
at up to 2500 ft (762 m) for single run, or 10,000 ft (3048 m) total
if wiring is Class B and T-tapped. If more distance is required, up to
four total RUI channels are supported per master controller (up to
three A100-1291 RUI expansion modules may be added). A100-1291
provides un-isolated RUI communications.
• System power supply (SPS) is rated for 9 A total; includes battery
charger, auxiliary power, auxiliary relay, three on-board NACs, and
provisions for either an optional city connect module or an optional
alarm relay module (see data sheet AC4100-0031 for details)
• Battery charger is dual rate, temperature compensated, and charges
up to 50 Ah sealed lead-acid batteries mounted in the battery
compartment (33 Ah for single bay cabinets); also is UL listed for
charging up to 110 Ah batteries mounted in an external cabinet (see
data sheet AC2081-0012 for details) includes battery charger status
and low or depleted battery conditions; status information provided to
the master controller for battery voltage, charger voltage and current,
actual system voltage and current, and individual NAC currents
• Battery and charger monitoring includes battery charger status and
low or depleted battery conditions; status information provided to the

4100ES Network Display Units with SPS Power Supplies for 4120 Network
Page 3 AC4100-0036 Rev. 19 3/2018
master controller includes analog values for: battery voltage, charger
voltage and current, actual system voltage and current, and individual
NAC currents
• Low battery cutout is selectable for each SPS power supply, Canadian
models are shipped selected, other models are shipped unselected is
selectable for detector reset, door holder, or coded output operation
• Outputs are power-limited, except for the battery charger
• 2 A auxiliary power output selectable for detector reset, door holder,
or coded output operation
Optional SPS modules (select one)
• Optional city connect module (A100-6031, with disc. switches, or
A100-6032, without disc. switches) can be selected for conventional
dual circuit city connections
• Optional alarm relay module (A100-6033) provides three C type relays
for alarm, trouble, and supervisory, rated 2 A resistive @ 32 VDC
Packaging Availability
• Modules are power-limited (unless specifically noted otherwise)
• Enclosure are available for one, two, or three bay sizes or for cabinet
rack mounting
• Additional cabinets can be mounted close-nippled for module
expansion
• NEMA 1/IP30 boxes, doors with tempered glass inserts, and dress
panels are available in platinum or red (ordered separately)
• Cabinet assembly design has been seismic tested and is certified to
IBC and CBC standards as well as to ASCE 7 categories A through F,
requires A100-7912 option for additional legacy card stabilizer brackets
and battery brackets as detailed on data sheet AC2081-0019
• Refer to data sheet AC4100-0037 for enclosure details
Software Feature Summary
• Selectable service override allows authorized operators to clear alarm
conditions during System Reset even if status has gone to trouble
before reset occurred
• Duplicate address error detection
• Convenient PC programming using a Microsoft Windows user interface
based program

Page 4 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Media Cards for 4120 Modular Network Interface Cards
For additional information on 4120 fire alarm products and specifications, refer to data sheet
AC4100-0056
.
Table 1: Media cards for 4120 Modular Network Interface Cards
Model Description Size Supv Alarm
A100-6056 Wired network media card
Select per network connection requirements;
mounts on the supplied modular network
interface card(s); up to two media cards are
required per network interface card; supports
Class B or X operation
N.A. 55 mA 55 mA
A100-6301 Left port, single-mode 4120 duplex fiber media
card N.A. 55 mA 55 mA
A100-6302 Right port, single-mode duplex 4120 fiber
media card N.A. 55 mA 55 mA
A100-6303 Left port, multi-mode 4120 duplex fiber media
card N.A. 55 mA 55 mA
A100-6304 Right port, multi-mode 4120 duplex fiber media
card
Select per network connection requirements;
mounts on the supplied modular network
interface card(s); up to two media cards are
required per network interface card; supports
Class B or X operation. Maximum of 1 left
port and 1 right port duplex fiber media card
per modular network interface card; field
connections require left port to right port
pairing. Order fiber media service kits for
retrofit jobs where ST connectors are already
installed (refer to data sheet AC4100-0056
for full fiber media module specifications and
retrofit information)
N.A. 55 mA 55 mA
Expansion Bay Module Loading Reference (exact locations are provided with shipped product)
Description Mounting
Terminal Block Module 4" x 5", 1 block
Class B Physical Bridge 2", 1 slot
Class X Physical Bridge 4", 2 slots
System or Remote Power Supply Blocks E, F, G & H ONLY
Expansion Power Supply Blocks G & H ONLY
Audio Controller Modules Blocks A & B
Flex-35 Amplifiers, 2 max/bay* Blocks E & F; C & D; or A & B
Flex-50 Amplifiers, 2 max/bay* Blocks E & F or C & D
100 W Amplifiers, 1 max/bay Blocks E, F, G & H
100 W Backup Amplifiers, 1 max. per bay with primary amplifier Blocks A, B, C & D
Master Telephone Module Blocks A & B
Master Microphone Module (do not mount next to telephone) Two vertical Blocks, any location
Telephone Module 1 Block
Operator LED/Switch Modules 1 Slot
Note: * When mounting dual Flex amplifiers on an expansion bay, special mounting rules apply.

Page 5 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Size Definitions
• Block = 4" W x 5" H (102 mm x 127 mm) card area
• Slot = 2" W x 8" H (51 mm x 203 mm) motherboard with daughter card
Operator Interface
Convenient Status Information. With the locking door closed, the glass window allows viewing of the display, status LEDs, and available operator
switches. Features include a two-line by 40-character, wide viewing angle (super-twist) LCD with status LEDs and switches as shown in Operator
Interface Features.
LED indicators describe the general category of activity being displayed with the LCD providing more detail. For the authorized user, unlocking the door
provides access to the control switches and allows further inquiry by scrolling the display for additional detail.

Page 6 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Operator Interface Features
• Convenient and extensive operator information is provided using a logical, menu-driven display
• Multiple automatic and manual diagnostics for maintenance reduction
• Alarm and Trouble History Logs (up to 1250 entries for each, 2500 total events) are available for viewing from the LCD, or capable of being printed to
a connected printer, or downloaded to a service computer
• Convenient PC programmer label editing
• Password access control

Page 7 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
NDU Equipment Selection
Table 2: NDU Equipment Selection
Model Description Size Supv. Alarm
A100-1291 Remote Unit Interface module (RUI); up to three maximum per
control panel 1 Slot 85 mA 85 mA
A100-6031 City Circuit, with
disconnect switches
For SPS only,
maximum 1 per
panel
Maximum 1 per
SPS or RPS N.A. 20 mA 36 mA
A100-6032 City Circuit, without
disconnect switches
For SPS only,
maximum 1 per
panel
Maximum 1 per
SPS or RPS N.A. 20 mA 36 mA
A100-6033 Alarm/Supv/Tbl Relay, 3 Form C relays, 2 A
@ 32 VDC
Maximum 1 per
SPS or RPS N.A 15 mA 37 mA
A100-6038 Dual RS-232 Interface; 3 maximum; can mount in Slot 3 or Slot
2 of Master Controller 1 Slot 60 mA 60 mA
A100-6046 Dual Port RS-232 standard interface (4 x 5 module) 1 Block 60 mA 60 mA
A100-6052 DACT, Point or Event Reporting; includes 2, 14 ft (4.3 m) DACT
cables 1 Slot 30 mA 40 mA
A100-0156 8 VDC Converter, required for multiple Physical Bridge Modules;
3 A @ 8 VDC maximum 1 Block included with loads
A100-9816 Master Clock Interface Module with one standard RS-232 port
(see AC4100-0033) 1 Slot 132 mA 132 mA
A100-6079 Safelinc internet interface module 2 Slots 145 mA 145 mA
Table 3: Network Display Unit, Non-Voice*
SKU SKU Type/Listing Description Supv. Alarm
A100-9141 120 VAC Input UL
4100ES NDU with Master Controller, LCD display and operator interface;
Network Interface Module (select media cards separately), Standard Master
Controller CPU Module with RUI output communications interface; 9 A System
Power Supply (SPS) with battery charger, one 2 A Auxiliary Power output and
expansion slot for City Circuit or Alarm/Supv/Tbl Relay option (NOTE: SPS IDNet
channel, NACs and Aux Relay are disabled in NDU bay).
419 mA 476 mA
A100-9241 220-240 VAC Input UL
4100ES NDU with Master Controller, LCD display and operator interface;
Network Interface Module (select media cards separately), Standard Master
Controller CPU Module with RUI output communications interface; 9 A System
Power Supply (SPS) with battery charger, one 2 A Auxiliary Power output and
expansion slot for City Circuit or Alarm/Supv/Tbl Relay option (NOTE: SPS IDNet
channel, NACs and Aux Relay are disabled in NDU bay).
see NDU, or NDU with
VCC Communication
Modules (with
exceptions as noted)
for selected Network
Media Card current
Table 4: Network Display Unit with Voice Command Center (VCC)*
SKU SKU Type/Listing Description Supv. Alarm
A100-9142 120 VAC Input UL
4100ES NDU with VCC includes the first bay equipment described for the NDU (above)
and a second bay assembly with separate: Network Interface Module (select media
cards separately); Standard Master Controller CPU with RUI output communications
interface; 9 A System Power Supply (SPS) with battery charger, three 3 A Class A/B
NACs, one 2 A Auxiliary Power output, one Aux Relay and expansion slot for City Circuit
or Alarm/Supv/Tbl Relay option
828 mA 907 mA
A100-9242 220-240 VAC Input UL
4100ES NDU with VCC includes the first bay equipment described for the NDU (above)
and a second bay assembly with separate: Network Interface Module (select media
cards separately); Standard Master Controller CPU with RUI output communications
interface; 9 A System Power Supply (SPS) with battery charger, three 3 A Class A/B
NACs, one 2 A Auxiliary Power output, one Aux Relay and expansion slot for City Circuit
or Alarm/Supv/Tbl Relay option
see NDU, or
NDU with VCC
Communication
Modules (with
exceptions
as noted)
for selected
Network Media
Card current
Table 5: System Option for Seismic Compliance
SKU Description
A100-7912 System option for Seismic compliance, provides additional stabilizer brackets required for legacy style cards
Note: * For InfoAlarm Command Center expanded content display products, refer to data sheet AC4100-0045 .

Page 8 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
VCC, Emergency Voice/Alarm Communications Selection
SKU Description Details and Mounting Reference
A100-1243 Master Microphone Module; one maximum per
audio system; mounts on front panel
Requires 2 Slots (4" [102 mm]), locate on expansion bay only; space behind for
4100ES flat modules only Supv. current = 2.4 mA; Active current = 6 mA
A100-1252 1 Channel (audio or mike)
A100-1253 1.5 Channel (audio + mike)
A100-1254 2 Channel (full audio)
A100-1255 3-8 Channel
Operator
Interface
Modules
Single slot modules requiring connection to an LED/switch controller; space behind
controller accepts 4100ES flat modules only
Additional adjacent LED/switch module(s) are required for specific speaker circuit
selection
Table 6: Firefighter Telephone System Products
SKU Description Details and Mounting Reference
A100-1270
Master Telephone with Telephone Control Module
and 3 Class B telephone NACs; for Fire Alarm
Control Panels
One max. per audio system; front panel module; space behind for 4100ES flat
modules only; telephone control module mounts on bay module mounting plate;
use LED/switch modules for circuit control
A100-1272 Telephone Module with 3 phone NACs Class B NACs, single Block module, mounts to bay mounting plate
A100-1273 Telephone Class A Adapter Module Mounts to A100-1272, no additional space required
Note: Refer to AC4100-0034 for additional detail.
Table 7: Analog Emergency Voice/Alarm Communications Equipment, Constant Supervision Compatible
SKU Description Details
A100-9620 Basic Analog Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, A100-1210 Analog Controller Board,
Microphone Module, and Audio Expansion Bay Kit
A100-1210 Analog Controller Board only; order expansion bay and audio
expansion bay kit separately Controller board mounts in Blocks A and B
A100-1361 25 VRMS output NAC rating = 1.4 A
A100-1362 70.07 VRMS output
Flex-35, 35 W Amplifier, constant
supervision compatible NAC rating = 0.5 A
35 W, or 100
speakers
A100-1312 25 VRMS output NAC rating = 2 A
A100-1313 70.7 VRMS output
Flex-50, 50 W Amplifier, constant
supervision compatible
Includes three on-board
Class B audio NACs; power is
supplied from an XPS, RPS,
or SPS NAC rating = 0.707 A
50 W, or 100
speakers
Table 8: 100 W Analog Amplifiers with Power Supply, Constant Supervision Compatible*
SKU/Output Voltage
25 VRMS 70.7 VRMS Power Supply Input/Listing Description Details
A100-1314 A100-1315 120 VAC, 60 Hz UL
A100-1318 A100-1319 220/230/240 VAC, 50/60 Hz UL
Primary 100 W
Amplifier
Includes six, Class B audio NACs; NAC rating = 50
W or 100 speakers maximum; 2 A @ 25 VRMS; 1.4
A @ 70.7 VRMS
A100-1320 A100-1321 120 VAC, 60 Hz UL
A100-1324 A100-1325 220/230/240 VAC, 50/60 Hz UL
Backup 100 W
Amplifier Uses the six Class B NACs of primary amplifier
ULC models
have low
battery
dropout
circuit
Table 9: Digital Emergency Voice/Alarm Communications Equipment*
SKU Description Details
A100-9621 Basic Digital Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, A100-1311 Digital Controller Board,
Microphone Module, and Audio Expansion Bay Kit
A100-1311 Eight Channel Digital Controller Board only; order expansion
bay and audio expansion bay kit separately Controller board mounts in Blocks A and B
A100-1363 25 VRMS output NAC rating = 1.4 A
A100-1364 70.07 VRMS output
Flex-35, 35 W Amplifier, constant
supervision compatible NAC rating = 0.5 A
35 W, or 100
speakers
A100-1326 25 VRMS output NAC rating = 2 A
A100-1327 70.7 VRMS output
Flex-50, 50 W Amplifier, constant
supervision compatible
Includes three on-board
Class B audio NACs; power is
supplied from an XPS, RPS,
or SPS NAC rating = 0.707 A
50 W, or 100
speakers
Note: * Refer to document AC4100-0034 for additional audio module information.
Table 10: 100 W Digital Amplifiers with Power Supply, Constant Supervision Compatible*
SKU/Output Voltage
25 VRMS 70.7 VRMS Power Supply Input/Listing Description Details
A100-1328 A100-1329 120 VAC, 60 Hz UL
A100-1332 A100-1333 220/230/240 VAC, 50/60 Hz UL
Primary 100 W
Amplifier
Includes six, Class B audio NACs; NAC rating = 50
W or 100 speakers maximum; 2 A @ 25 VRMS; 1.4
A @ 70.7 VRMS
A100-1334 A100-1335 120 VAC, 60 Hz UL
A100-1338 A100-1339 220/230/240 VAC, 50/60 Hz UL
Backup 100 W
Amplifier Uses the six Class B NACs of primary amplifier
ULC
models
have low
battery
dropout
circuit
Note: * Refer to document AC4100-0034 for additional audio module information.

Page 9 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Table 11: Options for use with either Analog or Digital Amplifiers*
SKU Description SKU Description
A100-1245 Flex-35/50 NAC Expansion Module; (Adds 3 Class B, 1.5
A NACs) A100-1248 100 W Amplifier NAC Expansion Module; (Adds six Class B, 2 A NACs)
A100-1246 Flex-35/50 Class A Adapter for 3 NACs A100-1249 100 W Amplifier Class A Adapter Module for 6 NACs
Note: * Refer to document AC4100-0034 for additional audio module information.
Table 12: Options for either Analog or Digital Systems
SKU Description SKU Description
Options for either Analog or Digital Systems (refer to data sheet AC4100-0034 for additional module details)
A100-1259 Constant Supervision Adapter for 25 VRMS Amplifiers A100-5116 Expansion Signal Module; three, 1.5 A NACs
A100-1260 Constant Supervision Adapter for 70.7 VRMS Amplifiers A100-1266 NAC Extender
A100-1240 Auxiliary Audio Input Module; four additional inputs A100-1267 Class A Adapter
A100-1241 8 Minute Message Expansion Module A100-1268 Constant Supervision Adapter
Options for use with
Expansion Signal
Module
A100-1242 32 Minute Message Expansion Module A4081-9018 End-of-line resistor for 70.7 VRMS NACs; 10 kΩ, 1 W
A100-0623 Network Audio Riser Controller Module for control of analog (-0621) or digital (-0622) riser module, see AC4100-0034 for details
NDU with VCC, LED/Switch Modules
Note: Refer to AC4100-0032 for additional detail.
Table 13: LED/Switch Modules, General Purpose (LED/switch controller and label kit is ordered separately)
Model LEDs per Switch LED Color(s) LED Quantity Switch Quantity
A100-1276 Red; pluggable 8
A100-1277 LEDs only Red on top, Yellow on bottom, pluggable 16 LEDs only
A100-1280 One Red
A100-1281 One Yellow 8
A100-1282 Two Red on top, Yellow on bottom
A100-1283 Two Yellow, top and bottom 16
A100-1284 Two Red on top, Green on bottom
8
A100-1285 One Red
A100-1278 One 8 Red on left, 8 Yellow on right
16 16
A100-1287 One Red 24 24
Table 14: LED/Switch Modules, Special Purpose (LED/switch controller and label kit is ordered separately)
Model Operation
A100-1286 Eight function HOA (On, Off, Auto) Control Module with labeled switches; ON/OFF/Auto; Green/Red/Green LEDs
Table 15: LED/Switch Controller Modules and Accessories
Model Description
A100-1288
64 LED/64 Switch Controller Module with mounting plate; controls up to 64 LEDs
and interfaces to up to 64 switches; mounts behind the LED/switch modules and
has provisions for one A100-1289 Controller Module
A100-1289 64 LED/64 Switch Controller Module without mounting plate; mounts on extra
space of A100-1288; controls an additional 64 LEDs and 64 switches
Note:
LED/switch controllers and their connected LED/
switch modules must be in the same bay; refer
to data sheet for additional LED/Switch module
details when Flex-35/50 amplifiers are in the same
bay
4100-1294 LED/Switch Module Slide-in Labels, required when LED/switch modules are present; order one per cabinet
Table 16: LED kits for A100-1276 and A100-1277 modules
Model Color Description
4100-9843 Yellow
4100-9844 Green
4100-9845 Red
Kits of 8 LEDs; order as required for A100-1276 and A100-1277 modules
Additional Expansion and Remote Power Supplies and Accessories
SKU Voltage/Listing Description Size Supv. Alarm
A100-5101 120 VAC UL
Expansion Power Supply (XPS); 9 A output rated same as SPS, 3
built-in 3 A Class A/B NACs that can provide synchronized strobe or
SmartSync, two-wire operation
2 Blocks 50 mA 50 mA
A100-5102 220-240 VAC UL
Expansion Power Supply (XPS); 9 A output rated same as SPS, 3
built-in 3 A Class A/B NACs that can provide synchronized strobe or
SmartSync, two-wire operation
2 Blocks 50 mA 50 mA
A100-5115 NAC Expansion Module, 3 NACs, Class A/B, mounts on XPS only N.A. 25 mA 25 mA

Page 10 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
SKU Voltage/Listing Description Size Supv. Alarm
A100-5111 120 VAC UL
Additional System Power Supply (SPS); 9 A power supply/charger ;
three 3 A Class A/B NACs, one programmable Aux Relay and one 2 A
Aux Power output, expansion slot for City Circuit or Alarm/Supv/Tbl
Relay option; Canadian model has low battery cutout
4 Blocks 175 mA 185 mA
A100-5113 220-240 VAC UL
Additional System Power Supply (SPS); 9 A power supply/charger;
three 3 A Class A/B NACs, one programmable Aux Relay and one 2 A
Aux Power output, expansion slot for City Circuit or Alarm/Supv/Tbl
Relay option; Canadian model has low battery cutout
4 Blocks 175 mA 185 mA
A100-5125 120 VAC UL Remote Power Supply (RPS); 9 A power supply/charger similar to
SPS except no City Circuits; will accept one A100-6033 4 Blocks 150 mA 185 mA
A100-5127 220/230/240 VAC UL
Remote Power Supply (RPS); 9 A power supply/charger similar
to SPS except no IDNet channel or City Circuits; will accept one
A100-6033
4 Blocks 150 mA 185 mA
A100-5152 12 VDC Power Option, 2 A @ 12 VDC maximum 1 Block 1.5 A maximum
A100-0634 120 VAC
A100-0635 220/230/240 VAC Power Distribution Module (PDM); select per system voltage; one required per box or cabinet rack
VCC – Additional Options
SKU Description
A100-6034 Door Tamper Switch with built-in addressable IDNet IAM, one per cabinet assembly if required
A100-2320 Audio Bay-to-Bay Interconnection Harness Kit; order one for each audio bay addition
A100-0637 Audio Box Interconnection Harness Kit; order one for each close-nippled audio cabinet
4100-9835 Termination and Address Label Kit (for module marking); provides additional labels for field installed modules
A100-1290 24 Point I/O Module; I Slot (see data sheet AC4100-0032 for details)
A100-1293 Panel Mount Thermal Printhead Printer, supplied with one roll of paper; requires 3 Slots; see AC4100-0032 for details
4190-9803 Replacement Paper for A100-1293 Printer, one roll
A100-6048 VESDA Air Aspiration Interface; 1 Slot module; 132 mA supervisory or alarm, see AC4100-0026 for details
A100-5013* 8 Point Zone / Relay Module
A100-3109* 250 Point IDNet 2 Module
A100-3110* 250 Point IDNet 2+2 Module
A100-3202* 4 DPDT Relays w/feedback, 10 A
A100-3204* 4 DPDT Relays w/feedback, 2 A
A100-3206* 8 SPDT Relays, 3 A
* See data sheet AC4100-0031 for details

Page 11 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
NDU or NDU with VCC Additional Options
Table 17: NDU or NDU with VCC Additional Options
SKU Description
A100-1279 Single blank 2" display cover; order as required (8 fill a bay front); two max. in a row between LED/switch modules
A100-2300 Expansion Bay Hardware, order for each expansion bay (unless included with selected option)
A100-0636 Box Interconnection Harness Kit; order one for each close-nippled cabinet
A100-0632 Terminal Block Module; 2, 16 position terminal blocks mounted on 4" x 5" single block size, for up to 12 AWG wire (3.31
mm2)
A100-5128 Battery Distribution Terminal Block; mounts to side of box; required for close-nippled cabinets that interconnect battery
wiring

Page 12 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
Wall Mounted Enclosure Installation Reference
Figure 3: Enclosure Install Reference
Note: A system ground must be provided for Earth Detection and transient protection devices. This connection shall be made to an approved, dedi-
cated Earth connection per NFPA 70, Article 250, and NFPA 780.
Additional 4100ES Technical Reference
Table 18: Additional technical documents
Document Document Number
Installation Instructions 574-848AC
Operating Instructions 579-197AC

Page 13 AC4100-0036 Rev. 19 3/2018
4100ES Network Display Units with SPS Power Supplies for 4120 Network
General Specifications
Table 19: NDU General Specifications
Specification Rating
120 VAC Models 4 A maximum @ 102 to 132 VAC, 60 Hz
Input Power [System (SPS); Expansion (XPS); Remote
(RPS); and 100 W amplifiers] 220-240 VAC Models 2 A maximum @ 204 to 264 VAC, 50/60 Hz; separate taps for
220/230/240 VAC
Total Power Supply
Output Rating
Including module currents and auxiliary power outputs; 9 A total for
"Special Application" appliances; 4 A total for "Regulated 24 DC" power
Auxiliary Power Tap 2 A maximum @ nominal 28 VDC
Power Supply Output
Ratings for SPS, XPS,
and RPS (see data sheet
AC4100-0031 for more
detail)
NACs Programmed for
Auxiliary Power
2 A maximum per NAC; 5 A
maximum total Rated 19.1 to 31.1 VDC
Output
switches to
battery during
AC failure or
brownout
Battery capacity range UL listed for battery charging of 6.2 Ah up to 110 Ah (batteries larger than 50 Ah require a
remote battery cabinet); ULC listed for charging up to 50 Ah batteries
Battery Charger Ratings
for SPS and RPS (sealed
lead-acid batteries) Charger characteristics
and performance
Temperature compensated, dual rate, recharges depleted batteries within 48 hours per UL
Standard 864, to 70% capacity in 12 hours per ULC Standard S527
Operating Temperature Range 32° to 120°F (0° to 49° C)
Environmental Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Additional 4100ES and 4120 Network Product Reference
Subject Data Sheet
Serial DACT (SDACT) for 4100ES, 4010ES, 4007ES AC2080-0009
Battery and Battery Cabinet Reference for 4100ES AC2081-0006
110 Ah Batteries and Cabinets for 4100ES AC2081-0012
External 110 Ah Battery Charger for 4100ES, 4010ES AC4081-0002
TCP/IP Physical Bridge Modules for 4120 Networks AC4100-0029
4100ES Basic Panels with SPS Power Supplies AC4100-0031
4100ES LED/Switch Modules & Printer AC4100-0032
4100ES Emergency Voice/Alarm Equipment AC4100-0034
4100ES Enclosures AC4100-0037
InfoAlarm Command Center with SPS Power Supplies AC4100-0045
Multiple Signal Fiber Optic Modems for 4120 Networks AC4100-0049
BACpac Ethernet Module AC4100-0051
4120 Network Products and Specifications AC4100-0056
Physical Bridge Modules for 4120 Networks AC4100-0057
Building Network Interface Card (BNIC) AC4100-0061
SafeLINC Internet Interface AC4100-0062
4100ES Basic Panels with EPS Power Supplies AC4100-0100
InfoAlarm Command Center with EPS Power Supplies AC4100-0101
NDU with EPS Power Supplies for 4120 Network AC4100-0102
TrueSite Workstation AC4190-0016
Network System Integrator (NSI) for 4120 Networks AC4190-0017
TrueSite Incident Commander AC4190-0020

AC4100-0036 Rev. 19 3/2018
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice.
Additional listings may be applicable, contact your local Autocall product supplier for the latest status. Listings and approvals under Tyco Fire & Security GmbH, and the
product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. NFPA 72 and National Fire Alarm Code are registered
trademarks of the National Fire Protection Association (NFPA).
4100ES Network Display Units with SPS Power Supplies for 4120 Network
