Remove the protective dust cover from the CF Slot #1 at the top of the
touch panel by prying up on one edge. Sit the dust cover aside for
re-installing after the CF card is installed.
CF Slot #1 shown above with the protective dust cover removed.
1-800-633-0405
Gently press the CF card into the slot until it stops. You should feel a slight
resistance as the CF card connector mates with the slot’s connector. The
CF card should be flush with the slot’s opening.
The dust cover can now be re-installed.
Orientate the compact flash memory card so that the front label is facing
the back of the panel and the CF card connector faces into the slot. There
are guides on each side of the slot that will match the guides on the CF
card. The CF card can only be inserted one way.
COMPACT FLASH MEMORY CARD INSTALLATION INSTRUCTIONS
P/NEA-FLASH-128MB
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
22
22
11
11
33
3344
44
WARNING: Take the necessary steps to prevent damage that may be caused by static electricity discharge. Disconnect input power to the touch panel before
proceeding.
Protective
dust cover CF Slot
#1
To remove the CF card from the CF Slot #1, press in on the eject button to
the right of the CF card. This will cause the CF card to be partially
ejected from the slot allowing removal.
55
55
CF Card Installed in CF Slot #1:
CF card
eject button
NOTE: CF CARD INSTALLATION FOR CF SLOT #2 IS SHOWN
ON THE BACK OF THIS DATA SHEET.
Preparation: If the touch panel is not already installed into a control cabinet, then in a clean environment,
place the panel face down on a lint-free soft surface to prevent scratching the front of the panel.
512KBFLASH CARD
EZ-FLASH-1
Date Code
0238
WARNING:
Install module with this
side down.
WARNING: Do NOT use EZTouch RAM or Flash memory cards with
the C-more touch panels.

Copyright 2005, Automationdirect.com Incorporated/All Rights Reserved Worldwide
Data Sheet: EA-FLASH-128MB-DS, Rev. A
www.automationdirect.com/c-more
1-800-633-0405
Gently press the CF card into the slot until it stops. You should feel a slight
resistance as the CF card connector mates with the slot’s connector. The
CF card should be flush with the slot’s opening.
Orientate the compact flash memory card so that the front label is facing
the power supply connector and the CF card connector faces into the slot.
There are guides on each side of the slot that will match the guides on the
CF card. The CF card can only be inserted one way.
11
1122
22
To remove the CF card from the CF Slot #2, press in on the eject button at
the bottom of the CF card. This will cause the CF card to be partially
ejected from the slot allowing removal.
33
33
CF Card Installed in CF Slot #2:
CF Slot
#2
CF card
eject button
NOTE: THE USE OF CF SLOT #2 REQUIRES THE INSTALLATION
OF THE EXPANSION ASSEMBLY, P/NEA-EXP-OPT AND THE CF
CARD INTERFACE MODULE, P/NEA-CF-IF.
Preparation: Disconnect input power and all other connections, then remove the touch panel from the
control cabinet. In a clean environment, place the panel face down on a lint-free soft surface to prevent
scratching the front of the panel.
512KBFLASH CARD
EZ-FLASH-1
Date Code
0238
WARNING:
Install module with this
side down.
WARNING: Do NOT use EZTouch RAM or Flash memory cards with
the C-more touch panels.
