AUXO CELSIUS User manual

CELSIUS USER MANUAL

READ THIS MANUAL BEFORE USING THE PRODUCT.
FAILURE TO FOLLOW INSTRUCTIONS AND SAFETY
PRECAUTIONS IN THIS MANUAL CAN RESULT IN SERIOUS
INJURY OR DEATH.
FOR EASY FUTURE REFERENCE, DOWNLOAD THIS USER
MANUAL AND WARRANTY CARD AT:
www.auxo-official.com/pages/download

What’s in the Box
Celsius x 1
Loading Tool x 1
Tweezers x 1
Cotton Swabs x 5
Power Adapter x 1 USB-C Charging Cable x 1
Concentrate Chamber x 1Cleaning Brush x 1 Quick Start Guide x 1
User Manual x 1
CELSIUS
QUICK START

QUICK START
Loading Dry Herb:
It is recommended to fully charge the device before first use.
Rotate the mouthpiece 180°, lift the magnetic mouthpiece from the Celsius base
to expose the heating oven.
Use medium-ground material. The grind should be small and crumbled but
not too fine. A powdery grind will restrict airflow.
Loosely fill the heating oven to the rim and tamp down gently. It is not
recommended to fill above the black line of the oven*.
Ensure the oven rim and other surfaces are completely free of debris for a
tight seal.
Put the magnetic mouthpiece back on the Celsius base. Make sure it is seated
correctly.
*Recommended fill weight: 0.3g
Loading Wax/Concentrates:
Use the loading tool to place a small amount of concentrate in either side of
the concentrate chamber. Do not fill both sides of the chamber at once.
For best performance, AUXO recommends using only 0.05g of material (about
the size of a dry lentil).
Insert the concentrate chamber right side up into the heating oven.
Put the magnetic mouthpiece back on the Celsius base. Make sure it is seated
correctly.
CoarseMediumFine
Best
Do Not Fill
Above the
Black Line.

Indicator
*Pro Mode's default temperature is 428°F (220°C)
*In case of the LED ring light turning to a steady red, an error may be
occurring in the device. Contact AUXO for troubleshooting if such an event
happens.
Turning On/Off the Device
●
●
●
●
Press the power button on the bottom of the device for 3 seconds to turn
on/off. The device’s LED ring light will illuminate/fade out and make a short
vibration respectively.
If no activity is detected for 10 minutes or longer, Celsius will turn off
automatically.
If the surface temperature of the device is over 118±1.8°F (48±1°C), the device
will implement overheat protection mode and automatically stop working.
If the battery runs out of power, the LED ring light will blink 10 times in red
and short vibrations will occur shortly before it turns off automatically.
Setting Up the Device
1.
2.
3.
4.
5.
There are 5 temperature settings (see table below). When the device is on,
press the ‘+/-’ buttons to choose between different settings and the LED ring
light will indicate the settings accordingly. In Pro Mode, the ring light reaches
a full circle.
Press the ‘+’ button for 3 seconds to start heating. The device will vibrate to
indicate the start of a session and enter its preheating phase.
The LED ring light will blink in blue cyclically during the preheating phase.
When preheating ends, the LED ring light turns to a steady green and the
session begins.
When the session is over, the LED ring light will switch from green to blue.
Assess the flavor of your material after every session. If you wish to continue
with another session, long press ‘+’ again.
Mode Settings
Temperature Recommended Use Session
12-16s
25-30s
6-30s
180s
40-180s
Light roast
Setting 1
374°F (190°C)
Preheat Time
Medium roast
Setting 2
392°F (200°C)
Heavy roast
Setting 3
428°F (220°C)
For concentrates
Setting 4
500°F (260°C)
Customize your own
heating curve via
the AUXO App
Pro Mode
284-500°F
(140-260°C)

AUXO Apps
1.
2.
3.
4.
5.
Due to safety precautions, the product cannot be used while charging.
To charge the device, connect one end of the USB-C charging cable to your
device and the other end to a power adapter.
Charging via the standard power adapter takes approximately 1.5 hours for a
full charge. Every full charge generates approximately 9 sessions of usage.
To check the current battery level of your device, gently shake the device twice
and the LED ring light will indicate the current battery level. Each bar indicates
~20% battery level.
When the battery runs out of power, the LED ring light will blink 10 times in
red and short vibrations will occur. The device will then turn off automatically.
Pro Mode
In the customizable Pro Mode, you can create a 40s-180s heating curve with five
different temperature settings of your liking. Details are covered in the AUXO App
section.
Charging & Battery Level
1.
2.
3.
4.
Scan the QR code or search for ‘All-On Browser’ in the App Store. Download and
install the app onto your phone.
Go to www.auxo-app.com.
Allow the app to access the phone’s Bluetooth and wireless data.
Connect your device to the app (see next step).
For iOS
1.
2.
Scan the QR code or search for ‘AUXO Connect’ on the Google Play Store.
Download and install the app onto your phone.
Connect your device to the app (see next step).
For Android
Download and Setup
1.
2.
3.
4.
Turn on the device.
Turn on Bluetooth on your phone and place the device near your phone.
When only one device is found, select accordingly. The LED ring light will blink
3 times when paired successfully. If multiple devices are found, the selected
device will blink slowly to indicate selection; if paired successfully, the LED ring
light will blink 3 times.
If the connection is unsuccessful, restart the app and try connecting again.
Connecting Your Device to the App
AUXO ConnectAll-On Browser

1.
2.
3.
4.
5.
Your AUXO App is up to date.
Your Celsius device is turned on
(restart if necessary).
The Bluetooth on your phone is
turned on.
The device is near your phone (as
close as possible).
If on Android, your location services
are enabled (mandated by Android).
If you're having trouble pairing your
Celsius device with your phone, please
ensure the following:
1.
2.
Select 'Preset' and swipe the
temperature bar left and right to
choose your preferred temperature.
Tap 'Start' to begin your session.
Preset Mode
In the customizable Pro Mode, you can create a 40s-180s heating curve with five
different temperature settings of your liking. On the main page, click on the ‘Pro’
button and enter Pro Mode. Move the sliders accordingly to your preferred
temperatures. Tap ‘Set and go’ once you have confirmed your heating curve.
You are also able to give your customized mode a name and share it with your
friends by tapping the share icon on the top right. Email, QR code, and social
media options are available for sharing with your friends so they can replicate
your experience.
Pro Mode
LONG-PRESS

Unit of Temperature
Vibration Intensity:
Open the menu in the top right
corner, and tap the 'Settings’
button.
In the ‘Vibration Intensity’
section, adjust the vibration
intensity to your preference.
1.
2.
1.
2.
Open the menu on the top right corner, and tap the 'Settings’ button.
In the ‘Temperature Unit’ section, select your preferred scale, Fahrenheit (°F)
or Celsius (°C).
Delete Account:
In 'Account Information', tap on
'Delete account'. Once deleted,
data and settings may not be
recovered.
1.
2.
Open the menu on the top right corner, and tap the 'Data' button; find your
historical activities on the page, including time, draws, and more.
If you can't access this page, check if the 'Data' function is enabled in your
'Account Information'.
View My Activity

*Please make sure the concentrate chamber has cooled down before cleaning.
2. Let the mouthpiece dry completely before use.
*Please note: cleaning and maintenance must NOT be performed before the device is
turned off and cools down to room temperature. Do not submerge the battery/device
base in any form of liquid.
1. Remove the mouthpiece from the battery by pulling up the mouthpiece.
•Basic cleaning: Insert the cleaning brush into the gap
of the mouthpiece, gently run the brush to the end and
move it back and forth to remove residue. The surface
can be wiped clean with cotton pads dipped in 90%
isopropyl alcohol.
•Thorough cleaning: The mouthpiece can be
disassembled into 6 separate parts by lifting the silicone
component on the bottom of the protruding filter piece.
Once isolated, submerge them in 90% isopropyl alcohol.
To see disassembling instruction videos, visit the AUXO
website or AUXO YouTube channel.
Mouthpiece
Don’t handle if hot.
STORAGE
●
●
Do not expose the device to direct sunlight, dust, moisture or mechanical
shock.
Do not place heavy loads on the device or drop it, the device may no longer
work properly if such events occur.
1. Let the oven cool down to room temperature. Pull up the mouthpiece to
expose the oven.
•After using dry herb: Use the cleaning brush to clean residue out of the oven.
•After using concentrates: Pour out the concentrate chamber onto a table.
Wipe clean with a cotton swab dipped in 90% isopropyl alcohol.*
Cleaning is highly recommended after each use.
Heating Oven
CLEANING & MAINTENANCE
2. Dip a cotton swab in 90% isopropyl alcohol and wipe the oven clean.
Isopropyl alcohol is highly flammable.
Let the device dry completely before heating.

●
●
●
●
●
SAFETY
Do not attempt to disassemble or repair the device as damage or personal
injury may occur.
Keep body parts, clothing, etc. away from the heat source to prevent scalding
or damage to personal property.
To prevent scalding, do not touch the heating oven and concentrate chamber
before they have completely cooled down.
Refrain from using other power adapters not provided with the device when
charging your Celsius.
Refrain from using the device while it is charging.
●
●
●
●
Keep hands dry when touching the device while it is charging to prevent
electric shock.
The device is not recommended for use outdoors while it is raining, or in other
circumstances where it may be exposed to water.
Do not use while pregnant or breastfeeding.
If any abnormality is observed, stop using immediately and contact a
professional after-sales service technician via the AUXO website.
Temperature and Humidity
Charging temperature: 50-113°F (10 to 45°C）
Working temperature: 14-140°F (-10 to 60°C)
Storage temperature: 68±9°F (20±5°C)
Operating humidity: 45%-75%
Storage humidity: 45%-75%
●
●
●
●
FCC/CE/RoHS
AUXO Celsius is in compliance with RoHS and the council EMC 2014/30/EU.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
