Autojack CTI-12V Installation manual

z
CTI-12V
Cordless Digital Tyre Inflator
CTI-12V
ORIGINAL INSTRUCTIONS
SAFETY AND OPERATING MANUAL

CTI-12V
TABLE OF CONTENTS
Welcome to Autojack!
Dear customer, Congratulations on your purchase. Before using the
Product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
General Power Tool Safety Warnings………………………………….……....01
Symbols & Cable Rating Chart ……….…………………………………….………05
Machine Details and Product features……….…………………………….….06
Operation……………………………………….…………………………………………..07
Autojack Guarantee…………………………………………………………………….09
Declaration of conformity……………………………………………………………11
Parts list……………………………………………………………………………………...12
Parts Diagram………………………………………………………………………………14

CTI-12V 01
WARNING Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a)Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators.There is an increased risk of electric
shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tyred or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
GENERAL POWER TOOL SAFETY WARNINGS

CTI-12V 02
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.
6. Battery Tool Use and Care
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury or fire.
GENERAL POWER TOOL SAFETY WARNINGS

CTI-12V 03
c) When Battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal object
that can make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
d) User abusive conditions, liquid may be
ejected from the battery; Avoid contact. If
contact accidentally occurs, flush with copious
amounts of water. If liquid contacts eyes, seek
medical help immediately. Liquid ejected from
the batter may cause irritation or burns.
7. General safety measures and
precautions that apply to the use of air
compressor
Safe operation of the air compressor requires
that you read the instructions and safety pre-
cautions carefully and follow all instructions
before using the air compressor
FOR HOSEHOLD USE ONLY
a) The air compressor is designed for
occasional use. Inflation over a long period will
overheat the air compressor and may cause
damage.
b)For safety purpose always allow unit to cool
for 15 minutes after every usage, Max working
pressure:10.3bar,1min on / 15 min off or Max.
working pressure:4.1bar, 10 min on / 15 min
off.
c) If the air compressor emits abnormal sounds
or overheats, turn it off immediately and let it
cool off for minimum 30 minutes.
d) Inspect air compressor before use. If cracked,
broken or damaged parts.
e)Incorrect use of the air compressor may result
in personal injury and/or property damage.
f)Never expose the air compressor to rain, frost
or temperatures above 50
℃
.
g)Never use the air compressor near flammable
fluids or gases. Make sure your working area is
well-lit.
h)Protect yourself against electric shock. Avoid
physical contact with grounded surfaces such as
pipes, radiators, electric stoves, refrigerator, etc.
i)Never allow children to connect/disconnect the
air compressor to/from power sources. Never
leave children unattended with the air
compressor and never allow them to play with
the accessories.
j)Never allow anyone to pump air into mouth,
ears, nose, etc of people, or animals. The air
compressor is not a toy.
k)Store air compressor in a secure location. If the
air compressor is going to be unused for long
periods of time, it should be stored in a dry place
inaccessible to children.
l)Keep the air compressor clean to maintain
maximum output and safety. Examine the plug,
charger and cable pack on a regular basis and
have them repaired by qualified technicians if
they are damaged.
m)Warning! For your own safety, you should only
use by the manufacturer. Use of accessories and
other parts that are not mentioned in the
instructions may entail an increased risk for the
use of the air compressor.
GENERAL POWER TOOL SAFETY WARNINGS

CTI-12V 04
This appliance is not intended for use by
persons(including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
8. Using an Extension Cable.
a) If an extension cable is required, use an
approved triple core extension cable suitable
for the power input of the tool.
b) Grounded tools always require a three wire
extension cable.
c) As the distance from the supply outlet
increases you must use a heavier gauge
extension cable. Using extension cables with
inadequately sized wire causes a serious drop in
voltage, resulting in loss of power and possible
tool damage.
d) The smaller the gauge numbers of the wire
the greater the capacity of the cord.
e) When using a cable reel, always unwind the
cable completely.
GENERAL POWER TOOL SAFETY WARNINGS

CTI-12V 05
SYMBOLS AND POWER RATING CHART
Danger! – Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause damage
to hearing.
Amperes 7.5M 15M 25M 30M 45M 60M
0 – 2.0 6 6 6 6 6 6
2.1 – 3.4
6
6
6
6
6
6
3.5 - 5.0 6 6 6 6 10 15
5.1 – 7.1
10
10
10
10
15
15
7.1 – 12.0 15 15 15 15 20 20
12.1 – 20.0 20 20 20 20 25 -
Caution! Risk of Injury! Do
not reach into the running
saw blade.
Caution! Wear a dust mask.

CTI-12V 06
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
Voltage – 12V
Battery capacity – 1500mAh
Maximum current – 8.5A
Max pressure – 150PSI
Pressure gauge accuracy – +/- 2PSI
Pressure unit– PSI,BAR,KPA
Length of hose – 50cm
Package Contents:
1 xAutomatic Cordless Tyre Inflator
1 xSteel pin tip
1 xPlastic wide tip
1 xFlexible air hose
1 xStorage bag
1x12VDC Car adaptor
1x AC battery charger
Intended Use
The 12V tyre inflator is designed for the tyre
inflation to pressures as recommended by
your vehicle manufacturer. It is intended for
occasional intermittent use and not
commercial purposes.
Caution! The 12V tyre inflator. This tool is
intended for consumer use only and is
intended for occasional and intermittent
operation. This tool is not designed for
professional use. It should not be used on
trucks and heavy machinery.

CTI-12V 07
Operation
Inflation instructions
1.Inflating tires
1. Line up the arrows on the “Flexible air
hose” and “Attachment lock” on unit.
2. Push “Flexible air hose” in and turn
clockwise until locked in place.
3. Choose desired tip and screw into
“Flexible air hose”
4. Press “+” or “-” to set desired pressure
level. Once set, wait a few seconds
and until current tyre pressure
displays.
Note: Always check and follow the
manufacturer’s recommended pressure,
usually located on the door jamb of your
vehicle.
5. Machine will begin to inflate the tyre to
the set pressure level, and shut off
automatically when reached.
6. When done, press the trigger once to
turn off.
7. Remove the thread connector from the
tyre quickly, and replace valve stem cap
on tyre, if required. Warning: Connector
may be hot. Use caution when removing.
Note: To avoid over-inflation of tyres,
please check the recommended tyre
pressure in the vehicle’s owner’s manual.
For bicycle tyres, check markings on tyre.
2. Using the 12V DC Car adapter
1. Unravel cord before use.
2. Connected with the Lithium battery.
3. Connect the adapter into the DC socket
in your car. When ready to use, Switch
ignition on.

`1`
CTI-12V 08
Operation
Warning! The LCD display mustturn on
before operating airinflator. Please read,
and understand the instructions provided
in the manual prior tooperation.
-Emergency lamp by the combination of
18piece LED. Turn on the button, LED
shows red recording light. When the car
have a fault occurs, you can press the
second time, LED shows red quick flashing
light. Press the third time, it shows white
light being used for illumination.
-Accessories 1 function is suitable ball
inflator, for example: basketball, football
and so on; Accessories 2 function is
suitable balloon, air cushion and so on.
Inflating items with additional tips
1. Loosen the attachment lock
approximately 3 rotations counter-
clockwise. Do not remove lock
completely.
2. Important: Insert the tip into the
attachment lock. Press in firmly while
screwing in clockwise until it can go no
further
3. Tighten attachment lock clockwise until
hand-tight.
4. Press the power button below the LCD
display to turn on.
Note: After 30 seconds of inactivity, the
digital tyre gauge will turn off automatically
to conserve energy.
5. Insert the tip adapter into inflatable
object and push trigger.
6. Allow machine to run until fully
inflated.
7. Remove tip adapter from the inflated
object quickly, and replace valve cover if
required.
Note: The pressure gauge will only provide
an estimated reading.
Press once for white light
Press twice for red light
Press three times for red flashing light

CTI-12V 09
AUTOJACK GUARANTEE
1. Guarantee
1.1 Autojack guarantees that for a period of 12
months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture
1.2 During this period, Autojack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2.
1.2.2 Autojack and its Authorised Dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product.
1.2.3 If asked to do so by Autojack or its
Authorised Dealer, you return the product at
your own cost to Autojack’s or the supplying
Authorised Dealer’s Premises, For the
examination to take place clearly stating the
Returns Material Authorisation Number given by
Autojack or an Authorised Dealer.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage, neglect, incorrect electrical
connection, misuse, alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only.
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts or other
wearing parts which can reasonably be expected
to wear at different rates depending on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you, as
the guarantee is not transferable from a private
sale.
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems with
machines that are thought to be fault due to faulty
parts are actually solved by correct setting up or
adjustment of the machine. A good Authorised
Dealer should be able to resolve the majority of
these issues much more quickly than processing a
claim under the guarantee. If a return is requested
by the Authorised Dealer or Autojack, you will be
provided with a Returns Material Authorisation
Number which must be clearly stated on the
returned package, and any accompanying
correspondence. Failure to provide a Returns
Material Authorisation Number may result in item
being refused delivery.

CTI-12V 10
AUTOJACK GUARANTEE
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this guarantee
should be made directly to Autojack. The claim
itself should be made in a letter setting out the
date and place of purchase, giving a brief
explanation of the problem which has led to the
claim. This letter should be then sent with proof
of purchase to Autojack. If you include a contact
number with this it will speed your claim up.
2.4 Please note that it is essential that the letter
of claim reaches Autojack on the last day of this
guarantee at the latest. Late claims will not be
considered.
3. Limitation of Liability.
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This guarantee does not confer any rights
other than these expressly set out above and does
not cover any claims for consequential loss or
damage. This guarantee is offered as an extra
benefit and does not affect your statutory rights as
a consumer.
4. Notice
This guarantee applies to all product purchased
from an Authorised Dealer of Autojack within the
United Kingdom. Terms of guarantee may vary in
other countries.

CTI-12V 11
CE DECLARATION OF CONFORMITY
TOOLSAVE
Unit C, Manders Ind. Est.,
Old Heath Road, Wolverhampton,
WV1 2RP.
Tel: [phone]
Declares that the Automatic Cordless Tyre Inflator (CTI-12V)
Is in compliance with the regulations included in the Directives:2006/42/EC
EC DECLARATION OF CONFORMITY
Certificate for EC-type examination delivered by Intertek Testing Services Shenzhen Ltd. Guangzhou
Branch Block E, No.7-2 Guang Dong Software Science City, GETDD, Guangzhou, China
(Verification No.:180613089GZU-001)
Person who declares: Bill Evans
20.12.2018
The Director

CTI-12V 12
No.
Description
No.
Description
1Air hose outlet 31 Motor
2Tube for Air hose 32 Fan
3Spring 33 LCD shell
4Braided tube 34 Cover
5Spring 35 LCD
6Connector 36 PCB main board
7Air inlet 37 Button
8Sealing ring 38 LCD shell
9Shockproof ring 39 Trigger
10 Air outlet shell 40 PCB
11 Air shell 41 PCB control board
12 Spring 42 Electric shock film
13 Anti-air plastic 43 Electric shock film
14 Shell 44 Electric shock cover
15 Pump sealing 45 Shockproof
16 Seamless tube 46 LED panel
17 Pistons 47 PCB
18 Pistons ring 48 LED light panel
19 Leather ring 49 Spring
20 Pistons 50 Switch cover
21 Pistons axis 51 Led light on/off switch
22 Pistons bearings 53 Left outer shell
23 Pistons 54 Right outer shell
24 Screw bearing 55 Logo panel
25 Bearing 56 Sticker
26 Part of Pump 57 Needle adaptor
27 Gear bearing 58 Inflating adaptor
28 Big gear bearing 59 Battery top cover
29 Gear shell 60 Electric shock film cover
30 Gear 62 Power ear cover
Parts List

CTI-12V 13
No.
Description
No.
Description
63 Power ear cover 73 Car adaptor top cover
64 Spring of ear cover 74 Spring
65 Spring of ear cover 75 Spring
66 DC connector part 76 Fuse
67 Battery 77 Screw cover
68 Base 78 Fuse cover
69 Double-sided adhesive 79 Screw cover
70 Battery base cover 80 Car adaptor base cover
71 Power cord 81 screw
72 Screw 82 Gear
Parts List

CTI-12V 14
Parts Diagram
